Model tests and simulation analyses on lateral deformation characteristics of PVD-improved ground
-
摘要:
为探明不同预压模式下塑料排水板（prefabricated vertical drains，PVD）处理软土地基的侧向变形特性，以指导软土地区相关工程的设计与施工，通过室内大比例模型试验对比分析堆载预压和真空联合堆载预压下PVD地基的侧向变形特性。此外，结合有限元仿真分析，系统研究真空联合堆载预压下堆载速率（LR）、堆载大小（ps）和真空压力大小（|pv|）对PVD地基侧向变形的影响规律。研究表明：真空联合堆载预压相较堆载预压可以匹配更快的堆载速率和更大的堆载，且达到最大堆载后的后续固结阶段，PVD地基的向外侧向变形并无明显增长，反观堆载预压工况，地基的最大向外侧向变形仍可增长达10%，局部深度位置侧向变形可增长超30%。真空联合堆载预压下PVD地基的侧向变形轮廓整体随ps与LR的增加及|pv|的减小而向预压区外侧移动，且地基的侧向变形速率及最大向外侧向变形（δom）深度随之增加。此外，堆载施加过程中PVD地基的向外侧向变形呈阶梯型规律增加，其最大值δom近似随ps增加而线性增大，随LR增加及|pv|减小而非线性增长。同等荷载改变量下，|pv|的改变相较于ps改变对地基侧向变形的影响更为显著。研究结果可为真空联合堆载预压处理软土地基的分析与设计提供参考。
Abstract:To explore the lateral deformation characteristics of prefabricated vertical drains (PVD)-improved soft ground under different preloading loads and provide guidance for the design and construction of relevant structures in soft deposit regions, this study analyzed the lateral deformation characteristics of PVD-improved ground under surcharge preloading and combined vacuum and surcharge preloading using large-scale model tests. The influence of loading rate (LR), surcharge load (ps), and vacuum pressure magnitude (|pv|) on the lateral deformation of PVD-improved ground under combined preloading was systematically studied using finite element analyses. The results show that the preloading under combined vacuum and surcharge could match faster loading rates and larger surcharge loads compared to surcharge preloading alone. In the subsequent consolidation stage after reaching maximum surcharge load, there is aninsignificant increase in the outward lateral deformation of PVD-improved ground under combined preloading; in contrast, the maximum outward lateral deformation of the ground under surcharge preloading could still increase by 10%, and the lateral deformation of localization depths could increase by over 30%. The lateral deformation profile of PVD-improved ground under combined preloading overall moves outward with the increase of ps and LR, and the decrease of the |pv|; meanwhile the lateral deformation rate and the depth of the maximum outward lateral deformation (δom) increase. The outward lateral deformation of PVD-improved presents step growth patterns during the surcharge loading process, and the δom increases approximately linearly with the increase of ps, but increases nonlinearly with the increase of LR and the decrease of |pv|. With the same load change, the variation in |pv| has a more significant impact on the ground lateral deformation compared to the variation in ps. This study can provide basic information for the analysis and design of soft ground improvement under combined vacuum pressure and surcharge load.
-
-
表 1 试验工况
Table 1. Test conditions
工况 pv/kPa ps/kPa LR/（kPa·d−1） 堆载预压 工况1 0 44 2 工况2 0 44 3 真空联合堆载预压 工况3 −65 60 4 工况4 −65 60 6 注：由于真空压力（pv）为抽吸荷载，为区别于堆载荷载，因此用负值表示真空作用。
下载: 导出CSV
表 2 预压静置后模型地基的物理力学参数
Table 2. Physical and mechanical properties of model ground after preloading and resting
荷载模式 γt/（kN·m−3） $w' $ /%$w $ /%e0 H0/m POP/kPa 仅堆载 16.22 80.8 62.4 1.650 0.72 6.125 真空联合堆载 15.47 100.0 70.0 1.875 0.65 3.500 注：γt为经砝码预压静置后的地基土的初始重度； $w' $ 为填筑模型地基时所用流塑态土体的含水率；$w $ 、e0和H0分别为填筑完成并经砝码预压静置后的模型地基的初始含水率、初始孔隙比和初始厚度；POP为模型地基的先期固结压力与其自重应力的差值（即静压砝码对应的压力值）。
下载: 导出CSV
表 3 模型地基的本构模型参数
Table 3. Constitutive properties of model ground
参数 γt/（kN·m−3） λ κ e0 K0 M kv/（m·d−1） kh/（m·d−1） khp/（m·d−1） POP/kPa 取值 15.47 0.2523 0.0505 1.875 0.558 1.41 2.35×10−5 3.53×10−5 1.41×10−5 3.5
下载: 导出CSV
表 4 加载参数分析工况
Table 4. Simulation conditions of loading parameters
工况 pv/kPa ps/kPa LR/（kPa∙d−1） 影响因素 备注 M1 −65 60 2 LR M2 −65 60 3 M3 −65 60 4 M4 −65 60 5 加载破坏 M5 −65 48 4 ps M6 −65 52 4 M7 −65 56 4 M8 −50 48 4 pv 加载破坏 M9 −55 48 4 M10 −60 48 4
下载: 导出CSV
-
[1] 袁波,邵吉成,骆嘉成,等. 基于固结-固化复合技术对温州淤泥加固的试验研究[J]. 水文地质工程地质,2022,49(1):66 − 74. [YUAN Bo,SHAO Jicheng,LUO Jiacheng,et al. An experimental study of reinforcement of the Wenzhou sludge based on the consolidation and solidification composite technology[J]. Hydrogeology & Engineering Geology,2022,49(1):66 − 74. (in Chinese with English abstract)]
YUAN Bo, SHAO Jicheng, LUO Jiacheng, et al. An experimental study of reinforcement of the Wenzhou sludge based on the consolidation and solidification composite technology[J]. Hydrogeology & Engineering Geology, 2022, 49（1）: 66 − 74. （in Chinese with English abstract）
[2] 袁帅, 王君, 吴朝峰, 等. 虹吸排水法处理软土地基的水位与沉降计算模型[J]. 吉林大学学报(地球科学版),2024,54(1):208 − 218. [YUAN Shuai, WANG Jun, WU Zhaofeng, et al. Calculation model for water level and settlement of soft foundation treated by siphon drainage[J]. Journal of Jilin University (Earth Science Edition),2024,54(1):208 − 218. (in Chinese with English abstract)]
YUAN Shuai, WANG Jun, WU Zhaofeng, et al. Calculation model for water level and settlement of soft foundation treated by siphon drainage[J]. Journal of Jilin University (Earth Science Edition), 2024, 54（1）: 208 − 218. （in Chinese with English abstract）
[3] 彭扬发,周洋,王宁波,等. 塑料排水板地基变形的简易计算法[J]. 铁道科学与工程学报,2022,19(7):1898 − 1907. [PENG Yangfa,ZHOU Yang,WANG Ningbo,et al. Simple method for evaluating deformation of PVD-improved grounds[J]. Journal of Railway Science and Engineering,2022,19(7):1898 − 1907. (in Chinese with English abstract)]
PENG Yangfa, ZHOU Yang, WANG Ningbo, et al. Simple method for evaluating deformation of PVD-improved grounds[J]. Journal of Railway Science and Engineering, 2022, 19（7）: 1898 − 1907. （in Chinese with English abstract）
[4] 程瑾,曹凯,吴玉涛,等. 基于增温加热技术的淤泥真空预压现场试验研究[J]. 水文地质工程地质,2022,49(4):125 − 134. [CHENG Jin,CAO Kai,WU Yutao,et al. A field experimental study of sludge vacuum preloading based on the temperature increasing heating technology[J]. Hydrogeology & Engineering Geology,2022,49(4):125 − 134. (in Chinese with English abstract)]
CHENG Jin, CAO Kai, WU Yutao, et al. A field experimental study of sludge vacuum preloading based on the temperature increasing heating technology[J]. Hydrogeology & Engineering Geology, 2022, 49（4）: 125 − 134. （in Chinese with English abstract）
[5] CHAI J C,SHEN J S L,LIU M D,et al. Predicting the performance of embankments on PVD-improved subsoils[J]. Computers and Geotechnics,2018,93:222 − 231. doi: 10.1016/j.compgeo.2017.05.018
[6] 刘松玉,周建,章定文,等. 地基处理技术进展[J]. 土木工程学报,2020,53(4):93 − 110. [LIU Songyu,ZHOU Jian,ZHANG Dingwen,et al. State of the art of the ground improvement technology in China[J]. China Civil Engineering Journal,2020,53(4):93 − 110. (in Chinese with English abstract)]
LIU Songyu, ZHOU Jian, ZHANG Dingwen, et al. State of the art of the ground improvement technology in China[J]. China Civil Engineering Journal, 2020, 53（4）: 93 − 110. （in Chinese with English abstract）
[7] INDRARATNA B,RUJIKIATKAMJORN C,BARAL P,et al. Performance of marine clay stabilised with vacuum pressure:Based on Queensland experience[J]. Journal of Rock Mechanics and Geotechnical Engineering,2019,11(3):598 − 611. doi: 10.1016/j.jrmge.2018.11.002
[8] 杨晓杰,刘冬明,王孝存. 深厚软弱土层沉降变形规律堆载试验研究[J]. 岩石力学与工程学报,2017,36(增刊2):4259 − 4266. [YANG Xiaojie,LIU Dongming,WANG Xiaocun. Loading test study on settlement deformation law of deep soft soil layer[J]. Chinese Journal of Rock Mechanics and Engineering,2017,36(Sup 2):4259 − 4266. (in Chinese with English abstract)]
YANG Xiaojie, LIU Dongming, WANG Xiaocun. Loading test study on settlement deformation law of deep soft soil layer[J]. Chinese Journal of Rock Mechanics and Engineering, 2017, 36（Sup 2）: 4259 − 4266. （in Chinese with English abstract）
[9] ALMEIDA M S S,DEOTTI L O G,ALMEIDA M C F,et al. Vacuum preloading on structured clay:Field,laboratory,and numerical studies[J]. International Journal of Geomechanics,2021,21(10):04021198. doi: 10.1061/(ASCE)GM.1943-5622.0002170
[10] 陈立国,吴昊天,陈晓斌,等. 超载预压处理软土的次固结特征及沉降计算[J]. 水文地质工程地质,2021,48(1):138 − 145. [CHEN Liguo,WU Haotian,CHEN Xiaobin,et al. Secondary consolidation characteristics and settlement calculation of soft soil treated by overload preloading[J]. Hydrogeology & Engineering Geology,2021,48(1):138 − 145. (in Chinese with English abstract)]
CHEN Liguo, WU Haotian, CHEN Xiaobin, et al. Secondary consolidation characteristics and settlement calculation of soft soil treated by overload preloading[J]. Hydrogeology & Engineering Geology, 2021, 48（1）: 138 − 145. （in Chinese with English abstract）
[11] NGUYEN T N,BERGADO D T,KIKUMOTO M,et al. A simple solution for prefabricated vertical drain with surcharge preloading combined with vacuum consolidation[J]. Geotextiles and Geomembranes,2021,49(1):304 − 322. doi: 10.1016/j.geotexmem.2020.10.004
[12] TIAN Yi,JIANG Guosheng,WU Wenbin,et al. Elliptical cylindrical equivalent model of PVD-assisted consolidation under surcharge combined with vacuum preloading and its application[J]. Computers and Geotechnics,2021,139:104389. doi: 10.1016/j.compgeo.2021.104389
[13] 蔡袁强,周岳富,王鹏,等. 考虑淤堵效应的疏浚淤泥真空固结沉降计算[J]. 岩土力学,2020,41(11):3705 − 3713. [CAI Yuanqiang,ZHOU Yuefu,WANG Peng,et al. Calculation on the settlement of dredged slurry treated by vacuum preloading method with consideration of clogging effects[J]. Rock and Soil Mechanics,2020,41(11):3705 − 3713. (in Chinese with English abstract)]
CAI Yuanqiang, ZHOU Yuefu, WANG Peng, et al. Calculation on the settlement of dredged slurry treated by vacuum preloading method with consideration of clogging effects[J]. Rock and Soil Mechanics, 2020, 41（11）: 3705 − 3713. （in Chinese with English abstract）
[14] 邹育麟,李建兴. 排水板堆载预压处理软土路基原位观测试验[J]. 铁道科学与工程学报,2017,14(8):1658 − 1663. [ZOU Yulin,LI Jianxing. In-situ observation test of soft soil subgrade treated by preloading method[J]. Journal of Railway Science and Engineering,2017,14(8):1658 − 1663. (in Chinese with English abstract)] doi: 10.3969/j.issn.1672-7029.2017.08.012
ZOU Yulin, LI Jianxing. In-situ observation test of soft soil subgrade treated by preloading method[J]. Journal of Railway Science and Engineering, 2017, 14（8）: 1658 − 1663. （in Chinese with English abstract） doi: 10.3969/j.issn.1672-7029.2017.08.012
[15] 蒋建清,曹国辉,刘热强. 排水板和砂井联合堆载预压加固海相软土地基的工作性状的现场试验[J]. 岩土力学,2015,36(增刊2):551 − 558. [JIANG Jianqing,CAO Guohui,LIU Reqiang. Field test on behaviours of marine soft soil foundation treated with plastic drainage plate and sand column combined with surcharge preloading[J]. Rock and Soil Mechanics,2015,36(Sup 2):551 − 558. (in Chinese with English abstract)]
JIANG Jianqing, CAO Guohui, LIU Reqiang. Field test on behaviours of marine soft soil foundation treated with plastic drainage plate and sand column combined with surcharge preloading[J]. Rock and Soil Mechanics, 2015, 36（Sup 2）: 551 − 558. （in Chinese with English abstract）
[16] 雷鸣,徐汉勇,匡希龙,等. 真空作用下软土固结机制及实例分析[J]. 铁道科学与工程学报,2019,16(6):1433 − 1439. [LEI Ming,XU Hanyong,KUANG Xilong,et al. Analysis of consolidation mechanism and example of treating soft foundation in vacuum preloading[J]. Journal of Railway Science and Engineering,2019,16(6):1433 − 1439. (in Chinese with English abstract)]
LEI Ming, XU Hanyong, KUANG Xilong, et al. Analysis of consolidation mechanism and example of treating soft foundation in vacuum preloading[J]. Journal of Railway Science and Engineering, 2019, 16（6）: 1433 − 1439. （in Chinese with English abstract）
[17] 张世民,王秀婷,崔耀,等. 真空联合堆载预压近海软基加固效果分析[J]. 水文地质工程地质,2017,44(5):59 − 65. [ZHANG Shimin,WANG Xiuting,CUI Yao,et al. An analysis of the effect of vacuum combined with surcharge preloading on offshore soft foundation reinforcement[J]. Hydrogeology & Engineering Geology,2017,44(5):59 − 65. (in Chinese with English abstract)]
ZHANG Shimin, WANG Xiuting, CUI Yao, et al. An analysis of the effect of vacuum combined with surcharge preloading on offshore soft foundation reinforcement[J]. Hydrogeology & Engineering Geology, 2017, 44（5）: 59 − 65. （in Chinese with English abstract）
[18] 陈继彬,赵其华,彭社琴,等. 塑料排水板处理软基侧向变形规律及预测模型[J]. 工程地质学报,2014,22(2):218 − 225. [CHEN Jibin,ZHAO Qihua,PENG Sheqin,et al. Lateral deformation law of soft soil subgrade treated by plastic drainage plate and forecasting model[J]. Journal of Engineering Geology,2014,22(2):218 − 225. (in Chinese with English abstract)] doi: 10.3969/j.issn.1004-9665.2014.02.007
CHEN Jibin, ZHAO Qihua, PENG Sheqin, et al. Lateral deformation law of soft soil subgrade treated by plastic drainage plate and forecasting model[J]. Journal of Engineering Geology, 2014, 22（2）: 218 − 225. （in Chinese with English abstract） doi: 10.3969/j.issn.1004-9665.2014.02.007
[19] CHAI Jinchun,ONG C Y,CARTER J P,et al. Lateral displacement under combined vacuum pressure and embankment loading[J]. Géotechnique,2013,63(10):842 − 856.
[20] XU Fang,CHAI Jinchun. Lateral displacement of PVD-improved deposit under embankment loading[J]. Geosynthetics International,2014,21(5):286 − 300. doi: 10.1680/gein.14.00016
[21] YE Guanbao,XU Yan,ZHANG Zhen. Performance evaluation of PVD-reinforced soft soil with surcharge and vacuum preloading[J]. International Journal of Civil Engineering,2018,16(4):421 − 433. doi: 10.1007/s40999-016-0142-y
[22] 高彦斌,张松波,郭永发. 软土地基的变形速率及稳定性控制[J]. 中国公路学报,2017,30(2):11 − 17. [GAO Yanbin,ZHANG Songbo,GUO Yongfa. Deformation rates and stability control of soft foundation[J]. China Journal of Highway and Transport,2017,30(2):11 − 17. (in Chinese with English abstract)] doi: 10.3969/j.issn.1001-7372.2017.02.002
GAO Yanbin, ZHANG Songbo, GUO Yongfa. Deformation rates and stability control of soft foundation[J]. China Journal of Highway and Transport, 2017, 30（2）: 11 − 17. （in Chinese with English abstract） doi: 10.3969/j.issn.1001-7372.2017.02.002
[23] CHAI Jinchun,XU Fang. Experimental investigation of lateral displacement of PVD-improved deposit[J]. Geomechanics and Engineering,2015,9(5):585 − 599.
[24] CHAI Jinchun,MIURA N,KIREKAWA T,et al. Optimum PVD installation depth for two-way drainage deposit[J]. Geomechanics and Engineering,2009,1(3):179 − 191. doi: 10.12989/gae.2009.1.3.179
[25] BERGADO D T,JAMSAWANG P,JONGPRADIST P,et al. Case study and numerical simulation of PVD improved soft Bangkok clay with surcharge and vacuum preloading using a modified air-water separation system[J]. Geotextiles and Geomembranes,2022,50(1):137 − 153. doi: 10.1016/j.geotexmem.2021.09.009
[26] 姜彦彬,何宁,许滨华,等. 真空预压负压分布规律模型试验研究[J]. 岩土工程学报,2017,39(10):1874 − 1883. [JIANG Yanbin,HE Ning,XU Binhua,et al. Model tests on negative pressure distribution in vacuum preloading[J]. Chinese Journal of Geotechnical Engineering,2017,39(10):1874 − 1883. (in Chinese with English abstract)] doi: 10.11779/CJGE201710016
JIANG Yanbin, HE Ning, XU Binhua, et al. Model tests on negative pressure distribution in vacuum preloading[J]. Chinese Journal of Geotechnical Engineering, 2017, 39（10）: 1874 − 1883. （in Chinese with English abstract） doi: 10.11779/CJGE201710016
[27] 孟静,高彦斌,袁聚云. 上海地区重塑粘性土有效内摩擦角试验研究[J]. 工程地质学报,2008,16(增刊1):677 − 680. [MENG Jing,GAO Yanbin,YUAN Juyun. Study on the effective angle of internal friction of remolded clay in shanghai[J] Journal of Engineering Geology,2008,16(Sup 1):677 − 680. (in Chinese with English abstract)]
MENG Jing, GAO Yanbin, YUAN Juyun. Study on the effective angle of internal friction of remolded clay in shanghai[J] Journal of Engineering Geology, 2008, 16（Sup 1）: 677 − 680. （in Chinese with English abstract）
[28] JAKY J. Pressure in silos[C]//Proceedings of the Second International Conference on Soil Mechanics and Foundation Engineering,London,Balkema,1948:103 − 107.
[29] PLAXIS 2D Material Model Manual[M]. Netherlands:Delft University of Technology & PLAXIS,2020.
[30] CHAI Jinchun,RONDONUWU S G. Surcharge loading rate for minimizing lateral displacement of PVD improved deposit with vacuum pressure[J]. Geotextiles and Geomembranes,2015,43(6):558 − 566. doi: 10.1016/j.geotexmem.2015.07.012
[31] 韩諝. 真空—堆载联合预压下PVD地基的侧向变形预测方法研究[D]. 长沙:中南大学,2021. [HAN Xu. Study on prediction method of lateral deformation of PVD-improved ground under combined vacuum pressure and surcharge load[D]. Changsha:Central South University,2021. (in Chinese with English abstract)]
HAN Xu. Study on prediction method of lateral deformation of PVD-improved ground under combined vacuum pressure and surcharge load[D]. Changsha: Central South University, 2021. （in Chinese with English abstract）
[32] HANSBO S. Consolidation of fine-grained soils by prefabricated drains[C]//Proceedings 10th International Conference on Soil Mechanics and Foundation Engineering. Stockholm,Balkema,1981:677 − 682.
[33] DAS B M. Principles of geotechnical engineering[M]. Singapore:Cengage Learning,2021.
-
