Geological resources and environment carrying capacity in the core port area of Oujiang River Estuary
-
摘要:
瓯江口大、小门岛港区和状元岙港区是温州港的重要组成部分，也是温州市海洋经济重点建设区块。基于对港区海岛岸线资源开发强度、水深地形条件、波浪动力环境、海床冲淤风险及海水富营养化的分类分级评价，从港区岸线资源供给能力、地质条件支撑能力及海洋环境纳污能力3个方面对大、小门岛港区和状元岙港区开发利用现状和地质资源环境承载力进行综合分析和评估，结果表明：核心港区地质资源环境承载力介于1.6～2.4，属于承载力临界区间中的较高范围；小门岛港区资源承载力最低，制约因素主要为自然岸线资源供给能力及海水纳污能力较低；大门岛港区承载力最高，水深地形条件为最大限制条件；状元岙港区承载力居中，限制因素为自然岸线供给能力。
Abstract:The port areas in Damen Island, Xiaomen Island, and Zhuangyuan'ao Island in the Oujiang River Estuary are important parts of Wenzhou Port, Zhejiang, and are important areas of marine economy in Wenzhou City. Based on the coastline exploitation intensity, bathymetric topography condition, wave dynamic environment, seabed erosion and siltation risk, and seawater eutrophication in the port area, the geological resources and environmental carrying capacity of the port areas were comprehensively analyzed and evaluated in three aspects of coastline resource supply capacity, geological condition support capacity, and environmental carrying capacity. Data were collected in 2019 and earlier. Results show that the geological resources and environmental carrying capacity of the port areas was between 1.6 and 2.4, belonging to the higher range of the critical range of carrying capacity. The resource carrying capacity of Xiaomen Island was the lowest due to its low supply capacity of natural coastline resource and weak environmental carrying capacity; that of Damen Island was the highest and the water depth and terrain condition were the main limiting factors; and that of Zhuangyuan'ao Island was in the middle, and the constraint was the supply capacity of natural coastline.
-
-
表 1 核心港区地质资源环境承载力评价指标体系
Table 1. Evaluation index system of geological resources and environment carrying capacity of the core port area
项目 因子 指标 划分标准 承载力等级量值 地质资源环境承载力（C） 岸线资源供给能力（S1） 岸线资源开发强度（N） N＜0.1 3 0.1≤N＜0.3 2 N≥0.3 1 地质条件支撑能力（S2） 水深地形（h） h＞20 m 3 20≥h＞10 m 2 h≤10 m 1 有效波高（W） W≤0.5 m 3 0.5＜W≤1 m 2 W＞1 m 1 冲淤风险（D） −10 ≤D＜10 cm 3 10～20 cm或−20～−10 cm 2 D≥20 cm或D＜−20 cm 1 海洋环境纳污能力（S3） 富营养化（E） 轻度富营养化 3 中度富营养化 2 重度富营养化 1
下载: 导出CSV
表 2 人工岸线类型及影响因子
Table 2. Classification of artificial coastline and the impact factor
分类 海洋资源环境影响描述 影响因子 人工海岸 围池坝 对海洋资源环境有一定影响 qB=0.6 交通运输 对海洋资源环境有明显影响 qH=0.8 工业用海 对海洋资源环境有较大影响，
部分影响不可恢复qT=1.0 城镇填海 对海洋资源环境有较大影响，
部分影响不可恢复qG=1.0
下载: 导出CSV
表 3 岸线类型及长度
Table 3. The type and length of coastline
km 岸线类型 基岩岸线 砂砾质岸线 淤泥质岸线 船舶工业岸线 交通道路岸线 城镇工业岸线 港口码头岸线 大门岛 39.545 1.69 0 0.015 1.33 2.07 2.42 小门岛 8.51 0.15 0.92 0 2.09 3.09 0.51 状元岙港区 15.63 0.42 0 0 1.66 8.1 1.19
下载: 导出CSV
表 4 海水富营养化指数
Table 4. Eutrophication index around the port areas
站位 WQ1 WQ2 WQ3 WQ4 WQ5 WQ6 WQ7 WQ8 WQ9 WQ10 指数值 1.13 0.45 2.51 26.96 5.27 0.90 3.14 0.52 0.48 10.37
下载: 导出CSV
表 5 小门岛港区地质资源环境承载力评价因子统计
Table 5. Geological resources and environmental carrying capacity in the Xiaomen Island port area
因子 指标 统计值 承载力等级
量值承载力
（C）岸线资源供给
能力（S1）岸线资源开发强度（N） 0.34 1 地质条件支撑
能力（S2）水深地形（h） 12.0 m 2 波浪动力（W） 0.34 m 3 冲淤风险（D） −10 cm 3 海洋环境纳污
能力（S3）富营养化（E） 重度 1
下载: 导出CSV
表 6 大门岛港区地质资源环境承载力评价因子统计值
Table 6. Geological resources and environmental carrying capacity in the Damen Island port area
因子 指标 统计值 承载力等级
量值承载力
（C）岸线资源供给
能力（S1）岸线资源开发强度（N） 0.10 3 地质条件支撑
能力（S2）水深地形（h） 10 m 1 波浪动力（W） 0.57 m 2 冲淤风险（D） −17 cm 2 海洋环境纳污
能力（S3）富营养化（E） 中度 2
下载: 导出CSV
表 7 状元岙岛港区地质资源环境承载力评价因子统计值
Table 7. Geological resources and environmental carrying capacity in the Zhuangyuan’ao Island port area
因子 指标 统计值 承载力等级
量值承载力
（C）岸线资源供给
能力（S1）岸线资源开发强度（N） 0.38 1 地质条件支撑
能力（S2）水深地形（h） 10.5 m 2 波浪动力（W） 0.51 m 2 冲淤风险（D） −19 cm 2 海洋环境纳污
能力（S3）富营养化（E） 轻度 3
下载: 导出CSV
-
[1] 马诗敏,徐新阳,倪金,等. 陆海统筹资源环境承载能力评价体系构建[J]. 地质与资源,2021,30(2):186-192.
MA S M,XU X Y,NI J,et al. Evaluation system construction for the resources and environment carrying capacity of sea-land coordination[J]. Geology and Resources,2021,30(2):186-192.
[2] 方静涛. 辽宁省海岸带地质环境综合评价研究[J]. 地质与资源,2020,29(1):85-100. doi: 10.3969/j.issn.1671-1947.2020.01.011
FANG J T. Comprehensive evaluation on the geo-environment of coastal zones in Liaoning Province[J]. Geology and Resources,2020,29(1):85-100. doi: 10.3969/j.issn.1671-1947.2020.01.011
[3] 白景峰,于航. 渤海湾港口区域发展与环境承载力响应机制研究[M]. 北京:海洋出版社,2016.
BAI J F,YU H. Research on the Response Mechanism of Bohai Bay Port Area Development and Environmental Carrying Capacity[M]. Beijing:China Ocean Press,2016.
[4] 黄丽华,姜昀,杨帆,等. 基于“3S”的沿海港口生态承载力预警系统构架研究:以厦门港为例[J]. 环境科学与技术,2019,42(12):195-201.
HUANG L H,JIANG Y,YANG F,et al. Early warning system construction of coastal port ecological carrying capacity based on "3S" technology:Xiamen Port for example[J]. Environmental Science & Technology,2019,42(12):195-201.
[5] 王瑞. 天津港港口环境承载力评价研究[D]. 青岛:中国海洋大学,2014.
WANG R. The evaluation study of Tianjin Port environmental carrying capacity[D]. Qingdao:Ocean University of China,2014.
[6] 张亚冬,张騄,崔凯杰,等. 港口环境承载力概念及其影响因素初探[J]. 水道港口,2008,29(5):372-376. doi: 10.3969/j.issn.1005-8443.2008.05.014
ZHANG Y D,ZHANG L,CUI K J,et al. Research on port environmental carrying capacity and the effecting factors[J]. Journal of Waterway and Harbor,2008,29(5):372-376. doi: 10.3969/j.issn.1005-8443.2008.05.014
[7] 郭子坚,望灿,王文渊,等. 基于生态足迹的港口生态承载力模型[J]. 港工技术,2015(2):48-51.
GUO Z J,WANG C,WANG W Y,et al. Port ecological capacity model based on ecological footprint[J]. Port Engineering Technology,2015(2):48-51.
[8] 温州港集团. 温州港总体规划[R]. 温州:温州港集团,2012.
Wenzhou Port Group. General plan of Wenzhou Port [R]. Wenzhou:Wenzhou Port Group,2012.
[9] 陈俊兵,王一鸣,董超,等. 浙江省海岸带重点区综合地质调查(温州重点区)成果报告[R]. 宁波:浙江省水文地质工程地质大队,2022.
CHEN J B,WANG Y M,DONG C,et al. Comprehensive geological survey of coastal zones in Zhejiang Province (key area of Wenzhou) [R]. Ningbo:Zhejiang Institute of Hydrogeology and Engineering Geology,2022.
[10] 陈鹏,顾海峰,吴剑,等. 海岛港口开发利用与保护适宜性分区评价:以大亚湾岛群为例[J]. 海洋环境科学,2013,32(4):614-618.
CHEN P,GU H F,WU J,et al. Zoning assessment of suitability for port development and protection of islands:an example of Dayawan Bay[J]. Marine Environmental Science,2013,32(4):614-618.
[11] 赵宇哲,刘芳. 生态港口评价指标体系的构建:基于R聚类、变异系数与专家经验的分析[J]. 科研管理,2015,36(2):124-132.
ZHAO Y Z,LIU F. The ecological port evaluation indicator system based on R-cluster,coefficient of variation and expert experience[J]. Science Research Management,2015,36(2):124-132.
[12] 黄沛,丰爱平,吴桑云,等. 基于GIS的港口功能适宜性评价模型构建研究[J]. 海洋开发与管理,2010,27(1):31-35. doi: 10.3969/j.issn.1005-9857.2010.01.008
HUANG P,FENG A P,WU S Y,et al. Research on the construction of port functional suitability evaluation model based on GIS[J]. Ocean Development and Management,2010,27(1):31-35. doi: 10.3969/j.issn.1005-9857.2010.01.008
[13] 自然资源部. 资源环境承能力和国土空间开发适宜性评价技术指南[S]. 北京,2020.
Ministry of Natural Resources. Technical Guidelines for the Evaluation of the Carrying Capacity of Resources and Environment and the Suitability of Territorial Spatial Development[S]. Beijing:Ministry of Natural Resources,2020.
[14] 李连伟,刘展,宋冬梅,等. 黄河三角洲环境脆弱性评价方法及其应用[J]. 中国农业大学学报,2013,18(1):195-201. doi: 10.11841/j.issn.1007-4333.2013.01.029
LI L W,LIU Z,SONG D M,et al. Application and method of environmental vulnerability evaluation in Yellow River Delta[J]. Journal of China Agricultural University,2013,18(1):195-201. doi: 10.11841/j.issn.1007-4333.2013.01.029
[15] 王公伯,李广雪,徐继尚. 近海人工岛稳定评价方法体系的研究[J]. 海洋地质与第四纪地质,2011,31(4):83-88.
WANG G B,LI G X,XU J S. A stability evaluation system for offshore artificial islands[J]. Marine Geology & Quaternary Geology,2011,31(4):83-88.
[16] 于莹. 海岸带地质环境脆弱性评价研究:以黄河口为例[D]. 北京:中国地质大学(北京),2016.
YU Y. Research on coast zone geological environment vulnerability evaluation:case study of Yellow River Estuary[D]. Beijing:China University of Geosciences,Beijing,2016.
[17] 徐元芹,李萍,刘乐军,等. 河北南堡—曹妃甸海域工程地质条件及海底稳定性评价[J]. 海洋学报,2017,39(5):103-114. doi: 10.3969/j.issn.0253-4193.2017.05.010
XU Y Q,LI P,LIU L J,et al. Engineering geological conditions and seabed stability assessment of Nanpu-Caofeidian,Hebei Province[J]. Acta Oceanologica Sinica,2017,39(5):103-114. doi: 10.3969/j.issn.0253-4193.2017.05.010
[18] 金翔龙. 浙江海洋资源环境于海洋开发[M]. 北京:海洋出版社,2014.
JIN X L. Marine Resources,Environment and Marine Development in Zhejiang[M]. Beijing:China Ocean Press,2014.
[19] 国家海洋局. 海水质量状况评价技术规程(试行)[S]. 北京:国家海洋局,2015.
State Oceanic Administration. Technical Regulations for the Evaluation of Seawater Quality Status (Trial) [S]. Beijing:State Oceanic Administration,2015.
[20] 国家海洋局. 海洋资源环境承载能力监测预警技术方法指南[S]. 北京:国家海洋局,2015.
State Oceanic Administration. Technical Guidelines for Monitoring and Early Warning of the Carrying Capacity of Marine Resources and Environment [S]. Beijing:State Oceanic Administration,2015.
[21] 赵蕾,曹议丹,高伟明. 昌黎县海洋环境承载力评估研究[J]. 海洋科学,2016,40(8):84-90. doi: 10.11759/hykx20151207001
ZHAO L,CAO Y D,GAO W M. Assessment of marine environmental carrying capacity in Changli County[J]. Marine Sciences,2016,40(8):84-90. doi: 10.11759/hykx20151207001
[22] 温州市人民政府. 温州市海洋功能区划(2011—2020年)[R]. 温州:温州市自然资源和规划局,2017.
Wenzhou Municipal People's Government. Marine functional zoning of Wenzhou City(2011-2012)[R]. Wenzhou:Wenzhou Bureau of Natural Resources and Planning,2017.
[23] 白玉川,廖世智. 广西钦州湾海域海床稳定性特征的研究[J]. 海洋通报,2005,24(2):26-32.
BAI Y C,LIAO S Z. Analysis on the features of seabed stability in Qinzhou Bay,Guangxi[J]. Marine Science Bulletin,2005,24(2):26-32.
[24] 季荣耀,陆永军,左利钦. 渤海湾曹妃甸深槽形成机制及稳定性分析[J]. 地理学报,2011,66(3):348-355.
JI R Y,LU Y J,ZUO L Q. Formation mechanism and stability of Caofeidian channel in the Bohai Bay[J]. Acta Geographica Sinica,2011,66(3):348-355.
[25] 曹祖德,肖辉. 潮流作用下淤泥质海床冲淤演变预测及应用[J]. 水道港口,2009,30(1):1-8.
CAO Z D,XIAO H. Seabed evolution prediction and application on muddy coast under action of tidal current[J]. Journal of Waterway and Harbor,2009,30(1):1-8.
-
