坦桑尼亚某晶质石墨大鳞片保护工艺研究

刘磊; 孙华星; 郭理想; 黄俊玮; 赵恒勤

doi:10.13779/j.cnki.issn1001-0076.2023.03.011

坦桑尼亚某晶质石墨大鳞片保护工艺研究

1.
中国地质科学院郑州矿产综合利用研究所，河南郑州 450006

2.
国家非金属矿资源综合利用工程技术研究中心，河南郑州 450006

基金项目: 自然资源部高层次科技创新人才工程项目（121106000000180039-2210）；自然资源部部门预算资助项目

详细信息

作者简介: 刘磊（1984—），男，博士，研究员，主要从事战略非金属矿高效利用关键技术研究; 孙华星（1999—），男，山东聊城人，硕士研究生。就读于中国地质科学院矿物加工工程专业，师从赵恒勤研究员和刘磊研究员，主要从事非金属矿资源加工与利用研究

通讯作者: 孙华星（1999—），男，硕士研究生，E-mail：2216228308@qq.com。

中图分类号: TD975⁺.2

收稿日期: 2023-02-20

刊出日期: 2023-06-15

Protection Technology of Large Scale Crystalline Graphite from Tanzania

1.
Zhengzhou Institute of Multipurpose Utilization of Mineral Resources, CAGS, Zhengzhou 450006, China

2.
China National Engineering Research Center for Utilization of Industrial Minerals, Zhengzhou 450006, China

More Information

Corresponding author: SUN Huaxing, 2216228308@qq.com

Received Date: 20 February 2023

Publish Date: 15 June 2023

摘要

摘要:
坦桑尼亚某晶质石墨矿固定碳含量为3.74%，鳞片粒径+147 µm占比97.18%。对比了高压辊磨机和球磨机两种磨矿方式下浮选粗精矿的分质产品差异，并开展了各分质产品再磨再选试验。试验结果表明，采用层压粉碎（高压辊磨机）—分质分选新工艺效果较好，粗粒低碳分质产品单独再磨避免了脉石对粗精矿中高解离度大鳞片石墨的破坏，且碳品位提升较快，其再选精矿与中粒中碳产品合并成一个产品，与细粒高碳产品分别经两段再磨再选后，精矿碳品位均大于96%，最终获得了碳品位96.24%、回收率95.30%的精矿。层压粉碎—分质分选工艺相比常规粗精矿混目再磨再选工艺减少了五次再磨六次精选，最终精矿碳品位高1.04百分点，+0.30 mm粒级精矿产率高3.25百分点。
- 晶质石墨 /
- 大鳞片保护 /
- 层压粉碎 /
- 分质分级
Abstract:
The fixed carbon content of a crystalline graphite ore from Tanzania is 3.74%, among of which the +147 µm size flake graphite accounts for 97.18%. In this paper, the different rough concentrates and further regrinding and reflotation tests between high pressure roller mill and ball mill were compared.The results showed that the effect of the new process of "particles bed comminution (high pressure roller mill)−grading and grading separation" was better. The regrinding of coarse−grained low−carbon products avoided the damage of gangue to large−scale graphite with high dissociation degree in coarse concentrate, and the carbon grade increased rapidly. Its recleaning concentrate and medium−grained medium−carbon were combined into one product, and fine−grained high−carbon products were regrinding and re−concentration in two stages respectively. The fixed carbon content of both concentrates were greater than 96%. Compared with the conventional process, "five times regrinding and six times flotation" were reduced. The final carbon grade of the concentrate was higher than 95% and the +0.15 mm particle size was about 65% in both processes. The +0.30 mm content in the new process was 3.37% higher.
- crystalline graphite /
- large-flaky graphite protection /
- particle bed breakage /
- grading and classification

HTML全文

图 1 石墨矿石结构构造特征

Figure 1.

下载: 全尺寸图片幻灯片

图 2 磨矿产品浮选—分质分级试验工艺流程

Figure 2.

下载: 全尺寸图片幻灯片

图 3 一段磨矿细度试验结果：(a)粗粒低碳产品 (b)中粒中碳产品 (c)细粒高碳产品

Figure 3.

下载: 全尺寸图片幻灯片

图 4 常规粗精矿混目再磨再选工艺闭路试验流程

Figure 4.

下载: 全尺寸图片幻灯片

图 5 层压粉碎—分质分选新工艺闭路试验流程

Figure 5.

下载: 全尺寸图片幻灯片

表 1 原矿化学多元素分析结果

Table 1. Multi-elements analysis results of raw ores /%

元素	固定C	SiO₂	Al₂O₃	Fe₂O₃	CaO	S	MgO	Na₂O	TiO₂	MnO
含量/%	3.74	69.88	8.05	4.19	3.64	1.86	1.73	1.05	0.42	0.12

下载: 导出CSV

表 2 原矿主要矿物组成分析结果

Table 2. Analysis results of main mineral composition of raw ores /%

矿物	石墨	石英	斜长石	白云母	黄铁矿	透辉石	黑云母	其他
含量	3~4	55~60	15~20	3~5	3~5	1~2	1~3	<1

下载: 导出CSV

表 3 原矿石墨鳞片片径统计表

Table 3. Graphite flake diameter statistics of raw ores

片径/mm	−0.147	−0.175+0.147	−0.287+0.175	+0.287
分布率/%	2.81	2.63	15.68	78.88

下载: 导出CSV

表 4 原矿石墨鳞片厚度统计表

Table 4. Graphite flake thickness statistics of raw ores

厚度/mm	−0.010	−0.030+0.010	−0.050+0.030	+0.050
分布率/%	3.00	40.88	35.30	20.82

下载: 导出CSV

表 5 高压辊磨和球磨磨矿产品粒度组成对比

Table 5. Comparison of particle size composition of high pressure roller mill and ball mill grinding products

粒级/mm	高压辊磨机产品			球磨机产品
粒级/mm	产率/%	碳品位/%	碳分布率/%	产率/%	碳品位/%	碳分布率/%
+0.300	24.39	4.04	26.73	12.24	14.40	48.30
−0.300+0.150	35.60	5.07	48.95	39.74	2.96	32.23
−0.150+0.074	20.81	3.05	17.21	29.61	1.81	14.69
−0.074+0.045	8.71	1.89	4.47	8.04	1.18	2.60
−0.045+0.030	5.12	1.09	1.51	4.36	0.61	0.73
−0.030	5.37	0.78	1.13	6.01	0.88	1.45
原矿	100.00	3.69	100.00	100.00	3.65	100.00

下载: 导出CSV

表 6 浮选−分质分级试验结果

Table 6. Flotation classification grading test results

产品名称	粒级	高压辊磨机			球磨机
产品名称	粒级	产率/%	碳品位/%		产率/%	碳品位/%
粗粒低碳	+0.15 mm	77.14	19.60	19.35	62.59	18.60	15.69
粗粒低碳	−0.15 mm	22.86	18.50	19.35	37.41	10.82	15.69
中粒中碳	+0.15 mm	54.19	74.50	75.92	53.52	67.76	66.20
中粒中碳	−0.15 mm	45.81	77.61	75.92	46.48	64.40	66.20
细粒高碳	+0.15 mm	42.07	84.40	82.14	45.76	82.02	76.93
细粒高碳	−0.15 mm	57.93	80.49	82.14	54.24	72.63	76.93

下载: 导出CSV

表 7 分质产品二段再磨再选精矿产品结果

Table 7. Concentrate product results of two-stage regrinding and reconcentration of quality products /%

产品名称	给矿固定碳含量	精矿固定碳含量	精矿回收率
粗粒低碳再选精矿和中粒中碳产品	70.18	98.11	88.31
细粒高碳产品	82.14	97.70	85.72

下载: 导出CSV

表 8 闭路试验结果

Table 8. Results of closed-circuit test

产品名称	常规粗精矿混目再磨再选工艺			层压粉碎—分质分选新工艺
产品名称	产率/%	固定碳含量/%	回收率/%	产率/%	固定碳含量/%	回收率/%
+0.3 mm精矿	0.96	95.82	24.48	1.09	97.43	27.26
−0.30+0.15 mm精矿	1.52	95.50	38.62	1.38	96.44	34.17
−0.15 mm精矿	1.35	94.41	33.91	1.38	95.09	33.87
精矿合计	3.83	95.20	97.01	3.85	96.24	95.30
总尾矿	96.17	0.12	2.99	96.15	0.19	4.70
原矿	100.00	3.76	100.00	100.00	3.76	100.00

下载: 导出CSV
