从盐酸 BiCl 3溶液中隔膜电积回收铋的研究

详细信息

刊出日期: 2014-10-25

Study on Recovery Bismuth by Diaphragm Electroylsis from Hydrochloric BiCl 3 Solution

Publish Date: 25 October 2014

摘要: 介绍了一种回收铋的清洁湿法冶金新工艺,运用隔膜电积法从盐酸BiCl 3溶液中回收铋,并考察了电流密度、温度、HCl、Bi3+和NaOH的浓度对电积的影响。结果表明:在电流密度150 A/m2、温度45~55℃、3.5 mol/L HCl、110 g/L Bi3+、15 g/L NaOH的最佳条件下,阳极NaOH反应生成NaClO3,Bi3+在阴极上沉积得到致密金属铋,电流效率最高可达到98.82%,阴极铋纯度为99.80%。电积后将阳极和阴极电积液返回循环利用,实现了物料的闭路循环。
- 隔膜电积 /
- 槽电压 /
- 电流密度 /
- 电流效率 /
- 铋
Abstract: This paper introduces a new clean hydrometallurgy technology of recovery bismuth from hydrochloric BiCl 3 solution by electrodeposition .Effects of current density , solution temperature , concentration of HCl , Bi3+and NaOH parameter on diaphragm were investigated .The experiments results show that , in the optimum conditions of current density 150 A/m2, temperature 45~55℃, 3.5 mol/L HCl, 110 g/L Bi 3+and 15 g/L NaOH.NaOH could transform into NaClO 3 through re-action in anode , bismuth could be obtained in cathode , current efficiency could reach a maximum of 98 .82 %, and the purity of cathodes bismuth was 99 .8%.The electric fluid of anode and cath-ode could be recycled , and which achieves closed circulation of materials .
