ACCUMULATION CHARACTERISTICS OF CHANG-2 RESERVOIR IN DALUGOU AREA OF JINGBIAN OILFIELD, ORDOS BASIN
-
摘要:
综合利用烃源岩地球化学、薄片分析、常规物性、测井曲线、流体包裹体及试油等资料, 研究了鄂尔多斯盆地靖边油田大路沟区长2油藏油源条件、储层特征、成藏年代及油气富集规律. 结果表明: 大路沟区发育长7优质烃源岩, 黑色页岩有机碳平均为4.57%, 有机质类型为以生油为主的Ⅰ—Ⅱ1型, 并已达到大量生油阶段, 可为长2油藏的形成提供物质基础. 长2油层组河道砂坝砂体储层物性较好, 面孔率平均高达11.4%, 储油能力强. 长2油藏类型为构造-岩性复合型, 具有油水界面; 矿物颗粒内流体包裹体均一温度揭示出油藏主要形成于早白垩世中晚期, 时间约为115 Ma; 长2油藏分布和富集主要受圈闭发育位置与规模、储盖层有效配置及储层物性的综合控制. 该研究可为靖边油田长2油藏的勘探部署提供地质依据.
Abstract:The oil source conditions, reservoir characteristics, accumulation age and oil-gas enrichment rule of Chang-2 reservoir in Dalugou area of Jingbian Oilfield, Ordos Basin, are studied based on the data of source rock geochemistry, thin section analysis, general physical properties, logging curves, fluid inclusions and oil test. The results show that the Chang-7 high-quality source rocks are developed in Dalugou area, with 4. 57% of average organic carbon content in black shale. The organic matter belongs to mainly oil-generating I—II1 type, reaching the stage of massive oil generation, which can provide material basis for the formation of Chang-2 reservoir. The channel sandbar in Chang-2 oil layer formation has good reservoir physical property with the average apparent porosity as high as 11. 4% and strong oil storage capacity. The Chang-2 reservoir type is structure-lithology compound with oil-water interface. The homogenization temperature of fluid inclusions in mineral particles reveals that the reservoir was mainly formed in the middle and late Early Cretaceous (about 115 Ma). The distribution and enrichment of Chang-2 reservoir are mainly under the integrated control of location and scale of trap development, effective configuration of reservoir-cap rocks and reservoir physical properties. The study can provide geological basis for the exploration and deployment of Chang-2 reservoir in Jingbian Oilfield.
-
Key words:
- reservoir /
- accumulation rule /
- Yanchang Formation /
- Jingbian Oilfield /
- Ordos Basin
-
-
表 1 靖边油田JT746井长7烃源岩地球化学数据表
Table 1. Geochemical data of Chang-7 source rocks in JT746 well, Jingbian Oilfield
深度/m 有机质丰度 有机质类型 有机质成熟度 TOC/% (S1+S2)/10-3 氯仿沥青"A"/% 腐泥组/% 镜质组/% 干酪根类型 Tmax/℃ 20RC29αββ/(αββ+ααα) αααC2920S/(20S+20R) 2023.41 6.81 39.51 0.7717 84.7 15.3 Ⅱ1 450 0.56 0.62 2027.18 4.63 23.92 0.5639 89.0 11.0 Ⅰ 453 0.60 0.64 2033.29 3.06 11.63 0.3376 82.7 17.3 Ⅱ1 450 0.61 0.65 2035.42 3.31 13.76 0.3677 90.3 9.7 Ⅰ 450 0.61 0.60 2037.03 5.03 24.17 0.4034 89.3 10.7 Ⅰ 450 0.52 0.63 2043.06 5.48 35.10 1.3338 87.0 13.0 Ⅱ1 448 0.57 0.66 2043.86 3.65 23.61 0.8996 79.0 21.0 Ⅱ1 450 0.62 0.67
下载: 导出CSV
-
[1] 王建民, 吴昌荣. 陕北东部地区长2+3油层组远源砂质辫状河沉积特征[J]. 矿物岩石, 2007, 27(4): 92-97. doi: 10.3969/j.issn.1001-6872.2007.04.015
Wang J M, Wu C R. Sedimentary characteristics of far-resource sand- braided river with low curvature channel for the Chang 2+3 oil reservoir in the east of Shaanxi Province[J]. Journal of Mineralogy and Petrology, 2007, 27(4): 92-97. doi: 10.3969/j.issn.1001-6872.2007.04.015
[2] 袁广金, 邢芬, 高倩, 等. 鄂尔多斯盆地下寺湾油田长2储层高含水低稳产特征与主控因素研究[J]. 西北地质, 2017, 50(4): 200- 208. doi: 10.3969/j.issn.1009-6248.2017.04.021
Yuan G J, Xing F, Gao Q, et al. Characteristics and main controlling factors of Chang 2 reservoir with low stable production and high water cut in the Xiasiwan Oilfield, Ordos Basin[J]. Northwestern Geology, 2017, 50(4): 200-208. doi: 10.3969/j.issn.1009-6248.2017.04.021
[3] 谢伟, 王延锋, 李红. 鄂尔多斯盆地延长组长2油层组油气富集规律——以永宁油田任山区块为例[J]. 岩性油气藏, 2017, 29(5): 36-45. doi: 10.3969/j.issn.1673-8926.2017.05.005
Xie W, Wang Y F, Li H. Geological controls on hydrocarbon accumulation of Chang 2 oil reservoir in Ordos Basin: A case from Renshan area, Yongning Oilfield[J]. Lithologic Reservoirs, 2017, 29 (5): 36-45. doi: 10.3969/j.issn.1673-8926.2017.05.005
[4] 钟张起, 焦涛, 李军建, 等. 鄂尔多斯盆地姬塬地区延长组成藏主控因素及成藏模式[J]. 石油地质与工程, 2016, 30(3): 28-31. doi: 10.3969/j.issn.1673-8217.2016.03.008
Zhong Z Q, Jiao T, Li J J, et al. Main control factors and accumulation model in Yanchang formation of Jiyuan region, Ordos Basin[J]. Petroleum Geology and Engineering, 2016, 30(3): 28-31. doi: 10.3969/j.issn.1673-8217.2016.03.008
[5] 张卫刚, 陈刚, 郭望, 等. 鄂尔多斯盆地姬塬地区延长组下组合油源特征综合研究[J]. 西北地质, 2020, 53(4): 140-152. https://www.cnki.com.cn/Article/CJFDTOTAL-XBDI202004016.htm
Zhang W G, Chen G, Guo W, et al. Comprehensive research of oil- source rock correlation of Lower Yanchang Formation in Jiyuan Field, Ordos Basin[J]. Northwestern Geology, 2020, 53(4): 140-152. https://www.cnki.com.cn/Article/CJFDTOTAL-XBDI202004016.htm
[6] 刘超威, 陈世加, 姚宜同, 等. 鄂尔多斯盆地姬塬地区长2油藏低含油饱和度成因[J]. 断块油气田, 2015, 22(3): 305-308. https://www.cnki.com.cn/Article/CJFDTOTAL-DKYT201503008.htm
Liu C W, Chen S J, Yao Y T, et al. Causes of low oil saturation for Chang 2 reservoir in Jiyuan area of Ordos Basin[J]. Fault-block Oil and Gas Field, 2015, 22(3): 305-308. https://www.cnki.com.cn/Article/CJFDTOTAL-DKYT201503008.htm
[7] 赵靖舟, 王永东, 孟祥振, 等. 鄂尔多斯盆地陕北斜坡东部三叠系长2油藏分布规律[J]. 石油勘探与开发, 2007, 34(1): 23-27. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK200701005.htm
Zhao J Z, Wang Y D, Meng X Z, et al. Law of petroleum accumulation and distribution in Triassic Chang 2 oil-bearing formation in eastern North Shaanxi Slope, Ordos Basin[J]. Petroleum Exploration and Development, 2007, 34(1): 23-27. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK200701005.htm
[8] 白玉彬, 赵靖舟, 章爱诚, 等. 蟠龙油田三叠系长2油组油气富集规律[J]. 西南石油大学学报(自然科学版), 2010, 32(4): 67-71. https://www.cnki.com.cn/Article/CJFDTOTAL-XNSY201004014.htm
Bai Y B, Zhao J Z, Zhang A C, et al. Petroleum accumulation and distribution law of Chang 2 formation in Panlong Oilfield Ordos Basin[J]. Journal of Southwest Petroleum University (Science and Technology Edition), 2010, 32(4): 67-71. https://www.cnki.com.cn/Article/CJFDTOTAL-XNSY201004014.htm
[9] 郑忠文, 刘建朝, 李荣西. 微构造对低渗透油气成藏的控制作用——以鄂尔多斯盆地丰富川油田西区为例[J]. 西北地质, 2015, 48(4): 234-242. doi: 10.3969/j.issn.1009-6248.2015.04.024
Zheng Z W, Liu J C, Li R X. Controls to oil accumulation in sandstone beds with low permeability by micro-structure: Example from western area of Fengfuchuan Oilfield in Northern Shaanxi[J]. Northwestern Geology, 2015, 48(4): 234-242. doi: 10.3969/j.issn.1009-6248.2015.04.024
[10] 冯顺彦, 张晓辉, 李成, 等. 鄂尔多斯盆地志靖-安塞地区长2油藏成藏主控因素分析[J]. 特种油气藏, 2020, 27(4): 54-59. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ202004008.htm
Feng S Y, Zhang X H, Li C, et al. Hydrocarbon accumulation main- controlling factor analysis of Chang 2 reservoir in Zhijing-Ansai of Ordos Basin[J]. Special Oil and Gas Reservoirs, 2020, 27(4): 54-59. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ202004008.htm
[11] 白玉彬, 罗静兰, 郝孝荣, 等. 鄂尔多斯盆地蟠龙油田延长组烃源岩地球化学特征[J]. 地质科技情报, 2013, 32(4): 19-24. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ201304005.htm
Bai Y B, Luo J L, Hao X R, et al. Geochemical characteristics of source rocks of Yanchang Formation in Panlong Oilfield, Ordos Basin[J]. Geological Science and Technology Information, 2013, 32(4): 19-24. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ201304005.htm
[12] 赵靖舟, 孟选刚, 韩载华. 近源成藏——来自鄂尔多斯盆地延长组湖盆东部"边缘"延长组6段原油的地球化学证据[J]. 石油学报, 2020, 41(12): 1513-1526. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202012006.htm
Zhao J Z, Meng X G, Han Z H. Near-source hydrocarbon accumulation: Geochemical evidence of lacustrine crude oil from the Member 6 of Yanchang Formation, eastern margin of Ordos Basin[J]. Acta Petrolei Sinica, 2020, 41(12): 1513-1526. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202012006.htm
[13] 林森虎, 袁选俊, 杨智. 陆相页岩与泥岩特征对比及其意义——以鄂尔多斯盆地延长组7段为例[J]. 石油与天然气地质, 2017, 38 (3): 517-523. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201703011.htm
Lin S H, Yuan X J, Yang Z. Comparative study on lacustrine shale and mudstone and its significance: A case from the 7th member of Yanchang Formation in the Ordos Basin[J]. Oil and Gas Geology, 2017, 38(3): 517-523. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201703011.htm
[14] 王贵文, 朱振宇, 朱广宇. 烃源岩测井识别与评价方法研究[J]. 石油勘探与开发, 2002, 29(4): 50-52. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK200204015.htm
Wang G W, Zhu Z Y, Zhu G Y. Logging identification and evaluation of Cambrian-Ordovician source rocks in syneclise of Tarim Basin[J]. Petroleum Exploration and Development, 2002, 29(4): 50-52. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK200204015.htm
[15] 荀兆杰, 钟建华, 李勇, 等. 鄂尔多斯盆地靖边油田马宁区长2油层组储层特征研究[J]. 地质与资源, 2016, 25(6): 550-557. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract8687.shtml
Xun Z J, Zhong J H, Li Y, et al. Characteristics of the C-2 reservoir in Maning area of Ordos Basin[J]. Geology and Resources, 2016, 25 (6): 550-557. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract8687.shtml
[16] 赵靖舟, 吴少波, 武富礼. 论低渗透储层的分类与评价标准——以鄂尔多斯盆地为例[J]. 岩性油气藏, 2007, 19(3): 28-31, 53. https://www.cnki.com.cn/Article/CJFDTOTAL-YANX200703006.htm
Zhao J Z, Wu S B, Wu F L. The classification and evaluation criterion of low permeability reservoir: An example from Ordos Basin[J]. Lithologic Reservoirs, 2007, 19(3): 28-31, 53. https://www.cnki.com.cn/Article/CJFDTOTAL-YANX200703006.htm
[17] 陶士振. 自生矿物序次是确定包裹体期次的根本依据[J]. 石油勘探与开发, 2006, 33(2): 154-159. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK200602006.htm
Tao S Z. Sequence of diagenetic authigenic mineral: The basis of timing the inclusions formation in sedimentary rocks[J]. Petroleum Exploration and Development, 2006, 33(2): 154-160. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK200602006.htm
[18] 邵晓州, 李勇, 张文选, 等. 鄂尔多斯盆地陕北地区长8致密砂岩流体包裹体特征与石油成藏[J]. 中国地质, 2020, https://kns.cnki.net/kcms/detail/11.1167.P.20200623.1304.004.html. (网络首发)
Shao X Y, Li Y, Zhang W X, et al. The fluid inclusion characteristics and petroleum accumulation of Chang 8 tight sandstone in northern Shaanxi, Ordos Basin[J]. Geology in China, 2020. https://kns.cnki.net/kcms/detail/11.1167.P.20200623.1304.004.html.
[19] 任战利. 鄂尔多斯盆地热演化史与油气关系的研究[J]. 石油学报, 1996, 17(1): 17-24. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB601.002.htm
Ren Z L. Research on the relations between geothermal history and oil-gas accumulation in the Ordos Basin[J]. Acta Petrolei Sinica, 1996, 17(1): 17-24. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB601.002.htm
[20] 陈瑞银, 罗晓容, 陈占坤, 等. 鄂尔多斯盆地埋藏演化史恢复[J]. 石油学报, 2006, 27(2): 43-47. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB200602008.htm
Chen R Y, Luo X R, Chen Z K, et al. Restoration of burial history of four periods in Ordos Basin[J]. Acta Petrolei Sinica, 2006, 27 (2): 43-47. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB200602008.htm
[21] 王龙军, 雷华伟, 周升沦. 鄂尔多斯盆地靖边油田东坑大阳湾区延9油藏主控因素分析[J]. 地质与资源, 2019, 28(4): 372-377. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract8362.shtml
Wang L J, Lei H W, Zhou S L. Analysis on the main controlling factors of Y-9 reservoir in Jingbian Oilfield Ordos Basin[J]. Geology and Resources, 2019, 28(4): 372-377. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract8362.shtml
-
