Amethod for determining the optimal height for upward continuation of gravity anomalies
-
摘要: 向上延拓方法是重力异常分离中的重要方法之一,但在应用时如何定量地选取合适的延拓高度是一直以来存在的问题。本文针对该问题展开研究,提出一种基于二乘误差的曲率分析方法来定量地给出相对合理的延拓高度。该方法对观测数据进行相邻不同高度的向上延拓,并用二乘法估算相邻高度延拓值的二乘误差,在各相邻高度延拓值二乘曲线中存在一个曲率最大值,在这个点最大程度地使局部异常衰减并尽可能地保留区域异常,可近似视为最佳延拓高度。利用理论模型数据对所提出的方法进行了测试,表明该方法能够定性给出较合适的延拓高度,从而为实际应用中延拓高度的选取提供参考。Abstract: Upward continuation is one of the important methods used to separate gravity anomalies. However, how to quantitatively select an appropriate upward-continuation height has always been a problem in the application of this method. Given this, this paper proposes a curvature analysis method based on the least square method to quantitatively determine a reasonable upward-continuation height. The steps of this method are as follows. Perform upward continuation to different adjacent heights for observation data, and then use the least square method to estimate the least square error of the upward continued value of adjacent heights.There is a maximum curvature in the least square curve of upward-continued values of all adjacent heights.At the point of the maximum curvature, the local anomalies are attenuated to the greatest extent, while the regional anomalies are preserved as far as possible. Therefore, this point can be approximately regarded as the optimal upward-continuation height. As indicated by tests using the data of a theoretical model, the method proposed in this paper can be used to qualitatively determine a suitable upward-continuation height, thus providing an important reference for the selection of upward-continuation height in practical applications.
-
Key words:
- gravity anomaly /
- analytic continuation /
- upward-continuation height
-
-
[1] 曾华霖. 重力场与重力勘探[M]. 北京: 地质出版社, 2005.；Zeng H L. Gravity field and gravity exploration[M]. Beijing: Geological Publishing House, 2005.
[2] 曾华霖. 重力梯度测量的现状及复兴[J]. 物探与化探, 1999, 23(1):1-6.
[3] Zeng H L. Present state and revival of gravity gradiometry[J]. Geophysical and Geochemical Exploration, 1999, 23(1):1-6.
[4] 徐连喜. 三维重磁场积分延拓计算方法[J]. 物探与化探, 1988, 12(2):91-98.
[5] Xu L X. Integral continuation method forthree-dimensional cravity and magnetic field[J]. Geophysical and Geochemical Exploration, 1988, 12(2):91-98.
[6] 王明, 王林飞, 何辉. 匹配滤波技术分离重力场源[J]. 物探与化探, 2015, 39(S1):126-132.
[7] Wang M, Wang L F, He H. The application of the matched filtering technology to the separation of gravity field sources[J]. Geophysical and Geochemical Exploration, 2015, 39(S1):126-132.
[8] 黎海龙, 朱国器. 桂西地区重力场小波多重分解及地质意义[J]. 物探与化探, 2007, 31(5):465-468.
[9] Li H L, Zhu G Q. The wavelet multiple decomposition of the gravity field in Guixi(Western Guangxi) area and its geological significance[J]. Geophysical and Geochemical Exploration, 2007, 31(5):465-468.
[10] 郭良辉, 孟小红, 石磊, 等. 重力异常分离的相关法[J]. 地球物理学进展, 2008, 23(5):1425-1430.
[11] Guo L H, Meng X H, Shi L, et al. The correlation method for gravity anomaly separation[J]. Progress in Geophysics, 2008, 23(5):1425-1430.
[12] Gupta V K, Ramani N. Some aspects of regional-residual separation of gravity anomalies in a Precambrian terrain[J]. Geophysics, 1980, 45(9):1412-1426.
[13] 陈玉. 解析法与随机法联合定量反演位场[J]. 物探与化探, 2002, 26(6):470-474.
[14] Cen Y. The combination of analytical method and stochastic method for quantitative inversion of potential field[J]. Geophysical and Geochemical Exploration, 2002, 26(6):470-474.
[15] 汪炳柱, 王硕儒. 二维位场向上延拓与向下延拓的样条函数法[J]. 物探化探计算技术, 1998, 20(2):125-129.
[16] Wang B Z, Wang S R. Spline function methods for upward continuation and downward continuation of 2D potential field[J]. Computing Techniques for Geophysical and Geochemical Exploration, 1998, 20(2):125-129.
[17] Kebede H, Alemu A, Fisseha S. Upward continuation and polynomial trend analysis as a gravity data decomposition,case study at Ziway-Shala basin,central Main Ethiopian rift[J]. Heliyon, 2020, 6(1):e03292.
[18] Christopher J, Jong K L, Jay H K. Modeling errors in upward continuation for INS gravity compensation[J]. Journal of Geodesy, 2007, 81(5) :297-309.
[19] Heikki V, Olaf A, Ari V. One-dimensional upward continuation of the ground magnetic field disturbance using spherical elementary current systems[J]. Earth,Planets and Space, 2003, 55(10):613-625.
[20] 熊光楚. 矿产预测中重磁异常变换的若干问题二—向上延拓的作用及问题[J]. 物探与化探, 1992, 16(5):358-364.
[21] Xiong G C. Some problems concerning the transformation of gravity and magnetic anomalies in prognosis of ore resources Ⅱ-The effect and problems of upward continuation[J]. Geophysical and Geochemical Exploration, 1992, 16(5):358-364.
[22] Tariq A. Full-model wavenumber inversion:An emphasis on the appropriate wavenumber continuation[J]. Geophysics, 2016, 81(3) :R89-R98.
[23] 熊光楚. 矿产预测中重磁异常变换的若干问题三—向上延拓高度与研究深度的关系[J]. 物探与化探, 1992, 16(6):452-455.
[24] Xiong G C. Some problems concerning the transformation of gravity and magnetic anomalies in prognosis of ore resources Ⅲ-The relationship between the height of upward continuation and the depth of investigation[J]. Geophysical and Geochemical Exploration, 1992, 16(6):452-455.
[25] 尹伟言, 陈真, 蒋涛, 等. 地面重力数据向上延拓方法比较[J]. 地理空间信息, 2018, 16(7):75-77.
[26] Yin W Y, Chen Z, Jiang T, et al. Comparison of upward continuation methods for ground gravity data[J]. Geospatial Information, 2018, 16(7):75-77.
[27] Pawlowski R S. Preferential continuation for potential-field anomaly enhancement[J]. Geophysics, 1995, 60(2):390-398.
[28] Jacobsen B H. A case for upward continuation as a standard separation filter for potential-field maps[J]. Geophysics, 1987, 52(8):1138-1148.
[29] 曾华霖, 许德树. 最佳向上延拓高度估计[J]. 地学前缘, 2002, 9(2):499-504.
[30] Zeng H L, Xu D S. Estimation of optimum upward continuation height[J]. Geoscience Frontiers, 2002, 9(2):499-504.
[31] Farhadinia B. A modified class of correlation coefficients of hesitant fuzzy information[J]. Soft Computing, 2021, 25(10):7009-7028.
[32] Zhang P J. The frequency drift and fine structures of Solar S-bursts in the high frequency band of LOFAR[J]. The Astrophysical Journal, 2002, 891(1):89.
[33] 孙海龙, 吕伟星, 陈鑫, 等. 解析延拓法在山阳磁法数据解释中的应用[J]. 中国煤炭地质, 2017, 29(2):76-82.
[34] Sun H L, Lyu W X, Chen X, et al. Application of analytical continuation method on magnetometric data interpretation in shanyang area[J]. Coal Geology of China, 2017, 29(2):76-82.
-
