Volcanic Stratigraphic Sequence, Age and Comparison with Mountain Layer Type Profile of Bai 72 Well in Xinjiang Oilfield
-
摘要:
井中地层层序的建立和时代确定，是岩石地层单位划分与对比的关键证据，对油气藏的勘探开发具有重要意义。针对新疆百口泉油田百72井主要地层缺乏时代依据，前人所划佳木河组与山区原佳木河组层型（建组）剖面岩石组合不可对比这一关键问题，笔者重新进行了岩心编录和配套样品分析测试，获得了高精度锆石U−Pb测年成果，并结合测井资料，确立百72井1 182～2 937 m井段层序、时代。研究结果表明：该井段下部以火山熔岩为主、上部以火山碎屑岩为主，间夹多层火山喷发间隙期的陆源碎屑沉积薄层。以陆源碎屑沉积薄层为分段标志，该井段可划分为6个岩性段。在第三岩段杏仁状玄武岩、第五岩段安山质角砾熔岩中分别获得（304.3±3.9）Ma、（306.6±5.1 ）Ma的LA−ICP−MS锆石U−Pb年龄，指示地层时代为晚石炭世。该岩石组合、层序及时代与百72井之北山区哈拉阿拉特组建组剖面总体可对比，故将前人对其划分二叠纪佳木河组修订为晚石炭世哈拉阿拉特组，这一成果为井中（“盆”）−北缘山区（“山”）地层对比提供了一个范例。
Abstract:Establishment of stratigraphic sequence and determination of age in the well is the key evidence for the delineation and comparison of rock stratigraphic units. This is of great significance to the exploration and development of oil and gas reservoirs. In response to the key problem that the main stratigraphy of the Baikouquan oilfield Bai 72 well, in Xinjiang, lacks a chronological basis and the rock assemblage of the formerly delineated Jiamuhe Formation and the original Jiamuhe Formation in the mountainous area is not comparable, we have reconducted core compilation and supporting sample analysis and testing, established the stratigraphic sequence in the well, obtained high−precision zircon U−Pb dating results, and combined with the logging data to establish the sequence and age of the 1 182～2 937 m well section of the Bai 72 well.The results show that:The well section is dominated by volcanic lava in the lower part and volcanic clastic rocks in the upper part, interspersed with multiple layers of land−derived clastic sedimentary thin layers during the interval of volcanic eruption. The well section can be divided into six lithologic sections using the thin layers of terrestrial clastic sediments as segmentation markers. The LA−ICP−MS zircon U−Pb age of (304.3±3.9) Ma and (306.6±5.1) Ma were obtained in the almond shaped basalt of the third rock section and the ambersite breccia lava of the fifth rock section, respectively, indicating that the stratigraphic age was Late Carboniferous. The rock assemblage, stratigraphy and age are generally comparable with the Hala’alate Formation section in the northern mountainous region of the Bai 72 well, so it is revised that the Permian Jiamuhe Formation belonged to the Late Carboniferous Hala’alate Formation, providing good example of a stratigraphic comparison between the well ("basin")−northern margin mountainous in the Baikouquan oilfield.
-
-
表 1 百72井下LA–ICP–MS锆石U–Pb同位素分析结果
Table 1. Results of LA–ICP–MS zircon U–Pb isotope analysis of Bai 72 well
样号 同位素比值 同位素年龄 206Pb
（10−6）232Th
（10−6）238U
（10−6）Th/U 207Pb/206Pb 207Pb/235U 206Pb/238U 207Pb/206Pb 207Pb/235U 206Pb/238U 比值 σ 比值 σ 比值 σ 年龄 σ 年龄 σ 年龄 σ B72-5-6TW01 0.05167 0.00146 0.34544 0.00863 0.04853 0.00084 271 28 301 7 305 5 106.09 123.98 188.47 0.66 B72-5-6TW02 0.05317 0.00197 0.35361 0.01197 0.04828 0.00091 336 44 307 9 304 6 33.6 25.64 59.95 0.43 B72-5-6TW03 0.05296 0.00233 0.34625 0.01409 0.04746 0.00097 327 56 302 11 299 6 102.81 128.31 186.39 0.69 B72-5-6TW04 0.05268 0.00137 0.35386 0.00801 0.04876 0.00082 315 24 308 6 307 5 128.59 185.81 226.78 0.82 B72-5-6TW05 0.05228 0.0016 0.35399 0.00966 0.04914 0.00087 298 32 308 7 309 5 182.72 184.2 319.29 0.58 B72-5-6TW06 0.05184 0.00172 0.34659 0.01038 0.04853 0.00086 278 37 302 8 305 5 39.43 42.35 69.68 0.61 B72-5-6TW07 0.05238 0.00182 0.34864 0.01097 0.04831 0.00088 302 40 304 8 304 5 60.84 63.18 107.4 0.59 B72-5-6TW08 0.05324 0.0016 0.35475 0.00943 0.04836 0.00084 339 31 308 7 304 5 123.17 169.48 216.35 0.78 B72-5-6TW09 0.05306 0.00142 0.35504 0.00824 0.04856 0.00081 331 25 309 6 306 5 90.19 93.3 157.58 0.59 B72-5-6TW10 0.05339 0.00173 0.35158 0.01021 0.04779 0.00085 345 35 306 8 301 5 152.78 257.7 269.71 0.96 B72-5-6TW11 0.05294 0.00147 0.35073 0.00852 0.04808 0.00081 326 27 305 6 303 5 106.35 117.67 186.37 0.63 B72-5-6TW12 0.05281 0.00273 0.34414 0.01663 0.04729 0.00103 321 70 300 13 298 6 37.42 29.92 66.55 0.45 B72-5-6TW13 0.05315 0.00143 0.35147 0.00814 0.04798 0.0008 335 25 306 6 302 5 221.29 379.14 386.14 0.98 B72-5-6TW14 0.05265 0.00207 0.35561 0.01278 0.04901 0.00093 314 48 309 10 308 6 33.86 23.63 57.82 0.41 B72-5-6TW15 0.05311 0.0015 0.35449 0.00874 0.04843 0.00081 333 28 308 7 305 5 124.44 155.98 214.73 0.73 B72-5-6TW16 0.0529 0.00122 0.35562 0.00678 0.04878 0.00078 325 19 309 5 307 5 239.32 184.24 409.78 0.45 B72-9-9TW01 0.05307 0.00134 0.35125 0.00741 0.04801 0.00077 332 22 306 6 302 5 89.86 220.71 472.05 0.47 B72-9-9TW02 0.0518 0.00143 0.34777 0.00825 0.0487 0.0008 277 27 303 6 307 5 61.12 198.61 316.47 0.63 B72-9-9TW03 0.05212 0.00145 0.35132 0.00843 0.04889 0.0008 291 27 306 6 308 5 58.21 184.94 299.93 0.62 B72-9-9TW04 0.05233 0.00219 0.35639 0.01386 0.04939 0.00091 300 55 310 10 311 6 36.3 82.49 184.9 0.45 B72-9-9TW05 0.05195 0.00195 0.35036 0.01208 0.04891 0.00087 283 47 305 9 308 5 65.38 169.33 335.64 0.5 B72-9-9TW06 0.05186 0.00133 0.34699 0.00753 0.04852 0.00079 279 23 302 6 305 5 90.18 227.56 466.48 0.49 B72-9-9TW07 0.05283 0.00145 0.35486 0.00837 0.04871 0.00081 322 26 308 6 307 5 191.73 352.05 987.85 0.36 B72-9-9TW08 0.05272 0.0012 0.35254 0.00653 0.04849 0.00077 317 19 307 5 305 5 160.04 278.04 827.82 0.34 B72-9-9TW09 0.05201 0.00128 0.35057 0.00722 0.04888 0.00079 286 22 305 5 308 5 53.48 140.74 274.1 0.51
下载: 导出CSV
-
[1] 陈江新, 徐倩, 李永军, 等. 车排子地区车47井石炭系划分及对比[J]. 新疆石油地质, 2022, 43(04): 410-416
CHEN Jiangxin, XU Qian, LI Yongjun, et al. Stratigraphic Division and Correlation of Carboniferous Strata in Well Che 47 in Chepaizi Area[J]. Xinjiang Petroleum Geology, 2022, 43(04): 410-416.
[2] 段丰浩. 西准噶尔达尔布特构造—岩浆带岩浆与成矿作用探讨[D]. 西安: 长安大学, 2016
DUAN Fenghao. The study on metallogenism and magmatism of the Darbut tectono-magmatic belt, Western Junggar[D]. Xi’an: Chang’an University, 2016.
[3] 何登发, 陈新发, 况军, 等. 准噶尔盆地石炭系油气成藏组合特征及勘探前景[J]. 石油学报, 2010, 31(01): 1-11 doi: 10.7623/syxb201001001
HE Dengfa, LU Xinfa, KUANG Jun, et al. Characteristics and exploration potential of Carboniferous hydrocarbon plays in Junggar Basin[J]. Acta Petrolei Sinica, 2010, 31(01): 1-11. doi: 10.7623/syxb201001001
[4] 胡雪冰. 车排子地区石炭系火山岩岩性识别及岩电模式研究[D]. 东营: 中国石油大学(华东), 2016
HU Xuebing. Study on the Identification and Lithology Well Logging Models of Carboniferous Volcanic Rocks in Chepaizi Area [D]. Dongying: China University of Petroleum (East China), 2016.
[5] 靳军, 王剑, 杨召等. 准噶尔盆地克-百断裂带石炭系内幕储层测井岩性识别[J]. 岩性油气藏, 2018, 30(2): 85–92
JIN Jun, WANG Jian, YANG Zhao et al. Well logging identification of Carboniferous volcanic inner buried-hill reservoirs in Ke-Bai fault zone in Junggar Basin[J]. Lithologic Reservoirs, 2018, 30(2): 85–92.
[6] 李甘雨, 李永军, 王冉, 等. 西准噶尔哈拉阿拉特组火山岩LA-ICP-MS锆石U-Pb年龄[J]. 西北地质, 2015, 48(03): 12-21 doi: 10.3969/j.issn.1009-6248.2015.03.002
LI Ganyu, LI Yongjun, WANG Ran, et al. Zircon LA- ICP- MS U- Pb Dating of Volcanics in Hala alate Formation of Western Junggar[J]. Northwestern Geology, 2015, 48(03): 12-21. doi: 10.3969/j.issn.1009-6248.2015.03.002
[7] 李甘雨, 李永军, 向坤鹏, 等. 西准噶尔哈拉阿拉特组的重新厘定及区域对比[J]. 地层学杂志, 2016, 40(01): 76-84
LI Ganyu, LI Yongjun, XIANG Kunpeng, et al. Revision and Regional Correlation of the Hala’alate Formation in Western Junggar Basin[J]. Journal of Stratigraphy, 2016, 40(01): 76-84.
[8] 李书领. 西准噶尔泥盆纪—石炭纪地层分区及典型剖面对比研究[D]. 西安: 长安大学, 2018
LI Shuling. A study on Devonian-Carboniferous stratigraphic division and stratotype section comparison in Western Junggar[D]. Xi’an: Chang’an University, 2018.
[9] 李永军, 李卫东, 杨高学, 等. 新疆东西准噶尔泥盆系-石炭系建组剖面及区域对比[M]. 北京: 地质出版社, 2021: 163-291
LI Yongjun, LI Weidong, YANG Gaoxue, et al. Devonian-Carboniferous Stratotype Sections and Regional Correlation in Eastern and Western Junggar, Xinjiang[M]. Beijing: Geological Publishing House, 2021: 163–291.
[10] 李永军, 佟丽莉, 张兵, 等. 论西准噶尔石炭系希贝库拉斯组与包古图组的新老关系[J]. 新疆地质, 2010, 28(02): 130-136 doi: 10.3969/j.issn.1000-8845.2010.02.003
LI Yongjun, TONG Lili, ZHANG Bin, et al. On the old and new relationship between Xibeikulasi Formation andA Baogutu Formation of the carboniferous system, west jaggar[J]. Xinjiang Geology, 2010, 28(02): 130-136. doi: 10.3969/j.issn.1000-8845.2010.02.003
[11] 李永军, 徐倩, 刘佳, 等. 新疆西准噶尔哈山地区佳木河组的重新厘定及地质意义[J]. 地球科学, 2016, 41(09): 1479-1488
LI Yongjun, XU Qian, LIU Jia, et al. Redefinition and Geological Significance of Jiamuhe Formation in Hala’alate Mountain of West Junggar, Xinjiang[J]. Earth Science, 2016, 41(09): 1479-1488.
[12] 宁文涛. 新疆东、西准噶尔下石炭统典型剖面对比研究[D]. 西安: 长安大学, 2019
NING Wentao. The Comparative Study of Standard Stratotype Section in Lower Carboniferous at East and West of Junggar, Xinjiang[D]. Xi’an: Chang’an University, 2019.
[13] 潘建国, 郝芳, 谭开俊, 等. 准噶尔盆地红车断裂带古生界火山岩油气藏特征及成藏规律[J]. 岩性油气藏, 2007, 19(2): 53–56 doi: 10.3969/j.issn.1673-8926.2007.02.010
PAN Jianguo, HAO Fang, TANKaijun, et al. Characteristics and accumulation of Paleozoic volcanic rock reservoirs in Hongche fault belt, Junggar Basin[J]. Lithologic Reservoirs, 2007, 19(2): 53–56. doi: 10.3969/j.issn.1673-8926.2007.02.010
[14] 覃建华, 李永军, 王盼龙, 等. 西准噶尔乌尔禾地区哈拉阿拉特组火山碎屑复理石的发现及地质意义[J]. 西北地质, 2022, 55(03): 274-285 doi: 10.19751/j.cnki.61-1149/p.2022.03.022
QIN Jianhua, LI Yongjun, WANG Panlong, et al. The Discovery and Geological Significance of Pyroclastic Flysch of Hala’alate Formation in Urho Area of West J unggar[J]. Northwestern Geology, 2022, 55(03): 274-285. doi: 10.19751/j.cnki.61-1149/p.2022.03.022
[15] 王辉, 邱争科, 周庆, 等. 克拉玛依油田六区、七区、九区石炭系火山岩内幕成藏规律研究[J]. 特种油气藏, 2019, 26(04): 33-37+153 doi: 10.3969/j.issn.1006-6535.2019.04.006
WANG Hui, QIU Zhenke, ZHOU Qing, et al. Carboniferous Volcanic Inside Hydrocarbon Accumulation Patterns in the 6th, 7th and 9th Districts of Karamay Oilfield [J]. Special Oil and Gas Reservoirs, 2019, 26(04): 33-37+153. doi: 10.3969/j.issn.1006-6535.2019.04.006
[16] 王韬, 徐倩, 李永军, 等. 车排子油田南部火山岩地质时代及成因[J]. 新疆石油地质, 2022, 43(02): 160-168
WANG Tao, XU Qian, LI Yongjun, et al. Geological Age and Petrogenesis of Volcanic Rocks in Southern Chepaizi Oilfield[J]. Xinjiang Petroleum Geology, 2022, 43(02): 160-168.
[17] 支倩. 新疆东、西准噶尔上石炭统典型剖面对比研究[D]. 西安: 长安大学, 2018
ZHI Qian. A comparative study on the upper Carboniferous standard stratotype-section profiles in the eastern and western Junggar, Xinjiang, NW China[D]. Xi’an: Chang’an University, 2018.
[18] 邹才能, 赵文智, 贾承造, 等. 中国沉积盆地火山岩油气藏形成与分布[J]. 石油勘探与开发, 2008, 35(3): 257-271 doi: 10.3321/j.issn:1000-0747.2008.03.001
ZOU Caineng, ZHAO Wenzhi, JIA Chengzao, et al. Formation and distribution of volcanic hydrocarbon reservoirs in sedimentary basins of China[J]. PETROL EUM EXPI OR ATION AND DEVELOPMENT, 2008, 35(3): 257-271. doi: 10.3321/j.issn:1000-0747.2008.03.001
[19] 张大权, 邹妞妞, 姜杨, 等. 火山岩岩性测井识别方法研究——以准噶尔盆地火山岩为例[J]. 岩性油气藏, 2015, 27(01): 108–114 doi: 10.3969/j.issn.1673-8926.2015.01.016
ZHANG Daquan, ZOU Niuniu, JIANG Yang, et al. Logging identification method of volcanic rock lithology: A case study from volcanic rock in Junggar Basin[J]. Lithologic Reservoirs, 2015, 27(01): 108–114. doi: 10.3969/j.issn.1673-8926.2015.01.016
[20] CHEN Zhonghong, WANG Xulong, ZHA Ming, et al. Characteristics and formation mechanisms of large volcanic rock oil reservoirs: A case study of the Carboniferous rocks in the Kebai fault zone of Junggar Basin, China[J]. AAPG Bulletin, 2016, 100(10): 1585–1617.
[21] Lewis W J. Occurrence of oil in igneous rocks of Cuba[J]. AAPG Bulletin, 1932, 16(8): 809-818.
[22] Ludwig K. R. Isoplot 3.00: A geochronological toolkit for Microsoft Excel[J]. Berkeley Geochronology Center Special Publication, 2003, 4: 1-70.
[23] Powers S, Cla G F. Nature and origin of occurrences of oil, gas, and bitumen in igneous and metamorphic rocks[J]. AAPG Bulletin, 1932, 16(8): 719-726.
[24] P. W. O. Hoskin, L. P. Black. Metamorphic zircon formation by solid‐state recrystallization of protolith igneous zircon[J]. Journal of metamorphic Geology, 2000, 18(4): 423-439. doi: 10.1046/j.1525-1314.2000.00266.x
[25] Shimamoto T, Inoue N, Sato K. Characterization of a Volcanic Formation Through Comprehensive Well Test Analyses[J]. Society of Petroleum Engineers, SPE(37413), 1997: 243-250.
[26] Sruoga P, Rubinstein N. Processes controlling porosity and permeability in volcanic reservoirs from the Austral and Neuquen basins, Argentina[J]. AAPG Bulletin, 2007, 91: 115-129. doi: 10.1306/08290605173
-
