青海省锡铁山铅锌矿床沉积盆地构造与找矿方向浅议

李正明; 王备战; 展卫露; 战嘉华; 郭文波; 王宏宇; 董星; 李增涛

doi:10.12401/j.nwg.2023173

青海省锡铁山铅锌矿床沉积盆地构造与找矿方向浅议

1.
西部矿业股份有限公司，青海西宁　810000

2.
西安西北有色物化探总队有限公司，陕西西安　710068

基金项目: 西北有色地质矿业集团地质科技项目“复杂条件下深部矿产高分辨电磁探测关键技术研究与工程示范”（XBDKKJ202101）。

详细信息

作者简介: 李正明（1987−），男，工程师，主要从事矿山地质工作。E−mail：455084813@qq.com

通讯作者: 王备战（1970−），男，高级工程师，主要从事矿产勘查工作。E−mail：728567950@qq.com。

中图分类号: P618.42；P618.43

收稿日期: 2022-10-05

修回日期: 2023-09-05

刊出日期: 2025-02-20

Discussion on Structure and Prospecting Direction of Xitieshan Lead-zinc Deposit Sedimentary Basin in Qinghai Province

1.
Western Mining Co., Ltd., Xining 810000, Qinghai, China

2.
Xi’an Northwest Non-ferrous Geophysical and Chemical Exploration Group Co., Ltd, Xi'an 710068, Shaanxi, China

More Information

Corresponding author: WANG Beizhan, 728567950@qq.com

Received Date: 05 October 2022

Revised Date: 05 September 2023

Publish Date: 20 February 2025

摘要

摘要:
锡铁山铅锌矿床位于柴达木盆地北缘，矿体主要产于奥陶系滩间山群O₃tn^a-2正常沉积岩段。对深部构造的探测和原始成矿环境的恢复一直是勘查研究工作的重点。矿山以往深部找矿投入了瞬变电磁法（TEM）和可控源音频大地电磁测深法（CSAMT），对深部的结构、构造反映不够清楚，找矿效果也不理想。2020年首次投入了高分辨广域电磁法（WEFM），取得了较好的勘查效果。笔者结合已有的地质资料，对广域电磁法成果进行综合分析，初步认为锡铁山铅锌矿床原始沉积盆地走向为EW向，属于南高北低的抬斜式盆地。受NE-SW向的斜向推覆作用，形成目前盆地的构造形态；同时推测盆地内部存在两条主要的同生断裂。笔者依据同生断裂和已知矿体的空间位置预测了找矿靶区，指出了锡铁山沉积盆地内铅锌矿的找矿方向。
- 锡铁山铅锌矿 /
- 原始沉积盆地 /
- 广域电磁法 /
- 斜向推覆 /
- 找矿方向
Abstract:
Xitieshan lead-zinc deposit is located in the northern margin of Qaidam Basin, and the ore body is mainly produced in the normal sedimentary rock section of O₃tn^a-2 of the Ordovician Tanjianshan Group. The exploration of deep structures and the restoration of the original metallogenic environment have always been the focus of exploration and research work. In the past, transient electromagnetic method (TEM) and controlled source audio frequency magnetotelluric sounding (CSAMT) were used in deep prospecting of the mine, which did not reflect the deep structure and structure clearly enough, and the prospecting effect was not ideal. In 2020, the high-resolution wide area electromagnetic method (WEFM) was put into use for the first time, and good exploration results were achieved. Based on the existing geological data and the comprehensive analysis of the results of the wide area electromagnetic method, this paper preliminarily believes that the original sedimentary basin of the Xitieshan lead-zinc deposit is oriented in the east-west direction and belongs to an uplifted basin with the south high and the north low. Due to the NE－SW oblique nappe, the current structural form of the basin was formed; At the same time, it is speculated that there are two main contemporaneous faults in the basin. Based on the syngenetic faults and the spatial location of known ore bodies, this paper predicts the prospecting target area and points out the prospecting direction of lead-zinc deposits in the Xitieshan sedimentary basin.
- Xitieshan lead-zinc mine /
- primitive sedimentary basin /
- WFEM /
- oblique nappe action /
- prospecting direction

HTML全文

图 1 锡铁山铅锌矿区地质简图（据魏俊浩等，2015）

Figure 1.

下载: 全尺寸图片幻灯片

图 2 推测深部成矿通道在地表的投影范围示意图

Figure 2.

下载: 全尺寸图片幻灯片

图 3 锡铁山铅锌矿区015线断面及推断成果图

Figure 3.

下载: 全尺寸图片幻灯片

图 4 锡铁山铅锌矿区找矿靶区预测图

Figure 4.

下载: 全尺寸图片幻灯片

表 1 岩矿石电性参数统计表

Table 1. Statistical table of electrical parameters of rocks and ores

岩（矿）石名称	块数	电阻率ρ（Ω·m）
岩（矿）石名称	块数	变化范围	几何平均值
块状铅锌矿	34	0.1～11	0.2
碳质绿泥片岩	6	90～810	170
碳质二云片岩	27	14～400	55
钙质绿泥片岩	83	800～3700	1800
绢云绿泥片岩	23	530～7570	2290
含碳片麻岩	57	140～8860	1400
片麻岩	55	440～6000	1560
紫色砂砾岩	37	26～2800	1160
角闪岩	95	180～8100	1400
大理岩	56	650～2500	1240

下载: 导出CSV

参考文献(21)

[1]	陈正乐. 锡铁山铅锌矿深部及外围成矿控制因素找矿靶区预测研究[R]. 北京: 中国地质科学院地质力学研究所, 2020
[2]	陈靖, 郭文波, 王宏宇, 等. 综合电磁法在凤太二里河铅锌矿深部的找矿效果分析[J]. 西北地质, 2024, 57（1）: 196−206. CHEN Jing, GUO Wenbo, WANG Hongyu, et al. Analysis on Prospecting Effect of Integrated Electromagnetic Methods in Deep Prospecting of Fengtai Erlihe Lead−Zinc Deposit[J]. Northwestern Geology, 2024, 57（1）: 196−206.
[3]	邓达文, 孔华, 奚小双, 等. 青海锡铁山热水沉积型铅锌矿床的地球化学特征[J], 矿物岩石地球化学通报, 2003, 22(4): 310-313 DENG Dawen, KONG Hua, XI Xiaoshuang, et al. Geochemistry of the Hydrothermal Sedimentary Xitieshan Pb-Zn Deposit, Qinghai Proyince. [J]. Bulletin of Mineralogy, Petrology and Geochemistry, 2003, 22(4): 310-313.
[4]	邓吉牛. 青海锡铁山矿区褶皱构造及其找矿预测[J], 有色金属矿产与勘查, 1999, 8(5): 283-288 DENG Jiniu. Fold structure and prodiction for prospecting in the Xitieshan ore field, Qinghai. [J]. Geological Exploration for Non-ferrous Metals, 1999, 8(5): 283-288.
[5]	冯志兴, 孙华山, 吴冠斌, 等. 青海锡铁山铅锌矿床类型刍议[J], 地质论评, 2010, 56(4): 501-512 FENG Zhixing, SUN Huashan, WU Guanbin, et al. A Discussion on Type of the Xitieshan Pb-Zn Ore Deposit, Qinghai. [J]. Geological Review, 2010, 56(4): 501-512.
[6]	何继善. 广域电磁法和伪随机信号电法[M]. 北京: 高等教育出版社, 2010 HE Jishan. Wide field electromagnetic method and pseudo-random signal electrical method [M]. Beijing: Higher Education Press, 2010.
[7]	李厚有, 王春龙. 青海省大柴旦镇中间沟—断层沟铅锌矿区勘探地质报告[R]. 2014.
[8]	李艳, 李春付, 安玉伟, 等. 大功率电磁法在青海锡铁山矿区绿石岗—红石岗矿段深部找矿上的应用[J], 黄金地质, 2017, 11(38): 24-28 LI Yan, LI Chunfu, An Yuwei, et al. Application of high power electromagnetic method to deep ore-prospecting in Lvshigang-Hongshigang of Xitieshan Mining District, Qinghai. [J]. Gold, 2017, 38(11): 24-28.
[9]	林成贵, 许荣科, 郑有业, 等. 柴北缘超高压变质带鱼卡榴辉岩型金红石矿地质特征及原岩性质探讨[J]. 西北地质, 2017, 50(2): 142-155 LIN Chenggui, XU Rongke, ZHENG Youye, et al. Geological Characteristic and Protolith Nature of Yuqia Eclogite-type Rutile Deposit in Northern Qaidam UHP Metamorphic Belt[J]. Northwestern Geology, 2017, 50(2): 142-155.
[10]	宋忠宝, 张雨莲, 张照伟, 等. 青海锡铁山铅锌矿的成因讨论[J]. 西北地质, 2012, 45(1): 134-139 SONG Zhongbao, ZHANG Yulian, ZHANG Zhaowei, et al. The origin discussion of the Xitieshan Lead Zinc Deposit in Qinghai Province. [J]. Northwestern Geology, 2012, 45(4): 134-139.
[11]	孙华山. 青海锡铁山铅锌矿深部及外围找矿预测研究[R]. 2017.
[12]	王佳兴, 蔺梦, 刘泽宇, 等. 柴北缘超高压变质带变质蛇绿岩组合及其地质意义[J]. 西北地质, 2020, 53(4): 1-10 WANG Jiaxing, LIN Meng, LIU Zeyu, et al. Petrological Study of the Meta-ophiolite from the North Qaidam UHP Metamorphic Belt and Its Geological Implications. [J]. Northwestern Geology, 2020, 53(4): 1-10.
[13]	王瑞廷, 秦西社, 李青锋, 等. 西秦岭凤太铅锌矿集区成矿特征、找矿预测及勘查方法技术组合[J]. 西北地质, 2023, 56(5): 85−97. WANG Ruiting, QIN Xishe, LI Qingfeng, et al. Metallogenic Characteristics, Prospecting Prediction and Exploration Methods Combination of Fengtai Pb−Zn Orefield, West Qinling[J]. Northwestern Geology, 2023,56(5): 85−97.
[14]	魏俊浩, 李鹏, 李义邦, 等. 青海省锡铁山铅锌矿成矿元素物质场结构及深部找矿潜力[J]. 地质科技通报, 2021, 40(2): 1-12 WEI Junhao, LI Peng, LI Yibang, et al. Material field structure of ore-forming elements and deep prospecting potential of Xitieshan lead-zinc deposit, Qinghai Province. [J]. Bulletin of Geological Science and Technology, 2021, 40(2): 1-12.
[15]	邬介人, 任秉琛, 张苺, 等. 青海锡铁山块状硫化物矿床的类型及地质特征[J], 西安地质矿产研究所所刊, 1987, (20): 1-88 WU Jieren, REN Bingshen, ZHANG Mei, et al. The genetic type and geological characteristics of the Xitieshan massive sulphide deposit, Qinghai. [J]. Bull. Xian Inst. Geol. Min. Res. , Chinese Acad. Geol. Sci. 1987, (20): 1-88.
[16]	魏俊浩. 青海省大柴旦锡铁山铅锌矿区成矿地质条件对比综合研究及靶区预测[R]. 武汉: 中国地质大学. 2015.
[17]	张德全, 王富春, 李大新, 等. 柴北缘地区的两类块状硫化物矿床-Ⅰ. 锡铁山式SEDEX型铅锌矿床[J]. 矿床地质, 2005, 24(05): 471-480 ZHANG Dequan, WANG Fuchun, LI Daxin, et al. Two types of massive sulfide deposits on northern margin of Qaidam basin, Qinghai Province: Ⅰ. Xitieshan style SEDEX lead-zinc deposits. [J]. Mineral Deposits, 2005, 24(5): 471-480.
[18]	张代斌. 青海锡铁山铅锌矿床成矿盆地特征及构造变形研究[D]. 长沙: 中南大学, 2004. ZHANG Daibin. A Study on the Characteristics and Structural Deformation of the Metallogenic Basin of the Xitieshan Lead-Zinc Deposit in Qinghai Province [D]. Changsha: Central South University, 2004.
[19]	张小路, 王钟, 罗润林, 等. 大功率TEM法在锡铁山矿区深边部找矿中的应用效果[J]. 桂林理工大学学报, 2010, 30(2): 179-187 ZHANG Xiaolu, WANG Zhong, LUO Runlin, et al. High-Power TEM Application in Deep and Verge Prospecting at Xitieshan Mining Area. [J]. Journal of Guilin University of Technology, 2010, 30(2): 179-187.
[20]	祝新友, 邓吉牛, 王京彬, 等. 锡铁山矿床两类喷流沉积成因的铅锌矿体研究[J], 矿床地质, 2006, 25(3): 252-262 ZHU Xinyou, DENG Jiniu, WANG Jingbin, et al. Study of two types of ore bodies in Xitieshan lead-zinc SEDEX deposit, Qinghai Province. [J]. Mineral Deposits, 2006, 25(3): 252-262.
[21]	祝新友, 邓吉牛, 王京彬, 等. 锡铁山喷流沉积矿床卤水与海水的相互作用[J], 地质评论, 2007, 53(1): 53-64 ZHU Xinyou, DENG Jiniu, WANG Jingbin, et al. Study on Marble of the Xitieshan Lead-Zinc SEDEX Deposit, Qinghai Province: Interaction between Exhaled Brine and Seawater. [J]. Geological Review, 2007, 53(1): 53-64.
