Influence of submarine pipeline vibration on soil liquefaction under random wave
-
摘要:
海底管道-土体-水体相互作用对土体和管道的稳定性具有重要影响，但波浪作用下海底管道对其周围土体性质的影响仍有待深入研究。通过一系列室内波浪水槽试验，研究了波浪荷载和管道振动作用下海床土体内部的超孔隙水压力响应。实验结果表明，管道的铺设会增大海底土体超孔隙水压力累积程度，当管道发生振动时，海床土体超孔隙水压力累积程度进一步增大，从而增加了土体液化势。此外，波高增加也会导致海床土体的超孔隙水压力累积程度增大。本文研究成果对管道-土体相互作用研究和海底管道维护具有指导意义。
Abstract:The interaction of submarine pipeline, soil, and water strongly affects the stability of submarine pipeline. However, the research on the change of soil properties around submarine pipeline under wave action is insufficient. The response of excess pore water pressure under wave load and pipeline vibration was studied in a series of laboratory wave flume tests. Results show that the existence of pipeline increased the accumulative pore water pressure of soil, thus enhancing the liquefaction potential of seabed. The pipeline vibration increased the accumulation degree of excess pore water pressure. In addition, wave conditions alter the response of seabed to the excess pore water pressure, namely, the increase of wave height intensify the accumulative pore water pressure. This study provided a guide to studying the pipe–soil-mass interaction and the submarine pipeline maintenance.
-
Key words:
- water tank experiment /
- silty seabed /
- random waves /
- pipeline vibration /
- pore pressure response
-
-
表 1 试验条件简表
Table 1. Summary of the experimental conditions
实验序号 水深D/cm 有效波高H/cm 平均周期T/s 振动荷载 Test1-1 50 10 2 无管道 Test1-2 14 Test1-3 16 Test2-1 50 10 2 否 Test2-2 14 Test2-3 16 Test3-1 50 10 2 是 Test3-2 14 Test3-3 16 Test4-1 50 14 1.5 是 Test4-2 2 Test4-3 2.2 Test4-4 2.5
下载: 导出CSV
表 2 最大累积孔隙水压力（
$ {\stackrel{-}{P}}_{\mathrm{m}\mathrm{a}\mathrm{x}} $ ）与波浪和管道条件之间的皮尔逊相关系数Table 2. Pearson correlation coefficient between the maximum cumulative pore water pressure (
${\stackrel{-}{P}}_{\mathrm{m}\mathrm{a}\mathrm{x}} $ ) and wave/pipeline conditions波高 平均周期 管道存在 管道振动 最大累积孔隙水压力
0.267* −0.158 0.486** 0.557** 注：*
受某变量影响的置信区间在95%以上；**
受某变量影响的置信区间在99%以上；相关性分析样本数量N=84。
下载: 导出CSV
表 3 不同管道状态下不同深度处海床累积孔压
$ {\stackrel{-}{P}}_{\mathrm{m}\mathrm{a}\mathrm{x}} $ 与液化度$ Y $ 统计Table 3. Statistics of accumulated pore pressure and liquefaction degree at different depths under different pipeline conditions
管道状态 孔压测量深度z/cm 最大累积孔隙水压力
/Pa有效应力
/Pa最大液化度
/%最大液化度平均值
无管道
（Test1-3）5 25.59 301.74 8.48
6.1410 39.019 603.48 6.46 15 48.74 905.22 5.38 30 76.41 1 810.44 4.22 静止管道
（Test2-3）5 38.27 301.74 12.68
11.0710 85.45 603.48 14.16 15 88.43 905.22 9.77 30 138.80 1 810.44 7.67 振动管道
（Test3-3）5 143.50 301.74 47.56
26.7510 163.97 603.48 27.17 15 165.97 905.22 18.33 30 252.57 1 810.44 13.95 注：波况条件为水深D=50 cm，波高H=16 cm，周期T=2.0 s。
下载: 导出CSV
-
