A method to quantitatively determine water content in unconsolidated sediments using low-field NMR
-
摘要:
核磁共振通过测定体系中氢质子弛豫的T2谱来确定液态水的含量。采用低场核磁共振技术定量测定松散沉积物体系中的含水量，探讨了沉积物粒径、黏土矿物种类与含量、孔隙水盐度、温度及气体压力等因素对测试结果的影响。由于不同介质体系中孔隙水表面弛豫机制不同，导致低场核磁测定松散沉积物中的含水量偏小。引入校正系数Cm对水量测试值进行了修正，结果表明：沉积物及孔隙水介质本身特性对水量测试结果几乎无影响，相对误差<0.5%，测试精密度<0.20%；温度变化对测试结果影响较大且呈负相关，温度从25 ℃降至1.7 ℃，水量测试值增加了10.71%；压力变化对测试结果的影响与充注气体是否含氢密切相关，不含氢气体的压力变化对测试结果没有影响，而对于含氢气体如甲烷，水量测试结果随压力变化线性增加，甲烷增加到5.05 MPa时，测试结果增加了12.15%。因此，在采用该法测量甲烷水合物生成分解过程中沉积物孔隙水的变化时，必须考虑体系的温度、压力对测试结果的影响，恒温恒压条件下监测的含水量变化能够准确指示甲烷水合物生成分解的微观过程，可望在海洋天然气水合物生成分解微观动力学研究方面得到广泛应用。
Abstract:The low-field nuclear magnetic resonance (LF-NMR) determines the content of liquid water by measuring the T2 spectrum of hydrogen.The water content was measured in unconsolidated sediments by the LF-NMR technique. The effects of particle size, mineral type and content, water salinity, temperature and gas pressure on the measured water content were investigated. Results show that the water content measured by LF-NMR was smaller than the actual value due to the surface relaxation of water in unconsolidated sediments. The correction factor Cm was introduced to correct the measured content of water. The characteristics of sediment and pore water have little influence on the measured content of water, with a relative error of <0.5% in precision of <0.20%. In contrast, temperature was negatively correlated with the measured content of water. The measured content of water increased by 10.71% when the temperature dropped from 25 to 1.7 ℃. The effect of pressure on the measured content of water depends on whether the gas contains hydrogen. The pressure change caused by the hydrogen-free gas had no effect on the measured content of water. For hydrogen gas, such as methane, the measured content of water increased linearly with the increase of pressure. The measured content of the water increased by 12.15% when the pressure increased from 0.10 to 5.05 MPa. Therefore, the effects of temperature and pressure on the measured content of water shall be considered when the change of water content is analyzed by LF-NMR during methane hydrate phase transition in sediment. The change in water content, which is monitored by LF-NMR under constant temperature and pressure, could accurately indicate the microscopic process of methane hydrate phase transition. Therefore, the method is expected to be widely used to study the microscopic kinetics of the formation and decomposition of methane hydrate.
-
Key words:
- unconsolidated sediment /
- low-field NMR /
- signal intensity /
- water content test /
- relative error
-
-
表 1 核磁测量参数-1（NMR1）
Table 1. Nuclear magnetic measurement parameters-1（NMR1）
参数名称 参数值 参数单位 参数名称 参数值 参数单位 主频SF 21 MHz 射频延时RFD 0.080 ms 频率偏置O1 不定 Hz 模拟增益RG1 20 dB 90度脉宽P1 6.60 μs 数字增益DRG1 3 / 180度脉宽P2 12.48 μs 前置放大增益PRG 1 / 采样频率SW 250 kHz 累加采样次数NS 16 / 等待时间TW 8 000 ms 回波时间TE 0.10 ms 采样点数TD 630 026 / 回波个数NECH 18 000 / 注：每次测试前通过重置O1校正中心频率。
下载: 导出CSV
表 2 核磁测量参数-2（NMR2）
Table 2. Nuclear magnetic measurement parameters-2（NMR2）
参数名称 参数值 参数单位 参数名称 参数值 参数单位 主频SF 21 MHz 射频延时RFD 0.080 ms 频率偏置O1 不定 Hz 模拟增益RG1 20 dB 90度脉宽P1 14.20 μs 数字增益DRG1 3 / 180度脉宽P2 28.64 us 前置放大增益PRG 1 / 采样频率SW 250 kHz 累加采样次数NS 32 / 等待时间TW 5 000 ms 回波时间TE 0.18 ms 采样点数TD 990 036 / 回波个数NECH 18 000 / 注：每次测试前通过重置O1校正中心频率。
下载: 导出CSV
表 3 核磁测量参数-3（NMR3）
Table 3. Nuclear magnetic measurement parameters-3 （NMR3）
参数名称 参数值 参数单位 参数名称 参数值 参数单位 主频SF 21 MHz 射频延时RFD 0.080 ms 频率偏置O1 不定 Hz 模拟增益RG1 20 dB 90度脉宽P1 13.20 μs 数字增益DRG1 3 / 180度脉宽P2 24.80 μs 前置放大增益PRG 1 / 采样频率SW 250 KHz 累加采样次数NS 32 / 等待时间TW 4500 ms 回波时间TE 0.18 ms 采样点数TD 810030 / 回波个数NECH 18000 / 注：每次测试前通过重置O1校正中心频率。
下载: 导出CSV
表 4 精密度测试结果
Table 4. The test results of precision
水量测试值/g 水量测试平均值
/g水量标准偏差S 相对标准偏差RSD/% 1.95 1.96 1.96 1.96 1.95 1.96 1.958 3.89×10−3 0.20 注：为减少计算误差，水量测试平均值
保留3位小数。
下载: 导出CSV
表 5 不同沉积物粒径的测试结果
Table 5. The test results of different particle sizes of sediments
沉积物粒径/μm 水量测试值/g 水量校正值/g 水量真实值/g 相对误差 45～53 1.93 1.969 2.00 −1.57% 58～75 1.95 1.992 2.00 −0.39% 80～120 1.95 1.995 2.00 −0.27% 120～180 1.95 1.997 2.00 −0.15% 250～380 1.99 2.031 2.03 0.07% 注：①水量校正值为水量测试值×校正系数Cm，为减少计算误差，保留3位小数；②校正系数Cm取值为1.022。
下载: 导出CSV
表 6 不同黏土矿物及其含量的测试结果
Table 6. The test results of different clay minerals and their contents
黏土类型 黏土比例/% 水量测试值/g 水量校正值/g 水量真实值/g 相对误差 蒙脱石 2 1.98 2.027 2.02 0.36% 蒙脱石 5 1.99 2.034 2.03 0.20% 蒙脱石 10 1.98 2.027 2.03 −0.14% 蒙脱石 20 1.95 1.994 2.00 −0.28% 蒙脱石 40 1.94 1.985 2.00 −0.73% 高岭石 2 1.95 1.995 2.00 −0.26% 高岭石 5 1.95 1.992 2.00 −0.38% 高岭石 10 1.95 1.996 2.01 −0.72% 高岭石 20 1.94 1.977 2.00 −1.17% 高岭石 40 1.94 1.980 2.01 −1.49% 伊利石 2 1.99 2.028 2.02 0.40% 伊利石 5 1.98 2.020 2.02 0.02% 伊利石 10 1.95 1.993 2.00 −0.37% 伊利石 20 1.96 2.004 2.02 −0.77% 伊利石 40 1.94 1.983 2.00 −0.86% 注：①水量校正值为水量测试值×校正系数Cm，为减少计算误差，保留3位小数；②校正系数Cm取值为1.022。
下载: 导出CSV
表 7 不同孔隙水盐度的测试结果
Table 7. The test results of different salinities of pore water
NaCl溶液浓度/（g/100mL） 水量测试值/g 水量校正值/g 水量真实值/g 相对误差 0.1 1.97 2.015 2.03 −0.72% 0.2 2.00 2.045 2.04 0.26% 0.4 1.99 2.029 2.03 −0.04% 0.6 1.97 2.009 2.00 0.43% 0.8 1.95 1.987 2.00 −0.63% 注：①水量校正值为水量测试值×校正系数Cm，为减少计算误差，保留3位小数；②校正系数Cm取值为1.022。
下载: 导出CSV
-
[1] FENG X,LARSON R A,DIGMAN M F. Evaluating the feasibility of a low-field nuclear magnetic resonance (NMR) sensor for manure nutrient prediction[J]. Sensors,2022,22(7):2438. doi: 10.3390/s22072438
[2] BAGNALL G C,KOONJOO N,ALTOBELLI S A,et al. Low-field magnetic resonance imaging of roots in intact clayey and silty soils[J]. Geoderma,2020,370:114356. doi: 10.1016/j.geoderma.2020.114356
[3] YAO Y,LIU D,XIE S. Quantitative characterization of methane adsorption on coal using a low-field NMR relaxation method[J]. International Journal of Coal Geology,2014,131:32-40. doi: 10.1016/j.coal.2014.06.001
[4] 翟成,孙勇,范宜仁,等. 低场核磁共振技术在煤孔隙结构精准表征中的应用与展望[J]. 煤炭学报,2022,47(2):828-848. doi: 10.13225/j.cnki.jccs.xr21.1766
[5] KATIKA K,ADDASSI M,ALAM M M,et al. The effect of divalent ions on the elasticity and pore collapse of chalk evaluated from compressional wave velocity and low-field Nuclear Magnetic Resonance (NMR)[J]. Journal of Petroleum Science and Engineering,2015,136:88-99. doi: 10.1016/j.petrol.2015.10.036
[6] ZHANG Z,LIU L,LI C,et al. A testing assembly for combination measurements on gas hydrate-bearing sediments using X-ray computed tomography and low-field nuclear magnetic resonance[J]. Review of Scientific Instruments,2021,92(8):085108. doi: 10.1063/5.0040858
[7] LEI X, YAO Y, SUN X, et al. Permeability change with respect to different hydrate saturation in clayey-silty sediments[J]. Energy, 2022: 124417.
[8] ZHANG Q,QIN X,ZHANG H,et al. Experimental insights into the in situ formation and dissociation of gas hydrate in sediments of Shenhu,South China Sea[J]. Frontiers in Earth Science,2022,10:882701. doi: 10.3389/feart.2022.882701
[9] 陈家宙,陈明亮,何圆球. 各具特色的当代土壤水分测量技术[J]. 湖北农业科学,2001,47(3):25-28. doi: 10.3969/j.issn.0439-8114.2001.03.015
[10] GARDNER W,KIRKHAM D. Determination of soil moisture by neutron scattering[J]. Soil Science,1952,73(5):391-402. doi: 10.1097/00010694-195205000-00007
[11] HU G W,YE Y G,DIAO S B,et al. Research of time domain reflectometry in measuring water content of marine sediments[J]. Geoscience,2010,24(3):622-626.
[12] SKINNER R J,陈志雄. 土壤水分测定[J]. 土壤学进展,1979,16(1):50-54.
[13] TOPP G C,DAVIS J L,ANNAN A P. Electromagnetic determination of soil water content:measurements in coaxial transmission lines[J]. Water resources research,1980,16(3):574-582. doi: 10.1029/WR016i003p00574
[14] 林杉,刘建然,王爱平. 中子散射法测量土壤水分时标定方法的概述[J]. 南方农机,2017,48(9):41-42,48. doi: 10.3969/j.issn.1672-3872.2017.09.020
[15] 胡高伟,业渝光,刁少波,等. 时域反射技术测量海洋沉积物含水量的研究[J]. 现代地质,2010,24(3):622-626. doi: 10.3969/j.issn.1000-8527.2010.03.029
[16] 李晓斌. 基于时域反射技术的土壤剖面分布式含水量测量研究[D]. 咸阳: 西北农林科技大学, 2022.
[17] 许伟. TDR表面反射法土体含水量测试理论及技术[D]. 杭州: 浙江大学, 2008.
[18] 毛书灿, 郝梦, 汪兰, 等. NMR在肉制品品质检测中的应用进展[J]. 现代食品科技, 2023（5）: 354-366.
[19] 赖谱富,翁敏劼,汤葆莎,等. 基于低场核磁共振技术研究不同干燥方式对海鲜菇复水及品质特性的影响[J]. 核农学报,2022,36(2):350-361. doi: 10.11869/j.issn.100-8551.2022.02.0350
[20] 陈玉磊. 超顺磁性纳米氧化铁的制备及性能研究[D]. 绵阳: 西南科技大学, 2016.
[21] 郭启悦. 基于水凝胶包覆的超顺磁性粒子的低场核磁传感技术[D]. 上海: 上海师范大学, 2020.
[22] JI Y,HOU J,CUI G,et al. Experimental study on methane hydrate formation in a partially saturated sandstone using low-field NMR technique[J]. Fuel,2019,251:82-90. doi: 10.1016/j.fuel.2019.04.021
[23] 高强勇,王昕,高建英,等. 致密岩心核磁共振孔隙度影响因素分析[J]. 测井技术,2021,45(4):424-430. doi: 10.16489/j.issn.1004-1338.2021.04.014
[24] TIAN H,WEI C,WEI H,et al. Freezing and thawing characteristics of frozen soils:bound water content and hysteresis phenomenon[J]. Cold Regions Science and Technology,2014,100(103):74-81.
[25] TIAN H,WEI C,WEI H,et al. An NMR-based analysis of soil-water characteristics[J]. Applied Magnetic Resonance,2014,45(1):49-61. doi: 10.1007/s00723-013-0496-0
[26] 谭龙,韦昌富,田慧会,等. 冻土未冻水含量的低场核磁共振试验研究[J]. 岩土力学,2015,36(6):1566-1572. doi: 10.16285/j.rsm.2015.06.006
[27] 汪红志, 张学龙, 武杰. 核磁共振成像技术实验教程[M]. 北京: 科学出版社, 2008: 3-28.
[28] 展静,张鹏,王英梅,等. 多孔介质水合物中未水合水的核磁共振实验研究[J]. 中南大学学报(自然科学版),2022,53(4):1525-1535. doi: 10.11817/j.issn.1672-7207.2022.04.036
[29] 田慧会,韦昌富,颜荣涛,等. 粉土中二氧化碳水合物分解过程的核磁试验研究[J]. 中国科学:物理学 力学 天文学,2019,49(3):173-180.
[30] 阮榕生. 核磁共振技术在食品和生物体系中的应用[M]. 北京: 中国轻工业出版社, 2009: 75-117.
[31] COATES G R, XIAO L Z, PRAMMER M G. NMR logging principles and applications[M]. Huston, USA: Halliburton Energy Services, 1999.
[32] KENYON W E. Petrophysical principles of applications of NMR logging[J]. The Log Analyst,1997,38(2):21-43.
[33] KLEINBERG R L. Nuclear magnetic resonance pore-scale investigation of permafrost and gas hydrate sediments[J]. Special Publication-Geological Society of London,2006,267(6):179-192.
[34] JAEGER F,BOWE S,VAN A H,et al. Evaluation of 1H NMR relaxometry for the assessment of pore-size distribution in soil samples[J]. European Journal of Soil Science,2009,60(6):1052-1064. doi: 10.1111/j.1365-2389.2009.01192.x
[35] JAEGER F,SHCHEGOLIKHINA A,VAN A H,et al. Proton NMR relaxometry as a useful tool to evaluate swelling processes in peat soils[J]. The Open Magnetic Resonance Journal,2010,3(1):27-45. doi: 10.2174/1874769801003010027
[36] DUSCHL M,POHLMEIER A,BROX T I,et al. Effect of magnetic pore surface coating on the NMR relaxation and diffusion signal in quartz sand[J]. Magnetic Resonance in Chemistry,2016,54(12):975-984. doi: 10.1002/mrc.4486
[37] 张准. 含水合物沉积物孔隙结构特征与渗流规律研究[D]. 武汉: 中国地质大学（武汉）, 2021.
[38] 杨居朋,汤天知,陈涛,等. 核磁共振测井仪CPMG脉冲射频场相位研究[J]. 测井技术,2019,43(3):288-290,332. doi: 10.16489/j.issn.1004-1338.2019.03.013
[39] ZHANG F,ZHANG C. Evaluating the potential of carbonate sub-facies classification using NMR longitudinal over transverse relaxation time ratio[J]. Advances in Geo-Energy Research,2021,5(1):87-103. doi: 10.46690/ager.2021.01.09
[40] COWAN B, COWAN B P. Nuclear magnetic resonance and relaxation[M]. Cambridge: Cambridge University Press, 1997.
[41] JI Y,LIU C L,ZHANG Z,et al. Experimental study on characteristics of pore water conversion during methane hydrates formation in unsaturated sand[J]. China Geology,2022,5(2):276-284.
-
