Optimization of the structural performance parameters of the dual-fluid powered rotary valve drilling impactor
-
摘要: 为了研究旋冲钻井中双液驱动DH型转阀钻井冲击器的冲击运动规律，优化其性能参数，通过分析其在冲程阶段和回程阶段的受力情况，采用有限差分法，建立转阀活塞运动数学模型，利用MATLAB软件编译仿真电算程序，对转阀活塞的动力学过程进行仿真电算，得出DH型转阀钻井冲击器的最优冲击性能参数。同时研究冲击器上下腔面积差、油压系统流量及压降对DH型转阀钻井冲击器冲击性能的影响，并设计关于冲击功、冲击频率和冲击功率的正交分析试验，利用Design-Expert软件对计算结果进行优化，以更好地提高冲击器的工作性能。研究结果表明：活塞杆直径和压降对冲击器工作性能的影响较为突出，流量对冲击器工作性能的影响较小。经优化，冲击功提高21.88%，冲击频率提高12.9%，冲击功率提高37.6%。相关研究对液动冲击器设计及应用具有一定的指导意义。Abstract: In order to research the impact motion law of the dual-fluid rotary valve impactor in rotary percussive drilling， and optimize its performance parameters， through the analysis of its forces in the phases of stroke and return， the finite difference method is used to create the mathematical model of the rotary valve piston movement， and a simulation computer program compiled with MATLAB software is applied to simulation of the dynamic process of the rotary valve piston to obtain the optimal impact performance parameters of the dual-fluid powered rotary valve drilling impactor. At the same time， the influence of the difference in the area between the upper and lower chambers of the impactor， and the flow rate and pressure drop of the oil pressure system on the impact performance of the dual-fluid powered rotary valve drilling impactor is studied， and the orthogonal analysis test for impact energy， impact frequency and impact power is designed. The results are optimized by Design-Expert software to improve the working performance of the impactor. The results show that the piston rod diameter and pressure drop have prominent effects on the impactor performance， while the flow rate has little effect on the impactor performance. After optimization， the impact energy， impact frequency and impact power are increased by 21.88%，12.9% and 37.6% respectively. The research has guiding significance to the design and application of hydraulic impactors.
-
-
[1] 王人杰，蒋荣庆，韩军智.液动冲击回转钻探［M］.北京：地质出版社，1998：2-4.
WANG Renjie， JIANG Rongqing， HAN Junzhi. Hydraulic Impact Rotary Drilling［M］. Beijing： Geological Publishing House， 1998：2-4.
[2] [2] Graf L.E.，Kogan D.I. Hydro-percussion machines and tools［C］//
Nedra ，Moscow，Russia ： 1972.[3] [3] 刘上.双作用液动冲击器性能研究［D］.成都：西南石油大学，2016.LIU Shang. Research on performance of double acting hydraulic impactor［D］. Chengdu： Southwest Petroleum University， 2016.
[4] [4] Whiteley M.C.， England W.P. Air drilling operations improved by percussion bit/hammer tool tandem［R］. SPE13429，1985.
[5] [5] 李国民.双液驱动旋冲钻井冲击器：
CN202020159715.2 ［P］.2020-12-08 .LI Guomin. Dual fluid driven rotary percussion drilling impactor：
CN202020159715.2 ［P］.2020-12-08 .[6] [6] 殷琨，菅志军，蒋荣庆.大冲击功液动锤的研究及其应用［J］.探矿工程，1996（4）：8-10.
YIN Kun， JIAN Zhijun， JIANG Rongqing. Research and application of hydraulic hammer with high impact power［J］. Exploration Engineering， 1996（4）：8-10.
[7] [7] 谢文卫，苏长寿，宋爱志.新型高冲击功液动潜孔锤的研究［J］.探矿工程，1998（6）：3-5.
XIE Wenwei， SU Changshou， SONG Aizhi. Research on new hydraulic DTH hammer with high impact power［J］. Exploration Engineering， 1998（6）：3-5.
[8] [8] Lazutkin S.L.，Lazutkina N. A. Perspective construction of hydraulic impact device［J］. Procedia Engineering，2015，129.
[9] [9] Xuan L.， Guan Z.， Hu H.， et al. The principle and application of a novel rotary percussion drilling tool drived by positive displacement motor［R］. SPE 180535，2016.
[10] [10] Huang X.， Hu G.，Meng Q.，et al. Impact performance optimization of a YDC valve-type double action hydraulic hammer［J］. Natural Gas Industry B， 2018.
[11] [11] Zhang X.， Zhang S.， Luo Y.，et al.Experimental study and analysis on a fluidic hammer—An innovative rotary-percussion drilling tool［J］. Journal of Petroleum Science and Engineering，2019，173.
[12] [12] 罗永江，李柏军，梁运培，等.一种转阀式液动冲击器：
CN201711459418.9 ［P］.2018-07-24 .LUO Yongjiang， LI Baijun， LIANG Yunpei， et al. A rotary valve type hydraulic impactor：
CN201711459418.9 ［P］.2018-07-24 .[13] [13] 张晨，赵钰，吴何洪，等.潜孔冲击器结构性能参数优化研究［J］.石油机械，2019，47（11）：32-37，58.
ZHANG Chen， ZHAO Yu， WU Hehong， et al. Optimization of structural performance parameters of submerged hole impactor［J］. China Petroleum Machinery， 2019，47（11）：32-37，58.
[14] [14] 王伟，张士新，郑瑞强，等.旋冲螺杆钻井工具研制与应用［J］.西部探矿工程，2020，32（4）：72-74.
WANG Wei， ZHANG Shixin， ZHENG Ruiqiang， et al. Development and application of rotary thrust screw drilling tool［J］. West-China Exploration Engineering， 2020，32（4）：72-74.
[15] [15] 肖新磊.水力旋冲钻井工具破岩影响因素模拟及应用［J］.石油矿场机械，2020，49（3）：52-57.
XIAO Xinlei. Simulation and application of influence factors of rock breaking by hydraulic rotary percussion drilling tool［J］. Oil Field Equipment， 2020，49（3）：52-57.
[16] [16] 甘心.钻井提速用振动冲击工具研究进展［J］.钻探工程，2021，48（2）：85-93.
GAN Xin. Advances in vibration impactors for drilling acceleration［J］. Drilling Engineering，2021，48（2）：85-93.
[17] [17] 郭强，翁炜，袁文真，等.射流式液动冲击器在ZK01-2井提速应用研究［J］.钻探工程，2021，48（10）：56-61.
GUO Qiang， WENG Wei， YUAN Wenzhen， et al. Use of the jet-type fluid hammer for increasing ROP at Well ZK01-2［J］. Drilling Engineering， 2021，48（10）：56-61.
[18] [18] 吴召明，陆洪智.基于压电力传感器冲击功的检测方法研究［J］.钻探工程，2022，49（4）：55-60.
WU Zhaoming， LU Hongzhi. Research on the impact energy detection method based on piezoelectric force sensors［J］. Drilling Engineering， 2022，49（4）：55-60.
[19] [19] 李国民.双液驱动旋冲钻井冲击器及双液驱动旋冲钻进方法：
CN202010084676.9 ［P］.2020-05-19 .LI Guomin. Dual fluid driven rotary percussion drilling impactor and dual fluid driven rotary percussion drilling method：
CN202010084676.9 ［P］.2020-05-19 . -
