Application of Audio Magnetotelluric Sounding in Deep Geothermal Structure Exploration
-
摘要:
为探测江苏泗洪县柳山湖景区的深部地热构造，搜集已有的地质地球物理资料和已知勘探钻孔资料，布置了14条音频大地电磁测深（AMT）测线，通过资料采集、预处理、反演，得到了研究区2 000 m以浅地质体电阻率空间分布情况。勘探结果表明：研究区存在较好的低阻分布带，且连续性好，推测发育两条深部构造断裂带f1和f2，其中f2断裂带规模较大，破碎带中含水，而断裂带上部为完整-较完整的高阻层，可能是良好的盖层。因此，推测深部断裂破碎带f2可能是良好的含水和储水通道，建议在构造带低阻异常中心位置重点研究，为下一步钻孔布设提供依据。
-
关键词:
- 音频大地电磁测深法(AMT) /
- 地热勘查 /
- 郯庐断裂带 /
- 深部构造 /
- 柳山湖
Abstract:In order to investigate the deep geothermal structure in Liushan Lake Scenic Area, Sihong County, Jiangsu Province, geological and geophysical data and known exploration borehole data were collected, 14 Audio Magnetotelluric Sounding (AMT) survey lines were laid, and the resistivity distribution of the shallow geological body at 2000 m in the study area was obtained through data acquisition, pre-processing and inversion. The exploration results show that there was a good low resistance distribution zone in the study area with good continuity, and two deep structural fault f1 and f2 are inferred. Among them, fault f2 is presumed to be large in scale and contains water in the fracture zone, while the upper part of the fracture zone is a complete-more complete high-resistance layer, which may be a good cover layer. Therefore, it is speculated that the deep fracture zone f2 has good water-bearing and storage channels, and it is suggested to focus on the location of the low resistance anomaly in the tectonic zone to provide a basis for the next drilling placement.
-
-
图 1 区域地质构造图（江苏省地质矿产局，1984）
Figure 1.
表 1 AMT测线技术参数
Table 1. Main technique parame of AMT line
测线 有效点 测线长度（m） 备注 C1 73 3900 N30°E C1JM1 22 1100 C1加密线距200 m C1JM2 61 3100 C1加密线距200 m C1JM3 25 1200 C1加密线距400 m C1JM4 25 1200 C1加密线距600 m C2 61 3200 N60°W C2JM1 20 950 C2加密线距600 m FQC1-1 25 1200 房屋拆迁区 FQC1-2 25 1150 FQC2 25 1145 SYC1 4 120 砂岩出露区 SYC2 20 1035 ZKC1 10 440 钻孔验证区 ZKC2 10 450 总计 406 20190
下载: 导出CSV
-
[1] 洪连明. 江苏东海县黑龙潭水库地区地热地质特征与地热远景评价研究[J]. 西部资源, 2017(4): 112-113 doi: 10.3969/j.issn.1672-562X.2017.04.047
HONG Lianming. Study on geothermal geological characteristics and geothermal prospect evaluation in Heilongtan reservoir area, Donghai County, Jiangsu [J]. Western resources, 2017 (4): 112-113. doi: 10.3969/j.issn.1672-562X.2017.04.047
[2] 洪连明. 江苏泗洪县柳山铜矿矿区地球物理特征与找矿潜力分析[J]. 世界有色金属, 2017(13): 141-142
HONG Lianming. Geophysical characteristics and prospecting potential analysis of Liushan copper mine in Sihong County, Jiangsu Province [J]. World nonferrous metals, 2017 (13): 141-142.
[3] 何帅, 张德全, 张德实, 等. 音频大地电磁法对隐伏储热构造的识别与应用—以贵州省石阡县地热靶区勘查为例[J]. 工程地球物理学报, 2018, 15(2): 153-158
HE Shuai, ZHANG Dequan, ZHANG Deshi, et al. The application of AMT to concealed reservoir structure—Taken the eothermalexploration area of Shiqian county in Guizhou province [J]. Chinese Journal of Engineering Greophysics. 2018, 15(2): 153-158.
[4] 黄太岭, 高建国. 山东省区域地球物理场[J]. 山东地质, 2002, 18(4): 88-94
HUANG tailing, GAO Jianguo. Regional geophysical field of Shandong Province [J]. Shandong geology, 2002, 18 (4): 88-94.
[5] 韩姚飞, 孙远彬, 朱大伟, 等. 音频大地电磁法和氡气测量在金沙县某地热调查中的应用[J]. 煤炭技术, 2021, 40(1): 46-49
HAN Yaofei, SUN Yuanbin, ZHU Dawei, et al. Application of audio magnetotelluric method and radon measurement in a geothermal survey in jinsha county [J]. Coal Technology, 2021, 40(1): 46-49.
[6] 江苏省地质矿产局. 江苏省及上海市区域地质志[M]. 北京: 地质出版社, 1984.
Jiangsu Geology&Mineral Exploration Bureau. Regional geology of Jiangsu Province and Shanghai [M]. Beijing: Geological Publishing House, 1984.
[7] 刘垒. 音频大地电磁测深在地热勘查中的应用研究[D]. 成都: 成都理工大学, 2014
LIU Lei. Application of audio magnetotelluric sounding in geothermal exploration [D]. Chengdu: Chengdu University of technology, 2014.
[8] 李学云, 刘百红. 音频大地电磁法在汝城县暖水镇地热调查中的应用研究[J]. 工程地球物理学报, 2017, 14(6): 725-731
LI Xueyun, Liu Baihong. Application of Audio-frequency Magnetotelluric Method to Geothermal Exploration in Nuanshui Town of Rucheng County[J]. Chinese Journal of Engineering Geophysics, 2017, 14(6): 725-731.
[9] 李占奎. 1: 20万江苏中部地区高精度航空磁测成果报告[R]. 北京: 地矿部航空物探总队航空物探遥感中心成果部, 1987.
[10] 裴发根, 方慧, 仇根根, 等. 青海哈拉湖东南缘多年冻土厚度及其影响因素研究—基于音频大地电磁探测[J]. 物探与化探, 2017, 41(6): 1175-1182
PEI Fagen, FANG Hui, QIU Gengen, et al. A study of the permafrost thickness and its influence factors based on AMT detection technologyon the southeastern margin of Hala Lake, Qinghai Province[J]. Geophysical and Geochemical Exploration, 2017, 41(6): 1175-1182.
[11] 孙彬, 谷天峰, 孔嘉旭, 等. 非饱和黄土电阻率和含水率间关系试验研究[J]. 西北地质, 2020(4): 216-222
SUN Bin, GU Tianfeng, KONG Jiaxu, et al. Experimental Research on Relationship between Resistivity andMoisture Content of Unsaturated Loess[J]. Northwestern Geology, 2020, 53(4): 216-222.
[12] 袁淑芝. 1: 20宿迁幅区域重力图编图说明书[R]. 南京: 江苏省地质矿产局物化探大队, 1988.
[13] 袁星芳, 邢立亭, 贾群龙, 等. 威海市七里汤地热田特征及其成因机制[J]. 西北地质, 2023, 56(6): 209−218.
YUAN Xingfang, XING Liting, JIA Qunlong, et al. Characteristics and Genetic Mechanism of Qilitang Geothermal Field in Weihai[J]. Northwestern Geology, 2023, 56(6): 209−218.
[14] 王陆超. 江苏泗洪县柳山地区热液铜矿化地质特征与找矿[J]. 四川地质学报, 2019, 39(1): 65-67
WANG Luchao. Geological Features and Prospecting potential for Hydrothermal Cu Mineralization in the Liushan area, Sihong, Jiangsu[J]. Sichuan Journal of geology, 2019, 39(1): 65-67.
[15] 王家映. 大地电磁法在地热调查中的应用[J]. 国外地质勘探技术, 1981(06): 14-24
WANG Jiaying. Application of magnetotelluric method in geothermal survey [J]. Foreign Geological Exploration Technology, 1981(06): 14-24.
[16] 王连芳, 牛美琴, 孙庆茹. 江苏省泗洪县地区地热资源勘查方法有效性分析探讨[J]. 西部资源, 2013(1): 92-95
WANG Lianfang, Niu Meiqin, Sun Qingru. Exploration on the effectiveness analysis of geothermal resource exploration methods in Sihong County area of Jiangsu Province[J]. Western Resources, 2013(1): 92-95.
[17] 薛怀友, 徐祖阳, 张芳, 等. 江苏泗洪重岗垃圾填埋场选址的地质调查和建议[J]. 地质学刊, 2011, 35(2): 191-195 doi: 10.3969/j.issn.1674-3636.2011.02.191
XUE Huaiyou, XU Zuyang, ZHANG Fang, et al. Geological investigation and proposals on Chonggang solid waste landfill site selection in Sihong County of Jiangsu Province[J]. Journal of geology, 2011, 35 (2): 191-195. doi: 10.3969/j.issn.1674-3636.2011.02.191
[18] 严小丽, 康慧敏, 王光杰, 等. AMT方法在鳌山卫花岗岩地区深部地热构造勘探中的应用[J]. 地球物理学进展, 2019, 34(5): 1945-1953 doi: 10.6038/pg2019CC0083
YAN Xiaoli, KANG Huimin, WANG Guangjie, et al. Application of AMT in deep geothermal structure exploration in Aoshanwei granitearea of Qingdao[J]. Progress in Geophysics, 2019, 34(5): 1945-1953. doi: 10.6038/pg2019CC0083
[19] 严小丽. 鳌山卫花岗岩地区深部地热构造电磁法探测研究[D]. 北京: 中国科学院大学, 2018
YAN Xiaoli. Electromagnetic exploration of deep geothermal structure in aoshanwei granite area[D]. Beijing: University of Chinese Academy of Sciences, 2018.
[20] 余年, 庞方. 音频大地电磁测深法在地热勘查中的应用研究[J]. 水文地质工程地质, 2010, 37(3): 135-138
YU Nian, PANG Fang. Application of audio magnetotelluric sounding in the geothermal exploration[J]. Hydrogeology & Enginneering Geology, 2010, 37(3): 135-138.
[21] 杨学明, 雷清, 聂冀强, 等. 太行拱断束地热资源调查评价-基于大地电磁测深结果的分析[J]. 西北地质, 2020, 53(4): 235-245
YANG Xueming, LEI Qing, NIE Jiqiang, et al. Investigation and Evaluation of Geothermal Resources of Taihang Arch Fault Cluster Based on the Magnetotelluric Exploration[J]. Northwestern Geology, 2020, 53(4): 235-245.
[22] 邹鹏飞, 邱杨, 姚文江, 等. 宿迁城市规划区浅层地热能资源调查与评价[J]. 城市地质, 2020, 15(4): 421-431
ZOU Pengfei, QIU Yang, YAO Wenjiang, et al. Investigation and evaluation of shallow geothermal energy resources in Suqian urbanplanning area [J]. Urban geology, 2020, 15 (4): 421-431.
[23] 祖金华, 吴乾蕃, 廉雨方. 郯庐断裂带中段及邻区的地热研究[J]. 中国地震, 1996, 12(1): 43-48
ZU Jinhua, WU Qianfan, LIAN Yufang. The geothermal study of the mid-segment of the Tancheng-Lujiang fault zone and its neighboringregion[J]. Earthquake Research in China, 1996, 12(1): 43-48.
-
