Multi-scale response characteristics of overlying soil-tunnel system under reverse fault dislocation
-
摘要:
基岩断层错动在上覆土层中的传播破裂过程受多种因素控制，上覆土中跨断层隧道结构在断层错动下的响应机制尚不清晰。为解决这一问题，建立了基岩断层上覆土与隧道结构的三维离散-连续耦合模型，采用离散元模拟上覆土层细观颗粒特性与变形模式，采用有限差分法计算隧道结构宏观力学响应，并通过界面耦合实现宏-细观交互传递。基于该方法，分析了基岩断层错动在上覆土层中的破裂传播过程和上覆土中隧道结构的变形受力响应，并探究了断层倾角与隧道埋深对隧道响应及失效模式的影响机制。结果表明：基岩断层错动在上覆土层中以剪切带的形式传播，隧道结构的存在将增大地层位错变形范围；隧道结构的受力变形模式为由隧道纵向受弯导致的受弯区上下盘衬砌应力反对称分布，隧道结构失效最先发生在上盘区段，体现出显著的上盘效应；在相同基岩错动量条件下，断层倾角越小，隧道结构受力越不利；隧道埋深越深，其周围土体变形范围越集中，隧道结构受力越不利。研究可为基岩断层错动作用下上覆土中隧道结构抗震设计提供科学依据。
Abstract:The propagation and rupture process of bedrock fault dislocation in the overlying soil layer is controlled by many factors, which makes the response mechanism of the tunnel structure crossing the overlying soil under fault dislocation unclear. To solve this problem, a three-dimensional discrete-continuous coupling model is established, in which the discrete element is used to simulate the microscopic characteristics of the soil particles and deformation mode of the overburden layer, the finite difference method is used to calculate the macroscopic mechanical response of the tunnel structure, and the interface coupling is used to realize the interactive transfer between the above two methods. Based on the multi-scale model, the rupture propagation process of bedrock fault dislocation in the overlying soil layer, as well as the deformation response of the tunnel structure in the overlying soil are investigated. The effects of the fault dip and the depth of tunnel on the tunnel failure mode are also investigated. Results show that the bedrock fault dislocation propagates in the form of shear zone in the overburden, and the existence of tunnel structure will increase the deformation area of the soil. The deformation mode is the anti-symmetric distribution of lining stress in the upper and lower disks of the bending area caused by longitudinal bending of the tunnel, and the structural failure of the tunnel structure occurs firstly in the upper disk section, which shows the significant effect of the upper disk. Suffering the same bedrock dislocation, the tunnel structural is more likely to be damaged with a smaller fault dip. In addition, under a higher depth of tunnel, the deformation zone of the surrounding soil will be concentrated, resulting in the instability of the tunnel. The study can provide a scientific basis for the seismic design of tunnel structures in the overlying soil under the action of bedrock fault dislocation.
-
-
表 1 隧道衬砌模型等效参数取值
Table 1. Equivalent parameter of tunnel lining model
参数 弹性模量/GPa 泊松比 黏聚力/MPa 内摩擦角/（°） 剪胀角/（°） 隧道衬砌 32 0.2 7.2 45 30
下载: 导出CSV
表 2 三维试样细观参数标定结果
Table 2. Calibration results of 3D sample microparameters
变量 过程 参数 取值 孔隙率 — n 0.3 有效模量/GPa — E 55 法切向刚度比 — $ k_{\mathrm{n}}/k_{\mathrm{s}} $ 1.0 ball-ball摩擦系数 成样阶段 $ fric $ 0.02 剪切阶段 $ fric $ 0.2 ball-facet摩擦系数 剪切阶段 $ fric $ 0.0 抗转动组摩擦系数 剪切阶段 $ rrfric $ 0.15
下载: 导出CSV
表 3 计算工况表
Table 3. Simulation cases
工况 断层倾角/（°） 隧道埋深/m 分析因素 R60T30 60 30 断层倾角 R45T30 45 30 R30T30 30 30 R60T30 60 30 隧道埋深 R60T20 60 20 R60T10 60 10
下载: 导出CSV
-
[1] 王志民,罗刚,王媛,等. 切割斜坡断层的几何形态对斜坡地震响应影响研究[J]. 水文地质工程地质,2023,50(6):147 − 157. [WANG Zhimin,LUO Gang,WANG Yuan,et al. A study of the influence of the crossing-slope fault geometry on the slope seismic response[J]. Hydrogeology & Engineering Geology,2023,50(6):147 − 157. (in Chinese with English abstract)]
WANG Zhimin, LUO Gang, WANG Yuan, et al. A study of the influence of the crossing-slope fault geometry on the slope seismic response[J]. Hydrogeology & Engineering Geology, 2023, 50（6）: 147 − 157. （in Chinese with English abstract）
[2] 李远远,李春鹏,和大钊,等. 基于流固耦合作用的富水断层区隧道初期支护优化分析[J]. 水文地质工程地质,2025,52(3):144 − 152. [LI Yuanyuan,LI Chunpeng,HE Dazhao,et al. Optimization analysis of initial support for tunnels in water-rich fault zone based on fluid-solid interaction[J]. Hydrogeology & Engineering Geology,2025,52(3):144 − 152. (in Chinese with English abstract)]
LI Yuanyuan, LI Chunpeng, HE Dazhao, et al. Optimization analysis of initial support for tunnels in water-rich fault zone based on fluid-solid interaction[J]. Hydrogeology & Engineering Geology, 2025, 52（3）: 144 − 152. （in Chinese with English abstract）
[3] BRAY J D,SEED R B,CLUFF L S,et al. Earthquake fault rupture propagation through soil[J]. Journal of Geotechnical Engineering,1994,120(3):543 − 561. doi: 10.1061/(ASCE)0733-9410(1994)120:3(543)
[4] 张永双,任三绍,郭长宝,等. 活动断裂带工程地质研究[J]. 地质学报,2019,93(4):763 − 775. [ZHANG Yongshuang,REN Sanshao,GUO Changbao,et al. Research on engineering geology related with active fault zone[J]. Acta Geologica Sinica,2019,93(4):763 − 775. (in Chinese with English abstract)]
ZHANG Yongshuang, REN Sanshao, GUO Changbao, et al. Research on engineering geology related with active fault zone[J]. Acta Geologica Sinica, 2019, 93（4）: 763 − 775. （in Chinese with English abstract）
[5] BURRIDGE P B,SCOTT R F,HALL J F. Centrifuge study of faulting effects on tunnel[J]. Journal of Geotechnical Engineering,1989,115(7):949 − 967 doi: 10.1061/(ASCE)0733-9410(1989)115:7(949)
[6] LIU Xuezeng,LI Xuefeng,SANG Yunlong,et al. Experimental study on normal fault rupture propagation in loose strata and its impact on mountain tunnels[J]. Tunnelling and Underground Space Technology,2015,49:417 − 425. doi: 10.1016/j.tust.2015.05.010
[7] CAI Q P,PENG J M,NG C W W,et al. Centrifuge and numerical modelling of tunnel intersected by normal fault rupture in sand[J]. Computers and Geotechnics,2019,111:137 − 146. doi: 10.1016/j.compgeo.2019.03.010
[8] 史秋艾. 珠江三角洲西北部晚第四纪沉积演化研究[J]. 中国煤炭地质,2024,36(7):25 − 28. [SHI Qiuai. Study on late Quaternary sedimentary evolution in northwest the Pearl River Delta[J]. Coal Geology of China,2024,36(7):25 − 28. (in Chinese with English abstract)] doi: 10.3969/j.issn.1674-1803.2024.07.04
SHI Qiuai. Study on late Quaternary sedimentary evolution in northwest the Pearl River Delta[J]. Coal Geology of China, 2024, 36（7）: 25 − 28. （in Chinese with English abstract） doi: 10.3969/j.issn.1674-1803.2024.07.04
[9] 鲁战乾. 新乡市第四纪沉积物粒度分析及其沉积相特征[D]. 北京:中国地质大学(北京),2013. [LU Zhanqian. Grain size analysis and sedimentary facies characteristics of Quaternary sediments in Xinxiang city[D]. Beijing:China University of Geosciences (Beijing),2013. (in Chinese with English abstract)]
LU Zhanqian. Grain size analysis and sedimentary facies characteristics of Quaternary sediments in Xinxiang city[D]. Beijing: China University of Geosciences （Beijing）, 2013. （in Chinese with English abstract）
[10] 尹小涛,郑亚娜,马双科. 基于颗粒流数值试验的岩土材料内尺度比研究[J]. 岩土力学,2011,32(4):1211 − 1215. [YIN Xiaotao,ZHENG Yana,MA Shuangke. Study of inner scale ratio of rock and soil material based on numerical tests of particle flow code[J]. Rock and Soil Mechanics,2011,32(4):1211 − 1215. (in Chinese with English abstract)] doi: 10.3969/j.issn.1000-7598.2011.04.043
YIN Xiaotao, ZHENG Yana, MA Shuangke. Study of inner scale ratio of rock and soil material based on numerical tests of particle flow code[J]. Rock and Soil Mechanics, 2011, 32（4）: 1211 − 1215. （in Chinese with English abstract） doi: 10.3969/j.issn.1000-7598.2011.04.043
[11] 刘凯,孔超,唐浚哲,等. 高地应力断层破碎带衬砌力学特性对比与分析[J]. 铁道标准设计,2014,58(12):99 − 103. [LIU Kai,KONG Chao,TANG Junzhe,et al. Comparison and analysis of mechanical properties of lining in fault fracture zone with high geostress[J]. Railway Standard Design,2014,58(12):99 − 103. (in Chinese with English abstract)]
LIU Kai, KONG Chao, TANG Junzhe, et al. Comparison and analysis of mechanical properties of lining in fault fracture zone with high geostress[J]. Railway Standard Design, 2014, 58（12）: 99 − 103. （in Chinese with English abstract）
[12] 王一伟,刘润,孙若晗,等. 基于抗转模型的颗粒材料宏-细观关系研究[J]. 岩土力学,2022,43(4):945 − 956. [WANG Yiwei,LIU Run,SUN Ruohan,et al. Macroscopic and mesoscopic correlation of granular materials based on rolling resistance linear contact model[J]. Rock and Soil Mechanics,2022,43(4):945 − 956. (in Chinese with English abstract)]
WANG Yiwei, LIU Run, SUN Ruohan, et al. Macroscopic and mesoscopic correlation of granular materials based on rolling resistance linear contact model[J]. Rock and Soil Mechanics, 2022, 43（4）: 945 − 956. （in Chinese with English abstract）
[13] ANASTASOPOULOS I,GAZETAS G,BRANSBY M F,et al. Fault rupture propagation through sand:Finite-element analysis and validation through centrifuge experiments[J]. Journal of Geotechnical and Geoenvironmental Engineering,2007,133(8):943 − 958. doi: 10.1061/(ASCE)1090-0241(2007)133:8(943)
[14] 张炳焜. 断层错动数值模拟中的几个关键影响因素[J]. 四川建筑,2014,34(2):124 − 125. [ZHANG Bingkun. Several key influencing factors in numerical simulation of fault dislocation[J]. Sichuan Architecture,2014,34(2):124 − 125. (in Chinese)] doi: 10.3969/j.issn.1007-8983.2014.02.053
ZHANG Bingkun. Several key influencing factors in numerical simulation of fault dislocation[J]. Sichuan Architecture, 2014, 34（2）: 124 − 125. （in Chinese） doi: 10.3969/j.issn.1007-8983.2014.02.053
[15] LIN Minglang,CHUNG C F,JENG F S. Deformation of overburden soil induced by thrust fault slip[J]. Engineering Geology,2006,88(1/2):70 − 89.
[16] 张培震,徐锡伟,闻学泽,等. 2008年汶川8.0级地震发震断裂的滑动速率、复发周期和构造成因[J]. 地球物理学报,2008,51(4):1066 − 1073. [ZHANG Peizhen,XU Xiwei,WEN Xueze,et al. Slip rates and recurrence intervals of the Longmen Shan active fault zone,and tectonic implications for the mechanism of the May 12 Wenchuan earthquake,2008,Sichuan,China[J]. Chinese Journal of Geophysics,2008,51(4):1066 − 1073. (in Chinese with English abstract)] doi: 10.3321/j.issn:0001-5733.2008.04.015
ZHANG Peizhen, XU Xiwei, WEN Xueze, et al. Slip rates and recurrence intervals of the Longmen Shan active fault zone, and tectonic implications for the mechanism of the May 12 Wenchuan earthquake, 2008, Sichuan, China[J]. Chinese Journal of Geophysics, 2008, 51（4）: 1066 − 1073. （in Chinese with English abstract） doi: 10.3321/j.issn:0001-5733.2008.04.015
[17] 李天斌. 汶川特大地震中山岭隧道变形破坏特征及影响因素分析[J]. 工程地质学报,2008,16(6):742 − 750. [LI Tianbin. Failure characteristics and influence factor analysis of mountain tunnels at epicenter zones of great Wenchuan earthquake[J]. Journal of Engineering Geology,2008,16(6):742 − 750. (in Chinese with English abstract)] doi: 10.3969/j.issn.1004-9665.2008.06.003
LI Tianbin. Failure characteristics and influence factor analysis of mountain tunnels at epicenter zones of great Wenchuan earthquake[J]. Journal of Engineering Geology, 2008, 16（6）: 742 − 750. （in Chinese with English abstract） doi: 10.3969/j.issn.1004-9665.2008.06.003
[18] MA Y,SHENG Qian,ZHANG Guimin,et al. A 3D discrete-continuum coupling approach for investigating the deformation and failure mechanism of tunnels across an active fault:A case study of Xianglushan tunnel[J]. Applied Sciences,2019,9(11):2318. doi: 10.3390/app9112318
[19] 禹海涛,许桦霖,卫一博. 穿活动断裂带隧道抗错动易损性分析方法[J]. 岩土工程学报,2024,46(10):2060 − 2068. [YU Haitao,XU Hualin,WEI Yibo. Seismic fragility analysis method for evaluation of dislocation resistance of tunnels crossing active fault zones[J]. Chinese Journal of Geotechnical Engineering,2024,46(10):2060 − 2068. (in Chinese with English abstract)]
YU Haitao, XU Hualin, WEI Yibo. Seismic fragility analysis method for evaluation of dislocation resistance of tunnels crossing active fault zones[J]. Chinese Journal of Geotechnical Engineering, 2024, 46（10）: 2060 − 2068. （in Chinese with English abstract）
-
