HIGH DENSITY WIDE LINE 2D SEISMIC ACQUISITION PRACTICE IN S281 BLOCK OF DAMINTUN SAG, LIAOHE DEPRESSION
-
摘要:
辽河拗陷大民屯凹陷S281块X井钻井显示该块油气潜力较大, 但以往地震资料采集时间早, 覆盖次数较低, 成像精度差, 导致主体断裂位置和微断裂体系难以落实, 制约区块成藏解释和后续开发. 为此, 开展了高密度宽线二维地震资料采集, 并基于采集数据开展了观测系统退化分析. 研究结果表明, 新采集的高密度宽线二维地震成像剖面较以往三维地震成果剖面断点更清晰, 断裂系统刻画更清楚, 构造形态更自然, 层间信息更丰富, 信噪比更高, 落实了的西部斜坡带的构造特征; 超高密度、极小面元对高陡构造和断裂刻画更清楚, 是提高复杂地质目标成像的有效方法; 退化处理说明S281块的地震资料采集观测系统的面元边长不能大于12.5 m, 最大炮检距不能小于3 500 m, 覆盖次数不能小于1 200次. 本研究可为大民屯凹陷西部斜坡带的下步地震资料采集和勘探开发提供借鉴.
Abstract:The drilling of well X in S281 block of Damintun sag, Liaohe depression, shows a great oil and gas potential. However, it is difficult to determine the main fault position and microfracture system due to the old acquisition time of previous seismic data, low coverage times and poor imaging precision, which restricts the interpretation of block accumulation and subsequent development. Therefore, the study carries out the high density wide line 2D seismic data acquisition and degradation analysis of the observation system based on the data. The results show that, compared with the previous 3D seismic imaging section, the newly acquired high density wide line 2D seismic imaging section has clearer breakpoints, clearer delineation of fault system, more natural structural configuration, richer interlayer information, and higher signal-to-noise ratio, which accurately realizes the structural characteristics of western slope zone. The ultrahigh density and minimum bin can depict high-steep structures and faults more clearly, which is an effective method to improve the imaging of complex geological targets. The degradation processing indicates that the bin side length of seismic data acquisition and observation system of S281 block should not be greater than 12.5 m, the maximum offset should not be less than 3 500 m, and the coverage times should not be less than 1 200 times. The study can provide reference for the next seismic data acquisition and exploration in the western slope zone of Damintun sag.
-
-
表 1 S281块以往三维采集参数表
Table 1. Previous 3D acquisition parameters of S281 block
参数 数值 观测系统 12L24S192T6R斜交 面元/m2 25×25 覆盖次数 12×6=72 接收道数 2304 接收线距/m 200 道间距/m 50 炮线距/m 400 炮点距/m 50/50 最大炮检距/m 5060.26 纵横比 0.35 炮道密度/（万道/km2） 11.52 激发方式 SN4-10，2串串联 接收方式 5井2 kg
下载: 导出CSV
表 2 S281块高密度宽线二维采集参数表
Table 2. High-density wide line 2D acquisition parameters of S281 block
观测系统 道距/m 炮点距/m 覆盖次数（满覆盖） 接收道数 接收线距/m 接收方式 激发方式 3L×2S 12.5 12.5 1000~4056 全排列接收 25 GT-DS-5H3X1超高灵敏度检波器，单点接收 EV56可控震源2~130 Hz，1台1次
下载: 导出CSV
-
