高压气体诱发煤岩动力破坏的实验研究

,

文章导航 > 地质力学学报 > 2021 > 27(4): 643-651

上一篇

下一篇

丁言露, 岳中琦. 2021. 高压气体诱发煤岩动力破坏的实验研究. 地质力学学报, 27(4): 643-651. doi: 10.12090/j.issn.1006-6616.2021.27.04.053
引用本文: 丁言露, 岳中琦. 2021. 高压气体诱发煤岩动力破坏的实验研究. 地质力学学报, 27(4): 643-651. doi: 10.12090/j.issn.1006-6616.2021.27.04.053
shu
DING Yanlu, YUE Zhongqi. 2021. Experimental study on the dynamic rupture of coal and rock caused by high-pressure gas. Journal of Geomechanics, 27(4): 643-651. doi: 10.12090/j.issn.1006-6616.2021.27.04.053
Citation: DING Yanlu, YUE Zhongqi. 2021. Experimental study on the dynamic rupture of coal and rock caused by high-pressure gas. Journal of Geomechanics, 27(4): 643-651. doi: 10.12090/j.issn.1006-6616.2021.27.04.053
shu

高压气体诱发煤岩动力破坏的实验研究

  • 1.

    北京大学工学院, 北京 100871

  • 2.

    北京大学北京天然气水合物国际研究中心, 北京 100871

  • 3.

    香港大学土木工程系, 香港特别行政区 999077

  • 基金项目:
    香港研究资助局资助项目（HKU17204415，HKU17207518）
详细信息
    作者简介: 丁言露(1990-), 男, 博士, 助理研究员, 从事岩土工程研究方向。E-mail: ylding@pku.edu.cn
    通讯作者: 岳中琦(1962-), 男, 博士, 教授, 从事岩土工程研究方向。E-mail: yueqzq@hku.hk

  • 中图分类号: TD315

Experimental study on the dynamic rupture of coal and rock caused by high-pressure gas

  • 1.

    College of Engineering, Peking University, Beijing 100871, China

  • 2.

    Beijing International Research Center for Gas Hydrate, Peking University, Beijing 100871, China

  • 3.

    Department of Civil Engineering, The University of Hong Kong, Hong Kong SAR 999077, China

  • Fund Project: This research is financially supported by the Hong Kong Research Grants Council (Grant No.HKU 17204415, HKU 17207518)
More Information

    摘要

  • 为了研究高压气体对煤岩材料变形破坏的作用，自主设计并制造了含高压气体煤岩实验装置，通过测量气体泄压作用诱发的煤岩动力破坏现象，研究了高压气体对煤岩材料变形破坏的作用。实验表明，当气体泄压速率小时，煤岩仅会出现轻微变形；当气体泄压速率大时，煤岩会产生破裂和破碎现象。同时发现煤岩的破坏程度不仅取决于气体的泄压速率，还取决于孔隙气体的压强。当气体泄压速率和气体压强都达到一定临界值时，煤岩才会发生剧烈破碎。通过气体压强与应变之间的关系，确定了煤岩发生破裂和破碎的临界气体压强。

    A special test apparatus has been designed and used to study the effect of high-pressure gas on the deformation and failure of coal and rock. Dynamic ruptures of coal and rock are carried out by gas decompression. The results show that low gas decompression rate only causes deformation of coal specimens slightly while high gas decompression rate leads to fracture and outburst phenomenon. The degree of damage of rocks depends on not only the gas decompression rate but also the gas pressure. Violent fragmentation occurs when gas decompression rate and high saturation pressure reach critical values. According to the relationship between the decompressed gas pressure and strain, the critical gas pressures are determined for the fracture and fragmentation of specimens.

    • HTML全文
  • 加载中

  • 图 1  含高压气体煤岩实验装置图

    Figure 1.

    下载: 全尺寸图片 幻灯片

    图 2  充入气体压强为0.5 MPa时快速泄压引起的试样破裂(时间间隔16.7 ms)

    Figure 2.

    下载: 全尺寸图片 幻灯片

    图 3  充入气体压强为1.0 MPa时快速泄压引起的试样破裂(时间间隔16.7 ms)

    Figure 3.

    下载: 全尺寸图片 幻灯片

    图 4  四组试验的试样在气体渗入和吸附过程中的应变变化

    Figure 4.

    下载: 全尺寸图片 幻灯片

    图 5  试样在气体泄压过程中的应变变化

    Figure 5.

    下载: 全尺寸图片 幻灯片

    图 6  气体泄压速率随时间变化图

    Figure 6.

    下载: 全尺寸图片 幻灯片

    图 7  气体压强和应变变化关系

    Figure 7.

    下载: 全尺寸图片 幻灯片

    图 8  充气过程与放气过程对煤岩体孔隙影响

    Figure 8.

    下载: 全尺寸图片 幻灯片

    表 1  实验参数与结果

    Table 1.  Summary of the experimental data and results

    编号 初始条件 测试条件 测试结果
    尺寸直径×高度/mm 饱和气压*/MPa 平均泄压速率/(MPa/s) 破裂压强/kPa 破碎压强/kPa 充气过程最大体积应变/×10-3 放气过程最大体积应变/×10-3 试样结果
    A Φ35.00×35.58 0.5 0.4 - - 4.944 -1.286 完整
    B Φ35.00×35.04 1.0 0.3 - - 7.392 -2.104 完整
    C Φ35.00×34.96 0.5 6.6 340 - 5.259 7.680 破裂
    D Φ35.00×36.16 1.0 8.2 - 960 7.349 12.015 破碎
    *注：气体压强数值为高于大气压强的差值
    下载: 导出CSV
    • 参考文献(34)

  • ATES Y, BARRON K, 1988. The effect of gas sorption on the strength of coal[J]. Mining Science and Technology, 6(3): 291-300. doi: 10.1016/S0167-9031(88)90287-3

    DING Y L, YUE Z Q, 2018. An experimental investigation of the roles of water content and gas decompression rate for outburst in coal briquettes[J]. Fuel, 234: 1221-1228. doi: 10.1016/j.fuel.2018.07.143

    EVANS I, POMEROY C D, 1966. The strength, fracture and workability of coal[M]. London: Pergamon Press.

    GUAN P, WANG H Y, ZHANG Y X, 2009. Mechanism of instantaneous coal outbursts[J]. Geology, 37(10): 915-918. doi: 10.1130/G25470A.1

    HE M C, MIAO J L, FENG J L, 2010. Rock burst process of limestone and its acoustic emission characteristics under true-triaxial unloading conditions[J]. International Journal of Rock Mechanics and Mining Sciences, 47(2): 286-298. doi: 10.1016/j.ijrmms.2009.09.003

    HU QT, ZHANG S T, WEN G C, et al., 2015. Coal-like material for coal and gas outburst simulation tests[J]. International Journal of Rock Mechanics and Mining Sciences, 74: 151-156. doi: 10.1016/j.ijrmms.2015.01.005

    HU S B, WANG E Y, LI X C, et al., 2016. Effects of gas adsorption on mechanical properties and erosion mechanism of coal[J]. Journal of Natural Gas Science and Engineering, 30: 531-538. doi: 10.1016/j.jngse.2016.02.039

    HUANG S, XIA K W, YAN F, et al., 2010. An experimental study of the rate dependence of tensile strength softening of Longyou sandstone[J]. Rock Mechanics and Rock Engineering, 43(6): 677-683. doi: 10.1007/s00603-010-0083-8

    KONG X G, WANG E Y, HU S B, et al., 2015. Critical slowing down on acoustic emission characteristics of coal containing methane[J]. Journal of Natural Gas Science and Engineering, 24: 156-165. doi: 10.1016/j.jngse.2015.03.020

    LITWINISZYN J, 1994. Rarefaction shock waves in porous media that accumulate CO2, CH4, N2[J]. Shock Waves, 3(3): 223-232. doi: 10.1007/BF01414716

    MAJEWSKA Z, MAJEWSKI S, ZIĘTEK J, 2010. Swelling of coal induced by cyclic sorption/desorption of gas: Experimental observations indicating changes in coal structure due to sorption of CO2 and CH4[J]. International Journal of Coal Geology, 83(4): 475-483. doi: 10.1016/j.coal.2010.07.001

    PAN Z J, CONNELL L D, 2007. A theoretical model for gas adsorption-induced coal swelling[J]. International Journal of Coal Geology, 69(4): 243-252. doi: 10.1016/j.coal.2006.04.006

    PINI R, OTTIGER S, BURLINI L, et al., 2009. Role of adsorption and swelling on the dynamics of gas injection in coal[J]. Journal of Geophysical Research: Solid Earth, 114(B4): B04203. http://www.researchgate.net/publication/255207823_Role_of_adsorption_and_swelling_on_the_dynamics_of_gas_injection_in_coal_-_article_no_B04203

    RANJITH P G, JASINGE D, CHOI S K, et al., 2010. The effect of CO2 saturation on mechanical properties of Australian black coal using acoustic emission[J]. Fuel, 89(8): 2110-2117. doi: 10.1016/j.fuel.2010.03.025

    SAGHAFI A, FAIZ M, ROBERTS D, 2007. CO2 storage and gas diffusivity properties of coals from Sydney Basin, Australia[J]. International Journal of Coal Geology, 70(1-3): 240-254. doi: 10.1016/j.coal.2006.03.006

    SKOCZYLAS N, DUTKA B, SOBCZYK J, 2014. Mechanical and gaseous properties of coal briquettes in terms of outburst risk[J]. Fuel, 134: 45-52. doi: 10.1016/j.fuel.2014.05.037

    TAN T K, KANG W F, 1991. On the locked in stress, creep and dilation of rocks, and the consititutive equations[J]. Chinese Journal of Rock Mechanics and Engineering, 10(4): 299-312. (in Chinese with English abstract) http://en.cnki.com.cn/Article_en/CJFDTOTAL-YSLX199104000.htm

    VIETE D R, RANJITH P G, 2006. The effect of CO2 on the geomechanical and permeability behaviour of brown coal: implications for coal seam CO2 sequestration[J]. International Journal of Coal Geology, 66(3): 204-216. doi: 10.1016/j.coal.2005.09.002

    VIETE D R, RANJITH P G, 2007. The mechanical behaviour of coal with respect to CO2 sequestration in deep coal seams[J]. Fuel, 86(17-18): 2667-2671. doi: 10.1016/j.fuel.2007.03.020

    WANG C H, GAO G Y, WANG H, et al, 2020. Integrated determination of principal stress and tensile strength of rock based on the laboratory and field hydraulic fracturing tests[J]. Journal of Geomechanics, 26(2): 167-174. (in Chinese with English abstract)

    WANG C J, YANG S Q, YANG D D, et al., 2018. Experimental analysis of the intensity and evolution of coal and gas outbursts[J]. Fuel, 226: 252-262. doi: 10.1016/j.fuel.2018.03.165

    WANG G, LI W X, WANG P F, et al., 2017. Deformation and gas flow characteristics of coal-like materials under triaxial stress conditions[J]. International Journal of Rock Mechanics and Mining Sciences, 91: 72-80. doi: 10.1016/j.ijrmms.2016.11.015

    WANG S G, ELSWORTH D, LIU J S, 2015. Rapid decompression and desorption induced energetic failure in coal[J]. Journal of Rock Mechanics and Geotechnical Engineering, 7(3): 345-350. doi: 10.1016/j.jrmge.2015.01.004

    YANG D D, CHEN Y J, TANG J, et al., 2018. Experimental research into the relationship between initial gas release and coal-gas outbursts[J]. Journal of Natural Gas Science and Engineering, 50: 157-165. doi: 10.1016/j.jngse.2017.12.015

    YIN G Z, JIANG C B, WANG J G, et al., 2016. A new experimental apparatus for coal and gas outburst simulation[J]. Rock Mechanics and Rock Engineering, 49(5): 2005-2013. doi: 10.1007/s00603-015-0818-7

    YUE Z Q, 2014. Gas inclusions and their expansion power as foundation of rock ""locked in"" stress hypothesis[J]. Journal of Engineering Geology, 22(4): 739-756. (in Chinese with English abstract) http://en.cnki.com.cn/Article_en/CJFDTOTAL-GCDZ201404028.htm

    YUE Z Q, 2015. Expansion power of compressed micro fluid inclusions as the cause of rockburst[J]. Mechanics in Engineering, 37(3): 287-294. (in Chinese with English abstract) http://www.zhangqiaokeyan.com/academic-journal-cn_mechanics-engineering_thesis/0201241946771.html

    ZANG J, WANG K, 2017. Gas sorption-induced coal swelling kinetics and its effects on coal permeability evolution: Model development and analysis[J]. Fuel, 189: 164-177. doi: 10.1016/j.fuel.2016.10.092

    ZHANG Q B, ZHAO J, 2014. Quasi-static and dynamic fracture behaviour of rock materials: phenomena and mechanisms[J]. International Journal of Fracture, 189(1): 1-32. doi: 10.1007/s10704-014-9959-z

    ZHAO Y X, LIU S M, JIANG Y D, et al., 2016. Dynamic tensile strength of coal under dry and saturated conditions[J]. Rock Mechanics and Rock Engineering, 49(5): 1709-1720. doi: 10.1007/s00603-015-0849-0

    陈宗基, 康文法, 1991. 岩石的封闭应力、蠕变和扩容及本构方程[J]. 岩石力学与工程学报, 10(4): 299-312. https://www.cnki.com.cn/Article/CJFDTOTAL-YSLX199104000.htm

    王成虎, 高桂云, 王洪, 等, 2020. 利用室内和现场水压致裂试验联合确定地应力与岩石抗拉强度[J]. 地质力学学报, 26(2): 167-174. https://journal.geomech.ac.cn/ch/reader/view_abstract.aspx?flag=1&file_no=20200202&journal_id=dzlxxb

    岳中琦, 2014. 奠基岩石""封闭应力""假说的气体包裹体和膨胀能力[J]. 工程地质学报, 22(4): 739-756. https://www.cnki.com.cn/Article/CJFDTOTAL-GCDZ201404028.htm

    岳中琦, 2015. 岩爆的压缩流体包裹体膨胀力源假说[J]. 力学与实践, 37(3): 287-294. https://www.cnki.com.cn/Article/CJFDTOTAL-LXYS201503001.htm
