Design of a near-bit downhole measurement system wlile drilling for wireline coring
-
摘要: 传统的随钻测量方法应用于取心钻探时，受限于岩心管对泥浆脉冲传输通道的堵塞，随钻仪器安装于取心钻具后方，导致测量仪器与钻头之间存在较大距离，造成测量的轨迹及工况数据存在滞后性，影响钻探工艺及轨迹的精确控制。针对此问题，提出了适用于绳索取心的近钻头随钻测量系统，利用近钻头发射端实时采集工况及轨迹数据，采集到的数据经甚低频电磁波发送到与取心钻具内管总成相连接的接收端进行存储，待取心完毕打捞岩心管时将仪器提出进行数据读取。介绍了系统的整体方案及电路设计，开展了系统短传功能的室内验证试验，试验结果表明系统可在井下进行跨取心钻具的近钻头信息传输，且无线短传距离可达8 m。研究成果可为近钻头随钻测量系统的相关研究提供借鉴。Abstract: When applied to core drilling, the traditional measurement methods while drilling are limited by the blockage of the mud pulse transmission channel by the core barrel. The measurement instrument are installed behind the core drilling assembly, resulting in a large distance between the instrument and the bit, which leads to significant lag in trajectory and operating condition data, and thereforea affects the precise control of drilling process and trajectory. A near-bit measurement system while drilling for wireline coring is proposed to address this issue. The system utilizes a near-bit transmitting unit to collect operating conditions and trajectory data in real time. The collected data is transmitted via very low frequency electromagnetic waves to be stored in a receiving unit connected to the core drilling assembly’s inner tube. After core extraction, the instrument is lifted along with the core barrel for data retrieval. This paper introduces the system’s overall scheme and circuit design, moreover, experiments for short-range transmission function are carried out. The results demonstrate that the system can achieve near-bit information transmission across the core drilling assembly downhole, with a wireless transmission distance of up to 8m. These research findings can serve as a reference for researchers in the field of near-bit measurement system while drilling.
-
-
[1] 陈岳,张杰丰,董凯飞,等.大口径绳索取心钻探技术在煤层气参数井勘探中的应用[J].地质装备,2024,25(4):28-33.
CHEN Yue, ZHANG Jiefeng, DONG Kaifei, et al. Application of large-diameter wireline core drilling technology in the exploration of coalbed methane parameter well[J]. Equipment for Geotechnical Engineering, 2024,25(4):28-33.
[2] 韦海瑞,朱芝同,吴川,等.近钻头随钻测量系统及其小型化设计关键技术分析[J].钻探工程,2022,49(5):156-162.
WEI Hairui, ZHU Zhitong, WU Chuan, et al. Analysis on current status and key technology of miniaturization design of near-bit MWD systems[J]. Drilling Engineering, 2022,49(5):156-162.
[3] 何蕙岚,王久全,李秋玥,等.直连绳索取心钻杆分区热处理技术研究[J].钻探工程,2024,51(3):125-130.
HE Huilan, WANG Jiuquan, LI Qiuyue, et al. Research on zone heat treatment technology of straight-connected wire-line core drill pipe[J]. Drilling Engineering, 2024,51(3):125-130.
[4] 徐世毅,王胜,舒智宏,等.全地层自适应绳索取心钻具割心机构优化[J].钻探工程,2023,50(S1):392-398.
XU Shiyi, WANG Sheng, SHU Zhihong, et al. Optimization of core cutting mechanism of all-strata self-adaptive wire-line core drilling tool[J]. Drilling Engineering, 2023,50(S1):392-398.
[5] 王红.复杂地层煤炭资源勘查绳索取心钻探技术应用与绿色勘查实践研究[J].西部探矿工程,2023,35(9):37-41.
WANG Hong. Rope coring drilling technology for coal resources exploration in complex strata[J]. West-China Exploration Engineering, 2023,35(9):37-41.
[6] 武治强,幸雪松,庞照宇,等.超深井长裸眼段岩屑运移规律及特征分析[J].科学技术与工程,2023,23(11):4596-4606.
WU Zhiqiang, XING Xuesong, PANG Zhaoyu, et al. Analysis of cuttings transport law and characteristics in long open hole section of ultra-deep well[J]. Science Technology and Engineering, 2023,23(11):4596-4606.
[7] 王居贺,孙伟光,于东兵.超深井连续管短半径侧钻工艺研究与现场试验[J].石油机械,2023,51(1):33-39.
WANG Juhe, SUN Weiguang, YU Dongbing. Research and field testing of CT Short-Radius sidetracking technology for ultra-deep wells[J]. China Petroleum Machinery, 2023,51(1):33-39.
[8] 宋山,赵小勇,付华才,等.随钻测井数据有损压缩算法改进探讨与应用[J].钻采工艺,2023,46(6):170-176.
SONG Shan, ZHAO Xiaoyong, FU Huacai, et al. Improvement and application of lossy compression algorithm for LWD data[J].Drilling & Production Technology, 2023,46(6):170-176.
[9] 胡中志,王佩赛.套管-钻杆窄间隙环形空间电磁波传输特性[J].天然气工业,2024,44(8):114-124.
HU Zhongzhi, WANG Peisai. Electromagnetic wave transmission characteristics in narrow casing-drill pipe annulus[J]. Natural Gas Industry, 2024,44(8):114-124.
[10] 刘振新,孙宏晶,杨怀俊,等.电磁波随钻测量系统在兰陵铁矿钻探工程中的应用[J].地质装备,2024,25(S1):168-175.
LIU Zhenxin, SUN Hongjing, YANG Huaijun, et al. Application of electromagnetic measurement while drilling system in the drilling project of Lanling Iron ore mine[J]. Equipment for Geotechnical Engineering, 2024,25(S1):168-175.
[11] 曲汉武,尚捷,卢华涛,等.摆动阀式泥浆脉冲器电机输出特性及影响因素分析[J].煤田地质与勘探,2023,51(9):180-188.
QU Hanwu, SHANG Jie, LU Huatao, et al. Analysis on motor output characteristics and influencing factors of oscillating valve mud pulser[J]. Coal Geology & Exploration, 2023,51(9):180-188.
[12] 张柏林,姬港,朱宇轩,等.基于深度学习的半监督信号调制样式识别算法[J].电子科技大学学报,2024,53(4):511-518.
ZHANG Bailin, JI Gang, ZHU Yuxuan, et al. A Semi-supervised signal modulation mode recognition algorithm based on deep learning[J]. Journal of University of Electronic Science and Technology of China, 2024,53(4):511-518.
[13] 张夏瑜,张佳浩,焦杰,等.面向新型声波激励超低频天线的2FSK通信系统解调算法[J].水下无人系统学报,2024,32(4):621-627.
ZHANG Xiayu, ZHANG Jiahao, JIAO Jie, et al. 2FSK communication system demodulation algorithm for novel acoustically excited SLF antennas[J]. Journal of Unmanned Undersea Systems, 2024,32(4):621-627.
[14] 令璐璐,王辅忠,信雅芯,等.Levy 噪声驱动下基于三稳态随机共振理论降低2FSK 信号误码率的研究[J].应用力学学报,2021,38(6):2224-2229.
LING Lulu, WANG Fuzhong, XIN Yaxin, et al. Reduction of bit error rate of 2FSK signal driven by Levy noise based on tristable stochastic resonance theory[J]. Chinese Journal of Applied Mechanics, 2021,38(6):2224-2229.
[15] 田鸿昌,朱权喆,郑国栋.基于频移键控的无线电能与数据共同传输方法[J].电子技术应用,2023,49(5):115-118.
TIAN Hongchang, ZHU Quanzhe, ZHENG Guodong. Wireless power and data transfer method based on frequency shift keying[J].Application of Electronic Technique, 2023,49(5):115-118.
[16] 王柏森,卢艳军,张晓东,等.基于巴特沃斯低通滤波的自适应步长梯度下降姿态解算方法[J].探测与控制学报,2023,45(3):116-120,125.
WANG Baisen, LU Yanjun, ZHANG Xiaodong, et al. Adaptive step gradient descent attitude algorithm of LPB[J]. Journal of Detection & Control, 2023,45(3):116-120,125.
-
