Chemical Phase Analysis of Arsenic Ores—A Study on Selective Separation Conditions of Orpiment and Realgar
-
摘要:
雌黄和雄黄是两种含砷硫化物的共生矿物，具有相似的理化性质，砷矿石化学物相分析方法一直将雌黄和雄黄作为同一相态分析，无法获得各自的含量，影响该类矿石选冶研究。本文以湖南石门雌黄和雄黄砷矿石为研究对象，采用单矿物选择分离技术，对雌黄和雄黄样品的分离条件进行了研究。结果表明：雌黄和雄黄单矿物采用4mol/L氨水溶液，35℃水浴浸取6h，雌黄浸取率为92.2%，雄黄浸取率为2.4%。分离雌黄后，雄黄采用2mol/L氢氧化钠溶液浸取，雄黄浸取率最高为75.8%，基于雄黄空间结构易被氧化，加入碘可将雄黄氧化为易溶于碱的砷氧化物，使雄黄浸取率提高至92.2%，实现雌黄和雄黄的选择性分离。通过X射线衍射仪、全自动矿物仪分析验证在此条件下雌黄和雄黄化学物相分析结果的正确度，两种分析方法的测定值均与化学物相测定值的相对偏差小于14.0%，满足地质矿产实验室测试质量管理规范的要求。该选择性分离条件的确定，有效地提高了雌黄和雄黄的浸取率，对于以雌黄和雄黄为主的砷矿石化学物相分析方法制定奠定了基础。
Abstract:As a rich symbiotic mineral resource, orpiment (As2S3) and realgar (AsS/As2S2/As4S4) are common sulfide minerals of arsenic. However, due to their similar chemical properties, the chemical phase analysis method of arsenic has always taken these two minerals as the same phase analysis and determination, and cannot obtain their respective contents. In the research, the orpiment and realgar arsenic ores of Shimen in Hunan Province were taken as the object. The separation conditions of orpiment and realgar samples were studied by single-mineral selective separation technology. The single mineral of orpiment and realgar was leached with 4mol/L ammonia solution and a 35℃ water bath for 6h. The extraction rate of orpiment and realgar was 92.2% and 2.4% respectively. Realgar was leached with sodium hydroxide solution, the extraction of realgar was 75.8%. Due to the spatial structure of realgar being oxidized, the addition of iodine can oxidize it into arsenic oxide that is easily soluble in alkali, increasing the extraction rate to 92.2%. The building of the selective separation conditions lays the foundation for the development of chemical phase separation methods for arsenic ores mainly composed of orpiment and realgar. The BRIEF REPORT is available for this paper at
http://www.ykcs.ac.cn/en/article/doi/10.15898/j.ykcs.202208050145 .-
Key words:
- orpiment /
- realgar /
- chemical phase analysis /
- ammonia /
- sodium hydroxide /
- selective separation conditions
-
-
表 1 砷矿石中雌黄和雄黄化学物相分析数据与X射线衍射分析仪分析数据比对
Table 1. Comparison of the measured data obtained by chemical phase analysis and those of X-ray diffraction analyzer for orpiment and realgar in arsenic ores
样品编号 雌黄 雄黄 化学物相As测定值
(%)X射线衍射As测定值
(%)相对偏差
(%)化学物相As测定值
(%)X射线衍射As测定值
(%)相对偏差
(%)SY-1 6.36 6.5 −1.1 4.38 4.5 −1.4 SY-2 2.33 2.0 7.6 2.39 3.0 −11.3 SY-3 2.45 2.0 10.1 4.98 5.0 −0.2 SY-4 2.12 2.7 −12.0 8.83 9.0 −0.95 SY-5 4.69 5.0 −3.2 12.12 12.0 0.50
下载: 导出CSV
表 2 砷矿石中雌黄和雄黄化学物相分析数据与全自动矿物分析仪分析数据比对
Table 2. Comparison of measured data obtained by chemical phase analysis and those of automatic mineral analyzer for realgar and orpiment in arsenic ores
样品编号 雌黄 雄黄 化学物相分析As
测定值(%)MLA分析As
测定值(%)相对偏差
(%)化学物相分析As
测定值(%)MLA分析As
测定值(%)相对偏差
(%)SH-7 2.62 3.46×0.606=2.10 11.0 2.32 2.51×0.700=1.76 13.7 SH-6 3.01 5.23×0.606=3.17 −2.6 4.70 6.48×0.700=4.53 1.7 SH-3 3.23 5.85×0.606=3.54 −4.6 8.04 11.24×0.700=7.86 1.1 SH-2 4.94 8.37×0.606=5.07 −1.3 12.52 17.32×0.700=12.12 1.6 SH-9 17.01 25.99×0.606=15.75 3.8 9.30 12.71×0.700=8.89 2.3 注：雌黄电子探针分析结果w(As)=60.6%；雄黄电子探针分析结果w(As)=70.0%。
下载: 导出CSV
表 3 砷矿石各矿物相数据加和与全量数据的相对偏差
Table 3. The relative standard deviation of the sum of the data of each mineral phase and the total data of arsenic ores
样品编号 全量As测定值
(%)相态加和As
测定值(%)相态加和与全量
的相对偏差(%)SH-7 5.70 5.84 −1.2 SH-6 8.71 8.65 0.35 SH-3 12.72 12.72 0.00 SH-2 18.95 18.87 0.21 SH-9 27.90 28.06 −0.29
下载: 导出CSV
表 4 砷矿石各矿物相化学物相分析方法的重复性限和再现性限
Table 4. Repeatability and reproducibility limits of chemical phase analysis of arsenic ores
总砷及相关化学
物相中砷范围或水平
m(%)重复性限
r(%)再现性限
R(%)总砷 5.59～27.78 r＝0.26+0.0016m R＝−0.55+0.60ln(m) 砷华中砷 0.29～0.72 r＝0.019+0.087m R＝−0.0049+0.55m 雌黄中砷 2.74～17.13 r＝0.029+0.076m R＝0.74+0.061m 雄黄中砷 2.38～12.35 r＝0.19+0.023m R＝0.82−0.0007m 毒砂中砷 0.24～0.88 r＝0.038+0.080m R＝0.035+0.23m
下载: 导出CSV
-
[1] 《岩石矿物分析》编委会. 岩石矿物分析(第四版 第三分册)[M]. 北京: 地质出版社, 2011: 280-282.
The editorial committee of “Rock and Mineral Analysis”. Rock and Mineral Analysis (The fourth edition: Vol. Ⅲ)[M]. Beijing: Geological Press, 2011: 280-282.
[2] 宣之强. 中国砷矿资源概述[J]. 化工矿产地质, 1998, 20(3): 205−210.
Xuan Z Q. An overview of arsenic resources in China[J]. Geology of Chemical Minerals, 1998, 20(3): 205−210.
[3] 熊先孝. 中国雄黄雌黄矿床类型成矿机制与找矿方向[J]. 化工矿产地质, 1999, 21(2): 76−79.
Xiong X X. Metallogenic mechanism and prospecting direction of realgar orpiment deposit types in China[J]. Chemical Mineral Geology, 1999, 21(2): 76−79.
[4] 赵欣, 张干. 含砷金精矿的处理方法[J]. 有色冶金设计与研究, 2007, 28(6): 7−9.
Zhao X, Zhang G. Treatment method of arsenic-bearing gold concentrate[J]. Nonferrous Metals Engineering & Research, 2007, 28(6): 7−9.
[5] 刘荣丽, 伍赠玲, 戴红光, 等. 甘肃坪定金矿含砷硫化矿的细菌浸出[J]. 矿产综合利用, 2006(5): 6−8.
Liu R L, Wu Z L, Dai H G, et al. Bioleaching of as-containing sulphide ore of Pingding gold mine in Gansu[J]. Multipurpose Utilization of Mineral Resources, 2006(5): 6−8.
[6] 刘树根, 田学达. 含砷固体废物的处理现状与展望[J]. 湿法冶金, 2005, 24(4): 183−186.
Liu S G, Tian X D. Situation and prospect on treating of arsenic-containing solid waste[J]. Hydrometallurgy of China, 2005, 24(4): 183−186.
[7] 袁秋红, 王跃虎, 张广积, 等. 不同菌种对雌黄的生物浸出机理[J]. 中国有色金属学报, 2010, 20(6): 1234−1240.
Yuan Q H, Wang Y H, Zhang G J, et al. Bioleaching mechanism of orpiment with different bacteria strains[J]. The Chinese Journal of Nonferrous Metals, 2010, 20(6): 1234−1240.
[8] 夏光祥, 石伟, 吴林荣, 等. 碱性催化氧化含砷难处理金矿石的理论及工艺研究[J]. 黄金, 1996, 17(2): 27−33.
Xia G X, Shi W, Wu L R, et al. Theoretical and technology research on alkaline catalytic oxidation of arsenic-containing refractory gold ores[J]. Gold, 1996, 17(2): 27−33.
[9] 马红周, 燕超, 王耀宁, 等. 氢氧化钠浸出含砷金矿中砷[J]. 贵金属, 2015, 36(1): 14−16, 20.
Ma H Z, Yan C, Wang Y N, et al. Leaching the arsenic in the gold ore by sodium hydroxide[J]. Precious Metals, 2015, 36(1): 14−16, 20.
[10] 刘许生. 石门雄黄: 一座矿山的传奇与悲伤[J]. 国土资源导刊, 2014, 11(11): 86−90.
Liu X S. Shimen realgar: Legend and sorrow of a mine[J]. Land Resources Guide, 2014, 11(11): 86−90.
[11] 㒰燕, 张英军, 李先荣. 湖南石门雄黄的研究[J]. 中国中医药科技, 1997, 4(5): 286−288.
Tong Y, Zhang Y J, Li X R. Research on realgar in Shimen of Hunan[J]. Chinese Medicine Science and Technology, 1997, 4(5): 286−288.
[12] 杨世平, 杨细华, 李安邦, 等. 电子探针技术研究大别造山带富硫独居石地球化学特征及稀土矿化成因[J]. 岩矿测试, 2022, 41(4): 541−553.
Yang S P, Yang X H, Li A B, et al. Study on geochemical characteristics and REE mineralization of S-enriched monazite in the Dabie orogenic belt by electron probe microanalysis[J]. Rock and Mineral Analysis, 2022, 41(4): 541−553.
[13] 秦玉娟, 宋光永, 吕玉珍, 等. 电子探针在枝管藻化石微观结构与成分分析中的应用[J]. 微体古生物学报, 2022, 39(4): 361−372.
Qin Y J, Song G Y, Lyu Y Z, et al. Application of electron probe in microstructure and composition analysis of cladophyllis fossils[J]. Journal of Micropaleontology, 2022, 39(4): 361−372.
[14] 李钢, 程永科, 黄长高, 等. 矿物药雄黄的结构与热稳定性研究[J]. 南京师大学报(自然科学版), 2008(3): 63−67.
Li G, Cheng Y K, Huang Z G, et al. Study on structure and thermal stability of mineral medicine realgar[J]. Journal of Nanjing Normal University (Natural Science Edition), 2008(3): 63−67.
[15] 夏光祥, 段东平, 周娥, 等. 加压催化氧化氨浸法处理坪定金矿的研究和新工艺开发[J]. 黄金科技, 2013, 21(5): 93−96.
Xia G X, Duan D P, Zhou E, et al. Research and development of new technology for treating Pingding gold mine by pressurized catalytic oxidation ammonia leaching[J]. Gold Technology, 2013, 21(5): 93−96.
[16] 夏光祥, 石伟, 涂桃枝, 等. 自含砷含碳难处理金矿中提金研究——Ⅱ. 硫氨脱砷-铜氨催化氧化-氰化[J]. 化工冶金, 1995, 16(4): 302−306.
Xia G X, Shi W, Tu T Z, et al. Extraction of gold from refractory gold orecontaining arsenic and arbon Ⅱ. Dearsenication with sulfur in ammonia water-catalytic oxidation with Cu ion in ammonia water-cyanidation[J]. Chemical Metallurgy, 1995, 16(4): 302−306.
[17] 周人龙. 难冶金矿中回收金银的雌黄法[J]. 有色矿冶, 1996(3): 44.
Zhou R L. The orpiment method for recovering gold and silver from refractory metallurgical mines[J]. Non-Ferrous Mining and Metallurgy, 1996(3): 44.
[18] 张国庆, 张明美, 王少锋, 等. 含氧溶液中毒砂氧化溶解的XAFS研究[J]. 核技术, 2016, 39(11): 19−24.
Zhang G Q, Zhang M M, Wang S F, et al. XAFS study on the oxidation dissolution of poisoned sand with oxygen solution[J]. Nuclear Engineering, 2016, 39(11): 19−24.
[19] 汪寅夫, 李清, 刘琦, 等. X射线衍射和电子探针技术在矿物药雄黄鉴定及质量评价中的应用[J]. 岩矿测试, 2014, 33(5): 706−713.
Wang Y F, Li Q, Liu Q, et al. Application of X-ray diffraction and electron probe technology in identification and quality evaluation of mineral realgar[J]. Rock and Mineral Analysis, 2014, 33(5): 706−713.
[20] 洪汉烈, 肖睿娟, 闵新民. 雄黄矿物表面氧化过程的量子化学计算[J]. 矿物学报, 2004(1): 95−98.
Hong H L, Xiao R J, Min X M. Quantum chemical calculation of surface oxidation process of realgar minerals[J]. Acta Mineralogica, 2004(1): 95−98.
[21] Tong M, Yuan S H, Ma S C, et al. Production of abundant hydroxyl radicals from oxygenation of subsurface sediments[J]. Environmental Science & Technology, 2015, 50(1): 4890−4891.
[22] 张淑媛. 亚铁诱导地表环境中雄黄的氧化转化行为研究[D]. 武汉: 华中科技大学, 2018.
Zhang S Y. Oxidative transformation behavior of realgar in surface environment induced by Fe2+[D]. Wuhan: Huazhong University of Science and Technology, 2018.
[23] Renock D, Becker U. A first principles study of the oxidation energetics and kinetics of realgar[J]. Geochimica et Cosmochimica Acta, 2010, 74(15): 4266−4284. doi: 10.1016/j.gca.2010.05.003
[24] 洪俊. 毒砂矿(光)化学氧化释放砷过程及活性氧物种的生成与作用机理[D]. 武汉: 华中农业大学, 2020.
Hong J. The process of releasing arsenic by photochemical oxidation of arsenopyrite ore and the formation and mechanism of active oxygen species[D]. Wuhan: Huazhong Agricultural University, 2020.
[25] 金华爱. 有机抑制剂浮选分离辉锑矿与毒砂[J]. 矿产综合利用, 1989(1): 21−25.
Jin H A. Separation of antimonite and arsenopyrite by organic inhibitor flotation[J]. Comprehensive Utilization of Minerals, 1989(1): 21−25.
[26] 邱廷省, 张宝红, 张卫星, 等. 毒砂与黄铁矿分离技术现状及研究进展[J]. 矿山机械, 2013, 41(4): 1−5.
Qiu T S, Zhang B H, Zhang W X, et al. Status and research progress of arsenopyrite and pyrite separation technology[J]. Mining Machine, 2013, 41(4): 1−5.
[27] 熊英, 董亚妮, 裴若会, 等. 锑矿石化学物相分析方法选择性分离条件验证及准确度评估[J]. 岩矿测试, 2017, 36(2): 156−162.
Xiong Y, Dong Y N, Pei R H, et al. Selective separation condition verification and accuracy evaluation of chemical phase analysis method for antimony ore[J]. Rock and Mineral Analysis, 2017, 36(2): 156−162.
[28] 车东, 刘成雁, 王志嘉, 等. X射线衍射全谱拟合法测定矿物药朱砂中硫化汞和二氧化硅的含量[J]. 测试技术学报, 2018, 32(1): 36−40.
Che D, Liu C Y, Wang Z J, et al. Determination of HgS and SiO2 in cinnabar by X-ray diffraction full spectrum fitting[J]. Journal of Testing Technology, 2018, 32(1): 36−40.
[29] 张立平. 钴酸锂原材料四氧化三钴中亚钴的X射线衍射定量分析[J]. 山东化工, 2022, 51(14): 120−121, 124.
Zhang L P. Quantitative analysis of Co2+ from Co3O4 by X-ray diffraction[J]. Shandong Chemical Industry, 2022, 51(14): 120−121, 124.
[30] 刘婷婷, 张超. MLA矿物参数自动分析系统在矿产品掺假判定中的应用[J]. 现代矿业, 2016, 32(6): 59−61.
Liu T T, Zhang C. Application of MLA automatic mineral parameter analysis system in determination of adulteration of mineral products[J]. Modern Mining Industry, 2016, 32(6): 59−61.
[31] 万双, 李先和, 吕广颖, 等. 碲化铜中碲含量测定方法的精密度[J]. 化学分析计量, 2019, 28(5): 93−98.
Wan S, Li X H, Lyu G Y, et al. Precision of the method for determination of Te content in CuTe[J]. Chemical Analytical Metrology, 2019, 28(5): 93−98.
[32] 郝福, 胡向青, 张志伟, 等. 药物质量控制对分析方法精密度的要求[J]. 中南药学, 2019, 17(1): 60−65.
Hao F, Hu X Q, Zhang Z W, et al. Drug quality control requirements for the precision of analytical methods[J]. Zhongnan Pharmaceutical, 2019, 17(1): 60−65.
-
