Evolution characteristics and potential area prediction of shale in Wuerxun Sag
-
摘要: 乌尔逊凹陷为海拉尔盆地南部重要的含油区,具有较大勘探潜力。笔者通过油源对比确定乌尔逊凹陷主力烃源岩层,分析不同区域源岩发育特征及有机质丰度、类型等地球化学指标,评价乌尔逊凹陷主力烃源岩生油成熟期和成藏阶段,通过流体包裹体均一化温度的测量,来判断油气充注史,预测优先勘探潜力部位。研究发现,乌尔逊凹陷不同区域油源不完全相同,乌尔逊北部油藏源于南屯组泥页岩母质,乌尔逊南部区域除了南屯组泥页岩,还有铜钵庙组暗色泥岩生成的油流混入。乌尔逊凹陷具有两期成藏:第一期为伊敏组后期—青元岗组早期,原油由烃岩层排出、运移注入圈闭成藏;第二期为青元岗组后期构造活动使早期油藏原油重新调整分配注入新的圈闭成藏。综合分析认为乌北洼陷西侧、乌南洼陷东侧构造带为两个重要的勘探潜力带。Abstract: Wuerxun Sag is an important oil-bearing area in the south of Hailaer basin, which has great exploration potential. This paper determines the main source rocks in Wuerxun Sag by oil source correlation, analyzes the development characteristics of source rocks in different regions and geochemical indicators such as organic matter abundance and type, evaluates the oil generation maturity and accumulation stage of main source rocks in Wuerxun Sag, and judges the oil and gas filling history and predicts the preferred exploration potential position by measuring the homogenization temperature of fluid inclusions. It is found that the oil source in different areas of Wuerxun Sag is not identical. The oil reservoir in the north of Wuerxun Sag is derived from the parent material of mud shale rock of Nantun formation. In the south of Wuerxun Sag, besides the mud shale of Nantun formation, there is oil flow from dark mudstone of Tongbomiao formation. Wuerxun Sag has two stages of hydrocarbon accumulation: The first stage is from the later Yimin formation to the early Qingyuangang formation; The second stage is the late structural activity of Qingyuangang formation, which makes the early oil reservoir redistribute and inject new traps. It is considered that the west side of Wubei sag and the east side of Wunan sag are two important exploration potential zones.
-
Key words:
- Hailar /
- Wuerxun area /
- shale /
- potential area /
- inclusion
-
-
[1] 齐士龙. 海拉尔油田薄差储层细分多层压裂技术[J]. 大庆石油地质与开发, 2015,34(5):81-86.
[2] Qi S L. Subdivided multilayer fracturing technology for the thin and poor reservoirs of hailer oilfield[J]. Petroleum Geology and Oilfield Development in Daqing, 2015,34(5):81-86.
[3] 吴文祥, 张海祥, 李占东, 等. 层序地层地球化学方法在烃源岩评价中的应用——以海拉尔盆地乌尔逊凹陷为例[J]. 石油与天然气地质, 2015,36(4):705-710.
[4] Wu W X, Zhang H Y, Li Z D, et al. Sequence stratigraphic geochemistry and its application in evaluation of source rocks: taking Beier sag of Hailar Basin as an example[J]. Oil & Gas Geology, 2015,36(4):705-710.
[5] 申文静. 海拉尔盆地中部断陷带与外围凹陷烃源条件类比分析[J]. 西部探矿工程, 2016,30(4):39-46.
[6] Shi W J. Analogical analysis of hydrocarbon source conditions between central fault depression and peripheral depression in Hailaer Basin[J]. West-China Exploration Engineering, 2016,30(4):39-46.
[7] 李娇娜, 徐然, 张健, 等. 内蒙古海拉尔盆地侏罗系烃源岩地球化学特征[J]. 地质与资源, 2017,26(2):147-156.
[8] Li J N, Xu R, Zhang J, et al. Geochemistry of the jurassic source rocks in hailar basin,inner Mongolia[J]. Geology and Resources, 2017,26(2):147-156.
[9] 徐立恒, 宋宝权, 韩嵩, 等. 变尺度构造模型在地质统计学反演储层预测中的应用[J]. 石油学报, 2019,40(2):190-196.
[10] Xu L H, Song B Q, Han S, et al. Application of variable-scale structure modelon geostatistics inversion reservoir prediction[J]. Acta Petrolei Sinica, 2019,40(2):190-196.
[11] Tissot B P, Pelet R, Ungerer P. Thermal history of sedimentary basins, maturation indices,and kinetics of oil and gas generation[J]. AAPG Bull., 1987,71(12):445-466.
[12] 邬立言, 顾信章. 热解技术在我国生油岩研究中的应用[J]. 石油学报, 1986,7(2):13-19.
[13] Wu L Y, Gu X Z. The application of pyrolysis technique in source rock research[J]. Acta Petrolei Sinica, 1986 , 7(2):13-19.
[14] 卢双舫, 张敏. 油气地球化学[M]. 北京: 石油工业出版社, 2007: 174-199.
[15] Lu S F, Zhang M. Petroleum geochemistry[M]. Beijing: Petroleum Industry Press, 2007: 174-199.
[16] 刘超英, 闫相宾, 徐旭辉, 等. 应用流体包裹体研究惠民凹陷南斜坡油气充注史[J]. 石油天然气学报, 2008,29(4):507-510.
[17] Liu C Y, Yan X B, Xu X H, et al. Application of fluid inclusion to the study of hydrocarbon charge history of the south slope in the Huimin Sag[J]. Oil & Gas Geology, 2008,29(4):507-510.
[18] 崔军平. 海拉尔盆地热演化史与油气成藏史研究[D]. 西安:西北大学, 2014, 15-56.
[19] Cui J P. Geothermal evolution and hydrocarbon accumulation history of Hailaer Basin[D]. Xi'an:Northwest University, 2014: 15-56.
[20] 刘新颖. 海拉尔盆地乌尔逊凹陷油气生成、运移及成藏[D]. 大庆:东北石油大学, 2016: 10-30.
[21] Liu X Y. Hydrocarbon generation in Wuerxun Sag, Hailaer Basin:Migration and accumulation[D]. Daqing:Northeast Petroleum University, 2016: 10-30.
[22] 王成, 张安达. 海拉尔盆地乌尔逊—贝尔凹陷储层特征及其孔隙演化[J]. 大庆石油地质与开发, 2019,38(5):151-159.
[23] Wang C, Zhang A D. Reservoir characteristics and pore evolution of Wuerxun-Beier Sag in Hailar Basin[J]. Petroleum Geology & Oilfield Development in Daqing, 2019,38(5):151-159.
-
