Optimizationof the Working Parameters of LA-ICP-MS and Its Application to Zircon U-Pb Dating
-
摘要: 将激光器（LA）和电感耦合等离子体质谱仪（ICP-MS）联用避免了溶液分析繁琐、耗时的前处理操作，减少了样品制备过程中可能带来的污染，同时又具备分析成本低、测试速度快、分析数据精度高等优势。本文将LA与ICP-MS联接使用，通过激光能量密度和剥蚀频率组合来讨论较低的元素分馏效应，同时匹配RF功率、采样深度、载气及He气流速等主要工作参数以获得较高的元素信号灵敏度和稳定性，从而得到仪器最优工作参数组合，建立了可靠的锆石U-Pb定年方法。通过对锆石标样91500、GJ-1及Plešovic互测结果表明，其206Pb/238U加权平均年龄分别为1063.9±6.0 Ma（2σ，n=20）、600.3±2.6 Ma（2σ，n=27）及337.6±1.7 Ma（2σ，n=20），测试结果准确度和精度均在1%范围内，与前人报道的误差范围一致。使用优化后的仪器参数对来自鄂东南铜绿山矿区石英正长闪长玢岩岩体中的实际锆石样品进行测试，获得其206Pb/238U年龄与前人研究结果基本一致，表明本法能准确地对锆石进行定年分析。
-
关键词:
- 激光剥蚀电感耦合等离子体质谱 /
- 参数优化 /
- 元素分馏指数 /
- 信号灵敏度 /
- 信号稳定性 /
- 206Pb/238U加权平均年龄
Abstract: Laser Ablation (LA) combined with Inductively Coupled Plasma-Mass Spectrometry (ICP-MS) avoids cumbersome analysis of solution and time-consuming pre process, thus reducing possible pollution during sample preparation. Moreover, LA-ICP-MS has the advantages of low cost, rapid determination, and high precision of analysis data. The lower fractionation effect of elements is discussed by combing laser energy density and denudation frequency. Meanwhile, the main working parameters such as RF power, sampling depth, carrier gas and He gas flow rate are matched to obtain high sensitivity and stability of the signal. Based on these, the optimal parameters of the instrument are obtained and reliable zircon U-Pb dating method is established. By mutual determination of zircon age standard substance 91500, GJ-1, and Plešovic, the respective weighted average ages of 206Pb/238U were 1063.9±6.0 Ma (2σ, n=20), 600.3±2.6 Ma (2σ, n=27), and 337.6±1.7 Ma (2σ, n=20). The accuracy and precision are within 1%, consistent with previous studies. Using the optimized parameters of the instrument, the quartz-orthoclase diorite porphyrite from the Tonglushan Orefield in Southeast Hubei has the 206Pb/238U age of zircon, basically consistent with the previous results, indicating that this method can be used for zircon U-Pb dating. -
-
表 1 LA-ICP-MS主要工作参数
Table 1. Main working parameters of LA-ICP-MS
激光剥蚀系统(LA) 电感耦合等离子体质谱仪(ICP-MS) 分析参数 工作条件 分析参数 工作条件 单脉冲能量(mJ) 80 RF功率(W) 1450 能量密度(J/cm2) 6 RF匹配(V) 1.80 剥蚀频率(Hz) 7 采样深度(mm) 6.0 束斑直径(μm) 32 载气流速(L/min) 1.10 He气流速(mL/min) 750 信号采集模式 TRA
下载: 导出CSV
-
[1] Cook N, Ciobanu C L, George L, et al.Trace element analysis of minerals in magmatic-hydrothermal ores by laser ablation inductively-coupled plasma mass spectrometry:Approaches and opportunities[J].Minerals, 2016, 6(4):111. doi: 10.3390/min6040111
[2] Norman M, Robinson P, Clark D.Major-and trace-element analysis of sulfide ores by laser-ablation ICP-MS, solution ICP-MS, and XRF:New data on international reference materials[J].The Canadian Mineralogist, 2003, 41(2):293-305. doi: 10.2113/gscanmin.41.2.293
[3] Danyushevsky L, Robinson P, Gilbert S, et al.Routine quantitative multi-element analysis of sulphide minerals by laser ablation ICP-MS:Standard development and consideration of matrix effects[J].Geochemistry:Exploration, Environment, Analysis, 2011, 11(1):51-60. doi: 10.1144/1467-7873/09-244
[4] Ding L, Yang G, Xia F, et al.A LA-ICP-MS sulphide calibration standard based on a chalcogenide glass[J].Mineralogical Magazine, 2011, 75(2):279-287. doi: 10.1180/minmag.2011.075.2.279
[5] 吴石头, 王亚平, 许春雪.激光剥蚀电感耦合等离子体质谱元素微区分析标准物质研究进展[J].岩矿测试, 2015, 34(5):503-511. 激光剥蚀电感耦合等离子体质谱元素微区分析标准物质研究进展
Wu S T, Wang Y P, Xu C X.Research progress on reference materials for in situ elemental analysis by laser ablation-inductively coupled plasma-mass spectrometry[J].Rock and Mineral Analysis, 2015, 34(5):503-511. 激光剥蚀电感耦合等离子体质谱元素微区分析标准物质研究进展
[6] 肖志斌, 柳小明, 李正辉, 等.激光剥蚀-电感耦合等离子体质谱准确测定锆石中钛的含量[J].岩矿测试, 2012, 31(2):229-233. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20120206&flag=1
Xiao Z B, Liu X M, Li Z H, et al.Accurate determination of Ti in zircon by laser ablation-inductively coupled plasma-mass spectrometry[J].Rock and Mineral Analysis, 2012, 31(2):229-233. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20120206&flag=1
[7] 宗克清, 陈金勇, 胡兆初, 等.铀矿fs-LA-ICP-MS原位微区U-Pb定年[J].中国科学(地球科学), 2015, 45(9):1304-1315. http://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201509005.htm
Zong K Q, Chen J Y, Hu Z C, et al.In-situ U-Pb dating of uraninite by fs-LA-ICP-MS[J].Science China (Earth Sciences), 2015, 45(9):1304-1315. http://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201509005.htm
[8] 陈春飞, 刘先国, 胡兆初, 等.LA-ICP-MS微区原位准确分析含水硅酸盐矿物主量和微量元素[J].地球科学——中国地质大学学报, 2014, 39(5):525-536. http://www.cnki.com.cn/Article/CJFDTOTAL-DQKX201405003.htm
Chen C F, Liu X G, Hu Z C, et al.In situ analysis of major and trace element compositions of hydrous silicate minerals by LA-ICP-MS[J].Earth Science-Journal of China University of Geosciences, 2014, 39(5):525-536. http://www.cnki.com.cn/Article/CJFDTOTAL-DQKX201405003.htm
[9] 吴石头, 王亚平, 詹秀春, 等.CGSG系列标准物质元素分馏效应及主量微量元素单元内均匀性探究[J].岩矿测试, 2016, 35(6):612-620. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20160607&flag=1
Wu S T, Wang Y P, Zhan X C, et al.Study on the elemental fractionation effect of CGSG reference materials and the related within-unit homogeneity of major and trace elements[J].Rock and Mineral Analysis, 2016, 35(6):612-620. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20160607&flag=1
[10] 孟郁苗, 黄小文, 高剑峰, 等.无内标-多外标校正激光剥蚀等离子体质谱法测定磁铁矿微量元素组成[J].岩矿测试, 2016, 35(6):584-594. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20160604&flag=1
Meng Y M, Huang X W, Gao J F, et al.Determination of trace elements in magnetite by laser ablation-inductively coupled plasma-mass spectrometry using multiple external standards without an internal standard calibration[J].Rock and Mineral Analysis, 2016, 35(6):584-594. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20160604&flag=1
[11] 王岚, 杨理勤, 王亚平, 等.锆石LA-ICP-MS原位微区U-Pb定年及微量元素的同时测定[J].地球学报, 2012, 33(5):763-772. http://www.cnki.com.cn/Article/CJFDTOTAL-DQXB201205011.htm
Wang L, Yang L Q, Wang Y P, et al.In situ U-Pb dating and trace element simultaneity determination of zircon by LA-ICP-MS[J].Acta Geoscientica Sinica, 2012, 33(5):763-772. http://www.cnki.com.cn/Article/CJFDTOTAL-DQXB201205011.htm
[12] 涂湘林, 张红, 邓文峰, 等.RESOlution激光剥蚀系统在微量元素原位微区分析中的应用[J].地球化学, 2011, 40(1):83-98. http://www.cnki.com.cn/Article/CJFDTOTAL-DQHX201101009.htm
Tu X L, Zhang H, Deng W F, et al.Application of resolution in-situ laser ablation ICP-MS in trace element analyses[J].Geochimica, 2011, 40(1):83-98. http://www.cnki.com.cn/Article/CJFDTOTAL-DQHX201101009.htm
[13] 李凤春, 侯明兰, 栾日坚, 等.电感耦合等离子体质谱仪与激光器联用测量条件优化及其在锆石U-Pb定年中的应用[J].岩矿测试, 2016, 35(1):17-23. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20160104&flag=1
Li F C, Hou M L, Luan R J, et al.Optimization of analytical conditions for LA-ICP-MS and its application to zircon U-Pb dating[J].Rock and Mineral Analysis, 2016, 35(1):17-23. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20160104&flag=1
[14] 吴石头, 王亚平, 许春雪, 等.193nm ArF准分子激光剥蚀系统高空间分辨率下元素分馏研究[J].分析化学, 2016, 44(7):1035-1041. http://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201607006.htm
Wu S T, Wang Y P, Xu C X, et al.Elemental fractionation studies of 193nm ArF excimer laser ablation system at high space resolution mode[J].Chinese Journal of Analytical Chemistry, 2016, 44(7):1035-1041. http://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201607006.htm
[15] 刘勇胜, 胡兆初, 李明, 等.LA-ICP-MS在地质样品元素分析中的应用[J].科学通报, 2013, 58(36):3753-3769. http://www.cnki.com.cn/Article/CJFDTOTAL-KXTB201336003.htm
Liu Y S, Hu Z C, Li M, et al.Applications of LA-ICP-MS in the elemental analyses of geological samples[J].Chinese Science Bulltin, 2013, 58(36):3863-3878. http://www.cnki.com.cn/Article/CJFDTOTAL-KXTB201336003.htm
[16] 李凤春. LA-ICP-MS联用条件优化及在锆石U-Pb测年中的应用[D]. 成都: 成都理工大学, 2010.
http://cdmd.cnki.com.cn/Article/CDMD-10616-2010218463.htm Li F C.Optimization of Combined with Conditions of LA-ICP-MS and Its Application in the Zircon U-Pb Dating[D].Chengdu:Chengdu University of Technology, 2010.
[17] 李艳广, 汪双双, 刘民武, 等.斜锆石LA-ICP-MS U-Pb定年方法及应用[J].地质学报, 2015, 89(12):2400-2418. http://www.cnki.com.cn/Article/CJFDTOTAL-DZXE201512015.htm
Li Y G, Wang S S, Liu M W, et al.U-Pb dating study of baddeleyite by LA-ICP-MS:Technique and application[J].Acta Geologica Sinica, 2015, 89(12):2400-2418. http://www.cnki.com.cn/Article/CJFDTOTAL-DZXE201512015.htm
[18] 汪双双, 韩延兵, 李艳广, 等.利用LA-ICP-MS在16μm和10μm激光束斑条件下测定独居石U-Th-Pb年龄[J].岩矿测试, 2016, 35(4):349-357. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20160404&flag=1
Wang S S, Han Y B, Li Y G, et al.U-Th-Pb dating of monazite by LA-ICP-MS using ablation spot sizes of 16μm and 10μm[J].Rock and Mineral Analysis, 2016, 35(4):349-357. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20160404&flag=1
[19] Eggins S M, Kinsley L P J, Shelley J M G.Deposition and element fractionation processes during atmospheric pressure laser sampling for analysis by ICP-MS[J].Applied Surface Science, 1998, 127:278-286. http://www.deepdyve.com/lp/elsevier/deposition-and-element-fractionation-processes-during-atmospheric-ym0ReIjAGB
[20] Günther D, Heinrich C A.Enhanced sensitivity in laser ablation-ICP mass spectrometry using helium-argon mixtures as aerosol carrier[J].Journal of Analytical Atomic Spectrometry, 1999, 14(9):1363-1368. doi: 10.1039/A901648A
[21] 范晨子, 胡明月, 赵令浩, 等.锆石铀-铅定年激光剥蚀-电感耦合等离子体质谱原位微区分析进展[J].岩矿测试, 2012, 31(1):29-46. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20120105&flag=1
Fan C Z, Hu M Y, Zhao L H, et al.Advances in in situ microanalysis of U-Pb zircon geochronology using laser ablation-inductively coupled plasma-mass spectrometry[J].Rock and Mineral Analysis, 2012, 31(1):29-46. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20120105&flag=1
[22] Wiedenbeck M, Alle P, Corfu F, et al.Three natural zircon standards for U-Th-Pb, Lu-Hf, trace element and REE analyses[J].Geostandards Newsletter, 1995, 19(1):1-23. doi: 10.1111/ggr.1995.19.issue-1
[23] Wiedenbeck M, Hanchar J M, Peck W H, et al.Further characterisation of the 91500 zircon crystal[J].Geostandards and Geoanalytical Research, 2004, 28(1):9-39. doi: 10.1111/ggr.2004.28.issue-1
[24] Lopez R, Cameron K L, Jones N W.Evidence for Paleo-proterozoic, Grenvillian, and Pan-African age Gondwanan crust beneath Northeastern Mexico[J].Precambrian Research, 2001, 107(3):195-214. http://www.academia.edu/6806524/Evidence_for_Paleoproterozoic_Grenvillian_and_Pan-African_age_Gondwanan_crust_beneath_northeastern_Mexico
[25] Paquette J L, Pin C.A new miniaturized extraction chro-matography method for precise U-Pb zircon geochronology[J].Chemical Geology, 2001, 176(1):311-319. http://www.ingentaconnect.com/content/els/00092541/2001/00000176/00000001/art00408
[26] Amelin Y, Zaitsev A N.Precise geochronology of phos-corites and carbonatites:The critical role of U-series disequilibrium in age interpretations[J].Geochimica et Cosmochimica Acta, 2002, 66(13):2399-2419. doi: 10.1016/S0016-7037(02)00831-1
[27] Chen F, Siebel W, Satir M.Zircon U-Pb and Pb-isotope fractionation during stepwise Hf acid leaching and geochronological implications[J].Chemical Geology, 2002, 191(1):155-164. http://www.sciencedirect.com/science/article/pii/S0009254102001547
[28] Nebel-Jacobsen Y, Scherer E E, Münker C, et al.Sepa-ration of U, Pb, Lu, and Hf from single zircons for combined U-Pb dating and Hf isotope measurements by TIMS and MC-ICPMS[J].Chemical Geology, 2005, 220(1):105-120. http://www.academia.edu/14496571/2_Lu_Hf_and_Sm_Nd_isotope_systems_in_zircon
[29] 侯可军, 李延河, 田有荣.LA-MC-ICP-MS锆石微区原位U-Pb定年技术[J].矿床地质, 2009, 28(4):481-492. http://www.cnki.com.cn/Article/CJFDTOTAL-KCDZ200904009.htm
Hou K J, Li Y H, Tian Y R.In situ U-Pb zircon dating using laser ablation-multi ion counting-ICP-MS[J].Mineral Deposits, 2009, 28(4):481-492. http://www.cnki.com.cn/Article/CJFDTOTAL-KCDZ200904009.htm
[30] Jackson S E, Pearson N J, Griffin W L, et al.The app-lication of laser ablation-inductively coupled plasma-mass spectrometry to in situ U-Pb zircon geochronology[J].Chemical Geology, 2004, 211(1):47-69. http://minerva.mq.edu.au:8080/vital/access/manager/Repository/mq:2028
[31] Sláma J, Košler J, Condon D J, et al.Plešovice zircon-A new natural reference material for U-Pb and Hf isotopic microanalysis[J].Chemical Geology, 2008, 249(1):1-35. http://www.princeton.edu/geosciences/people/schoene/pdf/8.%20Slama_CG08.pdf
[32] 黄圭成, 夏金龙, 丁丽雪, 等.鄂东南地区铜绿山岩体的侵入期次和物源:锆石U-Pb年龄和Hf同位素证据[J].中国地质, 2013, 40(5):1392-1408. http://www.cnki.com.cn/Article/CJFDTOTAL-DIZI201305005.htm
Huang G C, Xia J L, Ding L X, et al.Stage division and origin of Tonglushan pluton in Southeast Hubei Province:Evidence from zircon U-Pb ages and Hf isotopes[J].Geology in China, 2013, 40(5):1392-1408. http://www.cnki.com.cn/Article/CJFDTOTAL-DIZI201305005.htm
[33] Li X H, Li W X, Wang X C, et al.SIMS U-Pb zircon geochronology of porphyry C-Au-(Mo) deposits in the Yangtze River Metallogenic Belt, Eastern China:Magmatic response to early Cretaceous lithospheric extension[J].Lithos, 2010, 119:427-438. doi: 10.1016/j.lithos.2010.07.018
[34] Xie G, Mao J, Zhao H, et al.Timing of skarn deposit formation of the Tonglushan ore district, Southeastern Hubei Province, middle-lower Yangtze River Valley metallogenic belt and its implications[J].Ore Geology Reviews, 2011, 43(1):62-77. doi: 10.1016/j.oregeorev.2011.05.005
[35] Yuan H L, Gao S, Dai M N, et al.Simultaneous deter-minations of U-Pb age, Hf isotopes and trace element compositions of zircon by excimer laser-ablation quadrupole and multiple-collector ICP-MS[J].Chemical Geology, 2008, 247(1):100-118. http://www.doc88.com/p-9149559709618.html
-
