Research on the Correlation between Methane and Hydrogen in Acid-hydrolyzed Gases for Geochemical Exploration Samples
-
摘要: 酸解烃是油气化探方法中准确度相对较高的一项指标，已得到广泛的应用，深入研究酸解气有助于对其机理的进一步解释，并且有利于开发新的分析指标。本文利用气相色谱法测定了油气化探样品经盐酸分解后所得气体中烃类组分与非烃气体组分的含量，发现了酸解气中甲烷与氢气的含量具有正相关性。进而通过X射线荧光光谱和X射线衍射分析样品的元素和矿物组成、样品再粉碎分析以及激光拉曼光谱分析包裹体成分等实验，获得以下结论：①酸解气中的甲烷和氢气含量与样品元素组成无关，与碳酸盐矿物正相关，其含量可以反映深部油气的情况；②两种气体并不是以物理吸附形式存在于样品中，而是存在于更小的空间内，证明了酸解烃分析方法具有相当高的稳定性；③获得了甲烷和氢气同时存在于包裹体的直接证据，由此推测这两种气体可能具有同源性。由于甲烷和氢气含量相关性的存在，酸解脱气中氢气的含量测定有望成为油气化探的新指标，应用于油气资源调查。Abstract: Acidolysis hydrocarbon is an important index with relatively high accuracy in the geochemical exploration for oil and gas and has been widely used. Detailed study of acid-hydrolyzed gases can help further explain its mechanism and help develop new analytical indicators. The content of acidolysis hydrocarbons and other gas released by hydrochloric acid in the samples from geochemical exploration for oil and gas by Gas Chromatography have been determined, and are presented in this paper. There is a positive correlation between the contents of methane and non hydrocarbon gas. The elements and mineral composition of the sample were measured by X-ray Fluorescence Spectrometry (XRF) and X-ray Diffraction (XRD), respectively, whereas the gas-liquid inclusion composition was analyzed by Laser Raman Spectroscopy after sample smashing. The conclusions are as follows:(1) The content of methane and hydrogen in the acidolysis hydrocarbons is independent of the elemental composition of the sample and is positively related to the carbonate minerals. The contents of methane and hydrogen can reflect the situation of deep oil and gas. (2) Two kinds of gas do not exist in the form of physical adsorption but in the smaller space. It is proved that the analysis method of acid hydrolysis hydrocarbon has high stability. (3) There is direct evidence that two kinds of gases exist in the inclusions at the same time, which infers that two types of gases have the same source. Due to the correlation between methane and hydrogen, the content of hydrogen from acidolysis hydrocarbons will be a new analysis index in the geochemical exploration for oil and gas.
-
Key words:
- geochemical exploration for oil and gas /
- acidolysis hydrocarbons /
- inclusion /
- methane /
- hydrogen
-
-
表 1 10个样品中各类矿物的X射线衍射数据
Table 1. The X-ray diffraction data of minerals in 10 samples
矿物种类 各样品中各类矿物的含量(%) 003 014 030 046 059 067 069 110 130 143 石英 42.4 44.6 48.6 42.4 42.6 39.2 48.9 43.5 39.3 39.9 斜长石 15.8 17.2 15.1 16.6 16 26.1 16.6 17.2 17.2 16.5 钾长石 5.2 4.1 4.1 4.0 3.6 1.6 3.5 3.1 5.6 1.8 方解石 16.7 12.4 10.2 18.6 14.4 1.3 12.5 14.2 14.3 18.8 白云石 1.3 1.4 - 2.0 3.4 0.5 - 2.0 2.0 2.9 菱铁矿 0.8 - - 0.6 - - - - - - 角闪石 1.2 1.3 1.1 1.3 2.5 3.3 1.7 1.0 1.1 2.6 赤铁矿 - - 0.9 - - 1.0 0.8 - - - 蒙脱石 1.0 - - - - 2.0 - 1 - - 伊蒙混层 - - 13.0 - - - - - - - 伊利石 8.0 9.0 7.0 9.5 12.0 10.0 9.0 11.5 9.0 绿泥石 7.6 6.0 5.0 7.5 6.0 13.0 6.0 6.0 6.0 8.5 高岭石 - 4.0 2.0 - 2.0 - - 3.0 3.0 -
下载: 导出CSV
-
[1] 李广之, 胡斌.中国油气化探分析技术新进展与发展方向[J].天然气地球科学, 2013, 24(6):1171-1185. http://industry.wanfangdata.com.cn/dl/Detail/Periodical?id=Periodical_trqdqkx201306011
Li G Z, Hu B.The latest progress of the analytical techniques of the petroleum geochemocal exploration China:Problems and development direction[J].Natural Gas Geoscience, 2013, 24(6):1171-1185. http://industry.wanfangdata.com.cn/dl/Detail/Periodical?id=Periodical_trqdqkx201306011
[2] 吴传璧.中国油气化探50年[J].地质通报, 2009, 8(11):1572-1604. doi: 10.3969/j.issn.1671-2552.2009.11.007
Wu C B.Fifty years history of Chinese oil and gas geo-chemical exploration[J].Geological Bulletin of China, 2009, 8(11):1572-1604. doi: 10.3969/j.issn.1671-2552.2009.11.007
[3] Schumacher D.Surface geochemical exploration for oil and gas:New life for an old technology[J].The Leading Edge, 2000, 19(3):258-261. doi: 10.1190/1.1438582
[4] 蒋涛, 汤玉平, 李武, 等.分析和认识我国油气化探技术[J].物探与化探, 2011, 35(1):7-11. http://www.cnki.com.cn/Article/CJFDTOTAL-WTZB200801002.htm
Jiang T, Tang Y P, Li W, et al.Analysis and understanding of oil and gas exploration technology in China[J].Geophysical and Geochemical Exploration, 2011, 35(1):7-11. http://www.cnki.com.cn/Article/CJFDTOTAL-WTZB200801002.htm
[5] 杨少平, 孙跃, 弓秋丽."十一五"以来化探方法技术研究主要进展[J].物探与化探, 2014, 38(2):194-199. doi: 10.11720/j.issn.1000-8918.2014.2.02
Yang S P, Sun Y, Gong Q L.The main progress in the research of geochemical exploration methods since 11th Five-Year[J].Geophysical and Geochemical Exploration, 2014, 38(2):194-199. doi: 10.11720/j.issn.1000-8918.2014.2.02
[6] 汤玉平, 姚亚明.我国油气化探的现状与发展趋势[J].物探与化探, 2006, 30(6):475-479. http://www.cnki.com.cn/Article/CJFDTOTAL-JXSI200606016.htm
Tang Y P, Yao Y M.Current situation and development trend of oil and gas geochemical exploration in China[J].Geophysical and Geochemical Exploration, 2006, 30(6):475-479. http://www.cnki.com.cn/Article/CJFDTOTAL-JXSI200606016.htm
[7] 贾承造, 郑民, 张永峰.中国非常规油气资源与勘探开发前景[J].石油勘探与开发, 2012, 39(2):129-136. http://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201202002.htm
Jia C Z, Zheng M, Zhang Y F.Unconventional hydrocarbon resources in China and the prospect of exploration and development[J].Petroleum Exploration and Development, 2012, 39(2):129-136. http://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201202002.htm
[8] 缪九军, 荣发准, 李广之.酸解烃技术在油气勘探中的应用[J].物探与化探, 2005, 29(3):209-212. http://www.cqvip.com/QK/95670X/200503/15977069.html
Miao J J, Rong F Z, Li G Z.Application of acidolysis hydrocarbon technology in oil and gas exploration[J].Geophysical and Geochemical Exploration, 2005, 29(3):209-212. http://www.cqvip.com/QK/95670X/200503/15977069.html
[9] 陈卫明, 肖细炼, 李庆霞, 等.气相色谱法测定油气化探样品中酸解烃的研究[J].岩矿测试, 2015, 34(6):698-703. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=ykcs201506019&dbname=CJFD&dbcode=CJFQ
Chen W M, Xiao X L, Li Q X, et al.Determination of acidolysis hydrocarbons in oil/gas geochemical exploration samples by gas chromatography[J].Rock and Mineral Analysis, 2015, 34(6):698-703. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=ykcs201506019&dbname=CJFD&dbcode=CJFQ
[10] 王振平, 傅晓泰.油气垂向化探酸解烃异常识别[J].石油勘探与开发, 1996, 23(1):39-42. http://www.cnki.com.cn/Article/CJFDTOTAL-KCYD702.013.htm
Wang Z P, Fu X T.Identification of acidolysis hydrocarbon anomaly in vertical geochemical prospecting for oil and gas[J].Petroleum Exploration and Development, 1996, 23(1):39-42. http://www.cnki.com.cn/Article/CJFDTOTAL-KCYD702.013.htm
[11] 梁前勇, 熊永强, 赵克斌, 等.高精度地表油气化探技术的发展及应用——以济阳凹陷垛石桥地区土壤酸解烃为例[J].地球化学, 2014, 43(2):141-148. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=dqhx201402005&dbname=CJFD&dbcode=CJFQ
Liang Q Y, Xiong Y Q, Zhao K B, et al.Development and application of high-precision surface geochemical exploration technique for petroleum:Take the soil acid-extraction hydrocarbons in Duoshiqiao area, Jiyang Depression as an example[J].Geochimica, 2014, 43(2):141-148. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=dqhx201402005&dbname=CJFD&dbcode=CJFQ
[12] 程党性, 邓秀芹, 孙勃, 等.西峰油区酸解烃指标异常与长8油藏关系[J].西南石油大学学报(自然科学版), 2016, 38(4):48-55. doi: 10.11885/j.issn.1674-5086.2014.04.05.05
Cheng D X, Deng X Q, Sun B, et al.Relationship between unusual index of soil acid hydrolysis hydrocarbon and Chang 8 oil pool in Xifeng oil area[J].Journal of Southwest Petroleum University(Science & Technology Edition), 2016, 38(4):48-55. doi: 10.11885/j.issn.1674-5086.2014.04.05.05
[13] 赵妮霞, 申鹏.油气包裹体研究进展及其在油气成藏中的应用[J].辽宁化工, 2012, 41(8):818-821. http://www.cnki.com.cn/Article/CJFDTOTAL-SYYT200503001.htm
Zhao N X, Shen P.Research progress in the oil inclusion and its application in oil and gas accumulation[J].Liaoning Chemical Industry, 2012, 41(8):818-821. http://www.cnki.com.cn/Article/CJFDTOTAL-SYYT200503001.htm
[14] 施伟军, 蒋宏, 席斌斌.油气包裹体成分及特征分析方法研究[J].石油实验地质, 2009, 31(6):643-648. doi: 10.11781/sysydz200906643
Shi W J, Jiang H, Xi B B.Studies of analysis approaches of oil and gas inclusion composition and characteristics[J].Petroleum Geology and Experiment, 2009, 31(6):643-648. doi: 10.11781/sysydz200906643
[15] 胡国艺, 单秀琴, 李志生, 等.流体包裹体烃类组成特征及对天然气成藏示踪作用——以鄂尔多斯盆地西北部奥陶系为例[J].岩石学报, 2005, 21(5):1461-1466. http://www.ysxb.ac.cn/ysxb/ch/reader/create_pdf.aspx?file_no=200505146&journal_id=ysxb&year_id=2005
Hu G Y, Shan X Q, Li Z S, et al.The component and isotope characteristics of hydrocarbon in fluid inclusions and its affection on the gas reservoir formation:The case of Ordovcian reservoir in the northwest area of Ordos Basin[J].Acta Petrologica Sinca, 2005, 21(5):1461-1466. http://www.ysxb.ac.cn/ysxb/ch/reader/create_pdf.aspx?file_no=200505146&journal_id=ysxb&year_id=2005
[16] 付孝悦, 孙庭金, 温景萍.南盘江盆地含烃非烃气藏的发现及意义[J].天然气工业, 2005, 25(5):26-28. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=trqgy200505007
Fu X Y, Sun T J, Wen J P.Discovery of hydrocarbon bearing nonhydrocarbon gas reservoirs in Nanpangjiang Basin and its significance[J].Natural Gas Industry, 2005, 25(5):26-28. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=trqgy200505007
[17] 史建南, 曾治平, 周陆扬, 等.中国沉积盆地非烃气成因机制研究[J].特种油气藏, 2003, 10(2):5-9. http://www.cnki.com.cn/Article/CJFDTOTAL-CJXB198502002.htm
Shi J N, Zeng Z P, Zhou L Y, et al.Genetic mechanism of non-hydrocarbon gas in China sedimentary basin[J].Special Oil and Gas Reservoirs, 2003, 10(2):5-9. http://www.cnki.com.cn/Article/CJFDTOTAL-CJXB198502002.htm
[18] 曹春辉, 张铭杰.四川盆地志留系龙马溪组页岩气气体地球化学特征及意义[J].天然气地球科学, 2015, 26(8):1604-1612. http://cdmd.cnki.com.cn/Article/CDMD-10730-1018803996.htm
Cao C H, Zhang M J.Geochemical characteristics and implications of shale gas in Longmaxi Formation Sichuan Basin, China[J].Natural Gas Geoscience, 2015, 26(8):1604-1612. http://cdmd.cnki.com.cn/Article/CDMD-10730-1018803996.htm
[19] 李吉鹏, 王国建, 汤玉平.一种痕量氦氖氢的检测方法及其化探效果[J].物探与化探, 2013, 37(2):251-254. http://or.nsfc.gov.cn/handle/00001903-5/58287
Li J P, Wang G J, Tang Y P.A detection method for trace helium, neon and hydrogen and its effect in oil and gas exploration[J].Geophysical and Geochemical Exploration, 2013, 37(2):251-254. http://or.nsfc.gov.cn/handle/00001903-5/58287
[20] 刘德汉, 戴金星, 肖贤明, 等.普光气田中高密度甲烷包裹体的发现及形成的温度和压力条件[J].科学通报, 2010, 55(4-5):359-366. http://mall.cnki.net/magazine/article/KXTB2010Z1010.htm
Liu D H, Dai J X, Xiao X M, et al.High density methane inclusions in Puguang gasfield:Discovery and a T-P genetic study[J].Chinese Science Bulletin, 2010, 55(4-5):359-366. http://mall.cnki.net/magazine/article/KXTB2010Z1010.htm
[21] 任鹏程, 苏亮, 刘卿, 等.小麦中元素含量相关性分析的方法比较[J].中国食品卫生杂志, 2017, 29(2):140-144. http://www.irgrid.ac.cn/handle/1471x/307593
Ren P C, Su L, Liu Q, et al.Method comparison of correlation analysis of element content in wheat[J].Chinese Journal of Food Hygiene, 2017, 29(2):140-144. http://www.irgrid.ac.cn/handle/1471x/307593
[22] 王建其, 柳小明.X射线荧光光谱法分析不同类型岩石中10种主量元素的测试能力验证[J].岩矿测试, 2016, 35(2):145-151. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2016.02.006
Wang J Q, Liu X M.Proficiency testing of the XRF method for measuring 10 major elements in different rock types[J].Rock and Mineral Analysis, 2016, 35(2):145-151. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2016.02.006
[23] 罗松英, 曹建劲, 吴政权.内蒙古草原拜仁达坝矿区地表土壤的X射线衍射和近红外光谱分析[J].光谱学与光谱分析, 2014, 34(8):2268-2272. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=guan201408057&dbname=CJFD&dbcode=CJFQ
Luo S Y, Cao J J, Wu Z Q.XRD and NIR analysis of the soil overlying the Bairendaba deposit of the Inner Mongolia[J].Spectroscopy and Spectral Analysis, 2014, 34(8):2268-2272. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=guan201408057&dbname=CJFD&dbcode=CJFQ
[24] 凡慧, 马诗淳, 王春芳, 等.产氢细菌FSC-15对稻草秸秆厌氧发酵产甲烷的影响[J].应用与环境生物学报, 2017, 23(2):251-255. http://mall.cnki.net/magazine/Article/ZGZQ201401011.htm
Fan H, Ma S C, Wang C F, et al.Effect of the hydrogen-producing bacterium FSC-15 on methanogenesis during rice straw anaerobic fermentation[J].Chinese Journal of Applied and Environmental Biology, 2017, 23(2):251-255. http://mall.cnki.net/magazine/Article/ZGZQ201401011.htm
-
