Water abundance assessment model development and water hazard control strategies for karst aquifers in metal mines: A case study of the Maoping lead zinc mine in Northeast Yunnan, China
-
摘要:
针对岩溶区金属矿山仅依据钻孔单位涌水量划分岩溶含水层富水性的缺陷，以滇东北典型深采矿山毛坪铅锌矿为例，在充分考虑其水文地质结构特征的基础上，从渗流场特征、含水层特征、构造发育特征3方面，构建了包含渗透系数、水位降深、单位涌水量、含水层有效厚度、水样溶解性总固体、断层发育密度、冲洗液消耗量等7个评价指标的层次结构评价模型。采用层次分析法计算得到了各评价指标的主观权重，并在ArcGIS系统内根据富水性指数将研究区划分为弱富水区，较弱富水区，中等富水区，较强富水区，强富水区5个区域。评价结果表明：毛坪铅锌矿石门坎背斜西翼岩溶含水层的富水性整体较强；石门坎背斜轴部岩溶含水层的富水性呈现出上强下弱的特点；石门坎背斜东翼岩溶含水层的富水性总体偏弱，且浅部岩溶含水层的富水性向东逐渐减弱。针对金属矿山采掘揭露局部强富水区诱发高势能突水灾害，提出了“骨料灌注→充填注浆→水源封堵”的被动治理方式；以及针对区域强富水含水层的“物探先行→钻探验证→区域超前帷幕注浆”的主动治理方式。研究结果对于指导金属矿山深部采掘空间布置和制订疏放水方案具有重要的参考意义。
Abstract:To address the limitations of relying solely on borehole-specific water inflow rates to evaluate the water abundance of karst aquifers in metal mines, this study presented a comprehensive assessment in the Maoping lead zinc mine in Northeastern Yunnan, a typical deep karst mining area, using a hierarchical evaluation model for karst aquifer water abundance. This model integrated three key dimensions: Seepage field characteristics (permeability coefficient, water level drawdown, and unit water inflow), aquifer characteristics (effective thickness of aquifer and total dissolved solids in water samples), and structural development characteristics (fault density and drilling fluid loss). Subjective weights for each evaluation indicator were determined using the analytic hierarchy process (AHP). Using ArcGIS platform, the study area was categorized into five distinct water-richness zones based on the water abundance index thresholds: very low water-rich area, low water-rich area, moderate water-rich area, high water-rich area, and very high water-rich area. The evaluation results demonstrate that the karst aquifer in the western wing of the Shimenkan anticline, located at the Maoping lead zinc mine in Northeastern Yunnan, exhibits high overall water abundance. The karst aquifer in the axial zone of the Shimenkan anticline exhibits significant vertical zonation in water abundance, characterized by high values in the upper strata and low values in the lower strata. The water abundance of the karst aquifer in the eastern wing of the Shimenkan anticline is generally weak, and the water abundance of the shallow karst aquifer gradually weakens towards the east. The passive governance mode of “aggregate injection→filling grouting→water source blockage” was used to address the high potential water inrush disasters induced by the exposure of local strong water-rich areas in metal mines; the active governance mode of “geophysical exploration first→drilling verification→regional advanced curtain grouting” for strong water-rich aquifers in the region. This study offers critical technical guidance for optimizing deep mine layout and developing effective drainage strategies in karst metal mining regions.
-
-
表 1 9级标度打分表
Table 1. Scale rating of nine grades
序号 重要性等级级别 Cij标度值 1 指标i比指标j同等重要 1 2 指标i比指标j稍微重要 3 3 指标i比指标j明显重要 5 4 指标i比指标j强烈重要 7 5 指标i比指标j极端重要 9 6 指标i比指标j稍不重要 1/3 7 指标i比指标j明显不重要 1/5 8 指标i比指标j强烈不重要 1/7 9 指标i比指标j极端不重要 1/9
下载: 导出CSV
表 2 A-Bi （i=1, 2, 3）判断矩阵
Table 2. Judgment matrix of A-Bi (i=1, 2, 3)
A B1 B2 B3 B1 1 4 5 B2 1/4 1 5 B3 1/5 1/2 1
下载: 导出CSV
表 3 B1-Ci （i=1, 2, 3）判断矩阵
Table 3. Judgment matrix of B1-Ci (i=1, 2, 3)
B1 C1 C2 C3 C1 1 3 1/2 C2 1/3 1 1/4 C3 2 4 1
下载: 导出CSV
表 6 基于AHP的权重计算结果
Table 6. Weight calculation results based on AHP method
目标层 准则层 权重
Bi （i=1～3）指标层 指标权重
Ci （i=1～7）金属矿山
岩溶含水层
富水性
评价（A）渗流场特征
（B1）0.6833 渗透系数（C1） 0.2184 水位降深（C2） 0.0833 单位涌水量（C3） 0.3816 含水层特征
（B2）0.1999 含水层有效厚度（C4） 0.1499 水样溶解性总固体（C5） 0.0500 构造发育
特征（B3）0.1168 断层发育密度（C6） 0.0779 冲洗液消耗量（C7） 0.0389
下载: 导出CSV
-
[1] 吴建标,韩润生,周高明,等. 滇东北毛坪富锗铅锌矿床构造控矿作用及深部找矿方向[J]. 大地构造与成矿学,2023,47(5):984 − 1001. [WU Jianbiao,HAN Runsheng,ZHOU Gaoming,et al. Structural ore-controlling and deep prospecting direction of the Maoping lead-zinc deposit in Northeastern Yunnan,China[J]. Geotectonica et Metallogenia,2023,47(5):984 − 1001. (in Chinese with English abstract)]
WU Jianbiao, HAN Runsheng, ZHOU Gaoming, et al. Structural ore-controlling and deep prospecting direction of the Maoping lead-zinc deposit in Northeastern Yunnan, China[J]. Geotectonica et Metallogenia, 2023, 47（5）: 984 − 1001. （in Chinese with English abstract）
[2] 吴夏涛,周家喜,张浩,等. 川滇黔接壤地区铅锌矿床成矿物质来源:方铅矿原位Pb同位素制约[J]. 地球科学与环境学报,2023,45(2):266 − 278. [WU Xiatao,ZHOU Jiaxi,ZHANG Hao,et al. Source of ore-forming materials for the carbonate-hosted Pb-Zn deposits in Sichuan-Yunnan-Guizhou adjacent area,SW China:Constraints of galena in-situ Pb isotopes[J]. Journal of Earth Sciences and Environment,2023,45(2):266 − 278. (in Chinese with English abstract)]
WU Xiatao, ZHOU Jiaxi, ZHANG Hao, et al. Source of ore-forming materials for the carbonate-hosted Pb-Zn deposits in Sichuan-Yunnan-Guizhou adjacent area, SW China: Constraints of galena in-situ Pb isotopes[J]. Journal of Earth Sciences and Environment, 2023, 45（2）: 266 − 278. （in Chinese with English abstract）
[3] 陈启良. 滇东北渔户村组富铅锌矿成矿地质特征及找矿标志[J]. 地质与勘探,2002,38(1):22 − 26. [CHEN Qiliang. Metallogenetic geological features and ore guides of high-grade Pb-Zn deposits in Yuhucun formation,Northeast Yunnan[J]. Geology and Exploration,2002,38(1):22 − 26. (in Chinese with English abstract)] doi: 10.3969/j.issn.0495-5331.2002.01.007
CHEN Qiliang. Metallogenetic geological features and ore guides of high-grade Pb-Zn deposits in Yuhucun formation, Northeast Yunnan[J]. Geology and Exploration, 2002, 38（1）: 22 − 26. （in Chinese with English abstract） doi: 10.3969/j.issn.0495-5331.2002.01.007
[4] 马宏杰,张世涛,程先锋,等. 云南会泽石炭系摆佐组白云岩地球化学特征及其成因分析[J]. 沉积学报,2014,32(1):118 − 125. [MA Hongjie,ZHANG Shitao,CHENG Xianfeng,et al. Geochemical characteristics and genetic analysis of carboniferous dolomite in Huize Basin,Yunnan[J]. Acta Sedimentologica Sinica,2014,32(1):118 − 125. (in Chinese with English abstract)]
MA Hongjie, ZHANG Shitao, CHENG Xianfeng, et al. Geochemical characteristics and genetic analysis of carboniferous dolomite in Huize Basin, Yunnan[J]. Acta Sedimentologica Sinica, 2014, 32（1）: 118 − 125. （in Chinese with English abstract）
[5] 袁世冲,李强,孙帮涛,等. 金属矿山深部开采突水致灾危险源辨识与危险性评价——以滇东北毛坪铅锌矿为例[J]. 工程地质学报,2023,31(5):1668 − 1679. [YUAN Shichong,LI Qiang,SUN Bangtao,et al. Hazard identification and risk assessment of water inrush in deep mining of metal mines:A case study of Maoping lead-zinc mine in Northeast Yunnan,China[J]. Journal of Engineering Geology,2023,31(5):1668 − 1679. (in Chinese with English abstract)]
YUAN Shichong, LI Qiang, SUN Bangtao, et al. Hazard identification and risk assessment of water inrush in deep mining of metal mines: A case study of Maoping lead-zinc mine in Northeast Yunnan, China[J]. Journal of Engineering Geology, 2023, 31（5）: 1668 − 1679. （in Chinese with English abstract）
[6] 李博,韦韬,刘子捷. 西南地区煤层顶板岩溶含水层富水性评价指标体系构建及突水危险性评价[J]. 煤炭学报,2022,47(增刊1):152 − 159. [LI Bo,WEI Tao,LIU Zijie. Construction of evaluation index system for water abundance of karst aquifers and risk assessment of water inrush on coal seam roof in Southwest China[J]. Journal of China Coal Society,2022,47(Sup1):152 − 159. (in Chinese with English abstract)]
LI Bo, WEI Tao, LIU Zijie. Construction of evaluation index system for water abundance of karst aquifers and risk assessment of water inrush on coal seam roof in Southwest China[J]. Journal of China Coal Society, 2022, 47（Sup1）: 152 − 159. （in Chinese with English abstract）
[7] 曹贤发,李海玲. 中国典型岩溶发育区域划分[J]. 地球科学前沿,2018,8(4):845 − 851. [CAO Xianfa,LI Hailing. Typical zone division of karst development in China[J]. Advances in Geosciences,2018,8(4):845 − 851. (in Chinese with English abstract)] doi: 10.12677/AG.2018.84092
CAO Xianfa, LI Hailing. Typical zone division of karst development in China[J]. Advances in Geosciences, 2018, 8（4）: 845 − 851. （in Chinese with English abstract） doi: 10.12677/AG.2018.84092
[8] 袁世冲,李强,杭远,等. 深部矿山高承压应急防水闸门设计计算与数值模拟研究——以滇东北毛坪铅锌矿为例[J]. 工程地质学报,2024,32(2):632 − 644. [YUAN Shichong,LI Qiang,HANG Yuan,et al. Design calculation and numerical simulation investigation of high pressure emergency water retention bulk-head in deep mines:A case study of Maoping lead-zinc mine in Northeast Yunnan,China[J]. Journal of Engineering Geology,2024,32(2):632 − 644. (in Chinese with English abstract)]
YUAN Shichong, LI Qiang, HANG Yuan, et al. Design calculation and numerical simulation investigation of high pressure emergency water retention bulk-head in deep mines: A case study of Maoping lead-zinc mine in Northeast Yunnan, China[J]. Journal of Engineering Geology, 2024, 32（2）: 632 − 644. （in Chinese with English abstract）
[9] 隋旺华. 基于结构水文地质学的采掘诱发高势能突水溃砂主动防控[J]. 工程地质学报,2022,30(1):101 − 109. [SUI Wanghua. Active prevention and control of water-sand mixture inrush with high potential energy due to mining based on structural hydrogeology[J]. Journal of Engineering Geology,2022,30(1):101 − 109. (in Chinese with English abstract)]
SUI Wanghua. Active prevention and control of water-sand mixture inrush with high potential energy due to mining based on structural hydrogeology[J]. Journal of Engineering Geology, 2022, 30（1）: 101 − 109. （in Chinese with English abstract）
[10] 谢世平,徐磊,易伟功. 岩溶地区某尾矿库尾砂渗漏探查与治理[J]. 中国矿业,2024,33(5):101 − 108. [XIE Shiping,XU Lei,YI Weigong. Exploration and control of tailings leakage in a tailings reservoir in karst area[J]. China Mining Magazine,2024,33(5):101 − 108. (in Chinese with English abstract)] doi: 10.12075/j.issn.1004-4051.20230178
XIE Shiping, XU Lei, YI Weigong. Exploration and control of tailings leakage in a tailings reservoir in karst area[J]. China Mining Magazine, 2024, 33（5）: 101 − 108. （in Chinese with English abstract） doi: 10.12075/j.issn.1004-4051.20230178
[11] 武亚遵,于江浩,林云,等. 碳酸盐岩裂隙溶蚀扩展试验与模拟研究[J]. 水文地质工程地质,2024,51(1):41 − 46. [WU Yazun,YU Jianghao,LIN Yun,et al. Experiment and simulation study on dissolution widening of carbonate rock fracture[J]. Hydrogeology & Engineering Geology,2024,51(1):41 − 46. (in Chinese with English abstract)]
WU Yazun, YU Jianghao, LIN Yun, et al. Experiment and simulation study on dissolution widening of carbonate rock fracture[J]. Hydrogeology & Engineering Geology, 2024, 51（1）: 41 − 46. （in Chinese with English abstract）
[12] 国家市场监督管理总局,国家标准化管理委员会. 矿区水文地质工程地质勘查规范:GB/T 12719—2021[S]. 北京:中国标准出版社,2021. [State Administration for Market Regulation,Standardization Administration of the People’s Republic of China. Exploration specification of hydrogeology and engineering geology in mining areas:GB/T 12719—2021[S]. Beijing:Standards Press of China,2021. (in Chinese)]
State Administration for Market Regulation, Standardization Administration of the People’s Republic of China. Exploration specification of hydrogeology and engineering geology in mining areas: GB/T 12719—2021[S]. Beijing: Standards Press of China, 2021. （in Chinese）
[13] 李鑫,孙亚军,徐智敏,等. 矿山采动突水危险源划分与致灾危险性评价研究[J]. 煤炭工程,2023,55(9):108 − 115. [LI Xin,SUN Yajun,XU Zhimin,et al. Water sources classification and inrush hazard assessment approach in coal mining[J]. Coal Engineering,2023,55(9):108 − 115. (in Chinese with English abstract)]
LI Xin, SUN Yajun, XU Zhimin, et al. Water sources classification and inrush hazard assessment approach in coal mining[J]. Coal Engineering, 2023, 55（9）: 108 − 115. （in Chinese with English abstract）
[14] 郭小铭,王皓,周麟晟. 煤层顶板巨厚基岩含水层空间富水性评价[J]. 煤炭科学技术,2021,49(9):167 − 175. [GUO Xiaoming,WANG Hao,ZHOU Linsheng. Evaluation of spatial water enrichment of ultra-thick bedrock aquifer in coal seam roof[J]. Coal Science and Technology,2021,49(9):167 − 175. (in Chinese with English abstract)]
GUO Xiaoming, WANG Hao, ZHOU Linsheng. Evaluation of spatial water enrichment of ultra-thick bedrock aquifer in coal seam roof[J]. Coal Science and Technology, 2021, 49（9）: 167 − 175. （in Chinese with English abstract）
[15] 吴铁卫. 宁正矿区洛河组含水层水文地质特征及防治对策[J]. 中国煤炭地质,2021,33(增刊1):65 − 68. [WU Tiewei. Luohe Formation aquifer hydrogeological features and control countermeasures in Ningzheng mining area[J]. Coal Geology of China,2021,33(Sup1):65 − 68. (in Chinese with English abstract)]
WU Tiewei. Luohe Formation aquifer hydrogeological features and control countermeasures in Ningzheng mining area[J]. Coal Geology of China, 2021, 33（Sup1）: 65 − 68. （in Chinese with English abstract）
[16] 周对对,龙良良,刘家鹏,等. 大佛寺井田洛河组含水层微观孔隙结构及富水性研究[J]. 中国煤炭,2023,49(9):43 − 50. [ZHOU Duidui,LONG Liangliang,LIU Jiapeng,et al. Study on the micro-pore structure and water abundance of the Luohe Formation aquifer in Dafosi mine field[J]. China Coal,2023,49(9):43 − 50. (in Chinese with English abstract)]
ZHOU Duidui, LONG Liangliang, LIU Jiapeng, et al. Study on the micro-pore structure and water abundance of the Luohe Formation aquifer in Dafosi mine field[J]. China Coal, 2023, 49（9）: 43 − 50. （in Chinese with English abstract）
[17] 庞春燕. 金鸡滩煤矿基岩风化带含水层富水性评价[D]. 徐州:中国矿业大学,2023. [PANG Chunyan. Evaluation on the water abundance of aquifer in weathered zone of basement of Jinjitan coal mine[D]. Xuzhou:China University of Mining and Technology,2023. (in Chinese with English abstract)]
PANG Chunyan. Evaluation on the water abundance of aquifer in weathered zone of basement of Jinjitan coal mine[D]. Xuzhou: China University of Mining and Technology, 2023. （in Chinese with English abstract）
[18] 方楚婧,杨泽元,范立民,等. 神府南区直罗组含水层富水性研究[J]. 灾害学,2022,37(3):219 − 226. [FANG Chujing,YANG Zeyuan,FAN Limin,et al. Water yield property of Zhiluo formation aquifer in the Southern Shenmu-Fugu mine area[J]. Journal of Catastrophology,2022,37(3):219 − 226. (in Chinese with English abstract)] doi: 10.3969/j.issn.1000-811X.2022.03.035
FANG Chujing, YANG Zeyuan, FAN Limin, et al. Water yield property of Zhiluo formation aquifer in the Southern Shenmu-Fugu mine area[J]. Journal of Catastrophology, 2022, 37（3）: 219 − 226. （in Chinese with English abstract） doi: 10.3969/j.issn.1000-811X.2022.03.035
[19] YUAN Shichong,SUN Bangtao,HAN Guilei,et al. Application and prospect of curtain grouting technology in mine water safety management in China:A review[J]. Water,2022,14(24):4093. doi: 10.3390/w14244093
[20] 高利军,王海,韩强. 柠条塔煤矿采煤围岩渗透性变化规律及工作面涌水量预测[J]. 中国矿业,2024,33(6):183 − 193. [GAO Lijun,WANG Hai,HAN Qiang. Permeability changing laws of surrounding rock under the influence of coal mining and prediction of water yield of working face in Ningtiaota Coal Mine[J]. China Mining Magazine,2024,33(6):183 − 193. (in Chinese with English abstract)] doi: 10.12075/j.issn.1004-4051.20230927
GAO Lijun, WANG Hai, HAN Qiang. Permeability changing laws of surrounding rock under the influence of coal mining and prediction of water yield of working face in Ningtiaota Coal Mine[J]. China Mining Magazine, 2024, 33（6）: 183 − 193. （in Chinese with English abstract） doi: 10.12075/j.issn.1004-4051.20230927
[21] 武强,樊振丽,刘守强,等. 基于GIS的信息融合型含水层富水性评价方法——富水性指数法[J]. 煤炭学报,2011,36(7):1124 − 1128. [WU Qiang,FAN Zhenli,LIU Shouqiang,et al. Water-richness evaluation method of water-filled aquifer based on the principle of information fusion with GIS:Water-richness index method[J]. Journal of China Coal Society,2011,36(7):1124 − 1128. (in Chinese with English abstract)]
WU Qiang, FAN Zhenli, LIU Shouqiang, et al. Water-richness evaluation method of water-filled aquifer based on the principle of information fusion with GIS: Water-richness index method[J]. Journal of China Coal Society, 2011, 36（7）: 1124 − 1128. （in Chinese with English abstract）
[22] 李盼盼,侯恩科,姬亚东. 基于标准差修正主观权重的洛河组含水层富水性评价[J]. 能源与环保,2023,45(10):25 − 31. [LI Panpan,HOU Enke,JI Yadong. Water-rich evaluation of Luohe Formation aquifer based on standard deviation modified subjective weight[J]. China Energy and Environmental Protection,2023,45(10):25 − 31. (in Chinese with English abstract)]
LI Panpan, HOU Enke, JI Yadong. Water-rich evaluation of Luohe Formation aquifer based on standard deviation modified subjective weight[J]. China Energy and Environmental Protection, 2023, 45（10）: 25 − 31. （in Chinese with English abstract）
[23] 李超峰. 基于导水系数的含水层富水性评价方法[J]. 地下水,2023,45(5):15 − 17. [LI Chaofeng. Evaluation method of water-rich of aquifers based on transmissivity[J]. Ground Water,2023,45(5):15 − 17. (in Chinese with English abstract)]
LI Chaofeng. Evaluation method of water-rich of aquifers based on transmissivity[J]. Ground Water, 2023, 45（5）: 15 − 17. （in Chinese with English abstract）
[24] 薛森,李文平,郭启琛,等. 基于FAHP-GRA评价方法的顶板承压含水层富水性预测研究[J]. 金属矿山,2018(4):168 − 172. [XUE Sen,LI Wenping,GUO Qichen,et al. Prediction of water abundance of the roof confined aquifer strata based on FAHP-GRA evaluation method[J]. Metal Mine,2018(4):168 − 172. (in Chinese with English abstract)]
XUE Sen, LI Wenping, GUO Qichen, et al. Prediction of water abundance of the roof confined aquifer strata based on FAHP-GRA evaluation method[J]. Metal Mine, 2018（4）: 168 − 172. （in Chinese with English abstract）
[25] 葛如涛,陈陆望,王迎新,等. 基于改进AHP法和CRITIC法耦合赋权的松散承压含水层富水性评价[J]. 合肥工业大学学报(自然科学版),2023,46(4):519 − 528. [GE Rutao,CHEN Luwang,WANG Yingxin,et al. Water abundance assessment on unconsolidated confined aquifer based on the coupling of improved AHP and CRITIC[J]. Journal of Hefei University of Technology(Natural Science),2023,46(4):519 − 528. (in Chinese with English abstract)] doi: 10.3969/j.issn.1003-5060.2023.04.014
GE Rutao, CHEN Luwang, WANG Yingxin, et al. Water abundance assessment on unconsolidated confined aquifer based on the coupling of improved AHP and CRITIC[J]. Journal of Hefei University of Technology（Natural Science）, 2023, 46（4）: 519 − 528. （in Chinese with English abstract） doi: 10.3969/j.issn.1003-5060.2023.04.014
[26] LI Qiang,SUI Wanghua,SUN Bangtao,et al. Application of TOPSIS water abundance comprehensive evaluation method for karst aquifers in a lead zinc mine,China[J]. Earth Science Informatics,2022,15(1):397 − 411. doi: 10.1007/s12145-021-00730-2
[27] 白阳,牛超,李钒,等. 基于FAHP-变异系数法的风化基岩含水层富水性评价[J]. 煤矿安全,2023,54(8):143 − 149. [BAI Yang,NIU Chao,LI Fan,et al. Water abundance evaluation of weathered bedrock aquifers based on FAHP and coefficient of variance method[J]. Safety in Coal Mines,2023,54(8):143 − 149. (in Chinese with English abstract)]
BAI Yang, NIU Chao, LI Fan, et al. Water abundance evaluation of weathered bedrock aquifers based on FAHP and coefficient of variance method[J]. Safety in Coal Mines, 2023, 54（8）: 143 − 149. （in Chinese with English abstract）
[28] 孙帮涛. 滇东北岩溶大水深部矿山突水危险性评价研究[J]. 中国矿业,2023,32(增刊1):440 − 446. [SUN Bangtao. Study on the risk assessment of water inrush of karst deep mines in Northeast Yunnan,China[J]. China Mining Magazine,2023,32(Sup1):440 − 446. (in Chinese with English abstract)] doi: 10.12075/j.issn.1004-4051.20230338
SUN Bangtao. Study on the risk assessment of water inrush of karst deep mines in Northeast Yunnan, China[J]. China Mining Magazine, 2023, 32（Sup1）: 440 − 446. （in Chinese with English abstract） doi: 10.12075/j.issn.1004-4051.20230338
[29] 黄荷,陈植华,王涛,等. 岩溶矿区水文地球化学特征及其水源指示意义[J]. 水文地质工程地质,2019,46(1):19 − 26. [HUANG He,CHEN Zhihua,WANG Tao,et al. Groundwater source identification incarbonate-hosted deposit using hydrogeochemistry,hydrogen and oxygen isotope method[J]. Hydrogeology & Engineering Geology,2019,46(1):19 − 26. (in Chinese with English abstract)]
HUANG He, CHEN Zhihua, WANG Tao, et al. Groundwater source identification incarbonate-hosted deposit using hydrogeochemistry, hydrogen and oxygen isotope method[J]. Hydrogeology & Engineering Geology, 2019, 46（1）: 19 − 26. （in Chinese with English abstract）
[30] 袁世冲,张改玲,孙帮涛,等. 基于光纤与微震监测系统的注浆帷幕“浆-岩”组合体采动效应研究——以滇东北毛坪铅锌矿为例[J]. 中国矿业大学学报,2024,53(5):1022 − 1036. [YUAN Shichong,ZHANG Gailing,SUN Bangtao,et al. Mining effects of grouted-rock composite of grout curtains based on optical fiber and microseismic monitoring systems:A case study of the Maoping lead-zinc mine in Northeast Yunnan,China[J]. Journal of China University of Mining & Technology,2024,53(5):1022 − 1036. (in Chinese with English abstract)]
YUAN Shichong, ZHANG Gailing, SUN Bangtao, et al. Mining effects of grouted-rock composite of grout curtains based on optical fiber and microseismic monitoring systems: A case study of the Maoping lead-zinc mine in Northeast Yunnan, China[J]. Journal of China University of Mining & Technology, 2024, 53（5）: 1022 − 1036. （in Chinese with English abstract）
[31] 李加州,马俊杰. 基于AHP-TOPSIS模型的某矿采场结构参数优选[J]. 金属矿山,2023(8):189 − 195. [LI Jiazhou,MA Junjie. Optimization of stope structure parameters based on AHP-TOPSIS model of a mine[J]. Metal Mine,2023(8):189 − 195. (in Chinese with English abstract)]
LI Jiazhou, MA Junjie. Optimization of stope structure parameters based on AHP-TOPSIS model of a mine[J]. Metal Mine, 2023（8）: 189 − 195. （in Chinese with English abstract）
[32] 程香港,何昭宇,刘梦楠,等. 淮北古近系“红层”工程地质特性及不良地质分区研究[J]. 工程地质学报,2023,31(1):228 − 239. [CHENG Xianggang,HE Zhaoyu,LIU Mengnan,et al. Study on engineering geological characteristics and unfavorable geology subarea of Huaibei Paleogene red-bed[J]. Journal of Engineering Geology,2023,31(1):228 − 239. (in Chinese with English abstract)]
CHENG Xianggang, HE Zhaoyu, LIU Mengnan, et al. Study on engineering geological characteristics and unfavorable geology subarea of Huaibei Paleogene red-bed[J]. Journal of Engineering Geology, 2023, 31（1）: 228 − 239. （in Chinese with English abstract）
[33] LIU Jiawei,YANG Binbin,YUAN Shichong,et al. A fuzzy analytical process to assess the risk of disaster when backfill mining under aquifers and buildings[J]. Mine Water and the Environment,2021,40(4):891 − 901. doi: 10.1007/s10230-021-00822-x
[34] YUAN Shichong,HAN Guilei,LIU Dajin,et al. Multicriteria risk assessment of water inrush in underground mines with large-scale curtain grouting:A mine disaster risk reduction strategy[J]. Geomatics,Natural Hazards and Risk,2024,15(1):2409200. doi: 10.1080/19475705.2024.2409200
[35] 向俊兴,李东立,杨红军. 深孔模袋注浆技术在地下矿井突水治理中的应用[J]. 建井技术,2023,44(4):41 − 46. [XIANG Junxing,LI Dongli,YANG Hongjun. Application of deep hole mold bag grouting technology in water inrush control in underground mine[J]. Mine Construction Technology,2023,44(4):41 − 46. (in Chinese with English abstract)]
XIANG Junxing, LI Dongli, YANG Hongjun. Application of deep hole mold bag grouting technology in water inrush control in underground mine[J]. Mine Construction Technology, 2023, 44（4）: 41 − 46. （in Chinese with English abstract）
[36] 韩贵雷,李维欣,贾玉琴. 金属矿山地下水防治与协同保护技术研究[J]. 矿产勘查,2024,15(8):1508 − 1516. [HAN Guilei,LI Weixin,JIA Yuqin. Research on groundwater control and collaborative protection technology in metal mines[J]. Mineral Exploration,2024,15(8):1508 − 1516. (in Chinese with English abstract)]
HAN Guilei, LI Weixin, JIA Yuqin. Research on groundwater control and collaborative protection technology in metal mines[J]. Mineral Exploration, 2024, 15（8）: 1508 − 1516. （in Chinese with English abstract）
[37] 张改玲. 裂隙注浆偏流机理及帷幕体采动效应研究综述与展望[J]. 工程地质学报,2022,30(3):987 − 997. [ZHANG Gailing. Mechanism of deflection propagation for grouting in fractured rock mass with flowing water and mining effect on grouted curtain:A review[J]. Journal of Engineering Geology,2022,30(3):987 − 997. (in Chinese with English abstract)]
ZHANG Gailing. Mechanism of deflection propagation for grouting in fractured rock mass with flowing water and mining effect on grouted curtain: A review[J]. Journal of Engineering Geology, 2022, 30（3）: 987 − 997. （in Chinese with English abstract）
[38] 袁世冲. 深部矿山裂隙岩体帷幕注浆浆液扩散机理及“浆-岩”组合体采动效应研究[D]. 徐州:中国矿业大学,2023. [YUAN Shichong. Investigation on the grout propagation mechanism of curtain grouting in fractured rock mass in deep mines and mining influence on the grout-rock composite[D]. Xuzhou:China University of Mining and Technology,2023. (in Chinese with English abstract)]
YUAN Shichong. Investigation on the grout propagation mechanism of curtain grouting in fractured rock mass in deep mines and mining influence on the grout-rock composite[D]. Xuzhou: China University of Mining and Technology, 2023. （in Chinese with English abstract）
-
