Crystalline-Basement Crystalline Graphite Deposit Dataset on the Northern Margin of the Upper Yangtze and North Sichuan
-
摘要:
上扬子北缘川北地区出露的基底地层发育双层结构，其中上层的褶皱基底早已发现尖山、坪河、庙坪等中—大型、超大型石墨矿；但是直到最近，才在下层的结晶基底后河岩群汪家坪岩组细粒石英岩中发现了石墨矿。该矿体长约200米，宽约6.7米，矿体平均厚度4.9米，矿石平均品位5.13%。矿物组合为：石英+石墨+云母+黄铁矿+赤铁矿。该成果在上扬子北缘地区的发现，扩大了该区域的找矿前景，为区内晶质石墨矿的找矿工作提供了新的方向，同时为四川巴中地区超大型晶质石墨矿基地建设提供了新的资源潜力保障。数据集包括Excel表格数据，2个*.xls类型文件，记录了样品固定碳测试结果和氧化物测试数据。
Abstract:The basement strata outcropping on the northern margin of the upper Yangtze and North Sichuan have developed a dual-layer structure, where medium-large and extra-large graphite deposits have been found at Jianshan, Pinghe and Miaoping etc., which are located on fold basements in the upper layer. Until recently, however, a graphite deposit is found in fine-grain quartzite of the Wangjiaping Formation, Houhe Group complex of the crystalline basement in its lower part. The rock mass is about 200 m long, 6.7 m wide, 4.9 m thick on average and 5.13% in average grade. The ore combination is quartz + graphite + mica + pyrite + hematite. This discovery on the northern margin of the upper Yangtze expands the prospecting foreground in the region, provides new opportunities to prospect crystalline graphite ores therein and gives a new guarantee in resource potential to build an extra-large crystalline graphite ore base in Bazhong, Sichuan. The dataset contains data in Excel sheets, including 2 type files *.xls, recording results from fixed carbon testing of samples and data from oxide testing.
-
Key words:
- Graphite deposit /
- Crystalline basement /
- Upper Yangtze /
- Houhe complex Group /
- Dataset
-
-
图 1 Basement structure on the northern margin of the Upper Yangtze and northern Sichuan as well as location of newly discovered graphite deposit
图 2 Mineralization features of the Houhe Group-complex Wangjiaping Formation graphite deposit
表 1 数据库（集）元数据简表
条目 描述 数据库（集）名称 上扬子北缘川北地区结晶基底晶质石墨矿数据集 数据库（集）作者 罗茂金，中国地质调查局成都地质调查中心
马志鑫，中国地质调查局成都地质调查中心
孙志明，中国地质调查局成都地质调查中心
黄 腾，四川冶金局605地质队
任京伟，成都理工大学
姜 岩，四川冶金局605地质队数据时间范围 2016—2018年 地理区域 四川省川北地区（南江县） 数据格式 *.xlsx 数据量 上扬子北缘结晶基底石墨矿TC51固定碳分析结果表，数据量大小14 kb
上扬子北缘结晶基底石墨矿TC51氧化物分析结果表，数据量大小32 kb
数据服务系统网址 http://dcc.cgs.gov.cn 基金项目 中国地质调查局地质调查项目“龙门山—滇中成矿带通安—宁蒗地区地质矿产调查”（DD20160017）资助 语种 中文 数据库（集）组成 该数据集是由2个Excel表格组成，表格名称分别“上扬子北缘结晶基底石墨矿TC51固定碳分析结果表”、“上扬子北缘结晶基底石墨矿TC51氧化物分析结果表”。
下载: 导出CSV
表 2 样品特征表
样号 岩矿石名称 样长（m） 固定碳含量（%） H1 条带状石墨矿化石英岩 1.00 4.34 H2 碎裂石墨矿化石英岩 1.00 9.44 H3 石墨矿化石英岩 1.50 3.70 H4 石墨矿化石英岩 1.40 4.05 H5 硅化石墨矿化石英岩 1.00 7.79 H6 石墨矿化石英岩 0.80 2.02 H7 黑色石英岩 1.00 0.995
下载: 导出CSV
表 3 TC51固定碳分析结果表
序号 字段名称 量纲 数据类型 实例 1 样号 无 字符串 TC51-H1 2 分析号 无 字符串 A171960115 3 固定碳 % 浮点型 4.34
下载: 导出CSV
表 4 TC51氧化物分析结果表
序号 字段名称 量纲 数据类型 实例 1 样号 无 字符串 TC51-H1 2 分析号 无 字符串 A174340098 3 SiO2 % 浮点型 84.97 4 Al2O3 % 浮点型 2.82 5 Fe2O3 % 浮点型 2.04 6 TFe % 浮点型 2.25 7 FeO % 浮点型 1.06 8 CaO % 浮点型 0.780 9 MgO % 浮点型 0.640 10 K2O % 浮点型 0.796 11 Na2O % 浮点型 0.057 12 TiO2 % 浮点型 0.137 13 P2O5 % 浮点型 0.616 14 S % 浮点型 0.049 15 H2O+ % 浮点型 0.924 16 H2O− % 浮点型 0.403 17 V2O5 % 浮点型 0.007 18 CO2 % 浮点型 0.265 19 Cu % 浮点型 0.019 20 灰份 % 浮点型 94.11 21 挥发份 % 浮点型 2.16
下载: 导出CSV
表 1 Metadata Table of Database (Dataset)
Items Description Database(dataset) name Crystalline-Basement Crystalline Graphite Deposit Dataset on the Northern Margin of the Upper Yangtze and North Sichuan Database(dataset) authors Luo Maojin, Chengdu Center, China Geological Survey
Ma Zhixin, Chengdu Center, China Geological Survey
Sun Zhiming, Chengdu Center, China Geological Survey
Huang Teng, Geologic Team 605 of Sichuan Metallurgic Bureau
Ren Jingwei, Chengdu University of Technology
Jiang Yan, Geologic Team 605 of Sichuan Metallurgic BureauData acquision time 2016—2018 Geographic area North Sichuan (Nanjiang county) Data format *.xlsx Data size TC51 fixed carbon analysis results of crystalline basement graphite deposit in north of upper Yangtze, data size: 14kb
TC51 oxide analysis results of crystalline basement graphite deposit in north of upper Yangtze, data size: 32kbData service system URL http://dcc.cgs.gov.cn Fund project China Geology Survey project “Geological Mineral Survey in Tongan–Ninglang, Longmen Mountain–Central Yunnan Metallogenic Zone” (DD20160017) Language Chinese Database(dataset) composition The dataset consists of 2 Excel sheets titled as “TC51 fixed carbon analysis result sheet of crystalline basement graphite deposit on the northern margin of upper Yangtze” and “TC51 oxide analysis result sheet of crystalline basement graphite deposit on the northern margin of upper Yangtze”.
下载: 导出CSV
表 2 Sample features
Sample no. Rock and ore name Sample length (m) Content of fixed carbon (%) H1 Banded graphite-mineralized quartzite 1.00 4.34 H2 Cataclastic graphite-mineralized quartzite 1.00 9.44 H3 Graphite-mineralized quartzite 1.50 3.70 H4 Graphite-mineralized quartzite 1.40 4.05 H5 Silicified graphite-mineralized quartzite 1.00 7.79 H6 Graphite-mineralized quartzite 0.80 2.02 H7 Black quartzite 1.00 0.995
下载: 导出CSV
表 3 TC51 fixed carbon analysis result sheet
No. Field name Dimension Data category Real example 1 Sample no. None Character string TC51-H1 2 Analysis No. None Character string A171960115 3 Fixed carbon % Floating-point type 4.34
下载: 导出CSV
表 4 TC51 oxide analysis result sheet
No. Field name Dimension Data category Real example 1 Sample no. None Character string TC51-H1 2 Analysis No. None Character string A174340098 3 SiO2 % Floating-point type 84.97 4 Al2O3 % Floating-point type 2.82 5 Fe2O3 % Floating-point type 2.04 6 TFe % Floating-point type 2.25 7 FeO % Floating-point type 1.06 8 CaO % Floating-point type 0.780 9 MgO % Floating-point type 0.640 10 K2O % Floating-point type 0.796 11 Na2O % Floating-point type 0.057 12 TiO2 % Floating-point type 0.137 13 P2O5 % Floating-point type 0.616 14 S % Floating-point type 0.049 15 H2O+ % Floating-point type 0.924 16 H2O− % Floating-point type 0.403 17 V2O5 % Floating-point type 0.007 18 CO2 % Floating-point type 0.265 19 Cu % Floating-point type 0.019 20 ash % Floating-point type 94.11 21 volatiles % Floating-point type 2.16
下载: 导出CSV
-
[1] 高显忠. 2015. 南江县尖山石墨矿地质特征及成因浅析[A]. 四川省地质学会2015年资料汇编I[C]. 四川省地质学会: 4.
[2] 何政伟, 刘援朝, 魏显贵, 肖渊甫, 马润则, 吴德超. 1997. 扬子克拉通北缘米仓山地区基底变质岩系同位素地质年代学[J]. 矿物岩石, 17(S1): 83−87. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199700341987
[3] 李超, 王登红, 赵鸿, 裴浩翔, 李欣尉, 周利敏, 杜安道, 屈文俊. 2015. 中国石墨矿床成矿规律概要[J]. 矿床地质, 34(6): 1223−1236. http://d.old.wanfangdata.com.cn/Periodical/kcdz201506011
[4] 李寒滨, 张冰. 2014. 黑龙江云山石墨矿床变质作用及其意义[J]. 中国非金属矿工业导刊, 33(1): 45−46. doi: 10.3969/j.issn.1007-9386.2014.01.016
[5] 刘金中, 钱祥麟, 陈亚平. 1989. 中国内蒙中部孔兹岩系中石墨矿的构造成因[J]. 大地构造与成矿学, 13(2): 67−72. http://www.cnki.com.cn/Article/CJFDTOTAL-DGYK198902008.htm
[6] 刘敬党, 肖荣阁. 2015. 华北晶质石墨矿床[M]. 北京: 科学出版社, 1−675.
[7] 刘援朝, 魏显贵, 吴德超. 1997. 扬子地台北缘早前寒武纪结晶基底构造样式及变形特征[J]. 矿物岩石, 17(S1): 88−96. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199700341988
[8] 马彩凤, 彭同江, 孙红娟, 梁小毅, 张冬. 2018. 四川南江坪河石墨的矿物学特征[J]. 矿物学报, 38(3): 257−262. http://d.old.wanfangdata.com.cn/Periodical/kwxb201803003
[9] 马志鑫, 罗茂金, 刘喜停, 孙志明. 2018. 四川南江坪河石墨矿炭质来源及成矿机制[J]. 地质科技情报, 37(3): 134−139. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzkjqb201803018
[10] 莫如爵, 刘绍斌, 黄翠蓉, 张光荣, 谭冠民, 王宝娴, 肖祥章. 1989. 中国石墨矿床地质[M]. 北京: 中国建筑工业出版社, 65− 80.
[11] 孙厚江, 吴春林, 曲廷耀. 1995. 辽河群孔达岩系与石墨矿床[J]. 矿产与地质, 9(3): 208−212. http://d.old.wanfangdata.com.cn/Periodical/sdgyjs201705079
[12] 王红军, 侯学文, 岑海涛, 魏继生. 2017. 四川省南江县庙坪石墨矿成矿地质特征及成因探讨[J]. 科技创新导报, 14(6): 45−46, 48. http://d.old.wanfangdata.com.cn/Periodical/kjzxdb201706025
[13] 夏锦胜, 孙莉, 肖克炎, 朱裕生. 2017. 四川省南江县坪河石墨矿床地质特征及成因分析[J]. 现代矿业, 33(2): 57−59, 77. doi: 10.3969/j.issn.1674-6082.2017.02.015
[14] 夏锦胜, 孙莉, 肖克炎. 2017. 四川南江尖山石墨矿床地质特征及成因[J]. 地质学刊, 41(2): 212−217. doi: 10.3969/j.issn.1674-3636.2017.02.007
[15] 杨培奇, 刘敬党, 张艳飞. 2017. 黑龙江佳木斯地块典型石墨矿床含矿岩石地球化学特征及成矿时代[J]. 中国地质, 44(2): 301−315. http://geochina.cgs.gov.cn/geochina/ch/reader/view_abstract.aspx?file_no=20170207&flag=1
[1] Gao Xianzhong. 2015. Analysis on geological characteristics and genesis of jianshan graphite mine in nanjiang county [A]. Archives compiled by Sichuan geological society in 2015 I [C]. Geological Society of Sichuan Province: 4 (in Chinese).
[2] He Zhengwei, Liu Yuanchao, Wei Xiangui, Xiao Yuanfu, Ma Runze, Wu Dechao. 1997. Isotopic geochronology of basement metamorphic rock series in the micangshan area along the northern margin of Yangtze craton. China[J]. Journal of Mineralogy and Petrology, 17(S1): 83−87 (in Chinese with English abstract).
[3] Li Chao, Wang Denghong, Zhao Hong, Pei Haoxiang, Li Xinwei, Zhou Limin, Du Andao, Qu Wenjun. 2015. Minerogenetic regularity of graphite deposits in China[J]. Mineral Deposits, 34(6): 1223−1236 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=kcdz201506011
[4] Li Hanbin, Zhang Bing. 2014. Metamorphism and Its Significance of Yunshan Graphite Deposit in Heilongjiang[J]. China Non-Metallic Minerals Industry, 33(1): 45−46 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgfjskgydk201401016
[5] Liu Jinzhong, Qian Xianglin, Chen Yaping. 1989. The tect onic origin of graphite deposits in the khondalite group, the middle part of inner mongolia, China[J]. Geotectonica Et Metallogenia, 13(2): 67−72 (in Chinese with English abstract).
[6] Liu Jingdang, Xiao Rongge.2015. The crystalline graphite deposit in north China[M].Beijing, Science Press, 324−328 (in Chinese).
[7] Liu Yuanchao, Wei Xiangui, Wu Dechao. 1997. Structure styles and characteristics in early precambrian crystalline basement in the northern margn of Yangtze platform[J]. Journal of Mineralogy and Petrology, 17(S1): 88−96 (in Chinese with English abstract).
[8] Ma Caifeng, Peng Tongjiang, Sun Hongjuan, Liang Xiaoyi, Zhang Dong. 2018. A Study on Mineralogical Characteristics of Pinghe Graphite Deposit in Nanjiang County, Sichuan Province, China[J]. Acta Mineralogica Sinica, 38(3): 257−262 (in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/kwxb201803003
[9] Ma Zhixin, Luo Maojin, Liu Xiting, Sun Zhiming. 2018. Carbon Source and Metallogenic Mechanism of Pinghe Graphite Deposit at Nanjiang, Sichuan Province[J]. Geological Science and Technology Information, 37(3): 134−139 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzkjqb201803018
[10] Mo Rujue, Liu Shaobin, Huang Cuirong, Zhang Guangrong, Tan Guanmin, Wang Baoxian, Xiao Xiangzhang. 1989. Geology of graphite deposits in China [M]. Beijing: China Architecture & Building Press, 65−80 (in Chinese).
[11] Sun Houjiang, Wu Chunlin, Qu Tingyao. 1995. Graphite deposit and Kongda rock sekies in liaoning group[J]. Mineral sources and geology, 9(3): 208−212 (in Chinese).
[12] Wang Hongjun, Hou Xuewen, Cen Haitao, Wei Jisheng. 2017. Discussion on metallogenic geological characteristics and genesis of Miaoping graphite deposit in Nanjiang county, Sichuan province[J]. Science and Technology Innovation Herald, 14(06): 45−46,48 (in Chinese).
[13] Xia Jinsheng, Sun Li, Xiao Keyan, Zhu Yusheng. 2017. Geological characteristics and genetic analysis of graphite deposits in Pinghe, Nanjiang County, Sichuan Province[J]. Modern Mining, 33(02): 57−59,77 (in Chinese).
[14] Xia Jinsheng, Sun Li, Xiao Keyan. 2017. Geological characteristics and genesis of Jianshan graphite deposit in Nanjiang County, Sichuan Province[J]. Journal of Geology, 41(2): 212−217 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=jsdz201702007
[15] Yang Peiqi, Liu Jingdang, Zhang Yanfei. 2017. Ore geochemical characteristics and metallogenic epoch of typical graphite deposits in Jiamusi Massif, Heilongjiang Province[J]. Geology in China, 44(2): 301−315 (in Chinese with English abstract). http://geochina.cgs.gov.cn/geochina/ch/reader/view_abstract.aspx?file_no=20170207&flag=1
-
