The Relationship between Heavy Metal Contents of Soils and Rice in Coastal Areas, Fujian Province, including Influencing Factors
-
摘要: 福建沿海地区土壤Pb含量远高于我国其他地区及全国背景值,其对农产品安全、生态环境的影响值得关注。本文采集该地区典型耕作区58套土壤-水稻样品,查明Pb、Cd等重金属元素含量特征及其关键控制因素。研究表明从水稻根→茎叶→稻谷,重金属元素含量和富集系数呈现明显的下降趋势,有害重金属As、Pb等的递减速率远大于植物营养元素Cu、Zn,指示水稻根部对重金属元素具有一定的阻截作用。土壤-稻谷间Pb具有显著正相关性,显示土壤Pb是稻谷Pb的重要来源;稻谷Pb含量与土壤有机碳呈负相关关系,与土壤pH呈弱负相关关系,说明富含有机碳、相对碱性的土壤环境可降低土壤Pb的生物有效性,减少稻谷对土壤Pb的吸收富集。土壤理化条件对稻谷Cd富集系数有显著影响,富含有机碳、Al2O3、Fe2O3、CaO、MgO、S的土壤条件有利于阻断稻谷对土壤Cd的吸收,降低土壤Cd污染的生态风险。本项研究为开展水田土壤重金属污染治理修复、预测稻谷食用安全提供了依据。Abstract: Lead content of soil in coastal areas of Fujian Province is higher than that of soil in other areas and in the background level of China, and is therefore of significant influence on food safety and the ecological environment. Based on Pb and Cd contents of 58 suites of soil and rice samples, the characteristic of content and its influencing factors are discussed. Results show that the concentrations and BCF values of heavy metals decrease rapidly from root to stem leaf to rice, and concentrations of toxic elements like arsenic and lead decrease more obviously than those of plant nutrients such as copper and zinc, indicating that rice root has a barrier effect for toxic element uptake. Lead content of rice is positively correlated with that of soil, indicating the soil is the main source of lead in rice. Lead content of rice is negatively correlated with organic carbon contents and pH of soil. This indicates that the abundance of organic carbon and neutral-alkaline soil conditions may reduce bioavailability of lead in soils. The bio-concentration factor of cadmium has a good correlation with physicochemical conditions of soil. Abundance of organic carbon, Al2O3, Fe2O3, CaO, MgO and S can hinder the uptake of cadmium by rice and reduce its eco-risk. This research provides the foundation for restoring paddy fields polluted by heavy metals and contributes in predicting the impact of heavy metal pollution of soil on the safety of rice.
-
Key words:
- rice /
- soil /
- heavy metal content /
- BCF /
- influencing factors /
- coastal areas in Fujian Province
-
-
表 1 水稻样品分析方法、检出限及其分析质量
Table 1. Analytical methods, detection limits and analytical quality for vegetable samples
指标 提取方法 检测方法 方法检出限(mg/kg) 报出率 (%) 标样|RE|最大值*(%) 双份分析|RE|最大值**(%) 合格率(%) As 微波消解 ICP-MS 0.03 100 6.81 15.42 100 Cd 微波消解 ICP-MS 0.002 100 1.93 15.46 100 Cr 微波消解 ICP-MS 0.005 100 5.33 13.85 100 Cu 微波消解 ICP-MS 0.005 100 2.47 13.32 100 Hg 微波消解 ICP-MS 0.0005 100 1.32 15.03 100 Ni 微波消解 ICP-MS 0.005 100 0.60 14.11 100 Pb 微波消解 ICP-MS 0.005 100 4.35 15.55 100 Se 微波消解 ICP-MS 0.01 100 4.79 17.81 100 Zn 微波消解 ICP-OES 0.05 100 2.60 14.61 100 F 扩散法 ISE 0.5 100 20.18 13.33 100 注：*表示插入标样9件，插入标样分析相对误差绝对值要求低于10%；**表示水稻根、茎叶、稻谷样品各58件全部进行双份分析，即重复分析样174件，其相对误差绝对值要求低于20%。
下载: 导出CSV
表 2 土壤样品分析方法、检出限及其分析质量
Table 2. Analytical methods, detection limits and analytical quality for soil samples
指标 检测方法 方法检出限 报出率(%) 一级标准物质合格率(%) 重复样合格率(%) SiO2 XRF 0.1% 100 100 100 Al2O3 XRF 0.1% 100 100 100 TFe2O3 XRF 0.1% 100 100 100 MgO XRF 0.05% 100 100 100 CaO XRF 0.05% 100 100 100 Na2O XRF 0.05% 100 100 100 K2O XRF 0.05% 100 100 100 CEC 乙酸铵交换法 0.25 cmol(+)/kg 100 100 100 pH 电位法 0.1 100 100 100 有机碳 POT 0.1% 100 100 100 As HG-AFS 0.2 mg/kg 100 100 100 Cd ICP-MS 20 ng/g 100 100 100 Cr XRF 2 mg/kg 100 100 100 Cu ICP-MS 1 mg/kg 100 100 100 Hg CV-AFS 2 ng/g 100 100 100 Ni ICP-MS 2 mg/kg 100 100 100 Pb ICP-MS 2 mg/kg 100 100 100 Se HG-AFS 0.01 mg/kg 100 100 100 Zn ICP-MS 2 mg/kg 100 100 100 注：XRF为压片-X射线荧光光谱法；POT为氧化热解-电位法；HG-AFS为氢化物-原子荧光光谱法；CV-AFS为冷蒸气-原子荧光光谱法。
下载: 导出CSV
表 3 水稻土重金属含量统计参数及超标情况(n=58)
Table 3. Statistical parameters of heavy metal concentration in paddy soils (n=58)
项目 As Cd Cr Cu Hg Ni Pb Zn pH 平均值 6.8 210 35 27.5 315 15.1 68 122 5.8 中位数 6.7 200 33 25.4 175 14.3 62 117 5.8 标准差 5.6 100 16 16.3 329 8.0 30 51 0.8 变异系数 0.81 0.47 0.46 0.59 1.04 0.53 0.45 0.42 0.13 最小值 0.9 72 11 7.2 35 3.5 20 27 4.5 最大值 43.0 738 87 119.0 1612 38.5 205 353 7.8 超标样数* 1 6 0 2 16 0 0 4 超标率(%) 1.7 10.3 0 3.4 27.6 0 0 6.9 注：Cd、Hg单位为ng/g，其他为mg/kg。超标是指其含量大于土壤环境质量评价标准(GB15618—1995)中水田土壤二级标准值。
下载: 导出CSV
表 4 水稻根、茎叶、稻谷中重金属含量及其统计特征(n=58)
Table 4. The mean values of heavy metal content in root, stem leaf and rice (n=58)
项目 介质 As Cd Cr Cu Hg Ni Pb Se Zn 平均值 稻谷 0.14 0.15 0.25 6.14 0.006 0.67 0.17 0.060 34.13 茎叶 1.32 0.61 0.53 23.93 0.028 0.39 1.77 0.203 101.22 稻根 9.28 1.07 1.42 31.43 0.030 1.17 10.72 0.242 121.26 稻谷安全标准 - 0.2 1 0.02 0.2 稻谷超标率(％) - 20.7 0 0 17.2 富集系数 稻谷 0.03 0.81 0.009 0.28 0.04 0.064 0.003 0.27 0.34 茎叶 0.26 3.42 0.019 1.09 0.19 0.038 0.026 0.89 0.98 稻根 1.59 5.85 0.048 1.43 0.18 0.094 0.168 1.03 1.26 注：Cd、Hg单位为ng/g，其他为mg/kg。
下载: 导出CSV
-
[1] Demetriades A,Birke M,Albanese S,et al.Continental,Regional and Local Scale Geochemical Mapping[J].Journal of Geochemical Exploration,2015,154:1-5.
[2] 张慧敏,王丽平,章明奎.城市土壤不同颗粒中重金属的分布及其对人体吸入重金属的影响[J].广东微量元素科学,2007,14(7):14-19.
Zhang H M,Wang L P,Zhang M K.Metal Distribution in Various Particle Fractions of Urban Soils and Its Relation to Soil Ingestion by Man[J].Guangdong Trace Elements Science,2007,14(7):14-19.
[3] 李坤权,刘建国,陆小龙,等.水稻不同品种对镉的吸收及分配的差异[J].农业环境科学报,2003,22(5):529-532.
Li K Q,Liu J G,Lu X L,et al.Uptake and Distribution of Cadmium in Different Rice Cultivars[J].Journal of Agro-Environment Science,2003,22(5):529-532.
[4] 刘建国,李坤权,张祖建,等.水稻不同品种对铅的吸收、分配的差异及机理[J].应用生态学报,2004,15(2):291-294.
Liu J G,Li K Q,Zhang Z J,et al.Difference of Lead Uptake and Distribution in Rice Cultivars and Its Mechanism[J].Chinese Journal of Applied Ecology,2004,15(2):291-294.
[5] Gabrielson J,Kühn I.Microplate-based Microbial Assay for Risk Assessment and (Eco)toxic Finger Printing of Chemicals[J].Analytica Chimica Acta,2003,485:121-130.
[6] 关天霞,何红波,张旭东,等.土壤中重金属元素形态分析方法及形态分布的影响因素[J].土壤通报,2011,42(2):503-512.
Guan T X,He H B,Zhang X D,et al.The Methodology of Fractionation Analysis and the Factors Affecting the Species of Heavy Metals in Soil[J].Chinese Journal of SoilScience,2011,42(2):503-512.
[7] 胡红青,陈松,李妍,等.几种土壤的基本理化性质与Cu2+吸附的关系[J].生态环境,2004, 13(4):544-545.
Hu H Q,Chen S,LI Y,et al.Heavy Metal Distribution along the Tibet Railroad[J].Ecology and Environment,2004,13(4):544-545.
[8] 周国华.土壤重金属生物有效性研究进展[J].物探与化探,2014,38(6):1097-1106.
Zhou G H.Recent Advances of Heavy Metal Bioavailability in Soil[J].Geophysical ＆ Geochemical Exploration,2014,38(6):1097-1106.
[9] 林才浩,许美辉,杨军华.福建省沿海经济带生态地球化学调查与评价[J].地质通报,2007,26(5):605-612.
Lin C H,Xu M H,Yang J H.Eco-geochemical Investigations and Assessments of the Coastal Economic Zone of Fujian Province,China[J].Geological Bulletin of China,2007,26(5):605-612.
[10] 柳检,罗立强.As、Cd和Pb植物根系吸收途径和影响因素研究现状与进展[J].岩矿测试,2015,34(3):269-277.
Liu J,Luo L Q.Research Progress on Root Uptake Pathway of As,Cd and Pb and Its Influence Factors [J].Rock and Mineral Analysis,2015,34(3):269-277.
[11] 杨金燕,杨肖娥,何振立.土壤中铅的来源及生物有效性[J].土壤通报,2005,356:765-772.
Yang J Y,Yang X E,He Z L.Resource and Bio-availability of Lead in Soil[J].Chinese Journal of Soil Science,2005,356:765-772.
[12] 鄢明才,迟清华.中国东部地壳与岩石的化学组成[J].物探与化探,1997,21(6):451-459.
Yan M C, Chi Q H.Chemical Compositions of Continental Crust and Rocks in Eastern China[J].Geophysical ＆ Geochemical Exploration,1997,21(6):451-459.
[13] 王芳,李恋卿,潘根兴.黄土泥不同粒径微团聚体对Cd2+的吸附与解吸研究[J].环境科学,2006,27(3):590-593.
Wang F,Li L Q,Pan G X.Sorption and Desorption of Cd2+ by Size Fractions of Micro-aggregates from a Paddy Soil[J].Environmental Science,2006,27(3):590-593.
[14] 谢丹,徐仁扣,蒋新,等.有机酸对Cu,Pb,Cd在土壤表面竞争吸附的影响[J].农业环境科学学报,2005,25(3):704-710.
Xie D,Xu R K,Jiang X,et al.Effect of Organic Acids on Competitive Adsorption of Cu(Ⅱ), Pb(Ⅱ) and Cd(Ⅱ) by Variable Charge Soils[J].Journal of Agro-Environment Science,2005,25(3):704-710.
[15] 周通,潘根兴,李恋卿,等.南方几种水稻土重金属污染下的土壤呼吸及微生物学效应[J].南方环境科学学报,2009,28(12):2568-2573.
Zhou T,Pan G X,Li L Q,et al.Effects of Heavy Metals on Soil Respiration and Microbial Indices in Paddy Field of South China[J].Journal of Agro-Environment Science,2009,28(12):2568-2573.
[16] 王岚,王亚平,许春雪,等.水稻土中重金属元素Cd、Pb的竞争吸附[J].地质通报,2012,31(4):601-607.
Wang L,Wang Y P,Xu C X,et al.Competitive Adsorption of Cadmium and Lead in Paddy Soils:A Case Study of Paddy Soils in Changsha-Zhuzhou-Xiangtan Area of Hunan Province[J].Geological Bulletin of China,2012,31(4):601-607.
[17] 王开峰,彭娜,王凯荣,等.长期施用有机肥对稻田土壤重金属含量及其有效性的影响[J].水土保持学报,2008,22(1):105-108.
Wang K F,Peng N,Wang K R,et al.Effects of Long-term Manure Fertilization on Heavy Metal Content and Its Availability in Paddy Soils[J].Journal of Soil and Water Conservation,2008,22(1):105-108.
[18] 利锋,张学先,戴睿志.重金属有效态与土壤环境质量标准制定[J].广东微量元素科学,2008,15(1):7-10.
Li F,Zhang X X,Dai R Z.The Bioavailability of Heavy Metal and Environmental Quality Standard for Soil[J].Guangdong Trace Elements Science,2008,15(1):7-10.
[19] 李俊莉,宋华明.土壤理化性质对重金属行为的影响分析[J].环境科学动态,2003(1):24-25.
Li J L,Song H M.The Physicochemical Property of Soil Have Effects on Behavior of Heavy Metals[J].Environmental Science Trends,2003(1):24-25.
[20] 雷鸣,廖柏寒,秦普丰.土壤重金属化学形态的生物可利用性评价[J].生态环境,2007,16(5):1551-1556.
Lei M,Liao B H,Qin P F.Assessment of Bioavailability of Heavy Metal in Contaminated Soils with Chemical Fractionation[J].Ecology and Environment,2007,16(5):1551-1556.
[21] 浦瑞丰,康尔泗,艾崇蒿,等.黑河流域农业土壤重金属人为污染的富集因子分析[J].干旱区资源与环境,2007,21(5):108-111.
Pu R F,Kang E S,Ai C H,et al.The Analysis on the Enrichment Factors of Heavy Metal Pollution in the Agricultural Soil Made by People in Heihe River Valley[J].Journal of Arid Land Resources and Environment,2007,21(5):108-111.
[22] Nicholson F A,Smith S R,Alloway B J,et al.An Inventory of Heavy Metals Inputs to Agricultural Soils in England and Wales[J].Science of the Total Environment,2003,311: 205-219.
[23] 何电源.关于稻田施用石灰的研究[J].土壤学报,1992,29(1):87-93.
He D Y.A Review About Studies Sliming Paddy Soil[J].Acta Pedologica Sinic,1992,29(1):87-93.
[24] 李波,青长乐,周正宾,等.肥料中氮磷和有机质对土壤重金属的影响及治污中的应用[J].重庆环境科学,2000(6):37-40.
Li B,Qing C L,Zhou Z B,et al.Influence of N,P and Organic Matter of Fertilizers on Heavy Metals in Soil and Its Application[J].Chongqing Environmental Science,2000(6):37-40.
[25] 孙彬彬,周国华,刘占元,等.黄河下游山东段沿岸土壤中重金属元素异常的成因[J].地质通报,2008,27(2):265-270.
Sun B B,Zhou G H,Liu Z Y,et al.Origin of Heavy Metal Anomalies in Soils along the Shandong Reach of the Lower Yellow River,China[J].Geological Bulletin of China,2008, 27(2):265-270.
[26] 陈守莉,孙波,王平祖,等.污染水稻土中重金属的形态分布及其影响因素[J].土壤,2007,39(3):375-380.
Chen S L,Sun B,Wang P Z,et al.Chemical Form Distribution of Heavy Metals in Polluted Paddy Soils and Its Influencing Factors[J].Soils,2007,39(3):375-380.
-
