The Paleoproterozoic basin evolution of the Zhongtiao Mountain region in the Trans-North China Orogen, North China Craton
-
摘要:
对华北克拉通中部造山带南部中条山地区古元古代中条群和担山石群岩石组合及地层详细调查研究，认为中条群为一套由粗碎屑岩-泥质岩-碳酸盐岩组成的多旋回沉积岩，变质砂岩地球化学特征显示，中条群经历了早期相对稳定到后期较活跃的转变。结合前人碎屑锆石年龄、源区特征和火山岩夹层年龄得出，中条群形成于2.1 Ga左右的活动大陆边缘弧后盆地。担山石群为一套砾岩-砂岩组成的磨拉石建造，碎屑锆石年龄显示，担山石群形成于1.85 Ga左右的碰撞造山阶段的前陆盆地内。结合前人研究，认为中条山地区古元古代盆地演化模式为，约2.1 Ga开始，西部陆块的前导洋向东部陆块活动大陆边缘之下持续俯冲，东部陆块西缘活动大陆边缘弧后盆地沉积了中条群，约1.85 Ga开始，东部陆块与西部陆块之间的大洋闭合，陆陆碰撞开始，中条群发生挤压褶皱变形，陆壳加厚及随后的快速抬升和剥蚀形成前陆盆地的担山石群磨拉石。中条山地区古元古代弧后盆地向前陆盆地的转化支持华北克拉通最初西部陆块向东俯冲，经历了约1.85 Ga的东、西陆块碰撞并最终克拉通化的演化模式。
Abstract:This paper conducted detailed investigations of the lithological assemblages and stratigraphy of the Zhongtiao Group and the Danshanshi Group in Zhongtiao Mountain region, Trans-North China Orogen (NTCO), North China Craton. The Zhongtiao Group comprises of a suit of metamorphic sedimentary rocks, consisting of multicyclic sedimentary rocks composed of clastic rocks, mudstones and carbonate rocks. The geochemical characteristics of the metamorphic sandstone show that the Zhongtiao group experienced a transition from early relative stability to late activity. The age and source characteristics of detrital zircons from the Zhongtiao Group and age of intercalated volcanic rock indicate that they were deposited in a back-arc basin of active continental margin from ~2.1 Ga. The Danshanshi Group is a series of conglomerates and sandstones forming a molasse basin during the collisional orogeny stage at ~1.85 Ga. Taken together, we present a brief scenario for the evolution of the sedimentary basin in Zhongtiao mountain region. From ~2.1 Ga, the eastward-directed subduction of the ocean between western block and eastern block, back-arc basin (Zhongtiao Group) developed behind the arc that located in the west margin of eastern block. At ~1.85 Ga, the ocean between western block and eastern block closed, resulting in the collision of the two blocks along TNCO, the Zhongtiao Back-arc basin underwent fold deformation and resulting in the crustal thickening followed by rapid exhumation/uplift, which shifted the back-arc basin to foreland basins. The Danshanshi molasse basin is formed in foreland basin. Such a shift from the back-arc basins to foreland basins in the Late Paleoproterozoic supports the model that the collision between Eastern and Western blocks occurred at ~1.85 Ga.
-
-
图 1 华北克拉通构造单元划分（据Zhao et al.，2005， 2011）
Figure 1.
图 2 中条山地区前寒武纪岩石分布地质简图（据刘树文等， 2007；张晗，2012）
Figure 2.
图 6 中条群变质砂岩的(TFeO+MgO)−TiO2判别图解（据Bhatia，1983）
Figure 6.
表 1 中条群碎屑岩主量、微量和稀土元素测试数据
Table 1. Test data of major, trace and rare earth elements of clastic rocks in Zhongtiao Group
元素 J01 J02 J03 W01 W02 W03 W04 W05 界牌梁组 界牌梁组 界牌梁组 吴家坪组 吴家坪组 吴家坪组 吴家坪组 吴家坪组 石英岩 绢英岩 绢英岩 绢英岩 绢英岩 绢英岩 绢英岩 绢英岩 SiO2 90.02 83.69 84.24 73.28 72.43 74.12 71.42 72.65 TiO2 0.42 0.38 0.41 0.56 0.59 0.71 0.68 0.69 Al2O3 6.21 7.78 6.95 15.21 16.84 14.92 14.73 15.74 Fe2O3 1.44 1.52 1.39 3.41 2.43 3.61 2.54 4.39 FeO 0.32 0.43 0.17 0.52 0.71 0.35 0.46 0.19 MnO 0.02 0.07 0.06 0.02 0.01 0.04 0.03 0.02 MgO 0.76 0.69 0.72 1.93 1.88 1.79 2.01 2.96 CaO 0.31 0.65 0.48 0.35 0.29 0.31 0.78 0.43 Na2O 0.23 0.19 0.27 0.19 0.41 0.46 0.76 0.23 K2O 0.95 2.15 2.47 2.65 2.57 2.04 3.78 2.44 P2O5 0.03 0.01 0.03 0.04 0.09 0.01 0.01 0.01 烧失量 1.21 2.11 2.31 2.83 2.78 1.68 3.02 1.94 总计 101.92 99.67 99.5 100.99 101.03 100.04 100.22 101.69 Cu 72.5 78.5 67.4 56.3 47.3 52.3 47.8 38.6 Ni 3.4 1.5 1.8 3.2 2.7 1.6 3.7 4.1 La 26.01 45.88 43.65 36.51 26.63 31.77 57.32 48.96 Ce 49.25 92.06 113.3 60.33 42.65 58.45 65.98 72.45 Pr 3.2 3.14 2.16 4.59 4.51 6.41 3.56 2.79 Nd 20.42 37.18 38.43 31.69 36.73 29.06 54.71 46.87 Sm 3.56 4.78 7.62 2.8 2.43 4.27 4.78 6.54 Eu 0.74 1.29 1.67 0.4 0.43 0.58 0.96 0.65 Gd 2.39 4.36 7.03 4.43 1.98 2.55 4.77 6.87 Tb 0.36 0.54 0.91 0.08 0.36 0.35 0.98 0.64 Dy 2.57 3.67 6.56 2.46 1.54 1.33 2.01 4.78 Ho 0.14 0.13 0.44 0.12 0.19 0.24 0.43 0.09 Er 2.76 3.82 3.67 2.28 1.55 3.67 4.31 3.78 Tm 0.01 0.04 0.06 0.04 0.04 0.07 0.06 0.03 Yb 1.93 2.89 3.59 1.28 1.36 1.49 1.94 1.78 Lu 0.23 0.44 0.55 0.14 0.29 0.34 0.41 0.33 Sr 71.81 78.31 76.23 75.23 45.39 72.47 79.43 79.48 Ba 342 241 442 223 243 232 446 379 Th 8.47 19.71 17.29 19.28 11.48 17.53 17.87 16.49 Zr 46.73 55.51 75.43 65.33 96.71 38.46 77.49 79.56 Hf 1.29 3.57 4.16 1.76 1.57 1.03 2.03 1.56 Y 18.64 14.57 31.26 12.46 13.76 14.58 13.78 14.12 Sc 8.62 10.59 20.41 9.88 1.65 0.89 4.56 7.63 Cr 58.41 92.31 83.16 310.33 103.36 110.3 145.78 147.68 Co 3.96 6.39 9.01 0.98 0.51 0.84 1.75 1.45 V 5.89 10.14 9.81 9.66 13.26 6.87 8.77 9.43 注：主量元素含量单位为%，微量和稀土元素含量单位为10−6
下载: 导出CSV
-
[1] Bhatia M R. 1983. Plate tectonics and geochemical composition of sandstones [J]. Jour. Geol., 91(4): 611−627.
[2] Faure M, Trap P, Lin W, et al. 2007. Polyorogenic evolution of the Paleoproterozoic Trans−North China Belt: New insights from the Luliangshan−Hengshan−Wutaishan and Fuping massifs[J]. Episodes, 30: 96−107. doi: 10.18814/epiiugs/2007/v30i2/004
[3] Krabbendam M, Prave T, Cheer D. 2008. A fluvial origin for the Neoproterozoic Morar Group, NW Scotland: Implications for Torridon Morar Group correlation and the Grenville Orogen foreland basin[J]. Journal of the Geological Society, 165: 379−394. doi: 10.1144/0016-76492007-076
[4] Kusky T M, Li J H. 2003. Paleoproterozoic tectonic evolution of the North China Craton[J]. Journal of Asian Earth Sciences, 22: 383−397. doi: 10.1016/S1367-9120(03)00071-3
[5] Li Q, Liu S, Wang Z, et al. 2011. Provenance and geotectonic setting of the Palaeoproterozoic Zhongtiao Group and implications for assembly of the North China Craton: Whole−rock geochemistry and detrital zircon data[J]. Journal of the Geological Society, 168(5): 1215−1224. doi: 10.1144/0016-76492010-146
[6] Li S Z, Zhao G C. 2007. SHRIMP U−Pb zircon geochronology of the Liaoji granitoids: Constraints on the evolution of the Paleoproterozoic Jiao−Liao−Ji belt in the Eastern Block of the North China Craton[J]. Precambrian Research, 158: 1−16. doi: 10.1016/j.precamres.2007.04.001
[7] Liu C H, Zhao G C, Sun M, et al. 2011a. U–Pb geochronology and Hf isotope geochemistry of detrital zircons from the Zhongtiao complex: Constraints on the tectonic evolution of the Trans−North China Orogen[J]. Precambrian Research, 222: 159−172.
[8] Liu C H, Zhao G C, Sun M, et al. 2011b. U−Pb and Hf isotopic study of detrital zircons from the Hutuo Group in the Trans−North China Orogen and tectonic implications[J]. Gondwana Research, 20(1): 106−121. doi: 10.1016/j.gr.2010.11.016
[9] Liu C H, Zhao G C, Sun M, et al. 2011c. U−Pb and Hf isotopic study of detrital zircons from the Yejishan Group of the Lüliang complex: Constraints on the timing of collision between the Eastern and Western Blocks, North China Craton[J]. Sedimentary Geology, 236(1/2): 129−140.
[10] Liu X, Fan H R, Santosh M, et al. 2016a. Geological and geochronological constraints on the genesis of the giant Tongkuangyu Cu deposit (Palacoproterozoic), North China Craton[J]. Int. Geol. Rev., 58: 155−170. doi: 10.1080/00206814.2015.1056759
[11] Liu X, Fan H R, Yang K F, et al. 2016b. Geochronology, redox−state and origin of the ore−hosting porphyry in the Tongkuangyu Cu deposit, North China Craton: Implications for metallogenesis and tectonic evolution[J]. Precambrian Research, 276: 211−232. doi: 10.1016/j.precamres.2016.02.006
[12] Meng X Y, Richards J P, Mao J W, et al. 2020. The Tongkuangyu Cu Deposit, Trans−North China Orogen: A metamorphosed Paleoproterozoic porphyry Cu deposit[J]. Economic Geology, 115(1): 51−77. doi: 10.5382/econgeo.4693
[13] Meng X Y, Kontak D J, Richards, J P, et al. 2021. Uncovering the missing magmatic link for the Tongkuangyu porphyry Cu deposit, Trans−North China Orogen: Implication for porphyry Cu deposit model and exploration[J]. Society of Economic Geologists Special Publication, 24(1): 121−135.
[14] Peng P, Zhai, M G, Ernst R E, et al. 2008. A 1.78 Ga large igneous province in the North China Craton: The Xiong’er volcanic province and the North China dyke swarm[J]. Lithos, 101: 260−280. doi: 10.1016/j.lithos.2007.07.006
[15] Qiu Z J, Fan H R, Liu X, et al. 2016. Mineralogy, chalcopyrite Re−Os geochronology and sulfur isotope of the Hujiayu Cu deposit in the Zhongtiao Mountains, North China Craton: Implications for a Paleoproterozoic metamorphogenic copper mineralization[J]. Ore Geology Reviews, 78: 252−267.
[16] Qiu Z J, Fan H R, Liu X, et al. 2017. Metamorphic P−T−t evolution of Paleoproterozoic schist−hosted Cu deposits in the Zhongtiao Mountains, North China Craton: Retrograde ore formation during sluggish exhumation[J]. Precambrian Research, 300: 59−77. doi: 10.1016/j.precamres.2017.08.014
[17] Rogers J W, Santosh M. 2002. Configuration of Columbia, a Mesoproterozoic supercontinent[J]. Gondwana Research, 5: 5−22.
[18] Tian W, Liu S W, Zhang H F. 2006. Paleoproterozoic potassic granitoids in the Sushui complex from the Zhongtiao Mountains, Northern China: Geochronology, geochemistry and petrogenesis[J]. Acta Geologyca Sinica (English Edition), 80: 875−885. doi: 10.1111/j.1755-6724.2006.tb00309.x
[19] Xia X P, Sun M, Zhao G C, et al. 2009. Detrital zircon U−Pb age and Hf isotope study of the khondalite in Trans−North China Orogen and its tectonic significance[J]. Geological Magazine, 146: 701−716. doi: 10.1017/S0016756809006396
[20] Yu S Q, Liu S W, Tian W, et al. 2006. SHRIMP zircon U−Pb chronology and geochemical of the Henglingguan and Beiyu granitoids in the Zhongtiao Mountains, Shanxi Province[J]. Acta Geologyca Sinica, 80: 912−922. doi: 10.1111/j.1755-6724.2006.tb00312.x
[21] Yuan L L, Zhang X H, Yang Z L, et al. 2017. Paleoproterozoic Alaskan−type ultramafic–mafic intrusions in the Zhongtiao Mountain region, North China Craton: Petrogenesis and tectonic implications[J]. Precambrian Research, 296: 39−61. doi: 10.1016/j.precamres.2017.04.037
[22] Zhang J, Zhao G C, Sun M, et al. 2006. High−pressure mafic granulites in the Trans−North China Orogen: Tectonic significance and age[J]. Gondwana Research, 9: 349−362. doi: 10.1016/j.gr.2005.10.005
[23] Zhang J, Zhao G C, Li S Z, et al. 2007. Deformation history of the Hengshan Complex: Implications for the tectonic evolution of the Trans−North China Orogen[J]. Journal of Structural Geology, 29: 933−949. doi: 10.1016/j.jsg.2007.02.013
[24] Zhang J, Zhao G C, Li S Z, et al. 2009. Deformational history of the Fuping Complex and new U−Th−Pb geochronological constraints: Implications for the tectonic evolution of the Trans−North China Orogen[J]. Journal of Structural Geology, 31: 177−193. doi: 10.1016/j.jsg.2008.11.008
[25] Zhao G C, Cawood P A, Wilde S A, et al. 2002. Review of global 2.1-1.8 Ga orogens: Implications for a pre−Rodinia supercontinent[J]. Earth−Science Reviews, 59: 125−162. doi: 10.1016/S0012-8252(02)00073-9
[26] Zhao G C, Sun M, Wilde S A, et al. 2003. Assembly, accretion and breakup of the Paleo−Mesoproterozoic Columbia supercontinent: Records in the North China Craton[J]. Gondwana Research, 6: 417−434.
[27] Zhao G C, Sun M, Wilde S A, et al. 2004. A Paleo−Mesoproterozoic supercontinent: Assembly, growth and breakup[J]. Earth−Science Reviews, 67: 91−123. doi: 10.1016/j.earscirev.2004.02.003
[28] Zhao G C, Sun M, Wilde S A, et al. 2005. Late Archean to Paleoproterozoic evolution of the North China Craton: Key issues revisited[J]. Precambrian Research, 136: 177−202. doi: 10.1016/j.precamres.2004.10.002
[29] Zhao G C, Wilde S A, Guo J H, et al. 2010. Single zircon grains record two Paleoproterozoic collisional events in the North China Craton[J]. Precambrian Research, 177: 266−276. doi: 10.1016/j.precamres.2009.12.007
[30] Zhao G C, Li S Z, Sun M, et al. 2011. Assembly, accretion, and break−up of the Palaeo−Mesoproterozoic Columbia supercontinent: record in the North China Craton[J]. International Geology Review, 53: 1331−1356. doi: 10.1080/00206814.2010.527631
[31] Zhao G C. 2016. Assembly, Accretion and Break−up of the Paleo−Mesoproterozoic Columbia (Nuna) supercontinent: Records in the North China Craton[J]. Acta Geologica Sinica (English Edition), 90(S1): 50. doi: 10.1111/1755-6724.12881
[32] 白瑾, 致信, 颜耀阳, 等. 1997. 中条山前寒武纪地质[M]. 天津: 天津科学技术出版社: 1−143.
[33] 耿元生, 沈其韩, 任留东. 2010. 华北克拉通晚太古代末—古元古代初的岩浆事件及构造热体制[J]. 岩石学报, 26(7): 1945−1966.
[34] 郭丽爽, 刘树文, 刘玉琳, 等. 2008. 中条山涑水杂岩中TTG片麻岩的锆石Hf同位素特征及其形成环境[J]. 岩石学报, 24(1): 139−148.
[35] 侯泉林, 郭谦谦, 方爱民. 2018. 造山带研究中有关复理石和磨拉石的几个问题[J]. 岩石学报, 34(7): 1885−1896.
[36] 胡国辉, 胡俊良, 陈伟, 等. 2010. 华北克拉通南缘中条山—嵩山地区1.78Ga基性岩墙群的地球化学特征及构造环境[J]. 岩石学报, 26: 1563−1576.
[37] 李宁波, 罗勇, 郭双龙, 等. 2013. 中条山铜矿峪变石英二长斑岩的锆石U−Pb年龄和Hf同位素特征及其地质意义[J]. 岩石学报, 29(7): 2416−2424.
[38] 李秋根, 刘树文, 王宗起, 等. 2008. 中条山绛县群碎屑锆石LA−ICP−MS U−Pb测年及其地质意义[J]. 岩石学报, 24(6): 1359−1368.
[39] 李三忠, 李玺瑶, 戴黎明, 等. 2015. 前寒武纪地球动力学(Ⅵ): 华北克拉通形成[J]. 地学前缘, 22(6): 77−96.
[40] 李三忠, 赵国春, 孙敏. 2016. 华北克拉通早元古代拼合与Columbia超大陆形成研究进展[J]. 科学通报, 61: 919−925.
[41] 刘超辉, 刘福来, 赵国春. 2012. 华北克拉通中部造山带早元古代盆地演化[J]. 岩石学报, 28: 2770−2784.
[42] 刘树文, 张臣, 刘超辉, 等. 2007. 中条山-吕梁山前寒武纪变质杂岩的独居石电子探针定年研究[J]. 地学前缘, (1): 64−74. doi: 10.3321/j.issn:1005-2321.2007.01.006
[43] 刘玄, 范宏瑞, 邱正杰, 等. 2015. 中条山地区绛县群和中条群沉积时限: 夹层斜长角闪岩SIMS锆石U−Pb年代学证据[J]. 岩石学报, 31(6): 1564−1572.
[44] 陆松年, 杨春亮, 李怀坤, 等. 2002. 华北古大陆与哥伦比亚超大陆[J]. 地学前缘, (4): 225−233.
[45] 邱正杰, 范宏瑞, 杨奎锋, 等. 2023. 中条山古元古代沉积岩容矿型铜钴矿床钴来源及富集过程[J]. 岩石学报, 39(4): 1019−1029.
[46] 孙大中, 李惠民, 林源贤, 等. 1991. 中条山前寒武纪年代学、年代构造格架和年代地壳结构模式的研究[J]. 地质学报, (3): 216−231.
[47] 孙大中, 胡维兴. 1993. 中条山前寒武纪年代构造格架和年代地壳结构[M]. 北京: 地质出版社: 1−168.
[48] 王雪, 黄小龙, 马金龙, 等. 2015. 华北克拉通中部造山带南段早前寒武纪变质杂岩的Hf−Nd同位素特征及其地壳演化意义[J]. 大地构造与成矿学, 39(6): 1108−1118.
[49] 肖玲玲, 刘福来. 2015. 华北克拉通中部造山带早前寒武纪变质演化历史评述[J]. 岩石学报, 31(10): 3012−3044.
[50] 杨崇辉, 杜利林, 任留东, 等. 2015. 中条山铜矿峪变质火山岩的时代、构造背景及对成矿的制约[J]. 地球学报, 36(5): 613−633. doi: 10.3975/cagsb.2015.05.10
[51] 杨崇辉, 杜利林, 宋会侠, 等. 2018. 华北克拉通古元古代地层划分与对比[J], 岩石学报, 34(4): 1019−1057, 1229−1232.
[52] 杨崇辉, 杜利林, 宋会侠, 等. 2020. 中条山地区涑水杂岩新太古代烟庄正长花岗岩年龄及成因: 对华北克拉通地壳演化的制约[J]. 地球科学, 45(9): 18.
[53] 翟明国, 卞爱国, 赵太平. 2000. 华北克拉通新太古代末超大陆拼合及古元古代末—中元古代裂解[J]. 中国科学(D辑), 43: 219−232.
[54] 翟明国. 2004. 华北克拉通2.1~1.7Ga地质事件群的分解和构造意义探讨[J]. 岩石学报, 6: 42−53.
[55] 翟明国, 彭澎. 2007. 华北克拉通古元古代构造事件[J]. 岩石学报, 11: 2665−2682.
[56] 翟明国. 2009. 华北克拉通两类早前寒武纪麻粒岩(HT−HP和HT−UHT)及其相关问题[J]. 岩石学报, 25(8): 1753−1771.
[57] 翟明国. 2011. 克拉通化与华北陆块的形成[J]. 中国科学:地球科学, 41(8): 10.
[58] 翟明国. 2012. 华北克拉通的形成以及早期板块构造[J]. 地质学报, 86(9): 1335−1349. doi: 10.3969/j.issn.0001-5717.2012.09.002
[59] 张晗. 2012. 山西中条山北段古元古代铜矿成矿作用[D]. 吉林大学博士学位论文: 1−168.
[60] 张瑞英, 张成立, 第五春荣, 等. 2012. 中条山前寒武纪花岗岩地球化学、年代学及其地质意义[J]. 岩石学报, 28: 3559−3573.
[61] 张瑞英, 张成立, 孙勇. 2013. 华北克拉通~2.5Ga地壳再造事件: 来自中条山TTG质片麻岩的证据[J]. 岩石学报, 29: 2265−2280.
[62] 张瑞英, 孙勇. 2017. 华北克拉通南部早前寒武纪基底形成与演化[J]. 岩石学报, 33(10): 3027−3041.
[63] 赵国春. 2009. 华北克拉通基底主要构造单元变质作用演化及其若干问题讨论[J]. 岩石学报, 25(8): 1772−1792.
[64] 赵凤清. 2006. 山西中条山地区古元古代地壳演化的年代学和地球化学制约[D]. 中国地质大学(北京)博士学位论文: 1−171.
[65] 赵太平, 邓小芹, 胡国辉, 等. 2015. 华北克拉通古/中元古代界线和相关地质问题讨论[J]. 岩石学报, 31(6): 1495−1508.
[66] 《中条山铜矿地质》编写组. 1978. 中条山铜矿地质[M]. 北京: 地质出版社: 25−88.
[67] 朱日祥, 郑天愉. 2009. 华北克拉通破坏机制与古元古代板块构造体系[J]. 科学通报, 54(14): 1950−1961.
-
