摘要:
传统的海滩监测剖面方法无法获得区域尺度的监测数据，制约了海滩区域地形变化规律的研究。根据2022年4月—2023年9月周期性RTK实测剖面数据和多期机载LiDAR数据，分析了烟台市金山湾局部地区的海滩地形变化特征。结果显示，机载LiDAR技术能够快速获得海滩的三维点云信息，具有厘米级的精度，且基于多测次的数据能够估算泥沙的侵蚀/淤积体量。2年的剖面监测数据表明，研究区海滩在年际变化中整体呈现淤积趋势，年平均淤积厚度约为0.19 m/a；海滩的季节变化特征表明，弱动力条件下的泥沙淤积量小于强动力条件；平均高潮线以上地形相对稳定，潮间带区域受风浪、潮流等因素影响地形变化频繁。4测次的机载LiDAR数据资料显示，研究区海滩在秋季整体以淤积为主，平均淤积厚度约为0.09 m，潮间带区域侵蚀和淤积相间分布状况明显。汉河入海口东侧海滩的侵蚀深度和淤积厚度相对西侧海滩偏大，河口沙坝东西向有一定增长，导致河口变窄。风浪、潮流、河流等自然因素是塑造海滩形态和控制海滩演化的主要动力因素。极端天气可影响海滩的季节性演化。人类活动在一定程度上影响了海滩地形的自然演化。
Abstract:The traditional beach monitoring uses profile method cannot obtain the monitoring data of regional scale, which restricts the study of the terrain change law of beach area. According to the periodic RTK (real time kinematic) measured profile data and multiple airborne LiDAR (light detection and ranging) data from April 2022 to September 2023, the geomorphic changes of beach in some parts of Jinshan Bay, Yantai City, Shandong, East China were studied. Results show that the airborne LiDAR technology could quickly obtain the three-dimensional point cloud information of beach in centimeter-level accuracy, and the amount of sedimentary scouring/siltation could be estimated based on multi-epoch data. The two-year profile monitoring data showed that the beach showed a general trend of siltation in the interannual scale, with an annual average siltation rate of ～0.19 m/a. The seasonal variation of the beach showed that the siltation was smaller under weak dynamic conditions than that under strong dynamic conditions. The areas above the average high tide line was relatively stable, and those of intertidal zone changed frequently due to wind wave, tidal current, and other factors. The airborne LiDAR data from four epochs indicate that in the autumn, siltation dominated in the beach, with an average siltation thickness of ～9 cm. Scouring and siltation within the intertidal zone exhibited distinct alternating patterns. The scouring depth and siltation thickness of the beach on the eastern side of the Hanhe River estuary were larger than those on the western side, and the estuary bar grew slightly in east-west direction, which narrowed the estuary mouth. Natural factors such as wind wave, tide, and river were the main dynamic factors shaping the beach and controlling the evolution of the beach. The seasonal evolution of the beach was affected by extreme weather, and the natural evolution of the beach was affected by human activities to some extents.
-
-
表 1 研究区海滩剖面信息统计
Table 1. Information of beach profile of the study area
剖面编号 起点坐标 剖面方向 测量时间 P1 37°27′12.2″N、121°44′25.9″E 8° 2022年4、9月，2023年4、9月 P2 37°27′11.7″N、121°44′43.9″E 8° 2022年4、9月，2023年4、9月 P3 37°27′16.5″N、121°45′35.9″E 6° 2022年4、9月，2023年4、8、9月 P4 37°27′23.7″N、121°45′49.3″E 6° 2022年4、9月，2023年4、8、9月
下载: 导出CSV
表 2 机载LiDAR传感器参数和数据采集时间
Table 2. Airborne LiDAR （light detection and ranging） sensor parameters and data acquisition time
参数 禅思L1 飞马LiDAR22 搭载平台 大疆M300 飞马D20 飞行高度 80 m 200 m 波长 905 nm 1 550 nm 回波数 3次 5次 分辨率 ＞100点/m2 ＞50点/m2 扫描角度 70.4° 360°可调 采集时间 2023年8、10、11月 2023年9月
下载: 导出CSV
-
[1] NICHOLAS J M,ROBERT S C,STUART R P,et al. Tracking the rapid loss of tidal wetlands in the Yellow Sea[J]. Frontiers in Ecology and the Environment,2014,12(5):267-272. doi: 10.1890/130260
[2] 张长宽,龚政,陈永平,等. 潮滩演变研究进展及前沿问题[C]//第十八届中国海洋(岸)工程学术讨论会论文集. 北京:海洋出版社,2017:759-766.
ZHANG C K,GONG Z,CHEN Y P,et al. Research progress and frontier issues on tidal flat evolution[C]//Proceedings of the 18th China Ocean (Coastal) Engineering Academic Symposium. Beijing:Ocean Press,2017:759-76.
[3] 岳保静,高茂生,邵家旺,等. 河北省京唐港附近沙坝-潟湖海岸地貌演化特征[J]. 海洋地质前沿,2018,34(9):10-16.
YUE B J,GAO M S,SHAO J W,et al. Geomorphological evolution of the barrier-lagoon system near the Jingtang Port,Hebei Province[J]. Marine Geology Frontiers,2018,34(9):10-16.
[4] 解航,杨怡红,朱龙海,等. 山东半岛东南部典型砂质岸滩季节性演化及控制因素探讨:以海阳万米海滩为例[J]. 海洋地质与第四纪地质,2022,42(1):57-67.
XIE H,YANG Y H,ZHU L H,et al. Seasonal evolution of the typical sandy coast of southeastern Shandong Peninsula and controlling factors:take the 10 000-meter beach in Haiyang as an example[J]. Marine Geology & Quaternary Geology,2022,42(1):57-67.
[5] 张鑫,李萍,杨奇铮,等. 广西北海涠洲岛典型岸滩剖面短期冲淤变化特征[J]. 海洋科学,2016,40(6):77-83.
ZHANG X,LI P,YANG Q Z,et al. Short-term shore change characteristics of erosion and deposition on Weizhou Island in Beihai,Guangxi Province[J]. Marine Sciences,2016,40(6):77-83.
[6] LI H,GONG Z ,DAI W Q,et al. Feasibility of elevation mapping in muddy tidal flats by remotely sensed moisture (RSM) method [J]. Journal of Coastal Research,2018,85 (Sp1):291-295.
[7] LI W Y,GONG P. Continuous monitoring of coastline dynamics in western Florida with a 30-year time series of Landsat imagery[J]. Remote Sensing of Environment,2016,179:196-209. doi: 10.1016/j.rse.2016.03.031
[8] KANG Y Y,LEI J,WANG M J,et al. Topographic evolution of tidal flats based on remote sensing:an example in Jiangsu coast,Southern Yellow Sea[J]. Frontiers in Marine Science,2023,10:1163302. doi: 10.3389/fmars.2023.1163302
[9] 王子赫,康彦彦,王敏京. ICESat-2与多源光学影像的潮滩地形反演方法[J]. 测绘通报,2023(5):51-55.
WANG Z H,KANG Y Y,WANG M J. ICESat-2 and multivariate optical image for tidal flat topography inversion methods[J]. Surveying and Mapping Bulletin,2023,5:51-55,61.
[10] FAN Y S,CHEN S L,ZHAO B,et al. Monitoring tidal flat dynamics affected by human activities along an eroded coast in the Yellow River Delta,China.[J]. Environmental Monitoring and Assessment,2018,190(7):396-412. doi: 10.1007/s10661-018-6747-7
[11] 胡勇,何旭涛,徐辉,等. RTK无人机在潮间带地形测量中的应用[J]. 地理空间信息,2021,19(4):41-43.
HU Y,HE X T,XU H,et al. Application of RTK UAV in the topography survey of intertidal zone[J]. Geospatial Information,2021,19(4):41-43.
[12] 庄佳铨,罗科,彭雲,等. 基于无人机SfM摄影测量的潮间带牡蛎礁地貌调查[J]. 海洋地质与第四纪地质,2023,43(6):45-54.
ZHUANG J Q,LUO K,PENG Y,et al. Geomorphological survey of intertidal oyster reefs based on UAV Structure-from-Motion photogrammetry[J]. Marine Geology & Quaternary Geology,2023,43(6):45-54.
[13] CHEN B Q,YANG Y M,WEN H T,et al. High-resolution monitoring of beach topography and its change using unmanned aerial vehicle imagery[J]. Ocean and Coastal Management,2018,160:103-116. doi: 10.1016/j.ocecoaman.2018.04.007
[14] LU C H,CHYI S J. Using UAV-SfM to monitor the dynamic evolution of a beach on Penghu Islands[J]. Terrestrial,Atmospheric and Oceanic Sciences,2020,31(3):283-293. doi: 10.3319/TAO.2019.09.25.01
[15] 陈奇,张阳,唐雯雯,等. 低空无人机平台应用于海滩地形监测的初步研究[J]. 海洋地质与第四纪地质,2023,43(6):55-68.
CHEN Q,ZHANG Y,TANG W W,et al. Application of low-altitude airspace UAVs in beach terrain monitoring[J]. Marine Geology & Quaternary Geology,2023,43(6):55-68.
[16] 郭一栋,林杭杰,于谦,等. 基于无人机SfM摄影测量的海岸盐沼前缘形态变化研究[J]. 海洋学报,2022,44(12):148-160.
GUO Y D,LIN H J,YU Q,et al. Morphology of coastal salt marsh margins:a study using UAV-based Structure-from-Motion photo-grammetry[J]. Haiyang Xuebao,2022,44(12):148-160.
[17] 许宝华,刘世振. 机载LiDAR测量技术在潮间带测量中的应用[J]. 人民长江,2019,50(11):95-98.
XU B H,LIU S Z. Application of airborne LiDAR measurement technology in intertidal zone measurement[J]. Yangtze River,2019,50(11):95-98.
[18] 别君. 基于机载LiDAR数据的滩涂地形形变监测[C]//“一带一路”战略与海洋科技创新—中国海洋学会2015年学术论文集:海洋出版社,2015:31-35.
Bei J. Beach topography deformation monitoring based on airborne LiDAR data [C]// "Belt and Road" Strategy and Marine Science and Technology Innovation-2015 Academic Proceedings of the Chinese Society of Oceanography. Beijing:Ocean Press,2015:31-35.
[19] 文学东,李俊峰,林昀. 机载LiDAR在高精度滩涂DEM制作中的关键技术分析[J]. 测绘通报,2019(6):92-95.
WEN X D,LI J F,LIN Y. Key technologies analysis of airborne LiDAR in high accuracy tidal flats DEM production[J]. Surveying and Mapping Bulletin,2019(6):92-95.
[20] ZHANG H F,WANG L,ZHAO Y F,et al. Application of Airborne LiDAR measurements to the topographic survey of the tidal flats of the northern Jiangsu radial sand ridges in the Southern Yellow Sea[J]. Frontiers in Marine Science,2022,9:871156. doi: 10.3389/fmars.2022.871156
[21] 杨帆,任闯,曲丹,等. 机载LiDAR技术在矿区地表沉陷灾害监测中的应用[J]. 测绘工程,2023,32(4):59-68.
YANG F,REN C,QU D,et al. Airborne LiDAR technology sinks on the surface of the mine application in disaster monitoring[J]. Engineering of Surveying and Mapping,2023,32(4):59-68.
[22] 郑俊良,姚顽强,蔺小虎,等. 无人机LiDAR在采空区沉陷监测中的应用[J]. 西安科技大学学报,2023,43(4):825-835.
ZHENG J L,YAO W Q,LIN X H,et al. Application of UAV LiDAR in monitoring subsidence of goaf[J]. Journal of Xi'an University of Science and Technology,2023,43(4):825-835.
[23] 岳保静,廖晶,高茂生,等. 山东半岛砂质海滩动力地貌演化特征[J]. 海洋科学,2017,41(4):118-127.
YUE B J,LIAO J,GAO M S,et al. Evolutionary features of morphodynamics of sandy beaches on the Shandong Peninsula[J]. Marine Sciences,2017,41(4):118-127.
[24] 周良勇,薛春汀,刘健,等. 山东半岛东、北部海滩动力地貌特征及影响因素[J]. 海洋科学进展,2013,31(1):83-94.
ZHOU L Y,XUE C T,LIU J,et al. Beach morphodynamics and impact factors on the beaches in the northern and eastern of Shandong Peninsula[J]. Advances in Marine Science,2013,31(1):83-94.
[25] 张丽丽,邢浩,张旭日,等. 山东半岛海滩动力地貌特征分类[J]. 海洋科学,2023,47(2):10-19.
ZHANG L L,XING H,ZHANG X R,et al. Classification of beach dynamic geomorphic features in the Shandong Peninsula[J]. Marine Science,2023,47(2):10-19.
[26] 中国海湾志编繁委员会. 中国海湾志第3分册(山东半岛北部和东部海湾)[M]. 北京:海洋出版社,1991.
Compilation Committee of Record of Bays in China (CCRBC). Records of Bays in China (Volume 3:Bays in the North and East Shandong Peninsula)[M].Beijing:Beijing China Ocean Press,1991.
[27] 蔡锋,苏贤泽,曹惠美,等. 华南砂质海滩的动力地貌分析[J]. 海洋学报,2005,27(2):106-114.
CAI F,SU X Z,CAO H M,et al. Analysis on morphodynamics of sandy beaches in South China[J]. Acta Oceanologica Sinica,2005,27(2):106-114.
[28] 韦钦胜,于志刚,冉祥滨,等. 黄海西部沿岸流系特征分析及其对物质输运的影响[J]. 地球科学进展,2011,26(2):145-156.
WE Q S,YU Z G,RAN X B,et al. Characteristics of the western coastal current of the Yellow Sea and its impacts on material transportation[J]. Advances in Earth Science,2011,26(2):145-156.
[29] 马晓红,韩宗珠,艾丽娜,等. 中国渤黄海的沉积物源及输运路径研究[J]. 中国海洋大学学报(自然科学版),2018,48(6):96-101.
MA X H,HAN Z Z,AI L N,et al. Research on provenance and transport pattern in the Bohai Sea and Yellow Sea[J]. Periodical of Ocean University of China,2018,48(6):96-101.
[30] 彭旸,龚承林,李顺利. 河流-波浪-潮汐混合作用过程研究进展[J]. 沉积学报,2022,40(4):957-978.
PENG Y,GONG C L,LI S L. Recent Advances in river-wave-tide mixed processes[J]. Acta Sedimentologica Sinica,2022,40(4):957-978.
-
