Application of X-ray Powder Diffraction and Inductively Coupled Plasma-Mass Spectrometry in Study on Mineralogical Characteristics and Significance of Wolframite from Xihuashan Tungsten Deposit, Jiangxi Province
-
摘要:
目前针对江西大型黑钨矿石英脉型钨矿床西华山的黑钨矿矿物学特征及指示意义研究较少.本文利用X射线粉晶衍射分析和电感耦合等离子体质谱分析技术对黑钨矿晶体结构、化学成分特征及空间变化规律开展研究.获得黑钨矿晶胞参数为a0=0.477 nm, b0=0.573 nm, c0=0.498 nm, β=90°21', 属于锰钨铁矿, 与前人得出的黑钨矿晶胞参数略有不同, 代表不同元素对铁锰的类质同象替代.主要化学成分WO3、FeO、MnO的含量在空间上具有一定的变化规律, 反映了成矿物质的运移特征.微量元素Sc、Y、Nb、Ta在垂向含量变化大, 说明矿液运移具有复杂性.稀土总量ΣREEs较高(397.16×10-6~1071.11×10-6), 具有强烈的Eu负异常, 具重稀土富集左倾的"躺椅式"球粒陨石标准化配分模式.将西华山、盘古山、淘锡坑、大吉山4个典型矿床的黑钨矿稀土元素特征进行对比, 反映产在花岗岩内接触带的黑钨矿的稀土总量(ΣREEs)相对最高, 分馏最明显; 产在花岗岩内及其外接触带的黑钨矿的稀土总量(ΣREEs)相对较低, 分馏程度最不明显; 而产在花岗岩外接触带的黑钨矿的稀土总量(ΣREEs)有高有低, 分馏程度有强有弱.因此, 黑钨矿的化学成分变化特征, 可以有效地指示成矿物质空间运移特征、物质来源和矿床成因.
-
关键词:
- 西华山钨矿床 /
- 黑钨矿 /
- 矿物学 /
- X射线粉晶衍射法 /
- 电感耦合等离子体质谱法
Abstract:The Xihuashan tungsten deposit is a typical large quartz-vein type tungsten deposit with systematical study, but researches on chemical composition and spatial distribution regulation of wolframite are relatively less. Based on microscopic mineralogy, the crystal structure, chemical composition, REEs and trace elements, geochemical characteristics of wolframite selected from different levels of Xihuashan tungsten deposit were studied using X-ray Powder Diffraction and Inductively Coupled Plasma-Mass Spectrometry. The obtained lattice parameters of a0(0.477nm), b0(0.573 nm), c0(0.498 nm), β (90°21') showed that the wolframite belongs to manganese tungsten ore. It is lightly different from lattice parameters of previous studies, which is caused primarily by isomorphous substituting on Fe and Mn. The chemical components of wolframite contain mainly WO3, FeO and MnO, showing some regularity in space, indicating migration features of ore-forming material. The wolframite also contains multiple kinds of trace elements. Sc, Y, Nb and Ta show dynamic changes of content in the vertical direction, which reflect complexity of ore fluid migration. The chondrite-standardized REEs distribution patterns are characterized by left-leaning shapes with high ΣREEs (397.16×10-6-1071.11×10-6), relatively heavy REEs enrichment and strong Eu negative anomaly. By comparing the REEs characteristics of wolframite from four typical tungsten deposits including Xihuashan, Pangushan, Taoxikeng and Dajishan, the results show that the wolframite in the inner contact zone of the granite body is characterized by relatively high ΣREEs with obvious REEs fractionation. Wolframite in the inner granite body and outer contact zone is characterized by relatively low ΣREEs with unobvious REEs fractionation. Wolframite in the outer contact zone of the granite body is characterized by large changes of ΣREEs and REEs contents and fractionation. Wolframite composition characteristics can not only be used to indicate migration features of ore-forming material in space, but also to discriminate ore-forming material sources and ore genesis.
-
-
表 1 西华山钨矿床黑钨矿X射线粉晶衍射测试结果
Table 1. The X-ray powder diffraction data of wolframite from Xihuashan tungsten deposit
序号 样品XHS186-1 样品XHS538-5 2θ(°) d(A) I(%) 2θ(°) d(A) I(%) 1 15.476 5.7207 41.9 15.436 5.7355 35.6 2 18.580 4.7716 17.9 18.541 4.7814 22 3 23.658 3.7577 17.2 23.601 3.7665 23.7 4 24.260 3.6658 19.4 24.221 3.6716 29.8 5 30.320 2.9454 53.3 30.298 2.9475 77.3 6 31.202 2.8642 100 31.162 2.8678 100 7 36.141 2.4833 19 36.098 2.4861 29.7 8 37.679 2.3854 5.4 37.659 2.3866 9.8 9 40.701 2.2150 4.1 40.960 2.2015 20.9 10 43.799 2.0652 1.5 43.998 2.0563 4.9 11 45.084 2.0093 4.9 45.078 2.0095 5.3 12 47.580 1.9095 17.2 47.540 1.9110 22.5 13 48.397 1.8792 3.9 48.341 1.8812 8.4 14 49.698 1.8330 4.1 49.663 1.8342 9.3 15 51.499 1.7731 22.7 51.478 1.7737 33.3 16 53.321 1.7167 13.2 53.298 1.7141 26.6
下载: 导出CSV
表 2 西华山钨矿床黑钨矿微量元素和稀土元素含量
Table 2. Analytical results of trace elements and REEs of wolframite from Xihuashan tungsten deposit by ICP-MS
元素 各样品元素含量(×10-6) XHS538-2a
(标高538 m)XHS538-5a
(标高538 m)XHS270-1c
(标高270 m)XHS215-1a
(标高215 m)XHS186-1b
(标高186 m)Li 11.5 19.14 4.05 3.757 3.852 Be 1.71 0.617 0.383 0.403 0.948 Sc 87.1 658.1 160.1 408.4 406.8 V 0.298 0.792 0.336 0.544 0.594 Cr 2.268 2.43 2.383 2.065 2.239 Co 9.322 9.168 8.693 10.11 8.939 Ni 7.474 7.64 8.022 6.847 7.648 Cu 9.962 3.351 103.7 43.01 13 Zn 122.1 117.9 276.3 104.4 116 Ga 9.676 8.51 9.112 6.167 7.131 Rb 10.45 12.1 11.68 10.07 11.01 Sr 4.288 14.67 8.583 6.803 15.24 Y 383.1 613.3 259.6 392.8 378.5 Zr 9.943 73.33 12.12 28.94 28.32 Nb 3.877 77.87 3.809 10.13 18.97 Cd 3.468 0.589 3.612 0.53 0.93 In 13.21 28.2 13.76 17.24 20.45 Cs 0.3 0.316 0.369 0.274 0.345 Ba 1.084 0.941 1.435 1.079 0.979 La 1.358 0.909 1.642 0.512 0.916 Ce 2.507 2.484 4.973 2.072 3.132 Pr 0.538 0.531 0.74 0.427 0.536 Nd 3.559 4.237 3.877 3.044 3.158 Sm 4.582 10.01 4.359 5.937 5.527 Eu 0.029 0.049 0.035 0.068 0.082 Gd 16.02 32.22 12.66 19.8 18.74 Tb 6.703 15.93 6.01 9.907 9.353 Dy 73.2 180.4 67.85 113.5 106.9 Ho 19.92 49.26 18.48 30.82 29.26 Er 81.66 212.6 78.06 129.2 120.7 Tm 17.72 48.17 17.35 28.33 25.84 Yb 158.2 446.9 157.8 257.3 225.5 Lu 23.69 67.41 23.32 37.04 31.61 Hf 0.86 5.299 0.906 2.148 2.131 Ta 0.638 14.38 0.928 1.374 2.169 Pb 2.432 2.223 695.2 0.708 5.9 Bi 2.35 0.198 438.8 0.581 28.07 Th 0.24 1.585 2.53 0.808 1.068 U 5.495 37.33 9.385 17.14 19.72 ΣREEs 409.69 1071.11 397.16 637.96 581.25 LREEs 12.57 18.22 15.63 12.06 13.35 HREEs 397.11 1052.89 381.53 625.9 567.9 LREEs 0.03 0.02 0.04 0.02 0.02 HREEs La N/Yb N 0.0058 0.0014 0.0070 0.0013 0.0027 δEu 0.01 0.01 0.01 0.02 0.02 δCe 0.69 0.82 1.05 0.96 1.02
下载: 导出CSV
表 3 黑钨矿晶胞参数
Table 3. Unit cell parameter data of wolframite
地区 类型 a0(nm) b0(nm) c0(nm) β 资料来源 西华山钨矿186中段248矿脉 锰钨铁矿 0.477 0.573 0.498 90°15′ 本文实测 西华山钨矿538中段248矿脉 锰钨铁矿 0.477 0.573 0.499 90°27′ 盘古山钨矿215中段盲3矿体 锰钨铁矿 0.477 0.572 0.496 90°17′ 文献[21] 盘古山钨矿335中段39号脉 锰钨铁矿 0.477 0.573 0.499 90°26′ 淘锡坑钨矿宝山056中段VN3脉 锰钨铁矿 0.478 0.574 0.499 90°30′ 文献[21] 淘锡坑钨矿宝山356中段V11脉 锰钨铁矿 0.477 0.573 0.498 90°28′ 赣南地区
(李秉伦和刘义茂，1965)铁钨锰矿 0.4780±0.0008 0.5744±0.0009 0.4970±0.0009 90°28′±6′ 文献[22] 钨铁锰矿 0.4758±0.0005 0.5730±0.001 0.4960±0.001 90°10′±8′ 锰钨铁矿 0.4758±0.0003 0.5700±0.001 0.4953±0.0009 90°4′±6′ 其他地区
(E.V.布洛奇，1929)MnWO4 0.484 0.576 0.497 90°53′ 文献[22] 钨锰矿 0.482 0.576 0.497 90°53′ 钨锰铁矿 0.478 0.573 0.498 90°26′ 钨铁矿 0.471 0.569 0.495 90°00′ FeWO 4 0.470 0.569 0.493 90°00′
下载: 导出CSV
表 4 西华山钨矿床V29脉黑钨矿化学成分
Table 4. The chemical composition of V29 wolframite from Xihuashan tungsten deposit
中段(样品数) 项目 WO3 FeO MnO CaO Nb2O5 Ta2O5 Sc2O3 670(1) 测定值(%) 74.68 14.03 9.16 0.38 0.45 0.05 0.06 632(4) 含量范围(%) 74.40~75.47 12.86~14.01 9.82~10.97 0.04~0.15 0.41~0.45 0.06~0.08 0.04~0.06 平均值(%) 75.13 13.46 10.42 0.10 0.44 0.07 0.02 594(6) 含量范围(%) 74.40~75.52 7.07~14.54 9.54~10.97 约0.28 0.5~1.05 0.06~0.30 约0.024 平均值(%) 74.79 12.29 10.33 0.05 0.73 0.16 0.00 583(6) 含量范围(%) 73.95~75.29 12.34~13.06 10.27~11.23 0.09~1.95 0.478~1.08 0.07~0.21 约0.09 平均值(%) 74.67 12.72 10.60 0.52 0.76 0.12 0.01 483(8) 含量范围(%) 72.51~75.36 11.66~14.15 9.84~11.72 0.04~2.00 0.54~1.05 0.09~0.33 约0.06 平均值(%) 74.40 13.01 10.29 0.48 0.79 0.17 0.01 注：数据来源于文献[12]
下载: 导出CSV
-
[1] [2] [3] [4] doi: 10.1007/BF01167286
[5] [6] [7] [8] [9] [10] [11] [12] [13] [14] [15] [16] [17] [18] [19] [20] [21] 于萍. 江西盘古山钨矿矿物学特征研究[D]. 西安: 长安大学, 2012.
Yu P. The Research on the Mineralogical Characteristics of Tungsten Deposit in Pangushan, JiangXi[D]. Xi'an: Chang'an University, 2012.
[22] [23] [24] [25] [26] [27] [28] [29] [30] 黑欢. 赣南地区淘锡坑钨矿床地质特征及成矿作用研究[D]. 西安: 长安大学, 2012.
Hei H. The Research on the Geological Characteristics and Mineralization of Taoxikeng Tungsten Deposit, South Jiangxi[D]. Xi'an: Chang'an University, 2012.
[31] 张思明. 江西省大吉山钨矿床的矿物学研究及矿床特征[D]. 北京: 中国地质大学, 2012.
Zhang S M. A Dissertation Submitted to China University of Geosciences for Master Degree[D]. Beijing: China University of Geosciences (Beijing), 2012.
