THE RELATION BETWEEN TECTONIC ACTIVITY AND SEDIMENTARY FRAMEWORK:EVIDENCE FROM THE LAKE ALBERT, EAST AFRICAN RIFT SYSTEM
-
摘要:
Albert湖盆作为东非裂谷系重要的裂谷盆地，具有巨大的油气资源潜力。但前期资料匮乏，制约着Albert盆地的研究进展，目前仍存在着构造活动背景下沉积物响应特征不明确等亟待解决的问题。通过录井、测井及地震地质资料，结合Google Earth对该区盆地结构、湖盆断裂体系和沉积体系开展研究，并深入探讨构造对沉积物分配的控制作用。研究表明，Albert湖盆发育非对称式地堑结构，盆地两侧以正断层发育为主，西侧陡，东侧缓；主要为三角洲-湖泊沉积体系，其中三角洲包括三角洲平原及前缘亚相，湖泊包括滨浅湖及深湖亚相。不同裂谷演化时期，构造对沉积物分配控制作用明显。低扩张阶段南侧断层活动强烈，沉积物主要从北侧入湖，主要发育河流及正常三角洲；初始断裂阶段西北侧断层活动强烈，沉积物从东南侧入湖，主要发育扇三角洲及辫状河三角洲；第2断裂阶段断裂活动基本终止，沉积物从东南、东北两方向入湖，主要发育扇三角洲、辫状河三角洲及河流相。湖盆内主要发育同向叠置型和相向平行型2类构造调节带，断层组合样式形成的构造低部位，作为沉积物搬运的有利通道，对沉积物的分配起到控制作用。
Abstract:The Lake Albert is a rift basin with large hydrocarbon potential as a part of the East African Rift System. The study of lake geology is limited for lacking of data. The sedimentation under the tectonic background remains unclear up to date.This paper is devoted to the basin tectonics and lake sedimentation based on logging, drilling, seismic data and the data from Google Earth. The Lake Albert is an unsymmetrical graben formed under active tectonics. A steep normal fault occurs in the west and a gentle slope in the east.Three major facies occur as infillings in the lake, i.e. the deep lacustrine, the shallow lacustrine and delta deposits consisting of deltaic plain and deltaic front. Structures have obvious control over the sedimentation pattern. Sediments came from the north side where fluvial and deltaic deposits prevailed.The first phase of rifting was characterized by strong tectonic activity on the northwest side of the lake, and in the second phase fan-delta and braid river delta facies developed astectonic activities weakened. Sediments were supplied from the southeast and northeast sides of the lake and dominated by fluvial fan delta and braid river delta deposits.There are two major transverse fault zones in the Lake Albert, a synthetic overlapping zone and a convergent collateral zone.The structural pattern of the fault assemblage formed in a relatively low position, which is the dominant path of transportation.Above all, the transverse fault zones have obvious control over the distribution pattern of depositional system.
-
Key words:
- East African Rift System /
- Lake Albert /
- fault system /
- sedimentary facies /
- transverse fault zones
-
-
表 1 沉积相类型及特征(据文献[21]修改)
Table 1. Sedimentary facies and their characteristics (modified from reference [21])
沉积相类型 岩性 沉积构造 生物特征
岩性剖面图 湖泊沉积体系 深湖亚相 层状暗色泥岩 铁质结核，石膏 有葡萄球藻，淡水双壳类少，富含有机质
滨浅湖亚相 以泥岩为主，暗色泥岩和粉砂到中砂交替出现，分选差 泥岩：块状、水平层理砂岩：交错层理和平行层理 构造多来源于母岩，偶见水平、竖直生物潜穴，可见盘兴藻，局部富含有机质
三角洲沉积体系 三角洲前缘亚相 主要以细粒砂岩为主 交错层理，冲刷面 有禾木科
三角洲平原亚相 主要是中粒砂岩，可见细粒到粗粒砂岩；分选好，向上变粗 水流波痕，爬升波痕和沙坝叠加而成的巨型交错层理 偶见垂直生物潜穴，泥岩之间可见盘兴藻
下载: 导出CSV
-
[1] Gregory J W.Contributions to the physical geography of British East Africa[J].The Geographical Journal, 1894, 4(4):289-315. doi: 10.2307/1773534
[2] Willis B, T C R.East African plateaus and rift valleys: studies in comparative seismology[J]. Journal of Geology, 1937, 45:216-219. doi: 10.1086/624520
[3] Morgan W J.Convection Plumes in the Lower Mantle[J].Nature, 1971, 230(5288):42-43. doi: 10.1038/230042a0
[4] Baker B H, McConnell R B.The Structural Pattern of the Afro-Arabian Rift System in Relation to Plate Tectonics:Discussion[J].Philosophical Transactions of the Royal Society of London A: Mathematical, Physical and Engineering Sciences, 1970, 267(1181):383-391. http://rsta.royalsocietypublishing.org/content/267/1181/383.abstract
[5] Rosendahl B R.Architecture of continental rifts with special reference to East Africa[J]. Annual Review of Earth and Planetary Sciences, 1987, 15(1):445-503. doi: 10.1146/annurev.ea.15.050187.002305
[6] Morley C K.Comparison of hydrocarbon prospectivity in rift systems[J]. AAPG Special Volumes, 1999, 44:233-242. https://www.researchgate.net/publication/313772007_Comparison_of_hydrocarbon_prospectivity_in_rift_system
[7] Karner G D, Byamungu B R, Ebinger C J, et al.Distribution of crustalextension and regional basin architecture of the Albertine Rift System, East Africa[J].Marine and Petroleum Geology, 2000, 17(10):1131-1150. doi: 10.1016/S0264-8172(00)00058-1
[8] Ebinger C J.Tectonic development of the western branch of the East Africanrift system[J]. Geological Society of America Bulletin, 1989, 101(7):885-903. doi: 10.1130/0016-7606(1989)101<0885:TDOTWB>2.3.CO;2
[9] Abeinomugisha D. Tectonics and Sedimentation[C]//Abeinomugisha D, Kasande R. Tectonic control on hydrocarbon accumulation in the intracontinental Albertine graben of the east African rift system, 2012, 16(special published): 209-228.
[10] 蔡文杰, 韩文明, 许志刚, 等.东非Lake Albert盆地构造调节带特征及其对油气成藏的控制作用[J].地质科技情报, 2015, 34(4):119-123. http://www.cnki.com.cn/Article/CJFDTotal-DZKQ201504017.htm
[11] Roller S, Homung J, Hinderer M, et al. Middle Miocene to Pleistocene sedimentary record of rift evolution in the southern Albert Rift(Uganda)[J].International Journal of Earth Sciences, 2010, 99(7):1643-1661. doi: 10.1007/s00531-010-0560-z
[12] 赵伟.裂谷盆地转换带浅水三角洲沉积特征与沉积模式——以东非Albertine地堑为例[J].西部资源, 2016(2): 118-121. http://www.cnki.com.cn/Article/CJFDTotal-XBZY201602048.htm
[13] 刘桂和, 彭文绪, 刘喜玲.Albertine地堑构造沉积响应及其油气勘探意义[J].长江大学学报:自然科学版, 2013, 10(14):27-29. http://www.cnki.com.cn/Article/CJFDTotal-CJDL201314008.htm
[14] 于水, 韩文明, 赵伟, 等.裂谷盆地陡断带三角洲沉积特征与成因模式——以东非裂谷Albertine地堑为例[J].中国海上油气, 2013, 25(6):31-35. http://www.cnki.com.cn/Article/CJFDTotal-ZHSD201306005.htm
[15] 张翠梅, 刘晓峰, 苏明.南堡凹陷老爷庙地区构造-沉积分析[J].地球科学:中国地质大学学报, 2009, 34(5):829-834. http://d.old.wanfangdata.com.cn/Periodical/dqkx200905015
[16] 吴康军, 龚福华, 易雪斐.转换带的分类浅述[J].长江大学学报:自然科学版, 2011, 8(12):67-70. http://d.old.wanfangdata.com.cn/Periodical/cjdxxb-rkxb201112024
[17] 漆家福.裂陷盆地中的构造变换带及其石油地质意义[J].海相油气地质, 2007, 12(4):43 -50. doi: 10.3969/j.issn.1672-9854.2007.04.007
[18] 刘子漩, 吴冬.断陷盆地构造转换带对砂体分布影响研究[J].复杂油气藏, 2016, 9(1):17-21. http://d.old.wanfangdata.com.cn/Periodical/fzyqc201601004
[19] 熊斌辉.构造控制下的西沙海槽沉积模式[J].海洋石油, 2013, 33(1):1-6. doi: 10.3969/j.issn.1008-2336.2013.01.001
[20] 张兴, 童晓光.艾伯特裂谷盆地含油气远景评价——极低勘探程度盆地评价实例[J].石油勘探与开发, 2001, 28(2):102-106. doi: 10.3321/j.issn:1000-0747.2001.02.030
[21] Simon B, Guillocheau F, Robin C, et al.Deformation and sedimentary evolution of the Lake Albert Rift(Uganda, East African Rift System)[J].Marine and Petroleum Geology, 2017, 86:17-37. doi: 10.1016/j.marpetgeo.2017.05.006
[22] 杨小丽, 胡光义, 庞玉茂, 等.Albert湖盆北区退积型浅水三角洲沉积及储层特征[J].中国海上油气, 2015, 27(5): 55-61. http://d.old.wanfangdata.com.cn/Periodical/zghsyq-gc201505009
[23] Morley C K, Nelson R A, Patton T L, et al.Transfer zones in the East African Rift System and their relevance to hydrocarbon exploration in rifts[J].The American Association of Petroleum Geologists Bulletin, 1990, 74(8):1234-1253. https://www.researchgate.net/publication/248149866_Transfer_zones_in_the_East_African_Rift_System_and_their_relevance_to_hydrocarbon_exploration_in_rifts
-
