Determination of Rare Earth Elements in Ultra-fine Rock and Soil Samples by ICP-MS Using Microwave Digestion
-
摘要: 应用电感耦合等离子体质谱法（ICP-MS）分析岩石和土壤样品中稀土元素的含量，取样量可低至数毫克级，但200目样品粒度要求分析取样100mg才能保证代表性，导致ICP-MS灵敏度高、取样量小的优势难以得到充分发挥。本文研究了研磨方式、研磨时间、物料比对超细粒度土壤和岩石样品制备的影响，结果表明采用乙醇作为分散剂进行湿法球磨，200目粒度的土壤、岩石样品分别研磨10min和15min，土壤样品的物料比采用物料7g、研磨球500个、分散剂45mL，岩石样品的物料比选取物料5g、研磨球500个、分散剂45mL，细化程度最佳。在此条件下制备的超细粒度土壤标准物质GBW07404、GBW07447的粒径分布D95可低至7.51μm、7.05μm，超细粒度岩石标准物质GBW07104、GBW07121的D95可低至8.42μm、8.30μm。在硝酸-氢氟酸-过氧化氢酸溶体系中微波消解处理超细粒度岩石标准物质GBW07104，取样量减少至5mg，总用酸量减少至0.25mL，消解时间降低为25min，稀土元素的测定值与认定值基本一致，相对标准偏差在1.64%~5.21%之间。该方法用于分析其他超细粒度标准物质（GBW07404、GBW07447和GBW07121）中的稀土元素，相对误差为0.17%~6.60%，满足《地质矿产实验室测试质量管理规范》的一级标准。Abstract:
BACKGROUNDThe sampling weight can be as low as milligram level when the contents of rare earth elements in rock and soil samples are determined by inductively coupled plasma-mass spectrometry (ICP-MS). However, the size of 200 mesh samples requires 100mg to ensure representativeness, which makes it difficult for ICP-MS to make full use of its advantages of high sensitivity and small sampling volume. OBJECTIVESTo establish the method for the determination of rare earth elements in ultra-fine rock and soil samples by ICP-MS with microwave digestion. METHODSA method was developed for the determination of rare earth elements in ultra-fine rock and soil samples by ICP-MS with microwave digestion. The ultra-fine rock and soil samples were prepared by the planetary superfine pulverizing machine with wet grinding. Some parameters influencing the preparation of ultra-fine rock and soil samples, including grinding method, grinding time and the proportion of grinding balls were optimized. Microwave digestion of ultrafine-grained rock and soil samples in a nitric acid-hydrofluoric acid-hydrogen peroxide solution system, the sampling amount was reduced to 5mg, the total acid amount was reduced to 0.25mL and the digestion time was reduced to 25 minutes. RESULTSThe results indicated that the samples were best refined when the wet-milling was adopted with ethanol as a dispersant and the milling time was 10 minutes and 15 minutes for 200 mesh soil and rock samples, respectively. The material ratios were 7g materials, 500 grinding balls, 45mL dispersants for the preparation of ultra-fine soil samples, whereas 5g materials, 500 grinding balls, 45mL dispersants for the preparation of ultra-fine rock samples. The particle size distribution D95 of soil standard substance GBW07404 and GBW07447 can be as low as 7.51μm and 7.05μm, and the D95 of rock standard substance GBW07104 and GBW07121 can be 8.42μm and 8.30μm under the optimized conditions. Microwave digestion of ultrafine-grained rock sample GBW07104 in a nitric acid-hydrofluoric acid-hydrogen peroxide solution system, the sampling amount was reduced to 5mg, the total acid amount was reduced to 0.25mL, the digestion time was reduced to 25 minutes, and the measured value of rare earth elements was consistent with the certified value with the relative standard deviation is between 1.64% and 5.21%. CONCLUSIONSThis method was used for the detection of rare earth elements in other ultra-fine standard materials (GBW07404, GBW07447 and GBW07121), which yielded the relative standard deviation of 0.17%-6.60%, meeting the first criterion of Geology and Minerals Laboratory Testing Quality Management Standards. -
-
表 1 超细样品消解条件
Table 1. Digestion conditions of ultra-fine sample
条件 称样量
(mg)样品溶解加酸量 消解温度保持时间(min) 定容体积
(mL)120℃ 150℃ 180℃ 条件1 50 1.5mL硝酸, 0.5mL氢氟酸, 0.5mL双氧水 3 5 10 100 条件2 10 0.3mL硝酸, 0.1mL氢氟酸, 0.1mL双氧水 2 4 8 20 条件3 5 0.15mL硝酸, 0.05mL氢氟酸, 0.05mL双氧水 2 3 5 10
下载: 导出CSV
表 2 不同研磨方法下超细样品的粒径分布
Table 2. Particle size distributions of ultra-fine samples under different grinding methods
标准物质编号 干磨 湿磨(水作分散剂) 湿磨(乙醇作分散剂) D50(μm) D75(μm) D95(μm) D50(μm) D75(μm) D95(μm) D50(μm) D75(μm) D95(μm) GBW07404(石灰岩土) 4.58 6.93 17.53 2.92 4.37 9.15 2.85 3.91 8.90 GBW07447(盐碱土) 4.40 6.64 19.61 2.86 4.15 8.62 2.76 3.93 8.71 GBW07104(安山岩) 5.15 7.85 19.96 4.17 6.08 13.56 2.83 4.27 9.79 GBW07121
(花岗质片麻岩)5.39 8.01 20.53 4.26 6.25 12.24 2.96 4.3 10.13 注：D表示粒径体积分数统计分布。例如D95 =8.90表示95%的样品粒径小于8.90μm。
下载: 导出CSV
表 3 不同研磨时间下超细样品的粒径分布
Table 3. Particle size distributions of ultra-fine samples under different grinding time
标准物质编号 研磨5min 研磨10min 研磨15min 研磨20min D50(μm) D75(μm) D95(μm) D50(μm) D75(μm) D95(μm) D50(μm) D75(μm) D95(μm) D50(μm) D75(μm) D95(μm) GBW07404
(石灰岩土)3.39 5.17 12.36 2.85 3.91 8.90 3.09 4.51 10.23 3.17 4.96 10.98 GBW07447
(盐碱土)3.14 5.06 10.75 2.76 3.93 8.71 2.93 4.60 9.68 3.15 4.71 9.34 GBW07104
(安山岩)3.32 5.30 11.26 2.83 4.27 9.79 2.73 3.86 8.64 2.91 4.15 9.57 GBW07121
(花岗质片麻岩)3.44 5.85 12.15 2.96 4.3 10.13 2.90 4.01 9.01 3.05 4.22 10.03
下载: 导出CSV
表 4 L9(33)正交实验设计
Table 4. Experimental design with L9(33) orthogonal array
实验编号 物料质量
(g)研磨球数量
(个)分散剂体积
(mL)水平1 5 300 15 水平2 7 500 30 水平3 10 700 45 1 5 300 15 2 5 500 30 3 5 700 45 4 7 300 30 5 7 500 45 6 7 700 15 7 10 300 45 8 10 500 15 9 10 700 30
下载: 导出CSV
表 5 L9(33)正交实验下超细样品的D95粒径
Table 5. Particle sizes of ultra-fine samples under L9(33) orthogonal array
编号 D95(μm) GBW07404 GBW07447 GBW07104 GBW07121 1 12.64 12.85 13.65 14.01 2 9.31 8.93 10.32 10.71 3 9.94 9.53 8.57 8.63 4 9.52 9.01 13.89 13.79 5 7.51 7.05 9.23 9.55 6 13.73 12.94 14.60 15.02 7 11.62 11.90 13.60 13.97 8 15.01 14.76 15.26 15.88 9 10.96 11.02 14.05 14.75 K1 10.63 11.26 13.79 10.44 11.25 13.52 10.85 13.71 14.50 11.12 13.92 14.97 K2 10.25 10.61 9.93 9.67 10.25 9.65 12.57 11.60 12.75 12.79 12.05 13.08 K3 12.53 11.54 9.69 12.56 11.16 9.49 14.30 12.41 10.47 14.87 12.80 10.72 R 1.90 0.93 4.10 2.89 1.00 4.02 3.45 2.11 4.03 3.75 1.87 4.25
下载: 导出CSV
表 6 不同条件超细标准样品GBW07104的分析结果
Table 6. Analytical results of ultra-fine standard sample GBW07104 with different preparation procedures
稀土元素 认定值
(μg/g)表 1中的条件1 表 1中的条件2 表 1中的条件3 封闭压力酸溶法 6次测定平均值
(μg/g)RSD
(%)6次测定平均值
(μg/g)RSD
(%)6次测定平均值
(μg/g)RSD
(%)6次测定平均值
(μg/g)RSD
(%)Sc 9.50±0.7 9.35 3.71 9.63 4.85 9.58 5.09 9.41 4.10 La 22.0±2.0 21.5 5.04 22.4 5.21 20.8 2.91 23.2 4.72 Ce 40.0±3.0 42.3 4.25 39.5 4.83 40.6 3.20 43.1 4.11 Pr 4.90±0.40 4.71 2.72 4.86 2.94 4.77 3.30 4.94 2.86 Nd 19.0±2.0 19.8 4.43 17.9 4.36 18.4 4.93 19.2 4.35 Sm 3.40±0.20 3.45 3.10 3.27 4.07 3.48 3.72 3.32 3.27 Eu 1.02±0.05 0.98 3.52 1.15 3.91 1.10 4.17 1.07 2.65 Gd 2.70±0.40 2.82 4.56 2.91 4.25 2.76 2.15 2.87 2.14 Tb 0.41±0.05 0.43 3.03 0.38 3.35 0.45 3.32 0.42 3.32 Dy 1.85±0.17 1.89 3.17 1.76 3.71 1.92 4.05 1.79 2.93 Ho 0.34±0.03 0.32 3.92 0.35 4.62 0.31 5.21 0.37 4.05 Er 0.85±0.13 0.89 4.71 0.91 2.11 0.79 1.64 0.82 4.41 Tm 0.15±0.05 0.14 3.94 0.15 4.22 0.16 3.82 0.15 3.96 Yb 0.89±0.13 0.85 3.81 0.79 4.43 0.83 4.50 0.90 3.40 Lu 0.12±0.03 0.11 3.77 0.12 3.92 0.11 4.16 0.12 2.70 Y 9.30±1.20 9.05 3.82 9.70 2.18 9.10 4.05 8.90 2.16
下载: 导出CSV
表 7 方法准确度
Table 7. Accuracy tests of the methods
稀土元素 GBW07404 GBW07447 GBW07121 认定值
(μg/g)测定值
(μg/g)相对误差
(%)认定值
(μg/g)测定值
(μg/g)相对误差
(%)认定值
(μg/g)测定值
(μg/g)相对误差
(%)Sc 20.0±2.0 18.2 4.00 9.70±0.40 9.48 2.27 5.00±4.0 5.22 4.40 La 53.0±4.0 51.5 2.83 30.0±1.0 28.6 4.67 25.0±2.0 23.7 5.20 Ce 136±11 132 2.94 57.0±2.0 59.1 3.68 48.0±3.0 49.5 3.13 Pr 8.40±1.70 8.00 4.76 6.90±0.30 6.75 2.17 5.80±0.80 5.81 0.17 Nd 27.0±2.0 27.2 0.74 26.0±1.0 24.7 5.00 21.0±4.0 21.9 4.29 Sm 4.40±0.40 4.22 4.09 5.0±0.2 5.20 4.00 3.30±0.30 3.18 3.64 Eu 0.85±0.07 0.88 3.53 1.06±0.05 1.09 2.83 1.00±0.20 0.98 2.00 Gd 4.70±0.50 4.39 6.60 4.40±0.20 4.63 5.23 2.40±0.30 2.51 4.58 Tb 0.94±0.09 0.91 3.19 0.74±0.04 0.72 2.70 0.29±0.03 0.30 3.45 Dy 6.60±0.60 6.47 1.97 4.20±0.20 4.11 2.14 1.52±0.14 1.57 3.29 Ho 1.46±0.12 1.38 5.48 0.84±0.06 0.87 3.57 0.27±0.03 0.28 3.70 Er 4.50±0.70 4.38 2.67 2.40±0.20 2.29 4.58 0.76±0.08 0.73 3.95 Tm 0.70±0.10 0.66 5.71 0.39±0.03 0.38 2.56 0.11±0.02 0.10 9.09 Yb 4.80±0.60 4.69 2.29 2.50±0.20 2.56 2.40 0.69±0.08 0.71 2.90 Lu 0.75±0.06 0.72 4.00 0.38±0.03 0.39 2.63 0.11±0.01 0.12 9.09 Y 39.0±6.0 37.3 4.36 23.0±2.0 24.1 4.78 7.30±0.90 7.50 2.74
下载: 导出CSV
-
