Key technologies for improving deep shale gas horizontal drilling ROP in Luzhou
-
摘要: 四川盆地泸州区块深层页岩气储层具有地层温度和压力高的特点，致使旋转导向仪器故障率高，四开平均钻井周期长；同时受井眼轨道“低造斜点+高造斜率”设计和长水平段轨迹频繁调整的影响，起下钻和下套管摩阻大。针对上述难题，通过现场试验，形成了降钻井液密度控压钻井、地面降温系统、旋转下套管等关键技术。现场应用表明：钻井液密度从2.20 g/cm3降至1.82 g/cm3，旋转导向仪器故障率从50%下降至30%；四开井段平均机械钻速从8 m/h提高到11.44 m/h，提高了43%；平均钻井周期从55.2 d降低到27.1 d，降幅51%；钻井提速提效显著。本文试验形成的关键技术对泸州深层页岩气水平井钻井工程提速提效具有良好的推广和借鉴意义。Abstract: Deep shale gas reservoir in Luzhou Block is featured of high formation temperature and pressure， leading to a high failure rate of 50% for the rotary-steering drilling tools and long average drilling time up to 50 days. Also， due to the wellbore trajectory design of “low kick-off point+high buildup rate” and the frequent adjustment of the long horizontal section trajectory， the frictional resistance during tripping of drilling strings and placement of casing was large. To address the above problems， several key technologies have been developed， including low-density-mud-based managed pressure drilling， the surface cooling system， and rotary casing placement. Field application showed that the density of drilling fluid was reduced from 2.20g/cm3 to 1.82g/cm3， the average ROP of the forth well section was 11.44m/h with an increase of 43%， the average drilling period was 27.1 days with a reduction of 51%， and the drilling speed and efficiency were significantly improved. The key technologies have good promotion and reference significance for improving the speed and efficiency of deep shale gas drilling projects in Luzhou.
-
Key words:
- deep shale gas /
- MPD /
- rotary-steering drilling /
- surface cooling system /
- rotary casing running /
- Luzhou Block /
- Sichuan Basin
-
-
[1] 李涛，郭清，程兴洁.四川盆地泸203井区钻井“漏喷同存”浅析［J］.石化技术，2021，5（4）：157-158.
LI Tao， GUO Qing， CHENG XingJie. Analysis of “lost circulation and overflow coexisting” in well of Sichuan Basin L203 Block［J］. Petrochemical Industy Technology， 2021，5（4）：157-158.
[2] [2] 万昕，左星.浅谈漏喷同存复杂地层的技术对策［J］.钻采工艺，2018，41（4）：34-36，47.
WANG Xin， ZUO Xing. Technology for loss-kick scenarios［J］. Drilling ＆ Production Technology， 2018，41（4）：34-36，47.
[3] [3] 姜智博，周英操，王倩.实现窄密度窗口安全钻井的控压钻井系统工程［J］.天然气工业，2011，31（8）：76-79.
JIANG Zhibo， ZHOU Yingcao， WANG Qing. Managed pressure drilling system used in narrow density window drilling scenarios［J］. Natural Gas Industry， 2011，31（8）：76-79.
[4] [4] 郑述全，欧云东，曾明昌.高含硫喷漏同存气井钻井与完井工艺技术研究［J］.天然气工业，2006，26（9）：65-67.
ZHENG Suquan， Yundong OU， ZENG Mingchang. Study on drilling and completion technology applied to high sulfur content gas wells where well kicks and losses coexist［J］. Natural Gas Industry， 2006，26（9）：65-67.
[5] [5] 刘汝山，曾义金.复杂条件下钻井技术难点及对策［M］.北京：中国石化出版社，2001.LIU Rushang， ZENG Yijin. Technical Difficulties and Solutions for Drilling under Complex Conditions［M］. Beijing： Sinopec Press， 2001.
[6] [6] 李希文.钻井事故与复杂问题［Ｍ］.北京：石油工业出版社，2001.LI Xiwen. Drilling Incidents and Complex Issues ［M］. Beijing： Petroleum Industry Press， 2001.
[7] [7] 王建龙，于志强.四川盆地泸州区块深层页岩气水平井关键技术［J］.石油钻探技术，2021，49（6），17-22.
WANG Jianglong， YU Zhiqiang. Key technology for deep shale gas horizontal well drilling in Luzhou Block in Sichuan Basin［J］. Pertroleum Drilling Techniques， 2021，49（6），17-22.
[8] [8] 张春林，古光平.四川盆地震旦系灯二段水平井优快钻井技术：以高石123井为例［J］.天然气勘探与开发，2020，43（2），53-57.
ZHANG Chunlin， GU Guangping. Optimal fast drilling for horizontal interval in simian dengying 2 member formation， Sichuan Basin：An example from Gaoshi 123 well［J］. Natural Gas Exploration and Develpoment， 2020，43（2），53-57.
[9] [9] 严俊涛，叶新群，付永强.川南深层页岩气旋转导向钻井技术瓶颈的突破［J］.录井工程，2021，32（3），6-10.
YAN Juntao， YE Xinqun， FU Yongqiang. A breakthrough in the technical bottleneck of rotary guided drilling in deep shale gas in Southern Sichuan［J］. Mud Logging Engineering， 2021，32（3），6-10.
[10] [10] 郑述权，谢祥峰，罗良仪，等.四川盆地深层页岩气水平井优快钻井技术［J］.天然气工业，2019，39（7），88-92.
ZHENG Shuquan， XIE Xiangfeng， LUO Liangyi， et al. Fast and efficient drilling technoligies for shale gas horizontal wells in the Sichuan Basin［J］. Natural Gas Industry， 2019，39（7），88-92.
[11] [11] 岳砚华，伍贤柱，张庆，等.川渝地区页岩气勘探开发工程技术集成与规模化应用［J］.天然气工业，2018，38（2）：74-82.
YUE Yanhua， WU Xianzhu， Zhang Qing， et al. Integration and scale application of shale gas exploration and development engineering technologies in Sichuan and Chongqing areas［J］. Natural Gas Industry， 2018，38（2）：74-82.
[12] [12] 余雷，高清春，吴兴国，等.四川盆地页岩气开发钻井技术难点与对策分析［J］.钻采工艺，2014，37（2）：1-4.
YU Lei， GAO Qingchun， WU Xingguo， et al. Drilling technical difficulties and countermeasures in shall gas development in Sichuan Basin［J］. Drilling & Production Technology， 2014，37（2）：1-4.
[13] [13] 樊好福，臧艳彬，张金成，等.深层页岩气钻井技术难点与对策［J］.钻采工艺，2019，42（3）：20-23.
FAN Haofu， ZANG Yanbin， ZHANG Jincheng， et al. Technical difficulties and countermeasures of deep shale gas drilling［J］. Drilling & Production Technology， 2019，42（3）：20-23.
[14] [14] 刘伟，白璟，陈东.川渝页岩气水平井水平段“一趟钻”关键技术与进展［J］.钻采工艺，2020，43（1）：1-4.
LIU Wei， BAI Jing， CHEN Dong. Cirtical techniques to ensure only one bit run when drilling horizontal interval drilling through shale at Sichuan and Chongqing area and technical advancements［J］. Drilling & Production Technology， 2020，43（1）：1-4.
[15] [15] 臧艳彬.川东南地区深层页岩气钻井关键技术［J］.石油钻探技术，2018，46（3）：7-12.
ZANG Yanbin. Key drilling technology for deep shale gas reservoirs in the Southeastern Sichuan region［J］. Petroleum Drilling Techniques， 2018，46（3）：7-12.
-
