Application of multi-attribute analysis technology based on FCM algorithm in fine characterization of sedimentary microfacies： take T Gas Field in Xihu Sag as an example
-
摘要:
西湖凹陷T气田经过十多年的勘探与开发，亟需在主力层花港组内寻找潜力目标。该区为浅水三角洲沉积体系，岩性组合在空间上变化快，为了精确识别河道砂体及其边界，在海上少井条件下利用三维地震资料识别并刻画河道砂体。在等时地层划分的基础上，对目的层段进行岩石物理性质分析，通过地震沉积学的技术方法结合岩芯及测井等资料，对沉积微相做出初步判断，在此基础上提取6类48种地震属性，与砂厚及各属性之间进行相关性分析，对地震属性进行优选，将优选出的3种反映地质体边界、岩性较好的地震属性采用基于模糊C-均值（FCM）算法的多属性聚类分析，以达到数据降维、减少冗余的效果，研究分流河道沉积体系的整体展布规律。再进行多属性RGB融合显示，增强河道砂体边界的刻画，结合构造特征以及预测的砂体厚度综合分析，提出有利目标区，为后续油田滚动开发及井位部署提供依据。
Abstract:After 10+ years of exploration and development of the T Gas Field in the Xihu Sag in East China Sea, it is urgent to find potential targets in the Oligocene Huagang Formation. To identify channel sand body and its boundary accurately, 3D seismic data were used based on data of several offshore wells. The petrophysical properties of the target stratum were analyzed based on isochronous stratigraphic division, and the sedimentary microfacies were preliminarily specified by seismic sedimentology and logging data. In total, 48 seismic attributes were extracted in six categories. Correlation analysis was conducted on sand thickness and each attribute, from which three most meaningful seismic attributes were determined and selected. The three seismic attributes could well reflect the geological body boundaries and ideal lithology. In addition, multi-attribute clustering analysis based on the FCM (Fuzzy C-Means clustering) algorithm was performed, by which the effect of data dimension and redundancy were reduced. In addition, the distribution of distributary channel depositional system was studied, and RGB fusion display was carried out to highlight channel sand body boundaries. By combining the comprehensive analysis on geological structure and predicted sand body thickness, the favorable target area was proposed, which provides a basis for the subsequent rolling development of oilfield and the well location deployment.
-
-
表 1 地震属性及砂厚相关系数矩阵
Table 1. Correlation coefficient matrix of seismic attribute and sand thickness
砂厚 RMS ATA AE AIF ARS EB IF IFB MIN EHT RAI SWEET 砂厚 1 RMS 0.591 1 ATA 0.516 0.623 1 AE 0.321 0.687 0.827 1 AIF 0.477 0.258 0.757 0.795 1 ARS 0.542 0.347 0.732 0.825 0.914 1 EB 0.254 0.024 0.335 0.452 0.426 0.387 1 IF 0.376 0.276 0.712 0.458 0.654 0.468 0.745 1 IFB 0.421 0.127 0.665 0.521 0.698 0.498 0.719 0.932 1 MIN 0.612 0.489 0.587 0.529 0.455 0.325 0.689 0.552 0.548 1 EHT 0.201 0.287 0.473 0.492 0.512 0.585 0.552 0.367 0.419 0.652 1 RAI 0.378 0.128 0.269 0.325 0.186 0.392 0.655 0.425 0.691 0.225 0.362 1 SWEET 0.318 0.165 0.285 0.487 0.287 0.348 0.318 0.189 0.254 0.347 0.395 0.516 1 注：RMS_Amplitude-均方根振幅，ATA-平均波谷振幅，AE-平均能量，AIF-平均反射频率，ARS-平均反射强度，EB-有效带宽，IF-瞬时频率，IFB-瞬时频宽，MIN-最小振幅值，EHT-能量半衰时，SWEET-甜点，RAI-相对声波阻抗。
下载: 导出CSV
-
[1] 蔡义峰,熊婷,姚卫江,等. 地震多属性分析技术在薄层砂体预测中的应用[J]. 石油地球物理勘探,2017,52(2):140-145.
[2] 张宪国,吴啸啸,黄德榕,等. 极限学习机驱动的地震多属性融合识别曲流带单一点坝[J]. 石油地球物理勘探,2021,56(6):1340-1350.
[3] 刘豪,郭奕杉,赵春晨,等. 浅水三角洲砂体预测的地震属性方法探讨[J]. 西南石油大学学报(自然科学版),2016,38(4):71-81.
[4] 刘英宪, 甘立琴, 徐中波, 等. 海上油田大井距条件下薄互储层刻画方法: 以渤海湾盆地P油田3井区馆陶组为例[J]. 大庆石油地质与开发, 2022, 41（5）: 130-136.
[5] 刘化清,苏明军,倪长宽,等. 薄砂体预测的地震沉积学研究方法[J]. 岩性油气藏,2018,30(2):1-11.
[6] 徐立恒,马耀军,朱遂珲,等. 油田开发后期井间砂体识别[J]. 石油地球物理勘探,2019,54(2):390-397.
[7] 常少英,刘玲利,崔钰瑶,等. 浅水三角洲薄砂层地震沉积表征技术:以准噶尔盆地芳草湖地区清水河组为例[J]. 岩性油气藏,2022,34(1):139-147.
[8] 张晶玉,范廷恩,王海峰,等. 海相薄砂岩储层精细描述及地震沉积学认识:以南海珠江口盆地H油田为例[J]. 油气藏评价与开发,2021,11(5):680-687.
[9] 曾洪流,赵贤正,朱筱敏,等. 隐性前积浅水曲流河三角洲地震沉积学特征:以渤海湾盆地冀中坳陷饶阳凹陷肃宁地区为例[J]. 石油勘探与开发,2015,42(5):566-576.
[10] 齐淼,张化祥. 改进的模糊C-均值聚类算法研究[J]. 计算机工程与应用,2009,45(20):133-135.
[11] 张阳,邱隆伟,李际,等. 基于模糊C均值地震属性聚类的沉积相分析[J]. 中国石油大学学报(自然科学版),2015,39(4):53-61.
[12] 徐彬,李建明,张永庶,等. T-R旋回层序在陆相盐湖盆地中的应用:以柴西南英西地区下干柴沟组上段为例[J]. 断块油气田,2020,27(4):412-417.
[13] 董春梅,赵仲祥,张宪国,等. 西湖凹陷中北部花港组物源及沉积相分析[J]. 东北石油大学学报,2018,42(5):25-34.
[14] 宋小勇,储呈林,芮志峰. 东海盆地西湖凹陷构造样式及其演化[J]. 高校地质学报,2010,16(1):86-93.
[15] 徐艳霞,胡明毅,梁建设,等. 东海盆地西湖凹陷渐新统花港组物源分析[J]. 石油天然气学报,2010,32(5):176-179.
[16] 武法东, 周平. 东海陆架盆地西湖凹陷第三系层序地层与沉积体系分析[M]. 北京: 地质出版社, 2000.
[17] 王天云,韩小锋,许海红,等. 无监督神经网络地震属性聚类方法在沉积相研究中的应用[J]. 石油地球物理勘探,2021,56(2):372-379.
-
