聚环氧琥珀酸在氟碳铈矿与萤石浮选分离中的选择性抑制作用机理研究

郭春雷; 刘婷; 刘程宏; 王维维; 笪宗扬

doi:10.13779/j.cnki.issn1001-0076.2025.03.003

聚环氧琥珀酸在氟碳铈矿与萤石浮选分离中的选择性抑制作用机理研究

1.
白云鄂博稀土资源研究与综合利用全国重点实验室，内蒙古包头 014060

2.
鞍钢集团矿业设计研究院有限公司，辽宁鞍山 114001

基金项目: 国家重点研发计划项目（2022YFC2905300）；内蒙古自治区自然科学基金项目（2023LHMS05050）

详细信息

通讯作者: 郭春雷（1988—），男，山西晋城人，硕士，高级工程师，研究方向为白云鄂博矿资源综合利用，E-mail：regcl@brire.com。

中图分类号: TD923⁺.14；TD955

收稿日期: 2025-02-07

刊出日期: 2025-06-15

Selective Depression Effect and Mechanism of Polyepoxy Succinic Acid in the Flotation Separation of Bastnaesite and Fluorite

1.
National Key Laboratory for Research and Comprehensive Utilization of Baiyun Obo Rare Earth Resources, Baotou 014060, Inner Mongolia, China

2.
Ansteel Group Mining Design and Research Institute Co., Ltd., Anshan 114001, Liaoning, China

More Information

Corresponding author: GUO Chunlei, regcl@brire.com

Received Date: 07 February 2025

Publish Date: 15 June 2025

摘要

摘要:
稀土浮选中氟碳铈矿与萤石因表面化学性质相似而导致分离较为困难。以聚环氧琥珀酸[PESA，（C₄H₄O₅）_n]为选择性抑制剂，通过单矿物和实际矿石（白云鄂博磁选铁尾矿）浮选实验考察了其对氟碳铈矿和萤石可浮性的影响，并采用Zeta电位、傅里叶变换红外光谱（FTIR）、X射线光电子能谱（XPS）等分析了其作用机理。浮选实验结果表明：在单矿物浮选条件下，以油酸钠（NaOL）为捕收剂，氟碳铈矿和萤石的回收率均在90%以上；采用40 mg/L PESA为抑制剂时，氟碳铈矿的回收率为98.65%，而萤石的回收率几乎降至零。在实际矿石浮选时，以P8为捕收剂、水玻璃和PESA为抑制剂、2^#油为起泡剂，获得了REO、CaO含量分别为57.27%、4.50%，REO回收率为52.10%的稀土精矿；与未添加PESA相比，稀土精矿中REO含量提高了1.92百分点，而CaO含量则降低了5.48百分点。机理分析结果表明：添加PESA后，氟碳铈矿的Zeta电位发生了负移，但红外吸收峰及表面原子的结合能偏移不显著，其在氟碳铈矿表面的吸附主要是物理吸附，化学吸附较弱，NaOL仍然可吸附到氟碳铈矿表面，使其保持良好的可浮性；而萤石的Zeta电位、红外吸收峰及表面原子的结合能均发生了明显的偏移，其在萤石表面的吸附作用存在化学键合作用，阻碍了NaOL在萤石表面的吸附，使其可浮性显著降低。该研究为氟碳铈矿与萤石的高效浮选分离提供了新的药剂制度参考。
- 聚环氧琥珀酸 /
- 抑制剂 /
- 氟碳铈矿 /
- 萤石 /
- 浮选
Abstract:
The separation of bastnaesite from fluorite during the flotation process of rare earth minerals presents significant challenges due to the similarities in their surface chemical properties. This study investigates the effectiveness of polyepoxysuccinic acid (PESA, C₄H₄O₅)_n) as a selective depressant, and assesses its effect on the floatability of bastnaesite and fluorite through both single mineral and actual ore flotation experiments, specifically using magnetic separation of iron tailings from Baiyun Obo. The underlying mechanisms were investigated using Zeta potential measurements, Fourier−transform infrared spectroscopy (FTIR), and X−ray photoelectron spectroscopy (XPS). The results of flotation experiment indicate that, under single mineral flotation conditions with sodium oleate (NaOL) as the collector, recoveries of both bastnaesite and fluorite exceed 90%. When 40 mg/L of PESA is used as an inhibitor, the recovery of bastnaesite reaches 98.65%, while the recovery of fluorite drops to almost zero. In practical ore flotation scenarios, employing P8 as the collector, together with water glass and PESA as the inhibitors, and 2^# oil as the frother, results in a rare earth concentrate with rare earth oxide (REO) and CaO contents of 57.27% and 4.50%, respectively, achieving a recovery rate of 52.10%. The introduction of PESA contributes to an increase of 1.92 percentage points in the REO content of the concentrate, and a reduction of 5.48 percentage points in CaO content compared to conditions without PESA. Mechanistic analyses indicate that the introduction of PESA results in a negative alteration of the Zeta potential of bastnaesite; however, no significant changes are observed in the infrared absorption peaks or the binding energy of the surface atoms. The adsorption occurring on the bastnaesite surface is predominantly characterized as physical adsorption, with limited evidence of chemical adsorption. Consequently, NaOL continues to adsorb on the bastnaesite surface, thereby maintaining its favorable floatability. In contrast, the Zeta potential, infrared absorption peaks, and binding energy of the surface atoms of fluorite show significant changes, suggesting a chemical bonding effect during the adsorption process on the fluorite surface. This effect inhibits the adsorption of NaOL on fluorite, resulting in a marked decrease in its floatability. This study provides new insights into the reagent scheme for effective separation of bastnaesite and fluorite.
- polyepoxysuccinic acid /
- depressant /
- bastnaesite /
- fluorite /
- flotation

HTML全文

图 1 氟碳铈矿（a）和萤石（b）样品的XRD谱

Figure 1.

下载: 全尺寸图片幻灯片

图 2 实际矿石浮选的工艺流程

Figure 2.

下载: 全尺寸图片幻灯片

图 3 pH对氟碳铈矿和萤石可浮性的影响

Figure 3.

下载: 全尺寸图片幻灯片

图 4 NaOL用量对氟碳铈矿和萤石可浮性的影响

Figure 4.

下载: 全尺寸图片幻灯片

图 5 PESA用量对氟碳铈矿和萤石可浮性的影响

Figure 5.

下载: 全尺寸图片幻灯片

图 6 pH值对氟碳铈矿Zeta电位的影响

Figure 6.

下载: 全尺寸图片幻灯片

图 7 pH值对萤石Zeta电位的影响

Figure 7.

下载: 全尺寸图片幻灯片

图 8 氟碳铈矿经PESA处理前后的FTIR结果

Figure 8.

下载: 全尺寸图片幻灯片

图 9 萤石经PESA处理前后的FTIR结果

Figure 9.

下载: 全尺寸图片幻灯片

图 10 氟碳铈矿经PESA处理前后的C 1s（a）、O 1s（b）和Ce 3d（c）XPS精细谱

Figure 10.

下载: 全尺寸图片幻灯片

图 11 萤石经PESA处理前后的C 1s（a）、O 1s（b）和Ca 2p（c）XPS精细谱

Figure 11.

下载: 全尺寸图片幻灯片

表 1 氟碳铈矿样品的化学多元素分析结果

Table 1. Multi−element chemical analysis of bastnaesite sample /%

化学成分	REO	CaO	F	TFe	Al₂O₃
含量	70.94	2.30	7.77	0.26	<0.05

下载: 导出CSV

表 2 氟碳铈矿样品的配分分析结果

Table 2. Distribution analysis of rare earth elements in bastnaesite ore samples /%

稀土配分	REO	Y₂O₃	La₂O₃	CeO₂	Pr₆O₁₁	Nd₂O₅	Sm₂O₃	Eu₂O₃
含量	70.94	0.18	31.40	48.95	4.51	13.13	1.14	0.22

稀土配分	Gd₂O₃	Tb₄O₇	Dy₂O₃	Ho₂O₃	Er₂O₃	Tm₂O₃	Yb₂O₃	Lu₂O₃
含量	0.42	<0.10	<0.10	<0.10	<0.10	<0.10	<0.10	<0.10

下载: 导出CSV

表 3 萤石样品的化学多元素分析

Table 3. Multi−element chemical analysis of fluorite sample /%

化学成分	F	CaO	BaO	REO	TFe	MgO
含量	46.45	68.25	0.98	1.51	0.19	<0.10

下载: 导出CSV

表 4 铁尾矿样品的化学多元素分析结果

Table 4. Multi−element chemical analysis of iron beneficiation tailings sample /%

化学成分	REO	TFe	CaO	BaO	SiO₂	Al₂O₃	P₂O₅	F	MgO	Nb₂O₅
含量	9.34	9.78	25.26	4.50	14.52	0.83	3.40	16.15	3.44	0.13

下载: 导出CSV

表 5 铁尾矿样品中主要矿物的含量

Table 5. Content of major minerals in iron tailings sample /%

矿物	氟碳铈矿	独居石	萤石	辉石	石英	云母	黄铁矿
含量	6.93	3.81	26.37	12.87	6.16	6.06	1.47

矿物	长石	闪石	磁铁矿	磷灰石	重晶石	白云石	方解石
含量	2.19	6.17	2.66	4.63	4.68	7.65	3.41

下载: 导出CSV

表 6 铁尾矿浮选实验结果

Table 6. Flotation test results for iron tailings /%

产品名称	抑制剂	产率	品位		回收率
产品名称	抑制剂	产率	REO	CaO	REO	CaO
稀土精矿	添加PESA	8.49	57.27	4.50	52.10	1.51
稀土精矿	未添加 PESA	8.86	55.35	9.98	52.50	3.50
尾矿	添加PESA	91.51	4.89	27.19	47.90	98.49
尾矿	未添加 PESA	91.14	4.87	26.75	47.50	96.50
给矿		100.00	9.34	25.26	100.00	100.00

下载: 导出CSV
