摘要:
针对传统数值模拟方法在处理离散岩体和节理方面的不足，依据利用无人机测绘技术及三维地质建模技术的发展，提出一种基于离散元数值分析的露天矿边坡稳定性评价方法。首先利用无人机测地技术获取数字高程模型和数字正射影像数据，然后运用三维地质建模技术构建矿区概化模型，并结合离散裂隙网络，对结构面发育的坡体进行三维建模，最后采用FLAC3D和3DEC软件对边坡稳定性进行计算。结果表明：（1）对复杂地形采用真三维建模并基于离散裂隙网络进行节理化更符合实际工程；采用无人机及三维地质建模技术可有效评价大范围露天矿区的稳定性。（2）构建内蒙古某露天矿区的概化模型，计算得到矿区开挖后竖向回弹量5～7 cm，边坡水平位移不超过3 cm，矿区边坡稳定；考虑节理的离散元数值分析计算所得稳定性系数为1.504，比传统数值模拟获得的稳定系数2.758显著减小，计算结果更符合实际。
Abstract:This study addressed the limitations of conventional numerical simulation techniques for discrete rock masses and joints by introducing a novel method for assessing slope stability in open-pit mines. The approach integrates discrete element numerical analysis with UAV and 3D geological modeling technologies. UAV geodetic technology was employed to obtain DEM and DOM datasets. These datasets facilitate the development of a generalized model of the mining area using advanced 3D geological modeling techniques. Using a discrete fracture network (DFN), the three-dimensional modeling of slopes with fully characterized structural surfaces was constructed. The slope stability was then quantified using FLAC3D and 3DEC software applications. The results show that the modeling technique for intricate terrains in authentic 3D numerical simulations, along with the three-dimensional modeling approach for jointed slopes using the DFN, correspond more closely with practical engineering scenarios. The integration of UAVs and 3D geological modeling technology provides an effective method for ascertaining the stability of extensive open-pit mining regions. A case study of an open-pit mine in Inner Mongolia demonstrates the effectiveness of the proposed method. Post-excavation analysis indicates a vertical rebound of 5–7 cm and a maximum horizontal slope displacement of less than 3 cm, confirming the mine slope’s stability. The computed stability coefficient, incorporating joint presence through discrete element numerical analysis, stood at 1.504. This value is markedly less than the 2.758 stability coefficient derived from traditional numerical simulations, thereby aligning the computational outcomes more closely with observed realities.
-
Key words:
- stability evaluation /
- 3D geological modeling /
- numerical simulation /
- FLAC3D /
- 3DEC /
- DFN
-
-
表 1 DEM获取方法对比
Table 1. Get DEM method comparison
方法 优点 缺点 航空摄影测量 方法成熟，精度高，可获取大比例尺DEM 特殊地区受航空管制 高程点或等高线差值 成本低，操作简单 受数据源限制大，数据来源不足 卫星遥感 可以大范围获取DEM 受天气影响较大，可获取的比例尺较小 干涉雷达技术 可以大范围获取DEM，不受天气影响 难以获得大比例尺DEM 激光雷达技术 精度高，可获取大比例尺DEM 技术不成熟，技术门槛高
下载: 导出CSV
表 2 矿区断层特征表
Table 2. Faults in mining area
编号及性质 断距/m 倾角/（°） 倾向 F51正断层 40～50 70 SW F46正断层 15～20 70 N10°W F70正断层 5～10 76 S～SW F37正断层 3～4 80 S20°W F39正断层 3 70 S7°E～S7°W F77正断层 3～5 80 S10°W F41正断层 3～6 50～70 N30°E F74正断层 5 85 N25°E
下载: 导出CSV
表 3 FLAC3D计算参数
Table 3. FLAC3D calculates parameters
岩土层 密度/（kg·m−3） 弹性模量/GPa 泊松比 黏聚力/ kPa 内摩擦角/（°） 全风化层 1800 0.60 0.31 77 23.1 砂岩 2750 9.85 0.17 298 32.2 砂质泥岩 2530 6.90 0.15 310 26.4 泥岩 2320 9.10 0.20 280 31.0 煤层 1600 7.35 0.20 96 30.1 铁质砂岩 2400 10.20 0.17 305 30.0 石灰岩 2500 12.00 0.15 420 38.0 回填土 1800 0.30 0.32 18 29.0
下载: 导出CSV
表 4 节理计算参数
Table 4. Calculation parameters of joints
法向刚度
/MPa剪切刚度
/MPa抗拉刚度
/MPa黏聚力
/kPa内摩擦角
/（°）砂岩岩体 130 26 15 300 32.2 虚拟节理 4333 2166 15 300 32.2 节 理 15.0 5.0 0.01 10 32.0
下载: 导出CSV
-
[1] 成建华. 无人机摄影测量等效边坡模型建立及稳定性分析[J]. 测绘通报,2023(增刊1):36 − 41. [CHENG Jianhua. Establishment and stability analysis of equivalent slope model based on unmanned aerial vehicle photogrammetry[J]. Bulletin of Surveying and Mapping,2023(Sup1):36 − 41. (in Chinese with English abstract)]
CHENG Jianhua. Establishment and stability analysis of equivalent slope model based on unmanned aerial vehicle photogrammetry[J]. Bulletin of Surveying and Mapping, 2023（Sup1）: 36 − 41. （in Chinese with English abstract）
[2] 金爱兵,陈帅军,赵安宇,等. 基于无人机摄影测量的露天矿边坡数值模拟[J]. 岩土力学,2021,42(1):255 − 264. [JIN Aibing,CHEN Shuaijun,ZHAO Anyu,et al. Numerical simulation of open-pit mine slope based on unmanned aerial vehicle photogrammetry[J]. Rock and Soil Mechanics,2021,42(1):255 − 264. (in Chinese with English abstract)]
JIN Aibing, CHEN Shuaijun, ZHAO Anyu, et al. Numerical simulation of open-pit mine slope based on unmanned aerial vehicle photogrammetry[J]. Rock and Soil Mechanics, 2021, 42（1）: 255 − 264. （in Chinese with English abstract）
[3] 叶震,许强,刘谦,等. 无人机倾斜摄影测量在边坡岩体结构面调查中的应用[J]. 武汉大学学报(信息科学版),2020,45(11):1739 − 1746. [YE Zhen,XU Qiang,LIU Qian,et al. Application of unmanned aerial vehicle oblique photogrammetry to investigation of high slope rock structure[J]. Geomatics and Information Science of Wuhan University,2020,45(11):1739 − 1746. (in Chinese with English abstract)]
YE Zhen, XU Qiang, LIU Qian, et al. Application of unmanned aerial vehicle oblique photogrammetry to investigation of high slope rock structure[J]. Geomatics and Information Science of Wuhan University, 2020, 45（11）: 1739 − 1746. （in Chinese with English abstract）
[4] 陈昌彦,张菊明,杜永廉,等. 边坡工程地质信息的三维可视化及其在三峡船闸边坡工程中的应用[J]. 岩土工程学报,1998,20(4):1 − 6. [CHEN Changyan,ZHANG Juming,DU Yonglian,et al. 3-D visualization of geoinformation in slope engineering and its application to the permanent shiplock slope in the Three Gorges Project[J]. Chinese Journal of Geotechnical Engineering,1998,20(4):1 − 6. (in Chinese with English abstract)]
CHEN Changyan, ZHANG Juming, DU Yonglian, et al. 3-D visualization of geoinformation in slope engineering and its application to the permanent shiplock slope in the Three Gorges Project[J]. Chinese Journal of Geotechnical Engineering, 1998, 20（4）: 1 − 6. （in Chinese with English abstract）
[5] 黄地龙,柴贺军,黄润秋. 岩体结构可视化软件系统研究[J]. 成都理工学院学报,2001,28(4):416 − 420. [HUANG Delong,CHAI Hejun,HUANG Runqiu. Research on software-system about visualization of a roc k body structure[J]. Journal of Chengdu University of Technology,2001,28(4):416 − 420. (in Chinese with English abstract)]
HUANG Delong, CHAI Hejun, HUANG Runqiu. Research on software-system about visualization of a roc k body structure[J]. Journal of Chengdu University of Technology, 2001, 28（4）: 416 − 420. （in Chinese with English abstract）
[6] 童亮,胡卸文,汪雪瑞. GOCAD在某桥基边坡三维地质建模中的应用研究[J]. 地质灾害与环境保护,2009,20(1):60 − 65. [TONG Liang,HU Xiewen,WANG Xuerui. Study on application of three-dimensional modeling to a bridge slope by using the software named GOCAD[J]. Journal of Geological Hazards and Environment Preservation,2009,20(1):60 − 65. (in Chinese with English abstract)]
TONG Liang, HU Xiewen, WANG Xuerui. Study on application of three-dimensional modeling to a bridge slope by using the software named GOCAD[J]. Journal of Geological Hazards and Environment Preservation, 2009, 20（1）: 60 − 65. （in Chinese with English abstract）
[7] 李良平,胡伏生,尹立河. 鄂尔多斯盆地白垩系三维地质建模研究[J]. 西北地质,2007,40(2):109 − 113. [LI Liangping,HU Fusheng,YIN Lihe. On the 3-dimentional geological modeling of cretaceous system in the ordos basin[J]. Northwestern Geology,2007,40(2):109 − 113. (in Chinese with English abstract)]
LI Liangping, HU Fusheng, YIN Lihe. On the 3-dimentional geological modeling of cretaceous system in the ordos basin[J]. Northwestern Geology, 2007, 40（2）: 109 − 113. （in Chinese with English abstract）
[8] 王亚军,张明江,陈鲁. 物探数据在三维地质建模中的应用——以新疆哈密盆地为例[J]. 西北地质,2014,47(3):91 − 100. [WANG Yajun,ZHANG Mingjiang,CHEN Lu. The application of geophysical data in 3D geological modeling:A case study of Hami basin,Xinjiang[J]. Northwestern Geology,2014,47(3):91 − 100. (in Chinese with English abstract)]
WANG Yajun, ZHANG Mingjiang, CHEN Lu. The application of geophysical data in 3D geological modeling: A case study of Hami basin, Xinjiang[J]. Northwestern Geology, 2014, 47（3）: 91 − 100. （in Chinese with English abstract）
[9] 杨波,管后春,杨潘,等. 基于三维GIS的第四系古河道沉积区工程建设适宜性评价研究[J]. 西北地质,2021,54(3):244 − 252. [YANG Bo,GUAN Houchun,YANG Pan,et al. Research on 3d gis-based suitability evaluation of engineering construction of the quaternary paleo-channel sedimentary area[J]. Northwestern Geology,2021,54(3):244 − 252. (in Chinese with English abstract)]
YANG Bo, GUAN Houchun, YANG Pan, et al. Research on 3d gis-based suitability evaluation of engineering construction of the quaternary paleo-channel sedimentary area[J]. Northwestern Geology, 2021, 54（3）: 244 − 252. （in Chinese with English abstract）
[10] 张伟,高倩,梁雷江. 基于Petrel技术的油藏三维可视化建模研究[J]. 西北地质,2013,46(3):191 − 196. [ZHANG Wei,GAO Qian,LIANG Leijiang. Three-dimensional visualization modeling of oil reservoir research based on petrel technology[J]. Northwestern Geology,2013,46(3):191 − 196. (in Chinese with English abstract)]
ZHANG Wei, GAO Qian, LIANG Leijiang. Three-dimensional visualization modeling of oil reservoir research based on petrel technology[J]. Northwestern Geology, 2013, 46（3）: 191 − 196. （in Chinese with English abstract）
[11] HEYDARI M,OSANLOO M. Untangling the complex web of environmental,social,and economic impacts in deep and large-scale open-pit mining projects using a dynamic modeling framework[J]. Resources Policy,2024,90:104690. doi: 10.1016/j.resourpol.2024.104690
[12] 李红军,张克亮. 陕西省三亩台黄土滑坡三维模拟分析[J]. 上海国土资源,2012,33(4):60 − 63. [LI Hongjun,ZHANG Keliang. 3D simulation of the Sanmutai loess landslide,Shaanxi province[J]. Shanghai Land & Resources,2012,33(4):60 − 63. (in Chinese with English abstract)]
LI Hongjun, ZHANG Keliang. 3D simulation of the Sanmutai loess landslide, Shaanxi province[J]. Shanghai Land & Resources, 2012, 33（4）: 60 − 63. （in Chinese with English abstract）
[13] 黎晨,李丽慧,王学良,等. 基于Flac3D和3DEC数值模拟技术的岩体稳定性评价[C]//中国第四纪科学研究会应用第四纪专业委员会,国际工程地质与环境协会岩土体结构性委员会(C29). 2017年山区第四纪环境与城镇建设学术研讨会论文集. 北京:科学出版社,2017. [LI Chen,LI Lihui,WANG Xueliang,et al. Rock mass stability evaluation based on Flac3D and 3DEC numerical simulation technology[C]//Chinese Association of Quaternary Sciences Applied Quaternary Professional Committee,International Association of Engineering Geology and Environment Geotechnical Structure Committee (C29). Proceedings of the 2017 Academic Symposium on Quaternary Environment and Urban Construction in Mountainous Areas. Beijing:Science Press,2017. (in Chinese)]
LI Chen, LI Lihui, WANG Xueliang, et al. Rock mass stability evaluation based on Flac3D and 3DEC numerical simulation technology[C]//Chinese Association of Quaternary Sciences Applied Quaternary Professional Committee, International Association of Engineering Geology and Environment Geotechnical Structure Committee （C29）. Proceedings of the 2017 Academic Symposium on Quaternary Environment and Urban Construction in Mountainous Areas. Beijing: Science Press, 2017. （in Chinese）
[14] PENG Taixin,HUANG Ling,LUO Xin. Risk analysis of the Mabian Tonggu dangerous rock belt in Sichuan province by using semi-quantitative method finite difference method FLAC and discrete element method 3DEC[C]//Geological Society of China. Abstracts of the 9th World Chinese Conference of Geological Science. Beijing,2019:370 − 371.
[15] 孙光吉,邓小龙,何乃武,等. 基于三维地质建模的公路桥台岸坡数值分析[J]. 中外公路,2020,40(增刊2):47 − 49. [SUN Guangji,DENG Xiaolong,HE Naiwu,et al. Numerical analysis of bank slope of highway abutment based on 3D geological modeling[J]. Journal of China and Foreign Highway,2020,40(Sup 2):47 − 49. (in Chinese with English abstract)]
SUN Guangji, DENG Xiaolong, HE Naiwu, et al. Numerical analysis of bank slope of highway abutment based on 3D geological modeling[J]. Journal of China and Foreign Highway, 2020, 40（Sup 2）: 47 − 49. （in Chinese with English abstract）
[16] 杨鹏程,李思达,韩伟歌,等. 岩溶区多软弱层复合边坡变形破坏机制分析[J]. 科学技术与工程,2022,22(15):6264 − 6269. [YANG Pengcheng,LI Sida,HAN Weige,et al. Analysis on deformation and failure mechanism of multi-weak layer composite slope in karst region[J]. Science Technology and Engineering,2022,22(15):6264 − 6269. (in Chinese with English abstract)]
YANG Pengcheng, LI Sida, HAN Weige, et al. Analysis on deformation and failure mechanism of multi-weak layer composite slope in karst region[J]. Science Technology and Engineering, 2022, 22（15）: 6264 − 6269. （in Chinese with English abstract）
[17] 谭银龙,许万忠,曹家菊,等. 基于Midas-GTS的三峡库区金鸡岭滑坡成因机制与稳定性分析[J]. 水文地质工程地质,2023,50(1):113 − 121. [TAN Yinlong,XU Wanzhong,CAO Jiaju,et al. Mechanisms and stability analysis of the Jinjiling landslide in the Three Gorges Reservoir area based on Midas-GTS[J]. Hydrogeology & Engineering Geology,2023,50(1):113 − 121. (in Chinese with English abstract)]
TAN Yinlong, XU Wanzhong, CAO Jiaju, et al. Mechanisms and stability analysis of the Jinjiling landslide in the Three Gorges Reservoir area based on Midas-GTS[J]. Hydrogeology & Engineering Geology, 2023, 50（1）: 113 − 121. （in Chinese with English abstract）
[18] 王志民,罗刚,王媛,等. 切割斜坡断层的几何形态对斜坡地震响应影响研究[J]. 水文地质工程地质,2023,50(6):147 − 157. [WANG Zhimin,LUO Gang,WANG Yuan,et al. A study of the influence of the crossing-slope fault geometry on the slope seismic response[J]. Hydrogeology & Engineering Geology,2023,50(6):147 − 157. (in Chinese with English abstract)]
WANG Zhimin, LUO Gang, WANG Yuan, et al. A study of the influence of the crossing-slope fault geometry on the slope seismic response[J]. Hydrogeology & Engineering Geology, 2023, 50（6）: 147 − 157. （in Chinese with English abstract）
[19] 刘先林,唐正辉. 三维地质建模与数值模拟关键技术研究[J]. 西部交通科技,2016(5):1 − 5. [LIU Xianlin,TANG Zhenghui. Research on key technology of geological modeling and numerical simulation[J]. Western China Communication Science & Technology,2016(5):1 − 5. (in Chinese with English abstract)]
LIU Xianlin, TANG Zhenghui. Research on key technology of geological modeling and numerical simulation[J]. Western China Communication Science & Technology, 2016（5）: 1 − 5. （in Chinese with English abstract）
[20] 张健,李春永,许尚博. 基于钻孔数据的煤岩层三维数值模型构建与应用[J]. 能源技术与管理,2022,47(5):1 − 4. [ZHANG Jian,LI Chunyong,XU Shangbo. Construction and application of 3D numerical model of coal rock formation based on drilling data[J]. Energy Technology and Management,2022,47(5):1 − 4. (in Chinese with English abstract)]
ZHANG Jian, LI Chunyong, XU Shangbo. Construction and application of 3D numerical model of coal rock formation based on drilling data[J]. Energy Technology and Management, 2022, 47（5）: 1 − 4. （in Chinese with English abstract）
[21] CHAND K,KONER R. Failure Zone identification and slope stability analysis of mine dump based on realistic 3D numerical modeling[J]. Geotechnical and Geological Engineering,2024,42(1):543 − 560. doi: 10.1007/s10706-023-02588-1
[22] PETER K,OLANREWAJU N O,PROSPER M,et al. DFN:An emerging tool for stochastic modelling and geomechanical design[J]. Eng,2023,4(1):174 − 205. doi: 10.3390/eng4010011
[23] ALENCAR M L,DE MIRANDA T S,CORREIA FILHO O J,et al. The effect of fracture networks on the vertical permeability of a tight carbonate reservoir analogue:Laminites from the Crato Formation,NE Brazil[J]. Marine and Petroleum Geology,2024,162:106735. doi: 10.1016/j.marpetgeo.2024.106735
[24] YAO Wenli,SHARIFZADEH M,ZHEN Yang,et al. Assessment of fracture characteristics controlling fluid flow performance in discrete fracture networks (DFN)[J]. Journal of Petroleum Science and Engineering,2019,178:1104 − 1111. doi: 10.1016/j.petrol.2019.04.011
[25] DU Cheng,LI Xinxin,GONG Wenping. A DFN-based framework for probabilistic assessment of groundwater contamination in fractured aquifers[J]. Chemosphere,2023,337:139232. doi: 10.1016/j.chemosphere.2023.139232
[26] SONI A,MONSALVE J J,BISHOP R,et al. Modified design of pillar based on estimated stresses and strength of pillar in an underground limestone mine[J]. Mining,Metallurgy & Exploratio,2023,40(2):529-541.
[27] SINGH J,PRADHAN S P,VISHAL V,et al. Characterization of a fractured rock mass using geological strength index:A discrete fracture network approach[J]. Transportation Geotechnics,2023,40:100984. doi: 10.1016/j.trgeo.2023.100984
[28] MA Weili,XU Zengguang,CHAI Junrui,et al. Estimation of REV size of 2-D DFN models in nonlinear flow:Considering the fracture length-aperture correlation[J]. Computers and Geotechnics,2023,161:105601.
[29] 杨忠民,高永涛,吴顺川,等. 基于等效岩体技术的节理参数对岩体强度影响性研究[J]. 中国矿业大学学报,2018,47(5):979 − 986. [YANG Zhongmin,GAO Yongtao,WU Shunchuan,et al. Study of the influence of joint parameters on rock mass strength based on equivalent rock mass technology[J]. Journal of China University of Mining & Technology,2018,47(5):979 − 986. (in Chinese with English abstract)]
YANG Zhongmin, GAO Yongtao, WU Shunchuan, et al. Study of the influence of joint parameters on rock mass strength based on equivalent rock mass technology[J]. Journal of China University of Mining & Technology, 2018, 47（5）: 979 − 986. （in Chinese with English abstract）
[30] FAN Hongyun,LI Liping,ZONG Peijun,et al. Advanced stability analysis method for the tunnel face in jointed rock mass based on DFN-DEM[J]. Underground Space,2023,13:136 − 149.
[31] WANG Xin,CAI Ming. A DFN–DEM multi-scale modeling approach for simulating tunnel excavation response in jointed rock masses[J]. Rock Mechanics and Rock Engineering,2020,53(3):1053 − 1077. doi: 10.1007/s00603-019-01957-8
[32] 郑程程,贺鹏,王刚,等. 隧道裂隙岩体结构信息解译与危石垮塌空间展布规律研究[J]. 岩石力学与工程学报,2022,41(3):515 − 532. [ZHENG Chengcheng,HE Peng,WANG Gang,et al. Structure information interpretation of fractured rock mass and spatial distribution law of dangerous rock collapse in tunnels[J]. Chinese Journal of Rock Mechanics and Engineering,2022,41(3):515 − 532. (in Chinese with English abstract)]
ZHENG Chengcheng, HE Peng, WANG Gang, et al. Structure information interpretation of fractured rock mass and spatial distribution law of dangerous rock collapse in tunnels[J]. Chinese Journal of Rock Mechanics and Engineering, 2022, 41（3）: 515 − 532. （in Chinese with English abstract）
[33] MALLET J L. Discrete smooth interpolation[J]. ACM Transactions on Graphics(TOG),1989,8(2):121 − 144. doi: 10.1145/62054.62057
[34] 朱权洁,刘金海,王胜开,等. 多软件联合的煤矿三维数值建模方法及其应用[J]. 中国安全生产科学技术,2017,13(6):115 − 120. [ZHU Quanjie,LIU Jinhai,WANG Shengkai,et al. Method of 3D numerical modeling on coal mine with multi-software combination and its application[J]. Journal of Safety Science and Technology,2017,13(6):115 − 120. (in Chinese with English abstract)]
ZHU Quanjie, LIU Jinhai, WANG Shengkai, et al. Method of 3D numerical modeling on coal mine with multi-software combination and its application[J]. Journal of Safety Science and Technology, 2017, 13（6）: 115 − 120. （in Chinese with English abstract）
[35] 徐文杰,胡瑞林,李厚恩,等. CAD软件在工程地质三维建模中的应用[J]. 工程地质学报,2007,15(2):279 − 283. [XU Wenjie,HU Ruilin,LI Houen,et al. Application of CAD software in 3D modeling of engineering geology[J]. Journal of Engineering Geology,2007,15(2):279 − 283. (in Chinese with English abstract)]
XU Wenjie, HU Ruilin, LI Houen, et al. Application of CAD software in 3D modeling of engineering geology[J]. Journal of Engineering Geology, 2007, 15（2）: 279 − 283. （in Chinese with English abstract）
[36] 刘文,余天彬,王猛,等. 四川宜宾市地质灾害隐患与地层岩性-地质构造关系分析[J]. 中国地质灾害与防治学报,2023,34(3):118 − 126. [LIU Wen,YU Tianbin,WANG Meng,et al. Analysis on the relationship between geological hazard and lithology,geological structure in Yibin City of Sichuan Province[J]. The Chinese Journal of Geological Hazard and Control,2023,34(3):118 − 126. (in Chinese with English abstract)]
LIU Wen, YU Tianbin, WANG Meng, et al. Analysis on the relationship between geological hazard and lithology, geological structure in Yibin City of Sichuan Province[J]. The Chinese Journal of Geological Hazard and Control, 2023, 34（3）: 118 − 126. （in Chinese with English abstract）
[37] 卢海燕. 基于Kinect的岩体节理统计方案设计与实现[D]. 北京:中国科学院大学,2018. [LU Haiyan. The design and implementation of rock mass joint statistical scheme based on kinect[D]. Beijing:University of Chinese Academy of Sciences,2018. (in Chinese with English abstract)]
LU Haiyan. The design and implementation of rock mass joint statistical scheme based on kinect[D]. Beijing: University of Chinese Academy of Sciences, 2018. （in Chinese with English abstract）
[38] 吴顺川,周喻,高永涛,等. 等效岩体随机节理三维网络模型构建方法研究[J]. 岩石力学与工程学报,2012,31(增刊1):3082 − 3090. [WU Shunchuan,ZHOU Yu,GAO Yongtao,et al. Research on construction method of stochastic joints 3D-network model of equivalent rock mass[J]. Chinese Journal of Rock Mechanics and Engineering,2012,31(Sup1):3082 − 3090. (in Chinese with English abstract)]
WU Shunchuan, ZHOU Yu, GAO Yongtao, et al. Research on construction method of stochastic joints 3D-network model of equivalent rock mass[J]. Chinese Journal of Rock Mechanics and Engineering, 2012, 31（Sup1）: 3082 − 3090. （in Chinese with English abstract）
[39] 胡训健,卞康,刘建,等. 离散裂隙网络对岩石力学性质和声发射特性影响的颗粒流分析[J]. 岩土力学,2022,43(增刊1):542 − 552. [HU Xunjian,BIAN Kang,LIU Jian,et al. Particle flow code analysis of the effect of discrete fracture network on rock mechanical properties and acoustic emission characteristics[J]. Rock and Soil Mechanics,2022,43(Sup1):542 − 552. (in Chinese with English abstract)]
HU Xunjian, BIAN Kang, LIU Jian, et al. Particle flow code analysis of the effect of discrete fracture network on rock mechanical properties and acoustic emission characteristics[J]. Rock and Soil Mechanics, 2022, 43（Sup1）: 542 − 552. （in Chinese with English abstract）
[40] 魏亚强,董艳辉,周鹏鹏,等. 基于离散裂隙网络模型的核素粒子迁移数值模拟研究[J]. 水文地质工程地质,2017,44(1):123 − 130. [WEI Yaqiang,DONG Yanhui,ZHOU Pengpeng,et al. Numerical simulation of radionuclide particle tracking based on discrete fracture network[J]. Hydrogeology & Engineering Geology,2017,44(1):123 − 130. (in Chinese with English abstract)]
WEI Yaqiang, DONG Yanhui, ZHOU Pengpeng, et al. Numerical simulation of radionuclide particle tracking based on discrete fracture network[J]. Hydrogeology & Engineering Geology, 2017, 44（1）: 123 − 130. （in Chinese with English abstract）
[41] KULATILAKE P H S W,UCPIRTI H,WANG S,et al. Use of the distinct element method to perform stress analysis in rock with non-persistent joints and to study the effect of joint geometry parameters on the strength and deformability of rock masses[J]. Rock Mechanics and Rock Engineering,1992,25(4):253 − 274. doi: 10.1007/BF01041807
[42] 中华人民共和国住房和城乡建设部. 建筑边坡工程技术规范:GB 50330—2013[S]. 北京:中国建筑工业出版社,2013. [Ministry of Housing and Urban-Rural Development of the People’s Republic of China. Technical code for building slope engineering:GB 50330—2013[S]. Beijing:China Architecture & Building Press,2013. (in Chinese)]
Ministry of Housing and Urban-Rural Development of the People’s Republic of China. Technical code for building slope engineering: GB 50330—2013[S]. Beijing: China Architecture & Building Press, 2013. （in Chinese）
[43] 刘佑荣,唐辉明. 岩体力学[M]. 北京:化学工业出版社,2018:55-80. [LIU Yourong,TANG Huiming. Rock Mass Mechanics[M]. Beijing:Chemical Industry Press,2009. (in Chinese)]
LIU Yourong, TANG Huiming. Rock Mass Mechanics[M]. Beijing: Chemical Industry Press, 2009. （in Chinese）
-
