Research and application of flushing fluid for uranium deposits drilling in Shiquantan area， Qaidam Basin
-
摘要: 柴达木盆地石圈滩地区铀矿资源调查评价钻探中钻遇地层高压异常，0~600 m地层压力系数为1.25~1.4；地层易溶，含盐量最高达1.025%，钻孔资料较少，在钻探过程中经常出现卡钻、塌孔等严重孔内事故。通过对该区地层进行岩性特征分析，根据地层特点进行冲洗液造浆粘土与处理剂优选，提出了一套适用于该区地层的抗盐防塌冲洗液体系，该体系具有良好的抗盐防塌性能，主要表现为：表观粘度38 mPa·s、动切力16.4 Pa、API滤失量4~5 mL、泥皮厚度0.3~0.4 mm，薄且致密，护壁效果良好。有效解决了该地区施工盐膏层缩径、塌孔及高压异常条件下冲洗液失稳等难题，平均台月效率从729.76 m提升至1378.78 m，孔径扩大率从130%下降至19.4%，泥浆材料和用水成本从57.91元/m降至38.92元/m，在现场实际应用中取得了良好的经济效益，具有推广应用价值。Abstract: During the investigation and evaluation of Uranium deposits in Shiquantan area of Qaidam Basin，the formation pressure anomaly was encountered. The formation pressure coefficient of 0~600m is 1.25~1.4. The formation is easily soluble with a high salt content of up to 1.025%. Accidents such as stuck and collapse usually happened during the drlling process as drilling information about this area is less. In this paper， a set of anti-salt and anti-collapse flushing fluid system suitable for the strata in this area is proposed by analyzing the lithological characteristics of the strata in this area， and preferentially selecting the corresponding slurry-making clay and treatment agent for the flushing fluid. As a result， this systerm has good anti-salt and anti-collapse performance， mainly showing as follows： the apparent viscosity 38MPa·s， the dynamic shear force is 16.4Pa， the API filter vector is 4~5mL， the mud skin is thin and dense with the thickness of 0.3~0.4mm which has good wall protection effect. It effectively solved the problems such as shrinkage in salt-gypsum layers， hole collapse and destabilization of flushing fluid under abnormal conditions of high pressure in this area. As a result， the average monthly efficiency is increased from 729.76m to 1378.78m， the hole expansion rate is reduced from 130% to 19.4%， and the cost of mud material and water is reduced from 57.91RMB/m to 38.92RMB/m. Good economic benefits have been achieved in practical application in the field which make it has the value of popularization and application.
-
-
[1] 孔北远.聚磺黄泥浆在岩盐钻井中的应用［J］.中国井矿盐，2014，45（5）：17-19.
KONG Beiyuan. Application of polysulfonate mud in the drilling of rock salt well［J］. China Well and Rock Salt， 2014，45（5）：17-19.
[2] [2] 曾义金.深部盐膏层蠕变关系研究［J］.石油钻探技术，2004（3）：5-7.
ZENG Yijin. Study on salt creep in deep formations［J］. Petroleum Drilling Techniques， 2004（3）：5-7.
[3] [3] 曾义金，王文立，石秉忠.深层盐膏岩蠕变特性研究及其在钻井中的应用［J］.石油钻探技术，2005（5）：51-54.
ZENG Yijin， WANG Wenli， SHI Bingzhong. Study on creep features of deep salt and gypsum beds and its applications in drilling operations［J］. Petroleum Drilling Techniques， 2005（5）：51-54.
[4] [4] 虞海法，左凤江，耿东士，等.盐膏层有机盐钻井液技术研究与应用［J］.钻井液与完井液，2004，21（5）：8-11.
YU Haifa， ZUO Fengjiang， GENG Dongshi， et al. Organic salt drilling fluid for salt gypsum formation drilling［J］. Drilling Fluid & Completion Fluid， 2004，21（5）：8-11.
[5] [5] 周建东，李在均，邹盛礼，等.有机盐钻井液在塔里木东河油田DH1-8-6井的应用［J］.钻井液与完井液，2002，19（4）：21-23.
ZHOU Jiandong， LI Zaijun， ZOU Shengli， et al. Application of organic salt drilling fluid in Well DH-8-6 of Donghe Oilfield in Tarim［J］. Drilling Fluid & Completion Fluid， 2002，19（4）：21-23.
[6] [6] 郑力会，王志军，张民立.盐膏层用高密度有机盐钻井液的研究与应用［J］.钻井液与完井液，2004，21（4）：37-39.
ZHENG Lihui， WANG Zhijun， ZHANG Minli. Study and application of high density organic salt drilling fluid for gypsum/salt bed［J］. Drilling Fluid & Completion Fluid， 2004，21（4）：37-39.
[7] [7] 邓诚，曾胡勇.伊拉克M油田A-25井盐膏层侧钻技术［J］.石化技术，2022，29（4）：147-148.
DENG Cheng， ZENG Huyong. Salt Layer Sidetrack technology of Well A-25 in M Oilfield［J］. Petrochemical Industry Technology， 2022，29（4）：147-148.
[8] [8] 杨晓冰，蔺志鹏，陈鑫，等.土库曼斯坦南约洛坦气田复杂盐膏层钻井液技术［J］.天然气工业，2011，31（7）：55-58.
YANG Xiaobing， LIN Zhipeng， CHEN Xin， et al. Drilling fluid technology used in the complicated gypsum beds in the South Yoloten Gas Field， Turkmenistan［J］. Natural Gas Industry， 2011，31（7）：55-58.
[9] [9] 刘晓阳.“双护”泥浆在地浸砂岩铀矿钻进中的应用［J］.探矿工程（岩土钻掘工程）， 2004，31（9）：55-56.
LIU Xiaoyang. Application of ‘Double Protections’ mud in sandstone uranium mine drilling［J］. Exploration Engineering （Rock & Soil Drilling and Tunneling）， 2004，31（9）：55-56.
[10] [10] 乌效鸣，蔡记华，胡郁乐.钻井液与岩土工程浆材［M］.武汉：中国地质大学出版社，2014.WU Xiaoming， CAI Jihua， HU Yule. Drilling Fluid and Geotechnical Engineering Slurry［M］. Wuhan： China University of Geosciences Press， 2014.
[11] [11] 徐培远，袁志坚.青海盐溶地层钻探卤水泥浆配方研制及应用［J］.探矿工程（岩土钻掘工程），2017，44（6）：41-44.
XU Peiyuan， YUAN Zhijian. Development and application of brine mud formula in salt soluble formation in Qinghai［J］. Exploration Engineering （Rock & Soil Drilling and Tunneling）， 2017，44（6）：41-44.
[12] [12] 纪卫军，张明德，赵长亮，等.青海省冷湖镇钾矿资源调查评价项目冲洗液技术研究及应用［J］.探矿工程（岩土钻掘工程），2016，43（1）：54-57.
JI Weijun， ZHANG Mingde， ZHAO Changliang， et al. Research and application of flushing fluid technology for potassium ore resource investigation project of Lenghu town in Qinghai［J］. Exploration Engineering （Rock & Soil Drilling and Tunneling）， 2016，43（1）：54 -57.
[13] [13] 程建祥，张德权，张家峰.漳县盐矿钻探施工与成井工艺［J］.探矿工程（岩土钻掘工程），2005，32（6）：54-56.
CHENG Jianxiang， ZHANG Dequan， ZHANG Jiafeng. Well drilling and completion techniques in Zhangxian county salt mine［J］. Exploration Engineering （Rock & Soil Drilling and Tunneling）， 2005，32（6）：54-56.
[14] [14] 张庆海，姚桂山，吴宁魁.盐矿钻探技术与工艺［M］.北京：地质出版社，1992.ZHANG Qinghai， YAO Guishan， WU Ningkui. Salt Mine Drilling Technology［M］. Beijing： Geological Publishing House， 1992.
[15] [15] 郑文龙，乌效鸣，吴笛，等.深部盐岩层绳索取心钻井液技术研究与应用［J］.地质与勘探，2015，51（5）：977-983.
ZHENG Wenlong， WU Xiaoming， WU Di， et al. Drilling fluid technology suitable for core drilling in deep salt beds［J］. Geology and Exploration， 2015，51（5）：977-983.
[16] [16] 祝学飞，孙俊，舒义勇，等.ZQ2井盐膏层高密度欠饱和盐水聚磺钻井液技术［J］.钻井液与完井液，2019，36（6）：716-720.
ZHU Xuefei， SUN Jun， SHU Yiyong， et al. A high density under saturated saltwater drilling fluid for salt and gypsum drilling in Well ZQ2［J］. Drilling Fluid & Completion Fluid， 2019，36（6）：716-720.
[17] [17] 李田周，陶士先，熊正强.磷石膏地层用钙基成膜环保冲洗液研究与应用［J］.钻探工程，2023，50（1）：49-54.
LI Tianzhou， TAO Shixian， XIONG Zhengqiang. Development and application of calcium-based film-forming environment-friendly drilling fluid for phosphogypsum formation［J］. Drilling Engineering， 2023，50（1）：49-54.
[18] [18] 王方博.川西海相破碎地层防塌钻井液技术研究及应用［J］.钻探工程，2021，48（9）：55-64.
WANG Fangbo. Application of anti-collapse drilling fluid technology in marine broken formation in western Sichuan［J］. Drilling Engineering， 2021，48（9）：55-64.
[19] [19] 刘学鹏.温敏堵漏水泥浆体系研究与应用［J］.钻探工程，2022，49（2）：110-116.
LIU Xuepeng. Research and application of the temperature sensitive plugging cement slurry system［J］. Drilling Engineering， 2022，49（2）：110-116.
[20] [20] 苏力才，谢健全，李永卫，等.PVA1788无固相冲洗液体系的研究与应用［J］.钻探工程，2022，49（4）：68-73.
SU Licai， XIE Jianquan， LI Yongwei， et al. Research and application of PVA1788 solid-free drilling fluid system［J］. Drilling Engineering， 2022，49（4）：68-73.
-
