MODELING STUDY ON MULTIPLE THIN-PLATE CONDUCTORS BASED ON SURFACE-HOLE TRANSIENT ELECTROMAGNETIC ANOMALY RESPONSES
-
摘要:
地-井瞬变电磁法(SHTEM)是指场源在地面激发, 接收线圈在钻井中观测瞬变响应, 用以勘查深部矿产资源的勘探方法. 从等效涡流环方法原理出发, 计算了等效涡流环与Rx之间的互感系数以及感应电压. 通过建立组合薄板导体的数学模型, 计算模拟地下存在多个薄板状良导体组合情况下的起响应叠加场, 以研究组合导体的地-井瞬变电磁异常响应, 并分析这些异常响应的特征及规律. 认为钻孔在距离多个组合薄板状矿体较近的情况下, 通过地-井瞬变电磁测量能够进行分辨.
Abstract:The surface-hole transient electromagnetic method (SHTEM) is used to explore deep mineral resources by which field source is excited on surface and transient responses are observed through receiving coil in borehole. The mutual inductance coefficient and induced voltage between equivalent eddy current ring and Rx are calculated based on the principle of equivalent eddy current ring method. By establishing a mathematic model of multiple thin-plate conductors, the response superimposed field is calculated and simulated under the condition that there are combinations of multiple thin conductive plates underground to study the surface-hole transient electromagnetic anomaly responses of multiple conductors and analyze their characteristics and rules. It is considered that multiple combinations of thin plate orebodies can be distinguished through SHTEM when they are close to the borehole.
-
Key words:
- SHTEM /
- multiple conductor /
- conductive plate /
- equivalent eddy current
-
-
[1] 蒋邦远. 实用近区磁源瞬变电磁法勘探[M]. 北京: 地质出版社, 1998: 199-237.
Jiang B Y. Practical near-field magnetic source transient electromagnetic exploration[M]. Beijing: Geological Publishing House, 1998: 199- 237. (in Chinese)
[2] 牛之琏. 时间域电磁法原理[M]. 长沙: 中南大学出版社, 2007: 249-267.
Niu Z L. Principle of time domain electromagnetic method[M]. Changsha: Central South University Press, 2007: 249-267. (in Chinese)
[3] Buselli G, Lee S K. Modelling of drill-hole TEM responses from multiple targets covered by a conductive overburden[J]. Exploration Geophysics, 1996, 27(2/3): 141-153.
[4] Singh N P, Mogi T. Electromagnetic response of a large circular loop source on a layered earth: A new computation method[J]. Pure and Applied Geophysics, 2005, 162(1): 181-200. doi: 10.1007/s00024-004-2586-2
[5] Richards D J. CRAE's approach to downhole TEM at Broken Hill[J]. Exploration Geophysics, 1987, 18(3): 279-284. doi: 10.1071/EG987279
[6] Eaton P A, Hohmann G W. The influence of a conductive host on two-dimensional borehole transient electromagnetic responses[J]. Geophysics, 1984, 49(7): 861-869. doi: 10.1190/1.1441732
[7] West R C, Ward S H. The borehole transient electromagnetic response of a three-dimensional fracture zone in a conductive half-space[J]. Geophysics, 1988, 53(11): 1469-1478. doi: 10.1190/1.1442427
[8] Macnae J, Staltari G. Classification of sign changes in Borehole TEM decays[J]. Exploration Geophysics, 1987, 18(3): 331-339. doi: 10.1071/EG987331
[9] Dyck A V, West G F. The role of simple computer models in interpretations of wide-band, drill-hole electromagnetic surveys in mineral exploration[J]. Geophysics, 1984, 49(7): 957-980. doi: 10.1190/1.1441741
[10] Telford W M, Geldart L P, Sheriff R E. Applied geophysics[M]. Cambridge: Cambridge University Press, 1990: 353.
[11] Paul C R. Inductance: Loop and partial[M]. Hoboken: John Wiley and Sons Ltd, 2010: 196-206.
[12] Dwight H B. Tables of integrals and other mathematical data[M]. 4th ed. New York: MacMillan, 1964: 45.
[13] Jeffrey A. Handbook of mathematical formulas and integrals[M]. San Diego: Academic Press, 1995: 178.
[14] Vella L. Taking downhole EM underground, at hill 50 decline, mount magnet, Western Australia[J]. Exploration Geophysics, 1997, 28(1/2): 141-146.
[15] Zhang Z, Xiao J. Inversions of surface and borehole data from large- loop transient electromagnetic system over a 1-D earth[J]. Geophysics, 2001, 66(4): 1090-1096. doi: 10.1190/1.1487056
[16] Aziz A A, Strack K, Hanstein T. Surface-to-borehole TEM for reservoir monitoring[C]//SEG Technical Program Expanded Abstracts 2011. Society of Exploration Geophysicists, 2011: 1882-1886.
[17] 李建慧, 刘树才, 焦险峰, 等. 地-井瞬变电磁法三维正演研究[J]. 石油地球物理勘探, 2015, 50(3): 556-564. https://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ201503029.htm
Li J H, Liu S C, Jiao X F, et al. Three-dimensional forward modeling for surface-borehole transient electromagnetic method[J]. Oil Geophysical Prospecting, 2015, 50(3): 556-564. https://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ201503029.htm
[18] 杨海燕, 岳建华, 徐正玉, 等. 覆盖层影响下典型地-井模型瞬变电磁法正演[J]. 吉林大学学报(地球科学版), 2016, 46(5): 1527-1537. https://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ201605025.htm
Yang H Y, Yue J H, Xu Z Y, et al. Transient electromagnetic method modeling in ground-borehole model with overburden influence[J]. Journal of Jilin University (Earth Science Edition), 2016, 46 (5): 1527-1537. https://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ201605025.htm
[19] Paggi J, Macklin D. Discovery of the Eureka volcanogenic massive sulphide lens using downhole electromagnetics[J]. Exploration Geophysics, 2016, 47(3): 248-257. doi: 10.1071/EG15096
[20] Kolaj M, Smith R. Robust conductance estimates from spatial and temporal derivatives of borehole electromagnetic data[J]. Geophysics, 2014, 79(3): E115-E123. doi: 10.1190/geo2013-0387.1
-
