Determination of Selenium in Soil by Inductively Coupled Plasma-Mass Spectrometry with Aqua Regia Digestion in Water Bath
-
摘要: 随着富硒产品关注度越来越高，对土壤中硒含量测定的研究也越来越受到人们的重视。应用传统电感耦合等离子体质谱法（ICP-MS）测定土壤样品中的硒时，受到的基体效应和多原子离子干扰比较显著，准确测定硒含量的难度较大。本文建立了采用50%王水-沸水浴消解体系，ICP-MS测定土壤样品中硒含量的方法，实验中采用动能歧视模式（KED）消除质谱干扰，选用103Rh元素作为在线加入内标以消除仪器信号漂移。用该方法对有证土壤标准物质进行分析，其结果均在不确定度范围内，测定值与认定值的相对误差介于-2.01%~2.99%之间，相对标准偏差（RSD）小于6.60%，检出限为0.012μg/g，测定下限为0.048μg/g。应用该方法与国家环境保护标准方法（HJ680—2013）对20个土壤实际样品进行比对分析，其结果基本一致。该方法适合于分析测定地质等行业大批量土壤样品中的硒。
-
关键词:
- 水浴消解 /
- 土壤 /
- 硒 /
- 电感耦合等离子体质谱法 /
- 动能歧视模式
Abstract:OBJECTIVES With more and more attention being paid to selenium-rich products, the study on the determination of selenium content in soil has become more significant. The accurate determination is difficult due to the serious interference of the matrix effect and polyatomic ion when determining selenium in soil samples by inductively coupled plasma-mass spectrometry (ICP-MS). OBJECTIVES To establish a method for accurate determination of Se in soil. METHODS The content of selenium in soil samples was determined by ICP-MS with 50% aqua regia-boiling water digestion. Kinetic energy discrimination mode (KED) was adopted to eliminate mass spectrum interference, and the 103Rh element was selected as the internal standard for on-line addition to eliminate instrument signal drift. RESULTS The results of the analysis of certified soil standard materials were consistent with those of certified standard materials within the uncertainty. The results showed that the relative errors (REs) of this method were between -2.01% and 2.99%, the relative standard deviation (RSD) was less than 6.60%, the detection limit was 0.012μg/g, and the minimum quantitative detection limit was 0.048μg/g. The method was applied to analyze 20 soil samples, and the results were consistent with those obtained by national environmental protection standard HJ680-2013. Conclusion The study results are suitable for the determination of selenium in large numbers of soil samples from the geological industry. -
-
表 1 不同消解时间下硒含量测定结果
Table 1. Analytical results of Se in different digestion time
土壤标准
物质编号Se认定值
(μg/g)不同消解时间Se测定值(μg/g) 0.5h 1.0h 1.5h 2.0h 2.5h 3.0h GBW07303 1.0±0.2 0.74 0.86 0.92 0.96 0.95 0.98 GBW07405 1.6±0.2 0.88 1.49 1.58 1.61 1.63 1.59
下载: 导出CSV
表 2 土壤标准物质中硒的测定结果
Table 2. Analytical results of Se in soil standard materials
土壤标准
物质编号Se认定值
(μg/g)12次Se测定值
(μg/g)测定平均值
(μg/g)相对误差
(%)RSD
(%)1.02 0.94 0.91 1.01 GBW07303 1.0±0.2 1.03 1.01 0.96 0.95 0.98 -1.67 3.76 1.00 1.01 0.97 0.99 0.26 0.32 0.28 0.28 GBW07304 0.29±0.08 0.26 0.29 0.27 0.28 0.28 -2.01 6.09 0.30 0.28 0.29 0.30 0.16 0.18 0.15 0.15 GBW07309 0.16±0.03 0.17 0.18 0.16 0.17 0.16 2.08 6.57 0.17 0.16 0.15 0.16 0.095 0.094 0.088 0.086 GBW07403 0.09±0.02 0.082 0.10 0.096 0.093 0.093 2.96 5.64 0.091 0.093 0.099 0.095 0.64 0.71 0.66 0.61 GBW07404 0.64±0.14 0.68 0.68 0.69 0.66 0.66 2.99 4.41 0.62 0.65 0.64 0.67 1.63 1.61 1.55 1.66 GBW07405 1.6±0.2 1.71 1.57 1.62 1.61 1.63 1.72 2.86 1.64 1.69 1.65 1.59
下载: 导出CSV
表 3 实际样品中硒的检测结果与方法比对结果
Table 3. Analytical results of Se in real samples and comparison of different methods
样品编号 Se测定值(μg/g) 本方法 HJ 680—2013方法 SY-1 0.34 0.36 SY-2 0.13 0.12 SY-3 0.63 0.61 SY-4 0.48 0.49 SY-5 1.03 1.05 SY-6 0.41 0.39 SY-7 0.25 0.26 SY-8 0.17 0.16 SY-9 0.52 0.49 SY-10 0.51 0.51 SY-11 0.84 0.88 SY-12 0.69 0.72 SY-13 0.23 0.21 SY-14 0.14 0.14 SY-15 1.83 1.85 SY-16 0.74 0.71 SY-17 0.096 0.10 SY-18 1.85 1.83 SY-19 0.32 0.30 SY-20 0.21 0.20
下载: 导出CSV
-
[1] 《岩石矿物分析》编委会.岩石矿物分析(第四版第三分册)[M].北京:地质出版社, 2011.
The editorial committee of <Rock and mineral analysis>. Rock and mineral analysis (The fourth edition:Vol.Ⅲ)[M].Beijing:Geological Publishing House, 2011.
[2] 刘金巍, 刘雪松, 边超, 等.甲烷动态反应电感耦合等离子体质谱法测定地下水中痕量硒[J].岩矿测试, 2019, 38(1):85-91. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201804200049
Liu J W, Liu X S, Bian C, et al.Determination of trace selenium in groundwater by DRC ICP-MS[J].Rock and Mineral Analysis, 2019, 38(1):85-91. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201804200049
[3] 王俊伟, 钱蜀, 李海霞, 等.电感耦合等离子体质谱法测定土壤样品中的痕量硒元素[J].中国环境监测, 2012, 28(3):97-100. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.202003050025
Wang J W, Qian S, Li H X, et al.Determination of trace selenium in soils by inductively coupled plasma-mass spectrometry[J].Environmental Monitoring in China, 2012, 28(3):97-100. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.202003050025
[4] 钱薇, 唐昊冶, 王如海, 等.一次消解土壤样品测定汞、砷和硒[J].分析化学, 2017, 45(8):1215-1221. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=fxhx201708020
Qian W, Tang H Y, Wang R H, et al.Determination of mercury, arsenic and selenium in soils by one-time digestion[J].Chinese Journal of Analytical Chemistry, 2017, 45(8):1215-1221. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=fxhx201708020
[5] 谭芳维, 黄菲, 唐秀龙, 等.水浴消解-原子荧光法测定土壤中硒、锑的研究[J].广州化工, 2019, 47(6):103-105. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gzhg201906043
Tan F W, Huang F, Tang X L, et al.Determination of selenium and antimony in soil by water bath digestion-atomic fluorescencel[J].Guangzhou Chemical Industry, 2019, 47(6):103-105. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gzhg201906043
[6] 陈海英.王水水浴消解-双道原子荧光光谱法(AFS)同时测定土壤中的汞和硒[J].农业科技与装备, 2013, 10(10):13-15. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=nyjxhydqh201310008
Chen H Y.Simultaneous determination of mercury and selenium in soil with aqua regia digestion in water bath and double channel atomic fluorescence spectrometry (AFS)[J].Agricultural Science & Technology and Equipment, 2013, 10(10):13-15. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=nyjxhydqh201310008
[7] 林海兰, 朱日龙, 于磊, 等.水浴消解-原子荧光光谱法测定土壤和沉积物中砷、汞、硒、锑和铋[J].光谱学与光谱分析, 2020, 40(5):1528-1533. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gpxygpfx202005037
Lin H L, Zhu R L, Yu L, et al.Determination of arsenic, mercury, selenium, antimony and bismuth in soil and sediments by water bath digestion-atomic fluorescence spectrometry[J].Spectroscopy and Spectral Analysis, 2020, 40(5):1528-1533. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gpxygpfx202005037
[8] 黄薇, 符式锦, 王旭日, 等.微波消解-ICP-MS测定土壤及植物中硒的含量[J].广州化工, 2014, 42(23):146-148. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgmengy201704053
Huang W, Fu S J, Wang X R, et al.Determination of selenium in soil and plant by microwave digestion-ICP-MS[J].Guangzhou Chemical Industry, 2014, 42(23):146-148. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgmengy201704053
[9] 刘芸, 曹国松, 程佩, 等.微波消解-ICP-MS法测定土壤中的硒含量[J].化学与生物工程, 2017, 34(11):67-70. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hbhg201711017
Liu Y, Cao G S, Cheng P, et al.Determination of selenium content in soil by microwave digestion-ICP-MS[J].Chemistry & Bioengineering, 2017, 34(11):67-70. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hbhg201711017
[10] 田敏, 刘畅.两种消解土壤中硒的方法对比分析[J].黑龙江环境通报, 2007, 31(3):33-34. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hljhjtb200703015
Tian M, Liu C.Comparative analysis of two digestion method of selenium in soil[J].Heilongjiang Environmental Journal, 2007, 31(3):33-34. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hljhjtb200703015
[11] 屈明华, 陈雄弟, 倪张林, 等.DRC-ICP-MS法测定土壤硒前处理方法研究[J].土壤通报, 2019, 50(3):698-703. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=trtb201903027
Qu M H, Chen X D, Ni Z L, et al.Pretreatment for determination of soil selenium by ICP-MS with dynamic reaction cell[J].Chinese Journal of Soil Science, 2019, 50(3):698-703. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=trtb201903027
[12] 严进.双氧水氧化1-(2-吡啶偶氮)-2-萘酚动力学光度法测定痕量硒[J].广州化工, 2016, 44(21):132-134. http://www.cqvip.com/QK/93773X/201621/670498070.html
Yan J.Determination of selenium by catalytic kinetic spectrophotometry in hydrogen peroxide-PAN system[J].Guangzhou Chemical Industry, 2016, 44(21):132-134. http://www.cqvip.com/QK/93773X/201621/670498070.html
[13] 韩亚, 郭伟, 汪洪.电感耦合等离子体质谱(ICP-MS)法与氢化物发生-原子吸收光谱(HG-AAS)法测定土壤中硒含量的对比研究[J].中国无机分析化学, 2020, 10(3):28-32. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgwjfxhxwz202003006
Han Y, Guo W, Wang H.Method comparison for determination of selenium in soil by ICP-MS and HG-AAS[J].Chinese Journal of Inorganic Analytical Chemistry, 2020, 10(3):28-32. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgwjfxhxwz202003006
[14] 冯永明, 邢应香, 刘洪青, 等.微波消解-电感耦合等离子体质谱法测定生物样品中微量硒的方法研究[J].岩矿测试, 2014, 33(1):34-39. http://www.ykcs.ac.cn/article/id/00a7dfe7-2a17-45e5-ada2-503f476cc501
Feng Y M, Xing Y X, Liu H Q, et al.Determination of trace selenium in biological samples by inductively coupled plasma-mass spectrometry with microwave digestion[J]. Rock and Mineral Analysis, 2014, 33(1):34-39. http://www.ykcs.ac.cn/article/id/00a7dfe7-2a17-45e5-ada2-503f476cc501
[15] 程秀花, 王海蓉, 黎卫亮, 等.电感耦合等离子体质谱法测定硒时多元素干扰的碰撞/反应研究及其在地质样品中的应用[J].冶金分析, 2015, 35(12):5-9. http://www.cnki.com.cn/Article/CJFDTotal-YJFX201512002.htm
Cheng X H, Wang H R, Li W L, et al.Study on collision/reaction for multielement interference in determination of selenium by inductively coupled plasma mass spectrometry and its application to geological sample[J].Metallurgical Analysis, 2015, 35(12):5-9. http://www.cnki.com.cn/Article/CJFDTotal-YJFX201512002.htm
[16] 徐鹏, 孙亚莉.Carius管密封溶样-等离子体质谱法测定环境样品中镓、锗、砷、硒、镉、锡、锑、碲、汞、铅和铋[J].分析化学, 2010, 38(4):581-584. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=fxhx201004027
Xu P, Sun Y L.Determination of Ga, Ge, As, Se, Cd, Sn, Sb, Te, Hg, Pb and Bi in environmental samples by inductively coupled plasma mass spectrometry combined with Carius tube digestion[J].Chinese Journal of Analytical Chemistry, 2010, 38(4):581-584. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=fxhx201004027
[17] D'Ilio S, Violante N, Majorani C, et al.Dynamic reaction cell ICP-MS for determination of total As, Cr, Se and Ⅴ in complex matrices:Still a challenge?A review[J].Analytica Chimica Acta, 2011, 698(1):6-13. http://test.europepmc.org/abstract/MED/21645653
[18] 陈波, 刘洪青, 邢应香.电感耦合等离子体质谱法同时测定地质样品中锗硒碲[J].岩矿测试, 2014, 33(2):192-196. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ykcs201402006
Chen B, Liu H Q, Xing Y X.Simultaneous determination of Ge, Se and Te in geological samples by inductively coupled plasma-mass spectrometry[J].Rock and Mineral Analysis, 2014, 33(2):192-196. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ykcs201402006
[19] 刘征宙, 曹丽丽, 陈浩云, 等.电感耦合等离子体质谱法-碰撞反应池技术测定高纯度磷酸二氢钾中痕量金属元素[J].化学试剂, 2015, 37(9):809-811, 842. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=huaxsj201509009
Liu Z Z, Cao L L, Chen H Y, et al.Detection of trace metal elements in potassium dihydrophate with ICP-MS(CCT) method[J].Chemical Reagents, 2015, 37(9):809-811, 842. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=huaxsj201509009
[20] 余兴.电感耦合等离子体四极杆质谱碰撞/反应池技术现状与进展[J].冶金分析, 2013, 33(3):14-23. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201303003
Yu X.The present situation and advance in collision/reaction cell technique of inductively coupled plasma quadrupole mass spectrometry[J].Metallurgical Analysis, 2013, 33(3):14-23. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201303003
[21] 章连香, 冯先进.八极杆碰撞/反应池(ORS) -电感耦合等离子体质谱(ICP-MS)法测定复杂矿物中的稀土元素[J].中国无机分析化学, 2017, 7(2):22-26. http://www.cnki.com.cn/Article/CJFDTotal-GUAN200506039.htm
Zhang L X, Feng X J.Determination of rare earth elements in complex minerals by octopole reaction system (ORS)-inductively coupled plasma mass spectrometry (ICP-MS)[J].Chinese Journal of Inorganic Analytical Chemistry, 2017, 7(2):22-26. http://www.cnki.com.cn/Article/CJFDTotal-GUAN200506039.htm
[22] 韩建华, 孙传强, 汪曣, 等.电感耦合等离子体质谱中碰撞反应池的模拟探讨[J].冶金分析, 2014, 34(9):1-7. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201409001
Han J H, Sun C Q, Wang Y, et al.Discussion on the simulation of collision reaction cell in inductively coupled plasma mass spectrometry[J].Metallurgical Analysis, 2014, 34(9):1-7. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201409001
[23] 陕红, 孙宝利, 黄金丽, 等.DRC-ICP-MS测定蜂王浆中硒的方法研究[J].分析测试学报, 2016, 35(9):1191-1194. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=fxcsxb201609022
Shan H, Sun B L, Huang J L, et al.Analysis of selenium in royal jelly by ICP-MS with dynamic reaction cell[J].Journal of Instrumental Analysis, 2016, 35(9):1191-1194. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=fxcsxb201609022
[24] 杏朝刚, 袁京群, 李士敏.微波消解-动态反应池电感耦合等离子体质谱测定农产品中的痕量硒[J].浙江农业学报, 2018, 30(8):1414-1419. http://www.cnki.com.cn/Article/CJFDTotal-ZJNB2018082400J.htm
Xing C G, Yuan J Q, Li S M.Determination of trace selenium in agricultural products with microwave digestion-dynamic reaction cell inductively coupled plasma mass spectrometry[J].Acta Agriculturae Zhejianggensis, 2018, 30(8):1414-1419. http://www.cnki.com.cn/Article/CJFDTotal-ZJNB2018082400J.htm
[25] 徐进力, 邢夏, 唐瑞玲, 等.动能歧视模式ICP-MS测定地球化学样品中14种痕量元素[J].岩矿测试, 2019, 38(4):394-402. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201812070131
Xu J L, Xing X, Tang R L, et al.Determination of 14 trace elements in geochemical samples by ICP-MS using kinetic energy discrimination mode[J].Rock and Mineral Analysis, 2019, 38(4):394-402. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201812070131
[26] 黄子敬, 陈孟君, 邓华阳, 等.微波消解-ICP-MS混合模式测定动植物源食品中11种金属元素[J].分析试验室, 2017, 36(1):24-28. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=fxsys201701006
Huang Z J, Chen M J, Deng H Y, et al.Determination of 11 trace elements in animal and plant origin food by microwave digestion with ICP-MS in mixed mode[J].Chinese Journal of Analysis Laboratory, 2017, 36(1):24-28. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=fxsys201701006
[27] 林珍, 黄超冠, 卢燕平, 等.沸水浴-氢化物发生原子荧光光谱法测定土壤中的硒[J].广州化学, 2017, 42(3):34-37. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gzhx201703006
Lin Z, Huang C G, Lu Y P, et al.Boilingwater bath-determination of selenium in soil by hydride generation atomic fluorescence spectrometry[J].Guangzhou Chemistry, 2017, 42(3):34-37. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gzhx201703006
[28] 郑欣.X Series 2 ICP-MS CCTED在食品样品超痕量元素分析中的应用[J].环境化学, 2009, 28(3):467-468. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hjhx200903036
Zheng X.Application of X Series 2 ICP-MS CCTED in analysis of ultra-trace elements of food samples[J].Environmental Chemistry, 2009, 28(3):467-468. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hjhx200903036
-
