COMPREHENSIVE GEOPHYSICAL INTERPRETATION FOR THE GEOLOGICAL AND MINERAL SURVEY IN BASALT-COVERED REGION OF CHANGBAI MOUNTAIN: A Case Study of Kaifeng Forest Farm Area
-
摘要:
结合长白山玄武岩覆盖区的7条综合物探剖面，利用重力、高精度磁法、可控源音频大地电磁测深、浅层地震勘探等多种物探工作方法，研究和探讨了玄武岩覆盖之下地质体的空间展布、岩性和构造特征，进行了地质填图和找矿方法的有效性试验，并结合工程钻孔加以验证.绘制了玄武岩覆盖区基底推断图和玄武岩厚度等值线图，总结了新生代玄武岩覆盖区区域地质矿产调查的有效工作方法手段.
Abstract:Combined with 7 comprehensive geophysical sections in the basalt-covered area of Changbai Mountains, multiple geophysical exploration methods such as gravity, high-precision magnetic survey, controlled source audio-frequency magnetotellurics (CSAMT) and shallow seismic exploration are used to study the spatial distribution, lithology and structural characteristics of basalt-covered geological bodies. Through geological mapping and validity test of prospecting methods, the results are verified with engineering drilling. Furthermore, the paper draws the inferred map of basement in the basalt covered area and contour map of basalt thickness, and summarizes the effective methods of geological and mineral survey in Cenozoic basalt-covered region.
-
Key words:
- basalt-covered area /
- gravity survey /
- high-precision magnetic survey /
- CSAMT /
- shallow seismic /
- Changbai Mountains
-
-
表 1 研究区典型岩石物性参数统计表
Table 1. Physical parameters of typical rocks in the study area
填图单位名称 岩性 样品数 密度/（kg/m3） 磁化率/4π×10-6 电阻率/Ωm 极化率/% 青白口系钓鱼台组石英砂岩 石英砂岩 31 2.91 53 677 0.9 中震旦统八道江组叠层石灰岩 叠层石灰岩 33 2.67 78 3095 0.6 寒武系第二-第三统馒头组粉砂岩 粉砂岩 31 2.34 45 574 0.8 寒武系芙蓉统-下奥陶统冶里组灰岩 灰岩 37 2.57 98 3896 0.7 中-下二叠统山西组砂岩 砂岩 30 2.01 170 479 0.9 上三叠统小河口组粉砂岩 粉砂岩 29 2.1 120 423 0.8 古元古代花岗片麻岩 花岗片麻岩 30 2.72 59 1589 0.9 新太古代英云闪长质片麻岩 英云闪长片麻岩 32 2.65 18330 1793 1.5 古元古界花山组绿泥片岩 绿泥片岩 31 2.98 210 497 1.2 古元古界珍珠门岩组大理岩 大理岩 30 2.83 67 3407 0.7 上三叠统小河口组球状风化火山岩 球状风化火山岩 30 2.78 170 1093 1.6 下白垩统果松组安山岩 安山岩 30 2.61 11690 994 1.8 下白垩统林子头组凝灰质砂砾岩 凝灰质砂砾岩 27 2.34 180 407 0.9 新近系-第四系玄武岩 玄武岩 30 2.94 15960 514 1.1 早白垩世花岗斑岩 花岗斑岩 29 2.79 11520 2876 1.2 早白垩世流纹斑岩 流纹斑岩 30 2.94 110 1198 0.9 注：各参数为该类岩石样品的平均值.
下载: 导出CSV
-
[1] 乔中坤, 黄大年, 周文月, 等. 长白山玄武岩盖层地质构造研究[J]. 地球物理学进展, 2016, 31(5): 1991-1997. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWJ201605014.htm
Qiao Z K, Huang D N, Zhou W Y, et al. Research of geological structure of Changbai Mountain basalt cover[J]. Progress in Geophysics, 2016, 31(5): 1991-1997. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWJ201605014.htm
[2] 唐钊, 朱奕先, 李桐林. 长白山玄武岩覆盖区重力异常的地质意义[J]. 吉林地质, 2018, 37(1): 66-70. https://www.cnki.com.cn/Article/CJFDTOTAL-JLDZ201801012.htm
Tang Z, Zhu Y X, Li T L. The geological significance of gravity anomaly of Changbai Mountain basalt cover[J]. Jilin Geology, 2018, 37(1): 66-70. https://www.cnki.com.cn/Article/CJFDTOTAL-JLDZ201801012.htm
[3] 李根. CSAMT方法在长白山玄武岩覆盖区找矿中的应用[D]. 南昌: 东华理工大学, 2017.
Li G. Application of geophysical prospecting method to study the geological structure of karst area in the Changbai Mountain[D]. Nanchang: East China University of Technology, 2017.
[4] 屈旭钧, 董晓健. 综合物探方法在玄武岩覆盖区的应用——以三道砬子河-马鞍山剖面为例[J]. 吉林地质, 2017, 36(4): 18-21. https://www.cnki.com.cn/Article/CJFDTOTAL-JLDZ201704005.htm
Qu X J, Dong X J. Application of comprehensive geophysical method in basalt covered area: Take Sandaolazihe-Ma'anshan section as an example[J]. Jilin Geology, 2017, 36(4): 18-21. https://www.cnki.com.cn/Article/CJFDTOTAL-JLDZ201704005.htm
[5] 姚美娟, 陈建平, 籍进柱. 月球南海地区玄武岩厚度估算[J]. 地学前缘, 2019, 26(3): 271-281. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201903037.htm
Yao M J, Chen J P, Ji J Z. Thickness estimation of basalts in Mare Australe[J]. Earth Science Frontiers, 2019, 26(3): 271-281. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201903037.htm
[6] 王开燕, 刘丹, 柳俊茹, 等. 东北地区地壳结构研究[J]. 地球物理学进展, 2015, 30(1): 61-69. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWJ201501010.htm
Wang K Y, Liu D, Liu J R, et al. Crustal seismic in the northeast of China[J]. Progress in Geophysics, 2015, 30(1): 61-69. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWJ201501010.htm
[7] 崔笃信, 王庆良, 李克, 等. 长白山天池火山近期形变场演化过程分析[J]. 地球物理学报, 2007, 50(6): 1731-1739. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX200706014.htm
Cui D X, Wang Q L, Li K, et al. Analysis of recent deformation of Changbaishan Tianchi volcano[J]. Chinese Journal of Geophysics, 2007, 50(6): 1731-1739. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX200706014.htm
[8] 刘若新, 樊祺诚, 郑祥身, 等. 长白山天池火山的岩浆演化[J]. 中国科学(D辑), 1998, 28(3): 226-231. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK199803005.htm
Liu R X, Fan Q C, Zheng X S, et al. Magmatic evolution of Tianchi volcano in Changbai Mountain[J]. Science in China (Series D), 1998, 28(3): 226-231. (in Chinese) https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK199803005.htm
[9] 赵亮. 辽宁桓仁-吉林通化地区中生代火山岩年代学研究[D]. 长春: 吉林大学, 2015.
Zhao L. Study on the geochronology of Mesozoic volcanic rocks in Huanren, Liaoning and Tonghua, Jilin[D]. Changchun: Jilin University, 2015.
[10] 滕大伟. 吉林白山市板石沟铁矿成矿要素及找矿预测研究[D]. 长春: 吉林大学, 2018.
Teng D W. Ore-forming factors and metallogenic prediction of Baishigou iron in Baishan City, Jilin Province[D]. Changchun: Jilin University, 2018.
[11] 韦选建, 罗先熔, 杨龙坤, 等. 吉林长白山玄武岩覆盖区地电化学找矿研究[J]. 矿产勘查, 2017, 8(3): 464-472. https://www.cnki.com.cn/Article/CJFDTOTAL-YSJS201703017.htm
Wei X J, Luo X R, Yang L K, et al. Application of geo-electrochemical method for prospecting in basalt coverage area, Changbai Mountain, Jilin[J]. Mineral Exploration, 2017, 8(3): 464-472. https://www.cnki.com.cn/Article/CJFDTOTAL-YSJS201703017.htm
[12] 佟智强. 吉林抚松四道砬子河岩组斜长角闪岩成因[D]. 长春: 吉林大学, 2018.
Tong Z Q. The genesis of amphibolite of Sidaolazihe Formation in Fusong area, Jilin Province[D]. Changchun: Jilin University, 2018.
[13] 潘波. 长白山天池火山晚更新世以来喷发序列研究[J]. 国际地震动态, 2017(11): 39-41. https://www.cnki.com.cn/Article/CJFDTOTAL-GJZT201711009.htm
Pan B. Eruptive history of the Changbaishan Tianchi volcano, China/DPRK, since the Late Pleistocene[J]. Recent Developments in World Seismology, 2017(11): 39-41. (in Chinese) https://www.cnki.com.cn/Article/CJFDTOTAL-GJZT201711009.htm
[14] 林琳. 长白山区矿泉水资源成因与开发调控的研究[D]. 长春: 吉林大学, 2016.
Lin L. The research on the genesis and the exploitation control scheme of the mineral spring water resource in the Changbai Mountain district[D]. Changchun: Jilin University, 2016.
[15] 丑述一. 吉南松树镇地区金及多金属矿综合信息预测[D]. 长春: 吉林大学, 2016.
Chou S Y. Comprehensive information prediction of gold and polymetallic ore in Songshu Town area of south of Jilin Province[D]. Changchun: Jilin University, 2016.
[16] 寿玲芳. 地面高精度磁测和CSAMT在淳安竹尖山多金属矿普查中的应用研究[D]. 杭州: 浙江大学, 2015.
Shou L F. The application of the ground high-precision magnetic survey method and CSAMT on polymetallic deposit investigation in Zhujiangshan of Chun'an County[D]. Hangzhou: Zhejiang University, 2015.
[17] 任伟龙, 宁君, 翟亮亮, 等. 综合地球物理勘探在八仙筒地区砂岩型铀矿勘查中的应用[J]. 东华理工大学学报(自然科学版), 2017, 40(3): 279-283. https://www.cnki.com.cn/Article/CJFDTOTAL-HDDZ201703010.htm
Ren W L, Ning J, Zhai L L, et al. Application of integrated geophysical prospecting to sandstone-type uranium deposits exploration in Baxiantong area[J]. Journal of East China University of Technology, 2017, 40(3): 279-283. https://www.cnki.com.cn/Article/CJFDTOTAL-HDDZ201703010.htm
[18] 刘波. 黑龙江省黑河市伊洛特河金矿床成矿地质条件及找矿潜力分析[D]. 长春: 吉林大学, 2016.
Liu B. Analysis of metallogenic geological conditions and prospecting potential of the Yiluote-River gold deposit in Heihe, Heilongjiang Provence[D]. Changchun: Jilin University, 2016.
[19] 张宏嘉. 本溪-集安地区三维地质结构重磁电综合解释[D]. 长春: 吉林大学, 2013.
Zhang H J. Integrated geophysical interpretation of 3D geological structure of Benxi-Ji'an metallogenic belt[D]. Changchun: Jilin University, 2013.
[20] 吴占彩, 贺克升. 重、磁、电在地热勘查中的应用[J]. 中国资源综合利用, 2017, 35(9): 132-134. https://www.cnki.com.cn/Article/CJFDTOTAL-ZWZS201709046.htm
Wu Z C, He K S. Application of gravity, magnetism and electricity in geothermal prospecting[J]. China Resources Comprehensive Utilization, 2017, 35(9): 132-134. https://www.cnki.com.cn/Article/CJFDTOTAL-ZWZS201709046.htm
[21] 李玉芹, 王学贞, 王振生, 等. 大兴安岭东坡甘珠尔庙银多金属矿地质特征及找矿方向[J]. 矿物学报, 2011, 31(3): 610-614. https://www.cnki.com.cn/Article/CJFDTOTAL-KWXB201103042.htm
Li Y Q, Wang X Z, Wang Z S, et al. A tentative study of the geology and ore potentiality of Ganzhuermiao Ag polymetallic deposit, east-side hill of Daxinganling, China[J]. Acta Mineralogica Sinica, 2011, 31(3): 610-614. https://www.cnki.com.cn/Article/CJFDTOTAL-KWXB201103042.htm
-
