Characteristics and Hydrocarbon Generation Potential for Source Rock of Carboniferous Shiqiantan Formation in Shiqiantan Depression, Eastern Junggar Basin
-
摘要:
石钱滩组烃源岩为准噶尔盆地石钱滩凹陷石炭系的主力生烃层位。在充分调研其空间展布的基础上，选取最新发现的双井子地质探槽剖面及石钱1井、石钱2井与钱1井进行系统的烃源岩总有机碳、热解、族组分组成、有机显微组分、镜质体反射率及饱和烃色质等有机地球化学分析测试。结果表明，石钱滩组烃源岩为一套典型的海湾泻湖相沉积，呈NW–SE向展布于石钱滩凹陷，局部地区厚度巨大，可达370 m，沉积厚度中心位于凹陷东南隅。富有机质层段主要集中在石钱滩组下部，次为上部。整体具有较高的有机质丰度，可达到好等级及以上，有机质类型以Ⅱ2-Ⅲ为主，且已进入到高成熟生气阶段。综合研究认为，石炭系石钱滩组烃源岩具有良好的生烃条件，能够为石钱滩凹陷提供充足的油气源。
Abstract:The source rock of Shiqiantan formation is a main hydrocarbon−generation bed of the carboniferous for Shiqiantan depression in Junggar basin. Based on the detailed investigation on spatial distribution of formation,the newly found Shuangjingzi geological trench section, Shiqian 1 well, Shiqian 2 well and Qian 1 well can be selected for systematic organic geochemistry analysis and testing of total organic carbon, pyrolysis, group composition, organic macerals, vitrinite reflectance, and chromatogram−mass spectrometry of saturated hydrocarbon for source rock samples, the results show that the source rock of the Shiqiantan formation is a set of typical bay lagoon deposits, which is mainly distributed in the Shiqiantan depressionin with northwest−southeast direction. Besides, the local thickness is huge, even up to 370 m. The center of sediment thickness is located in the southeastern corner. The organic rich strata are mainly concentrated in the lower part of formation, and the upper part comes second. The overall organic matter content is relatively high, and can reach the good grade or above, the main type of organic matter is II2-III, and has entered the high mature gas generation stage. It is concluded that the source rock of carboniferous Shiqiantan formation is characertized by good hydrocarbon generation condition and can provide sufficient resources for Shiqiantan depression.
-
Key words:
- Junggar basin /
- Shiqiantan formation /
- source rock /
- hyrocarbon−generation condition
-
-
表 1 泥岩有机质丰度评价标准统计表
Table 1. Evaluation criteria of organic matter content for mudstone
烃源岩等级 TOC（%） S1+S2（mg/g） “A”（%） 非烃源岩 ＜0.5 ＜2 0.05 一般烃源岩 0.5～1 2～6 0.05～0.1 好烃源岩 1～2 6～20 0.1～0.2 优质烃源岩 ≥2 ≥20 ≥0.2
下载: 导出CSV
表 2 烃源岩有机质成熟度评价标准统计表
Table 2. Evaluation criteria of organic matter maturity for source rock
演化阶段 Ro（%） Tmax（℃） 未成熟阶段 ＜0.5 ＜435 低成熟阶段 0.5～0.7 435～440 成熟阶段 0.7～1.3 440～455 高成熟阶段 1.3～2.0 455～490 过成熟阶段 ≥2.0 ≥490
下载: 导出CSV
表 3 双井子地质探槽剖面C2sh烃源岩镜检分类表
Table 3. Maceral analysis classification of C2sh source rock for geological trench section in Shuangjingzi area
段 样品编号 腐泥组（%） 壳质组（%） 镜质组（%） 惰性组（%） 有机质类型 石钱滩组上段 21SJZ-S41 0 14 80 6 III 石钱滩组下段 21SJZ-S33 0 62 35 3 II2 21SJZ-S30 0 72 26 2 II2 21SJZ-S23 0 61 35 4 II2 21SJZ-S36 0 54 42 4 III 21SJZ-S19 0 61 34 5 III 21SJZ-S13 0 35 59 6 III 21SJZ-S7 0 63 33 4 II2 21SJZ-S5 0 51 45 4 III
下载: 导出CSV
-
[1] 陈建平, 梁狄刚, 张水昌, 等. 中国古生界海相烃源岩生烃潜力评价标准与方法[J]. 地质学报, 2012, 86(7): 1132-1142
CHEN Jianping, LIANG Digang, ZAHNG Shuichang, et al. Evaluation Criterion and Methods of the Hydrocarbon Generation Potential for China′s Paleozoic Marine Source Rocks [J]. Acta Geologica Sinica, 2012, 86(7): 1132-1142.
[2] 陈践发, 卢进才, 石正勇, 等. 内蒙古西部额济纳旗及其邻区石炭系—二叠系烃源岩的发育特征和生烃潜力评价[J]. 地质通报, 2010, 29(2/3): 346-350
CHEN Jianfa, LU Jincai, SHI Zhengyong, et al. Development characteristics and hydrocarbon generating potential evolution of Permian-Carboniferous source rocks in Ejina Banner basin and its adjacent area, western Inner Mongolia, China [J]. Geological Bulletin of China, 2010, 29(2/3): 346-350.
[3] 顾超, 曹建康, 庄一鹏, 等. 鄂尔多斯盆地旬宜区块上古生界烃源岩地球化学特征[J]. 西北地质, 2020, 53(2): 263-269
GU Chao, CAO Jiankang, ZHUANG Yipeng, et al. Geochemical Characteristics of Upper Paleozoic Source Rocks in Xunyi Block, Ordos Basin [J]. Northwestern Geology, 2020, 53(2): 263-269.
[4] 何登发, 翟光明, 况军, 等. 准噶尔盆地古隆起的分布与基本特征[J]. 地质科学, 2005, 40(2): 248-261.
HE Dengfa, ZHAI Guangming, KUANG Jun, et al. Distribution and Tectonic Features of Paleo-uplifts in the Junggar Basin [J]. Chinese Journal of Geology, 2005, 40(2): 248-261, 304.
[5] 贺凯, 庞瑶, 何治亮, 等. 准东地区石炭系烃源岩评价及重要意义[J]. 西南石油大学学报(自然科学版), 2010, 32(6): 41-45
HE Kai, PANG Yao, HE Zhiliang, et al. The Evaluation and Significance of the Carboniferous Source Rocks in the East Junggar Area [J]. JOURNAL OF SOUTHWEST PETROLEUM UNIVERSITY ( SCIENCE & TECHNOLOGY EDITION), 2010, 32(6): 41-45.
[6] 贺凯. 准噶尔盆地东部石炭系火山岩油气成藏规律研究[D]. 北京: 中国地质大学(北京), 2009
HE Kai. Study on the reservoirs formation rule of volcanic rock of Carboniferous in the East of Junggar basin [D]. Beijing: China University of Geoscience (Beijing), 2009.
[7] 胡自龙, 卞保力, 刘海磊, 等. 准噶尔盆地大井地区天然气成因、来源与成藏过程[J]. 天然气地球科学, 2019, 30(6): 850-859
HU Zilong, BIAN Baoli, LIU Hailei, et al. Genetic types, origins and accumulation process of natural gases from Dajing area, Junggar Basin [J]. NATURAL GAS GEOSCIENCE, 2019, 30(6): 850-859.
[8] 马强, 梁辉, 付国斌, 等. 准东地区石油地质条件综合研究及突破方向选择[R]. 哈密: 吐哈油田勘探开发研究院, 2019.
[9] 孟元林, 肖丽华, 杨俊生, 等. 风化作用对西宁盆地野外露头有机质性质的影响及校正[J]. 地球化学, 1999, 28(1): 42-50
MENG Yuanlin, XIAO Lihua, YANG Junsheng, et al. Influences of weathering on organic matter of outcrop and correcting methods in Xining Basin [J]. GEOCHIMICA, 1999, 28(1): 42-50.
[10] 王圣柱, 王千军, 张关龙, 等. 准噶尔盆地石炭系烃源岩发育模式及地球化学特征[J]. 油气地质与采收率, 2020, 27(4): 13-25
WANG Shengzhu, WANG Qianjun, ZHANG Guanglong, et al. Development mode and geochemical characteristics of Carboniferous source rocks in Junggar Basin [J]. Petroleum Geology and Recovery Efficiency, 2020, 27(4): 13-25.
[11] 汪双清, 徐学敏. 银额盆地及其临区石炭—二叠系烃源岩关键测试技术研究[R]. 北京: 国家地质实验测试中心, 2014.
[12] 王万春, 徐永昌, Schidlowski M, 等. 不同沉积环境及成熟度干酪根的碳、氢同位素地球化学特征[J]. 沉积学报, 1997, 15(增刊): 133-137
WANG Wanchuan, XU Yongchang, SCHILOWSKI M, et al. The Geochemical Characteristics of Carbon and Hydrogen Isotopes of Kerogens of Various Maturity and Depositional Environments [J]. ACTA SEDIMENTOLOGICA SINICA, 1997, 15(S): 133-137.
[13] 魏建设, 姜亭, 王宝文, 等. 银额盆地居延海坳陷吉格达凹陷石炭系—二叠系烃源岩生物标志化合物特征及其意义[J]. 西北地质, 2020, 53(3): 273-283
WEI Jianshe, JIANG Ting, WANG Baowen, et al. The Biomarker Characteristics and Its Significance of the Carboniferous-Permian Source Rocks in Jigeda Sag of Juyanhai Depression in Yin'er Basin [J]. Northwestern Geology, 2020, 53(3): 273-283.
[14] 魏建设, 卢进才, 魏仙样, 等. 强烈风化作用对烃源岩评价指标的影响——以额济纳旗及邻区石炭系—二叠系为例[J]. 地质通报, 2012, 31(10): 1715-1723
WEI Jianshe, LU Jincai, WEI Xianyang, et al. The influence of intense weathering on the evaluation indexes of hydrocarbon source rocks: A case study of Carboniferous-Permian Strata of Ejin Banner and its neighboring areas [J]. Geological Bulletin of China, 2012, 31(10): 1715-1723.
[15] 徐银波, 姚树青, 罗晓玲, 等. 新疆三塘湖盆地石头梅地区芦草沟组油页岩测井响应特征及识别模型[J]. 地质通报, 2023, 42(11): 1808−1817.
XU Yinbo, YAO Shuqing, LUO Xiaoling, et al. Logging response characteristics and identification model of oil shale of Lucaogou Formation in Shitoumei area of Santanghu Basin, Xinjiang[J]. Geological Bulletin of China, 2023, 42(11): 1808− 1817.
[16] 杨树春, 卢庆治, 宋传真, 等. 库车前陆盆地中生界烃源岩有机质成熟度演化及影响因素[J]. 石油与天然气地质, 2005, 26(6): 770-777
YANG Shuchun, LU Qingzhi, SONG Chuanzhen, et al. Evolution of Mesozoic source rock's organic maturation in Kuqa foreland basin and its influence factors [J]. OIL & GAS GEOLOGY, 2005, 26(6): 770-777.
[17] 张水昌, 梁狄刚, 张大江. 关于古生界烃源岩有机质丰度的评价标准[J]. 石油勘探与开发, 2002, 29(2): 8-12
ZHANG Shuichang, LIANG Digang, ZHANG Dajiang. Evaluation criteria for Paleozoic effective hydrocarbon source rocks [J]. PETROLEUM EXPLOARATION AND EVELOPMENT, 2002, 29(2): 8-12.
[18] SHANMUGAM G. Significance of coniferous rain forests and related organic matter in generating commercial quantities of oil, Gippsland Basin, Australia [J]. AAPG Bulletin, 1985, 69: 1241-1254.
[19] HE Cong, JI Liming, SU Ao, et al. Source-rock evaluation and depositional environment of black shales in the Triassic Yanchang Formation, southern Ordos Basin, north-central China [J]. Journal of Petroleum Science and Engineering, 2019, 173: 899-911. doi: 10.1016/j.petrol.2018.10.089
[20] YANG Shengyu, BRIAN Horsfield. Critical review of the uncertainty of Tmax in revealing the thermal maturity of organic matter in sedimentary rocks [J]. International Journal of Coal Geology, 2020, 225: 103500 doi: 10.1016/j.coal.2020.103500
-
