海底观测平台多电池组电源管理系统

详细信息

收稿日期: 2015-03-09

MULTI-POWER MANAGEMENT SYSTEM OF SEAFLOOR OBSERVATION PLATFORM

Received Date: 09 March 2015

摘要: 主要介绍了一种用于海底观测平台的多电池组电源管理系统。该系统以STM32F103单片机为主控制芯片,控制多个的电池组的输入和输出,实现主电源与备用电源的自动切换。MCU通过A/D模块采集电池组和各个负载端口的电压、电流,并对其进行判断和处理,电池组按照优先级的顺序进行轮换供电,对输出端口进行智能控制。上位机应用软件对电池组电压、电流进行实时监测,实时显示当前电池组供电情况并对其进行控制。
- 海底观测平台 /
- MCU /
- A/D /
- 电源管理系统
Abstract: This paper deals with the multi-power management system for seafloor observation platforms. The master controller uses ST's 32-bit ARM core microprocessor STM32F103 in the system, which not only controls the multiple battery input and output, but also realizes automatic switching between the main and the stand-by powers. The MCU will judge and deal with the data of the voltage and current from the battery and load obtained by A/D module. The battery supplies power in an order of priority and the ON/OFF of output is intelligently controlled by MCU. The PC application software is used to real-time monitor the voltage and current of the battery and load as well as status of ON/OFF channels.
- seafloor observation platform /
- MCU /
- A/D /
- power management system
