The influence of shape memory on the performance of polymers used for sand control in hydrate production wells
-
摘要: 形状记忆聚合物防砂筛管在日本第二轮天然气水合物试采中成功应用，但形状记忆效应对聚合物孔渗特征和防砂性能等影响的研究较少。基于此，本文研发了一种以聚氨酯作为基质的形状记忆聚合物防砂材料，探究了聚合物形状记忆特性、形状记忆前后的孔渗特性和力学强度等的变化规律，并评价了防砂性能。实验结果表明：研制的多孔聚氨酯具有良好的形状记忆特性和孔渗特性，形状固定率>98%，形状恢复率为100%，形状记忆温度为59.8 ℃；回弹前后渗透率均维持在10 D左右，且回弹前后抗压强度均维持在1 MPa左右；压汞测试表明形状记忆是一个对材料内部大孔的压缩-回弹过程，会导致材料内部结构发生变化，造成抗压强度略有降低，但完全回弹后，渗透性会小幅度增加；防砂性能测试表明仅在实验初期会有少量砂产出，砂粒的产出会对聚氨酯渗透性有一定的损伤，但对完全回弹的聚氨酯的渗透率仍可保持在10 D左右。综合材料性能分析认为，研制的形状记忆聚氨酯材料可配合机械防砂筛管使用，能满足水合物开采井防砂的需求。Abstract: The shape memory polymer sand control system has been successfully applied in the second phase of natural gas hydrate production in Japan. However， the effects of the shape memory on the pore-permeability characteristics and sand control performance of polymers is rarely researched. Therefore， in this paper， a shape memory polymer sand control material taking the polyurethane as the matrix is developed. The polymer’s shape memory characteristics as well as the changes in pore-permeability and mechanical strength before and after the shape memory process are investigated and the sand control performance is also evaluated. The results revealed that the developed porous polyurethane shows excellent shape memory characteristics and pore-permeability properties： the shape fixed rate exceeded 98%， the shape recovery rate reached 100%， the shape memory temperature was 59.8°C， the permeability remained at approximately 10D before and after the shape memory process， and the compressive strength was maintained at around 1MPa. The mercury injection tests indicated that the shape memory process is a compression-rebound process for the polyurethane material with large pores， which will lead to some changes in the internal structure of the material， resulting in a slight decrease in compressive strength and a small increase in permeability after complete shape recovery. The sand control performance tests indicated that a small amount of sand production occurred only in the initial test， and the presence of sand particles caused some damage to the permeability of the polyurethane material， however， the permeability could still be maintained at around 10 D for the fully recovered polyurethane. According to the comprehensive performance analysis of the above materials， the developed shape memory polyurethane material can be used in conjunction with a mechanical sand control screen pipe， which could meet the requirements of sand control in hydrate production wells.
-
Key words:
- natural gas hydrate /
- shape memory polymer /
- porous polyurethane /
- sand control /
- permeability /
- pore structure
-
-
[1] 王锐.天然气水合物的研究现状与发展趋势［J］.广东化工，2017，44（18）：131-132.
WANG Rui. The research status and developing tendency of natural gas hydrate［J］. Guangdong Chemical Industry， 2017，44（18）：131-132.
[2] [2] 李清平，周守为，赵佳飞，等.天然气水合物开采技术研究现状与展望［J］.中国工程科学，2022，24（3）：214-224.
LI Qingping， ZHOU Shouwei， ZHAO Jiafei， et al. Research status and prospects of natural gas hydrate exploitation technology［J］. Engineering Science， 2022，24（3）：214-224.
[3] [3] 杨明清，赵佳伊，王倩.俄罗斯可燃冰开发现状及未来发展［J］. 石油钻采工艺，2018，40（2）：198-204.
YANG Mingqing， ZHAO Jiayi， WANG Qian. The development status and prospect of combustible ice in Russia［J］. Oil Drilling & Production Technology， 2018，40（2）：198-204.
[4] [4] 孙峰.天然气水合物开采技术现状及发展趋势［J］.化工设计通讯，2018，44（1）：55.SUN Feng. Status and development trend of natural gas hydrate mining technology［J］. Chemical Engineering Design Communications， 2018，44（1）：55.
[5] [5] 王志刚，李小洋，张永彬，等.海域非成岩天然气水合物储层改造方法分析［J］.钻探工程，2021，48（6）：32-38.
WANG Zhigang， LI Xiaoyang， ZHANG Yongbin， et al. Analysis of the stimulation methods for Marine non-diagenetic natural gas hydrate reservoirs［J］. Drilling Engineering， 2021，48（6）：32-38.
[6] [6] 卢静生，李栋梁，何勇，等.天然气水合物开采过程中出砂研究现状［J］.新能源进展，2017，5（5）：394-402.
LU Jingsheng， LI Dongliang， HE Yong， et al. Research status of sand production during the gas hydrate exploitation process［J］. Advances in New and Renewable Enengy， 2017，5（5）：394-402.
[7] [7] 罗强，刘志辉，宁伏龙，等.天然气水合物储层超声雾化防砂排水采气实验研究［J］.钻探工程，2022，49（3）：23-28.
LUO Qiang， LIU Zhihui， NING Fulong， et al. Sand control and water drainage by ultrasonic atomization for gas recovery from hydrate reservoirs［J］. Drilling Engineering， 2022，49（3）：23-28.
[8] [8] 齐赟，孙友宏，李冰，等.近井储层改造对天然气水合物藏降压开采特性影响的数值模拟研究［J］.钻探工程，2021，48（4）：85-96.
QI Yun， SUN Youhong， LI Bing， et al. Numerical simulation of the influence of reservoir stimulation in the near wellbore area on the depressurization production characteristics of natural gas hydrate reservoir［J］. Drilling Engineering， 2021，48（4）：85-96.
[9] [9] 史浩贤，谢文卫，于彦江，等.复合解堵技术在天然气水合物开发中的应用可行性分析［J］.钻探工程，2022，49（1）：5-15.
SHI Haoxian， XIE Wenwei， YU Yyanjiang， et al. Application feasibility of composite plugging removal technology in the development of natural gas hydrate［J］. Drilling Engineering， 2022，49（1）：5-15.
[10] [10] 张磊.置换减压法开发天然气水合物工艺及数值模拟［J］.钻采工艺，2021，44（6）：74-77.
ZHANG Lei. Process and numerical simulation of gas hydrate development by displacement and decompression method［J］. Drilling & Production Technology， 2021，44（6）：74-77.
[11] [11] Setiawan T， Putra A， Az-Zariat A， et al. Shallow reservoir development in mature field： From hazard to resources［C］//
SPE/IATMI Asia Pacific Oil & Gas Conference and Exhibition ，Jakarta， Indonesia 2017： SPE-186263-MS.[12] [12] Mohd N， Mohamed A， Shamsuddin S， et al. From shallow hazard to productive opportunity： Opening a new gas play in the North malay basin［C］//
International Petroleum Technology Conference ，Kuala Lumpur， Malaysia ， 2008：IPTC-12642-MS.[13] [13] van den Boogaard M.， Hoetz H. L. J. G.. Shallow gas play in the Netherlands takes off［C］//
74th EAGE Conference and Exhibition incorporating EUROPEC 2012 ， Houten： European Association of Geoscientists & Engineers， 2012.[14] [14] 姜平，薛国庆，成涛.海上中小型气田经济高效联合开发技术——以乐东22-1/15-1气田为例［J］.天然气工业，2013，33（11）：62-67.
JIANG Ping， XUE Guoqing， CHENG Tao. An economic and efficient joint development technology for medium and small offshore gas fields： A case study of Ledong 22-1 and 15-1 gas fields in the Yinggehai Basin［J］. Natural Gas Industry， 2013，33（11）：62-67.
[15] [15] Yamamoto K， Terao Y， Fujii T， et al. Operational overview of the first offshore production test of methane hydrates in the Eastern Nankai Trough［C］//
Offshore Technology Conference ，Houston， Texas ， 2014： OTC-25243-MS.[16] [16] Card R J， Howard P R， Féraud J P. A novel technology to control proppant backproduction［J］. SPE Production & Facilities， 1995，10（4）：271-276.
[17] [17] Lu W B， O’neil B， Zhang K W， et al. Enhancing proppant flowback control through surface treatment of proppant［C］//
International Petroleum Technology Conference ，Bangkok， Thailand ， 2016： IPTC-18796-MS.[18] [18] Marfo S A A， Appah D， Joel O F F， et al. Sand consolidation operations， challenges and remedy［C］//
SPE Nigeria Annual International Conference and Exhibition ，Lagos， Nigeria ， 2015： SPE-178306-MS.[19] [19] Duan P， McElfresh P M. Shape memory polyurethane foam for downhole sand control filtration devices：
7926565 ［P］.2011-04-19 .[20] [20] 李敏，黎厚斌.形状记忆材料研究综述［J］.包装学报，2014，6（4）：17-23.
LI Min， LI Houbin. Research review of shape memory materials［J］. Packaging Journal， 2014，6（4）：17-23.
[21] [21] 赵丽娟，龚占魁，李亚玲，等.形状记忆高分子材料的研究［J］.山东化工，2019，48（23）：141.ZHAO Lijuan， GONG Zhankui， LI Yaling， et al. Study of shape memory polymers［J］. Shandong Chemical Industry， 2019，48（23）：141.
[22] [22] 段 P，莫塞尔弗雷施P M.用于井下防砂过滤装置的形状记忆聚氨酯泡沫：
CN102224321A ［P］.2011 .10 .19 .DUAN P， MOSELFRESCH P M. Shape memory polyurethane foam for downhole sand control and filtration device：CN102224321A ［P］.2011 .10 .19 .[23] [23] HUGHES B，李世毅，唐山.形状记忆材料成就贝克休斯防砂系统［J］.石油知识，2016（2）：43.HUGHES B， LI Shiyi， TANG Shan. Shape memory materials make Baker Hughes sand control System［J］. Petroleum Knowledge， 2016（2）：43..
[24] [24] 孔德涛，宋吉明，阎兴涛，等.形状记忆聚合物在防砂中的应用［J］.石油化工应用，2022，41（11）：44-48.
KONG Detao， SONG Jiming， YAN Xingtao， et al. Application of shape memory polymer in sand control［J］. Petrochemical Industry Application， 2022，41（11）：44-48.
[25] [25] 邓福成，邓金根.组合膨胀筛管：
CN110295868A ［P］.2019 .10 .01 .DENG Fucheng， DENG Jingen. Combined expansion screen：CN110295868A ［P］.2019 .10 .01 .[26] [26] 张耕培，刘音，王红科，等.一种免填充可膨胀筛管：
CN205577959U ［P］.2016 .09 .14 .ZHANG Gengpei， LIU Yin， WANG Hongke， et al. A kind of non-filling expandable screen：CN205577959U ［P］.2016 .09 .14 .[27] [27] 段友智，艾爽，刘欢乐，等.形状记忆筛管自充填防砂完井技术［J］.石油钻探技术，2019，47（5）：86-90.
DUAN Youzhi， AI Shuang， LIU Huanle， et al. Shape memory screen self-packing sand control completion technology［J］. Petroleum Drilling Techniques， 2019，47（5）：86-90.
[28] [28] 李帅，张均，张成彬，等.聚氨酯多孔材料制备方法研究进展［J］.化学推进剂与高分子材料，2018，16（1）：34-39.LI Shuai， ZHANG Jun， ZHANG Chengbin， et al. Research progress in preparation methods of polyurethane porous materials［J］. Chemical Propellant & Polymer Materials， 2018，16（1）：34-39..
[29] [29] 房松.形状记忆聚氨酯泡沫研制及其在石油工程中应用［D］.北京：北京化工大学， 2016.FANG Song. Development of shape memory polyurethane foam and its application in petroleum engineering［D］. Beijing： Beijing University of Chemical Technology， 2016.
[30] [30] 段友智，刘欢乐，刘锦春.天然气水合物井完井用形状记忆材料研制［J］.西南石油大学学报（自然科学版），2022，44（4）：139-144.DUAN Youzhi， LIU Huanle， LIU Jinchun. A study on shape memory material for gas hydrate well completion［J］. Journal of Southwest Petroleum University（Science & Technology Edition）， 2022，44（4）：139-144..
[31] [31] Li J F， Ye J L， Qin X W， et al. The first offshore natural gas hydrate production test in South China Sea［J］. China Geology， 2018，1（1）：5-16.
[32] [32] Pang J， Tao Y， Freiberg S， et al. Syntheses， structures， and electroluminescence of new blue luminescent star-shaped compounds based on 1，3，5-triazine and 1，3，5-trisubstituted benzene［J］. Journal of Materials Chemistry， 2002，12（2）：206-212.
[33] [33] Liu P， Tong Z. A novel greenish blue-emitting amorphous molecular material： 2，5-Bis ｛4-［2-naphthyl （phenyl） amino ］ phenyl｝ thiophene［J］. Chinese Journal of Chemistry， 2001，19（10）：979-982.
[34] [34] Ko C W， Tao Y T. 9，9-bis｛4-［di-（p-biphenyl）aminophenyl］｝fluorene： A high Tg and efficient hole-transporting material for electroluminescent devices［J］. Synthetic Metals， 2002，126（1）：37-41.
-
