Determination of Trace Rhenium in Sandstone-type Uranium Deposits by Inductively Coupled Plasma-Mass Spectrometry with Magnesium Oxide Sintering
-
摘要: 砂岩型铀矿中铀的平均含量为635 μg/g，而铼的含量仅为0.3～1.9 μg/g，由于铼的含量低，准确测定高含量铀矿样中的低含量铼仍是分析化学的一个难题。本文建立了电感耦合等离子体质谱法测定砂岩型铀矿中痕量铼的方法。样品经过氧化镁烧结，热水浸提以及采用103Rh作内标元素等方式消除了铀、钼及其他基体元素对测定铼的干扰。在最佳条件下，痕量铼的检出限可低至0.12 ng/g，回收率达99.8%。本方法通过多种标准样品验证，铼的测定值与标准值吻合，对铼含量在0.06～180.57 μg/g范围内的实际样品进行测定，相对标准偏差均小于1.5%，能够满足砂岩型铀矿等高含量铀矿中痕量铼的测定需求。
-
关键词:
- 砂岩型铀矿 /
- 铼 /
- 烧结法 /
- 电感耦合等离子体质谱法
Abstract: The average content of uranium in sandstone-type uranium deposits is 635 μg/g, whereas the content of rhenium is 0.3-1.9 μg/g. Because of low rhenium content, now precise determination of low Re in high U ores remains unresolved. In this study, a method for the determination of trace Re in sandstone-type uranium deposits by Inductively Coupled Plasma-Mass Spectrometry was developed. Samples were digested by MgO sintering, and were then extracted by hot water. 103Rh was used as the internal standard element to eliminate the interferences of uranium, molybdenum and other matrix elements on Re. Under optimum conditions, the detection limit of trace rhenium is 0.12 ng/g, and the recovery is 99.8%. The method was validated by a variety of standard samples, the measured Re contents are in good agreement with the standard values. The relative standard deviation (RSD) is less than 1.5% for Re contents of 0.06-180.57 μg/g, which meets the requirement of determining trace Re in high U ores from sandstone type uranium deposits. -
-
表 1 ICP-MS测定铼的线性范围与计数值
Table 1. The linear range of ICP-MS determination and count value of rhenium
铼标准工作溶液浓度(ng/mL) 186Re计数值 相对标准偏差(RSD，%) 0.002 43.6 8.7 0.02 469.4 2.7 0.2 4785.3 0.9 2 48282.3 0.4 20 491440.1 1.1 200 5234455.2 1.4
下载: 导出CSV
表 2 标准物质中铼含量的测定结果
Table 2. Determination results of rhenium in the standard samples
标准物质编号 铼含量的测定值(μg/g) 铼含量的标准值(μg/g) 相对误差(%) GBW07238 0.34 0.35 -2.86 GBW07239 0.13 0.12 8.33
下载: 导出CSV
表 3 矿样中铼含量的测定结果
Table 3. Determination results of rhenium in actual ore samples
样品编号 铼含量5次测量的平均值(μg/g) RSD(%) 1 180.57 1.3 2 11.78 0.6 3 36.26 0.5 4 48.63 0.4 5 0.06 0.4 6 0.09 0.4 7 17.14 0.9 8 20.95 0.9
下载: 导出CSV
-
[1] 李红梅,贺小塘,赵雨,等.铼的资源、应用和提取[J].贵金属,2014(2):77-81. http://www.cnki.com.cn/Article/CJFDTOTAL-GJSZ201402015.htm
Li H M,He X T,Zhao Y,et al.Resources,Application and Extraction Status of Rhenium[J].Precious Metals,2014(2):77-81. http://www.cnki.com.cn/Article/CJFDTOTAL-GJSZ201402015.htm
[2] 罗善霞,焦圣兵.地质样品中铼的分离和测定方法研究进展[J].冶金分析,2013,33(2):22-27. http://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201302005.htm
Luo S X,Jiao S B.Research Progress on Separation and Determination Method of Rhenium in Geological Samples [J].Metallurgical Analysis,2013,33(2):22-27. http://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201302005.htm
[3] 梁波,沈宏伟,罗明标,等.铼的分析方法研究进展[J].江西化工,2014(3):76-80. http://www.cnki.com.cn/Article/CJFDTOTAL-PROV201403025.htm
Liang B,Shen H W,Luo M B,et al.Research Progress on the Determination of Rhenium [J].Jiangxi Chemical Industry,2014(3):76-80. http://www.cnki.com.cn/Article/CJFDTOTAL-PROV201403025.htm
[4] Evdokimova O V,Pechishcheva N V,Shunyaev K Y.Up-to-Date Methods for the Determination of Rhenium[J].Journal of Analytical Chemistry,2012,67(9):741-753. doi: 10.1134/S1061934812090043
[5] Kolpakova N A,Gol L G.Determination of Rhenium in Mineral Raw Materials by Stripping Voltammetry[J]. Journal of Analytical Chemistry,2007,62(4):377-381. doi: 10.1134/S1061934807040156
[6] 周恺,孙宝莲,李波,等.高含量铼的紫外分光光度法测定研究[J].中国无机分析化学,2011,1(3):46-49. http://www.cnki.com.cn/Article/CJFDTOTAL-WJFX201103013.htm
Zhou K,Sun B L,Li B,et al.Determination of High Level Rhenium Using UV Spectrophotometry[J].Chinese Journal of Inorganic Analytical Chemistry,2011,1(3):46-49. http://www.cnki.com.cn/Article/CJFDTOTAL-WJFX201103013.htm
[7] 周煜,谭艳山,朱利亚,等.硫脲光度法测定粗铼酸钾中铼时钼干扰的消除[J].冶金分析,2013,33(9):57-60. http://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201309016.htm
Zhou Y,Tan Y S,Zhu L Y,et al.Elimination of the Interference of Molybdenum in Determination of Rhenium in Raw Potassium Rhenate by Thiourea Spectro-photometry[J]. Metallurgical Analysis,2013,33(9):57-60. http://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201309016.htm
[8] 郑文英,李君,房勇,等.硫氰酸钾光度法测定铜精矿冶炼污酸中铼[J].冶金分析,2015,35(9):68-72. http://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201509018.htm
Zheng W Y,Li J,Fang Y,et al.Determination of Rhenium in Smelting Waste Acid of Copper Concentrate by Potassium Thiocyanate Spectrophotometry[J].Metallurgical Analysis,2015,35(9):68-72. http://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201509018.htm
[9] 史谊峰,郑文英,房勇,等.丁二酮肟分光光度法测定富铼渣中铼[J].冶金分析,2015,35(12):68-72. http://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201512018.htm
Shi Y F,Zheng W Y,Fang Y,et al.Determination of Rhenium in Rhenium-rich Slag by Dimethylglyoxime Spectrophotometry[J].Metallurgical Analysis,2015,35(12):68-72. http://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201512018.htm
[10] 包生祥,王守绪,马丽丽,等.行波管用钨铼合金中高含量铼的X射线荧光光谱测定[J].光谱学与光谱分析,2005,25(3):460-462. http://www.cnki.com.cn/Article/CJFDTOTAL-GUAN200503036.htm
Bao S X,Wang S X,Ma L L,et al.X-ray Fluorescence Spectrometric Determination of High Rhenium Content in Rhenium-Tungsten Alloys Used in Traveling Wave Tube[J].Spectroscopy and Spectral Analysis,2005,25(3):460-462. http://www.cnki.com.cn/Article/CJFDTOTAL-GUAN200503036.htm
[11] 冯先进,屈太原.电感耦合等离子体质谱法(ICP-MS)最新应用进展[J].中国无机分析化学,2011,1(1):46-52.
Feng X J,Qu T Y.The Latest Application Progress of Inductively Coupled Plasma Mass Spectrometry[J].Chinese Journal of Inorganic Analytical Chemistry,2011,1(1):46-52.
[12] 任志海,夏照明,李树强.电感耦合等离子体质谱法(ICP-MS)测定钼矿石中的铼 [J].中国无机分析化学,2013,3(3):27-29.
Ren Z H,Xia Z M,Li S Q.Determination of Rhenium in Molybdenum Ores by Inductively Coupled Plasma Mass Spectrometry (ICP-MS)[J].Chinese Journal of Inorganic Analytical Chemistry,2013,3(3):27-29.
[13] 熊英,吴赫,王龙山.电感耦合等离子体质谱法同时测定铜铅锌矿石中微量元素镓铟铊钨钼的干扰消除[J].岩矿测试,2011,30(1):7-11. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20110102&flag=1
Xiong Y,Wu H,Wang L S.Elimination of Interference in Simultaneous Determination of Trace Ga,In,Ta,W and Mo in Copper,Lead and Zinc Ores by Inductively Coupled Plasma-Mass Spectrometry[J].Rock and Mineral Analysis,2011,30(1):7-11. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20110102&flag=1
[14] Liu Y S,Hu Z C,Li M,et al.Applications of LA-ICP-MS in the Elemental Analyses of Geological Samples[J].Chinese Science Bulletin,2013,58(32):3863-3878. doi: 10.1007/s11434-013-5901-4
[15] 程秀花,黎卫亮.电感耦合等离子体质谱法测定钼矿石和钼精矿中铼[J].冶金分析,2013,33(1):54-58. http://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201301012.htm
Cheng X H,Li W L.Determination of Rhenium in Molybdenum Ores and Molybdenum Concentrate by Inductively Coupled Plasma Mass Spectrometry[J].Metallurgical Analysis,2013,33(1):54-58. http://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201301012.htm
[16] Li J,Jiang X Y,Xu J F,et al.Determination of Platinum-Group Elements and Re-Os Isotopes Using ID-ICP-MS and N-TIMS from a Single Digestion after Two-stage Column Separation[J].Geostandards & Geoanalytical Research,2014,38(1):37-50. http://cn.bing.com/academic/profile?id=2011238896&encoded=0&v=paper_preview&mkt=zh-cn
[17] 熊英,吴峥,董亚妮,等.封闭消解-阳离子交换分离-电感耦合等离子体质谱法测定铜铅锌矿石中的铼 [J].岩矿测试,2015,34(6):623-628. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20150604&flag=1
Xiong Y,Wu Z,Dong Y N,et al.Determination of Rhenium in Copper-Lead-Zinc Ore by Inductively Coupled Plasma-Mass Spectrometry with Closed Decomposition and Cation Exchange Separation[J].Metallurgical Analysis,2015,34(6):623-628. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20150604&flag=1
[18] Liu Y Y,Qi L,Gao J F,et al.Determination of Rhenium and Osmium by ICP-MS for Galena and Sphalerite[J].Acta Geochimica,2015,35(1):43-49. http://cn.bing.com/academic/profile?id=2440745577&encoded=0&v=paper_preview&mkt=zh-cn
[19] 黄小文,漆亮,高剑峰.铼-锇同位素分析样品预处理研究进展[J].岩矿测试,2011,30(1):90-103. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20110120&flag=1
Huang X W,Qi L,Gao J F.A Review on Sample Preparation in Re-Os Isotopic Analysis[J].Rock and Mineral Analysis,2011,30(1):90-103. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20110120&flag=1
[20] 张艳,郝辉,雒虹.电感耦合等离子体质谱(ICP-MS)法测定矿石中的铼——三种前处理方法比较[J].中国无机分析化学,2016,6(1):34-37.
Zhang Y,Hao H,Luo H.Comparison of Three Sample Pretreatment Methods in Determination of Rhenium in Ores by ICP-MS[J].Chinese Journal of Inorganic Analytical Chemistry,2016,6(1):34-37.
[21] 李亚男,王秀琴,尹金双.砂岩型铀矿地质样品中铼的测定[J].铀矿地质,1997,13(5):304-309. http://www.cnki.com.cn/Article/CJFDTOTAL-YKDZ199705009.htm
Li Y N,Wang X Q,Yin J S.Determination of Rhenium in Sandstone-type Uranium Deposits[J].Uranium Geology,1997,13(5):304-309. http://www.cnki.com.cn/Article/CJFDTOTAL-YKDZ199705009.htm
[22] 邱朝辉,钟宏,曹占芳,等.铼的分离分析方法研究进展[J].稀有金属与硬质合金,2010,38(1):56-59. http://www.cnki.com.cn/Article/CJFDTOTAL-XYJY201001015.htm
Qiu Z H,Zhong H,Cao Z F,et al.The Latest Development of Rhenium Separation and Analysis Methods[J].Rare Metals and Cemented Carbides,2010,38(1):56-59. http://www.cnki.com.cn/Article/CJFDTOTAL-XYJY201001015.htm
-
