Vibrational Spectroscopy Characteristics of Rare Mineral Chambersite in Jixian of Tianjin, China
-
摘要: 锰方硼石是一种罕见的锰氯硼酸盐矿物（Mn3B7O13Cl），天津蓟县锰方硼石矿床是世界上唯一一个锰方硼石矿床，该地锰方硼石矿物粒度细小（50~300 nm），与美国锰方硼石存在明显差别。目前涉及我国锰方硼石的研究较少，为了探究稀有矿物蓟县锰方硼石矿物学和材料学特征，本文对其进行振动光谱和高温拉曼光谱研究。常温振动光谱结果表明，蓟县锰方硼石与美国锰方硼石各主要谱带归属一致，但峰位整体上表现为向高频方向偏移且谱峰宽、强度小。高温拉曼光谱显示，随着温度升高，谱带向低频方向偏移，位移距离随温度升高呈现先增大后减小的趋势，且在680~687 K处位移距离出现转折。蓟县锰方硼石粒度细小是造成上述谱峰变化的主要原因。本文运用高温拉曼技术对粒度极为细小的锰方硼石进行测试分析，研究其谱峰变化与相变的关系，实验证明高温拉曼光谱可以作为研究矿物相变的一种有效手段。Abstract: Chambersite (Mn3B7O13Cl) is a type of rare mineral. The Chambersite deposit in Jixian, Tianjin is the only commercially valuable deposit in the world. The Chambersite particle in Jixian is very fine (50-300 nm), which is different from that of American Chambersite. Until now, little study was carried out has been conducted on Chinese Chambersite. In order to explore the mineralogical and material characteristics of Chambersite in Jixian, a Vibration Spectrum and high-temperature Raman Spectrum were recorded. Normal-temperature Vibration Spectrum shows that the main spectrum band assignment of Chinese Chambersite is the same as that of American Chambersite. However, as a whole, the peak position is shifted toward the high-frequency direction and the spectral width and intensity are small. High-temperature Raman Spectroscopy shows that with the increase of temperature, bands generally shift to the low frequency, the displacement distance increases first and then decreases, and the displacement distance turns at 680-687 K. The small particle size is the main reason for spectrum peak changes. High-temperature Raman Spectroscopy technique was used to test and analyze Chambersite with very fine particle size, and the relationship between the peak change and phase transition was studied, thus demonstrating that high temperature Raman Spectroscopy can be used as an effective method to study mineral phase transition.
-
-
表 1 天津蓟县锰方硼石拉曼、红外光谱振谱带动归属对比
Table 1. A comparison of the infrared and Raman spectra of Chambersite from Jixian, Tianjin
频率范围(cm-1) 拉曼谱带(cm-1) 红外谱带(cm-1) 谱带归属 3600~3000 - - OH或H2O伸缩振动 1660~1600 1611(强) - H2O弯曲振动 1500~1300 1467, 1302 1402, 1345(强) BO3非对称振动 1300~1000 1231, 1189, 1115(强) 1153, 1052 M—OH面内弯曲振动 1100~950 振动不明显 1153, 1052, 984, (强) BO4非对称振动 950~850 920(较强) 944, 920, 899, 869(弱) BO3对称振动 850~700 830(较强) 847, 820, 770, 702(弱) BO4对称振动，M—OH面内弯曲振动 700~400 661, 642, 601, 404(强) 685(弱) BO3、BO4的弯曲振动
下载: 导出CSV
-
[1] 肖成东, 张静, 张宝华, 等.天津蓟县锰方硼石矿床[J].地质调查与研究, 2007, 30(3):186-191. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=qhwjyjjz200703005
Xiao C D, Zhang J, Zhang B H, et al.Chambersite deposit in Jixian, Tianjin[J].Geological Survey and Research, 2007, 30(3):186-191. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=qhwjyjjz200703005
[2] 肖荣阁, 大井隆夫, 侯万荣, 等.天津蓟县硼矿床锰方硼石矿物的硼同位素研究[J].现代地质, 2002, 16(3):270-275. http://industry.wanfangdata.com.cn/dl/Detail/Periodical?id=Periodical_xddz200203009
Xiao R G, Tako O, Hou W R, et al.Boron isotopic composition of Dongshuichang Chambersite deposit, Jixian, Tianjin, China[J].Geoscience, 2002, 16(3):270-275. http://industry.wanfangdata.com.cn/dl/Detail/Periodical?id=Periodical_xddz200203009
[3] 王秋舒, 许虹, 高燊, 等.稀有矿物锰方硼石的合成及其矿床地质意义[J].地学前缘, 2013, 20(3):123-130. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy201303015
Wang Q S, Xu H, Gao S, et al.Synthesis of the rare mineral Chambersite and its ore deposit geological significance[J].Earth Science Frontiers, 2013, 20(3):123-130. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy201303015
[4] Grice J D, Gault R A, Velthuizen J V.Borate minerals of the Penobsquis and Millstream Deposit, Southern New Brunswick[J].Canadian Mineralogist, 2005, 43:1469-1488. doi: 10.2113/gscanmin.43.5.1469
[5] 王秋舒. 天津蓟县锰方硼石矿物学特征及其成矿机理初探[D]. 北京: 中国地质大学(北京), 2013.
Wang Q S. Mineralogical Characteristcis of the Chambersite and Its Ore Genesis of Jixian, Tianjin[D]. Beijing: China University of Geosciences (Beijing), 2013.
[6] 王富良, 付勇, 徐志刚, 等.天津蓟县东水厂锰方硼石矿床成因新认识[J].地质学报, 2016, 90(2):398-408. http://industry.wanfangdata.com.cn/jt/Magazine?magazineId=dizhixb&yearIssue=2016_2
Wang F L, Fu Y, Xu Z G, et al.The new understanding of the cause of Dongshuichang Chambersite deposit in Jixian, Tianjin[J].Acta Geologica Sinica, 2016, 90(2):398-408. http://industry.wanfangdata.com.cn/jt/Magazine?magazineId=dizhixb&yearIssue=2016_2
[7] Fan D L, Yang P J, Wang R, et al.Characteristics and origin of the Middle Proterozoic Dongshuichang Chambersite deposit, Jixian, Tianjin, China[J].Ore Geology Reviews, 1999, 15(1-3):15-29. doi: 10.1016/S0169-1368(99)00012-8
[8] 曾贻善.锰方硼石的合成及其地球化学意义[J].地质学报, 1983(4):401-409. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy201303015
Zeng Y S.Synthesis of Chambersite and its geochemical implication[J].Acta Geologica Sinica, 1983(4):401-409. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy201303015
[9] Frost R L, Lópze A, Scholz R, et al.Vibrational spectro-scopy of the borate mineral Chambersite Mn3B7O13Cl-Implications of the molecular structure[J].Spectrochimica Acta Part A:Molecular and Biomolecular Spectroscopy, 2014, 120:270-273. doi: 10.1016/j.saa.2013.10.026
[10] 查福标, 谢先德, 彭文世.硼酸盐矿物的振动光谱研究:Ⅲ.理论分析[J].矿物学报, 1993, 13(4):303-308. http://www.wanfangdata.com.cn/details/detail.do?_type=degree&id=Y151736
Zha F B, Xie X D, Peng W S.A vibrational spectral study of Borates-Ⅲ.Theoretical analyses[J].Acta Mineralogic Sinica, 1993, 13(4):303-308. http://www.wanfangdata.com.cn/details/detail.do?_type=degree&id=Y151736
[11] 查福标, 谢先德, 彭文世.硼酸盐矿物的振动光谱研究:Ⅱ.红外光谱特征[J].矿物学报, 1993, 13(3):230-236.
Zha F B, Xie X D, Peng W S.A vibrational spectral study of Borates-Ⅱ.Infraed spectroscopy[J].Acta Mineralogic Sinica, 1993, 13(3):230-236.
[12] Wachowiak J, Pieczak A.Congolite and Trembathite from the Klodawa salt mine, central Poland:Records of the thermal history of the parental salt dome[J].The Canadian Mineralogist, 2012, 50:1387-1399. doi: 10.3749/canmin.50.5.1387
[13] 谢先德, 查福标.硼酸盐矿物的振动光谱研究:Ⅰ.拉曼光谱特征[J].矿物学报, 1993, 13(2):130-136. http://www.cnki.com.cn/Article/CJFDTotal-GZHA201218006.htm
Xie X D, Zha F B.vibrational spectral study of Borates-Ⅰ.Raman spectroscopy[J].Acta Mineralogic Sinica, 1993, 13(2):130-136. http://www.cnki.com.cn/Article/CJFDTotal-GZHA201218006.htm
[14] 陈辉, 蒋国昌, 尤静林, 等.高温拉曼光谱技术的实现及应用[J].光谱学与光谱分析, 2007, 27(12):2464-2467. http://d.old.wanfangdata.com.cn/Periodical/gpxygpfx200712021
Chen H, Jiang G C, You J L, et al.High temperature Raman spectroscopy techniques and its applications[J].Spectroscopy and Spectral Analysis, 2007, 27(12):2464-2467. http://d.old.wanfangdata.com.cn/Periodical/gpxygpfx200712021
[15] 陈辉, 蒋国昌, 尤静林, 等.高温拉曼光谱提高信噪比的途径分析[J].光谱学与光谱分析, 2007, 27(6):1148-1151. http://d.wanfangdata.com.cn/Periodical_gpxygpfx200706029.aspx
Chen H, Jiang G C, You J L, et al.Analysis of different methods for denoising of high temperature Raman spectra[J].Spectroscopy and Spectral Analysis, 2007, 27(6):1148-1151. http://d.wanfangdata.com.cn/Periodical_gpxygpfx200706029.aspx
-
