Analysis of the rainfall threshold for post-fire debris flow initiation: A case study of the debris flow at Ren’eyong gully in Xiangcheng County, Sichuan Province
-
摘要:
2014年6月1日，中国西南中横断山区仁额拥沟遭受了一次森林大火，火后的短时低雨强降雨在3#支沟内激发了3次泥石流；2015年8月的一次强降雨在仁额拥沟的1#、2#和3#支沟及其他附近的多个更小的流域内均激发了泥石流。为了解火后泥石流的降雨响应特征，文章采用距离修正的方式处理降雨数据，对4次泥石流进行降雨过程分析，查明了流域特征对泥石流启动的作用及其对各支沟泥石流不同降雨阈值的影响。研究发现：（1）泥石流降雨阈值在火后非常低且有随时间推移而增大的趋势；（2）仁额拥沟火后泥石流具有高频率特征，其原因除了在火后天然植被的破坏后降雨对坡面径流和侵蚀效应的放大，流域本身的性质也有极大的贡献；（3）各支沟内泥石流降雨阈值差异的主要原因在于流域面积的差异，泥石流侵蚀受制于径流量大小。
Abstract:In the early summer of 2014, a wildfire ravaged the Ren’eyong valley in the central Mt. Hengduan region of southwestern China. Following the blaze, debris flows were triggered three times in branch No. 3 due to short-term, low intensity rainfall. A year later, in August 2015, a brief period of high-intensity rainfall generated debris flows not only in branch No.3, but also in branch No. 1 and No. 2, as well as several smaller basins in the vicinity. To investigate the rainfall response characteristics of post-wildfire debris flow, the distance correction method was used to process the rainfall data. By analyzing the rainfall patterns of four debris flow events, the reseachers were able to identify the effects of watershed characteristics on the initiation of debris flow and its influence on different rainfall thresholds in each branch. The study found that: 1） Post fire debris flows can occur at a low rainfall threshold, which tends to increase over time. 2） The Ren’eyong valley experience high-frequency post fire debris flows, which can be attributed not only to the amplification of slope runoff and erosion caused by rainfall after the destruction of natural vegetation due to the wildfire, but also to the geological and geomorphic conditions of the area. 3） The rainfall threshold in each branch is primarily dependent on the drainage area, as the magnitude of discharge controls the entrainment.
-
-
表 1 1#—3#支沟基本信息
Table 1. Geographic information of branches No.1−No.3
编号 流域面积/km2 沟长/m 平均坡度/（°） 1# 0.37 544 27 2# 0.73 755 26 3# 2.30 836 15
下载: 导出CSV
表 2 1#—3#支沟火烧强烈程度及面积统计
Table 2. Summary of fire severity classification and affected areas of branches No.1−No.3
编号 火烧面积/km2 轻度火烧/km2 中度火烧/km2 1#支沟 0.31 0.21 0.10 2#支沟 0.64 0.45 0.19 3#支沟 2.11 0.6 1.51
下载: 导出CSV
表 3 泥石流基本情况
Table 3. Basic property information of the debris flows
序号 时刻 位置 冲出量
/（104 m3）前期3 d
降雨量/mmDF1 2014年6月8日16:08 3# 0.8 1.11 DF2 2014年6月30日16:00 3# 1.4 14.84 DF3 2014年7月10日23:20 3# 0.5 0.81 DF4 2015年8月24日19:43 1#、2#、3# 2.2 39.97
下载: 导出CSV
表 4 3处雨量站基本情况
Table 4. Summary of the basic property information of the three rain gauges
序号 气象站名 海拔/m 距泥石流沟
距离/km精度/mm
1 正斗站 2858 4.10 0.1 0.577 2 热打站 3363 5.56 0.1 0.313 3 阿都站 2783 9.40 0.1 0.110
下载: 导出CSV
-
[1] LARSEN I J,MACDONALD L H,BROWN E,et al. Causes of post-fire runoff and erosion:Water repellency,cover,or soil sealing?[J]. Soil Science Society of America Journal,2009,73(4):1393 − 1407. doi: 10.2136/sssaj2007.0432
[2] SCOTT,W WOODS,VICTORIA N,et al. The effects of soil texture and ash thickness on the post-fire hydrological response from ash-covered soils[J]. Journal of Hydrology,2010,393(3-4):274 − 286. doi: 10.1016/j.jhydrol.2010.08.025
[3] MACDONALD L H,HUFFMAN E L. Post-fire soil water repellency[J]. Soil Science Society of America Journal,2004,68(5):1729 − 1734. doi: 10.2136/sssaj2004.1729
[4] NYMAN P,SHERIDAN G,LANE P N J. Synergistic effects of water repellency and macropore flow on the hydraulic conductivity of a burned forest soil,south-east Australia[J]. Hydrological Processes,2010,24(20):2871 − 2887. doi: 10.1002/hyp.7701
[5] MOODY J A,EBEL B A,NYMAN P,et al. Relations between soil hydraulic properties and burn severity[J]. International Journal of Wildland Fire,2016,25(3):279. doi: 10.1071/WF14062
[6] MOODY J A,EBEL B A. Hyper-dry conditions provide new insights into the cause of extreme floods after wildfire[J]. CATENA,2012,93(93):58 − 63.
[7] KEAN J W,STALEY D M,CANNON S H. In situ measurements of post-fire debris flows in southern California:comparisons of the timing and magnitude of 24 debris-flow events with rainfall and soil moisture conditions[J]. Journal of Geophysical Research,2011,116(F4):F04019.
[8] SMITH H G,SHERIDAN G J,LANE P N J,et al. Paired Eucalyptus forest catchment study of prescribed fire effects on suspended sediment and nutrient exports in south-eastern Australia[J]. International Journal of Wildland Fire,2010,19(5):624. doi: 10.1071/WF08208
[9] JORDAN P. Post-wildfire debris flows in southern British Columbia,Canada[J]. International Journal of Wildland Fire,2016,25(3):322. doi: 10.1071/WF14070
[10] CONEDERA M,PETER L,MARXER P,et al. Consequences of forest fires on the hydrogeological response of mountain catchments:a case study of the Riale Buffaga,Ticino,Switzerland[J]. Earth Surface Processes and Landforms,2003,28(2):117 − 129. doi: 10.1002/esp.425
[11] 胡卸文,王严,杨瀛. 火后泥石流成灾特点及研究现状[J]. 工程地质学报,2018,26(6):1562 − 1573. [HU Xiewen,WANG Yan,YANG Ying. Research actuality and evolution mechanism of post-fire debris flow[J]. Journal of Engineering Geology,2018,26(6):1562 − 1573. (in Chinese with English abstract) doi: 10.13544/j.cnki.jeg.2018-073
HU Xiewen, WANG Yan, YANG Ying. Research actuality and evolution mechanism of post-fire debris flow[J]. Journal of Engineering Geology, 2018, 26（6）1562-1573（in Chinese with English abstract） doi: 10.13544/j.cnki.jeg.2018-073
[12] 王严,胡卸文,杨瀛,等. 火烧迹地土壤斥水性和渗透性变化特性[J]. 水文地质工程地质,2019,46(6):40 − 45. [WANG Yan,HU Xiewen,YANG Ying,et al. Research on the change in soil water repellency and permeability in burned areas[J]. Hydrogeology & Engineering Geology,2019,46(6):40 − 45. (in Chinese with English abstract) doi: 10.16030/j.cnki.issn.1000-3665.2019.06.06
WANG Yan, HU Xiewen, YANG Ying, et al. Research on the change in soil water repellency and permeability in burned areas[J]. Hydrogeology & Engineering Geology, 2019, 46（6）40-45（in Chinese with English abstract） doi: 10.16030/j.cnki.issn.1000-3665.2019.06.06
[13] 任云,胡卸文,王严,等. 四川省九龙县色脚沟火后泥石流成灾机理[J]. 水文地质工程地质,2018,45(6):150 − 156. [REN Yun,HU Xiewen,WANG Yan,et al. Disaster mechanism of the Sejiao post-fire debris flow in Jiulong County of Sichuan[J]. Hydrogeology & Engineering Geology,2018,45(6):150 − 156. (in Chinese with English abstract) doi: 10.16030/j.cnki.issn.1000-3665.2018.06.22
REN Yun, HU Xiewen, WANG Yan, et al. Disaster mechanism of the Sejiao post-fire debris flow in Jiulong County of Sichuan[J]. Hydrogeology and Engineering Geology, 2018, 45（6）150-156（in Chinese with English abstract） doi: 10.16030/j.cnki.issn.1000-3665.2018.06.22
[14] 黄健,胡卸文,金涛,等. 四川西昌 “3•30” 火烧区响水沟火后泥石流成灾机理[J]. 中国地质灾害与防治学报,2022,33(3):15 − 22. [HUANG Jian,HU Xiewen,JIN Tao,et al. Mechanism of the post-fire debris flow of the Xiangshui gully in “3•30” fire area of Xichang,Sichuan Province[J]. The Chinese Journal of Geological Hazard and Control,2022,33(3):15 − 22. (in Chinese with English abstract)
HUANG Jian, HU Xiewen, JIN Tao, et al. Mechanism of the post-fire debris flow of the Xiangshui gully in “3·30” fire area of Xichang, Sichuan Province[J]. The Chinese Journal of Geological Hazard and Control, 2022, 33（3）15-22（in Chinese with English abstract）
[15] 杨相斌,胡卸文,曹希超,等. 四川西昌电池厂沟火后泥石流成灾特征及防治措施分析[J]. 中国地质灾害与防治学报,2022,33(4):1 − 8. [YANG Xiangbin,HU Xiewen,CAO Xichao,et al. Analysis on disaster characteristics and prevention measures of the post-fire debris flow in Dianchichang gully,Xichang of Sichuan Province[J]. The Chinese Journal of Geological Hazard and Control,2022,33(4):1 − 8. (in Chinese with English abstract) doi: 10.16031/j.cnki.issn.1003-8035.202203039
YANG Xiangbin, HU Xiewen, CAO Xichao, et al. Analysis on disaster characteristics and prevention measures of the post-fire debris flow in Dianchichang gully, Xichang of Sichuan Province[J]. The Chinese Journal of Geological Hazard and Control, 2022, 33（4）1-8（in Chinese with English abstract） doi: 10.16031/j.cnki.issn.1003-8035.202203039
[16] CHEN J C,HUANG W S,JAN C D,et al. Recent changes in the number of rainfall events related to debris-flow occurrence in the Chenyulan Stream Watershed,Taiwan[J]. Natural Hazards and Earth System Science,2012,12(5):1539 − 1549. doi: 10.5194/nhess-12-1539-2012
[17] 刘世康,范宣梅,王文松,等. 降雨模式对震后泥石流起动模式影响的试验研究—以九寨天堂沟为例[J]. 地质科技通报,2022,41(6):278 − 286. [LIU Shikang,FAN Xuanmei,WANG Wensong,et al. Experimental study on the effect of rainfall patterns on the failure mode of debris flows after earthquakes:A case study of Tiantanggou, Jiuzhai[J]. Bulletin of Geological Science and Technology,2022,41(6):278 − 286. (in Chinese with English abstract)
[LIU Shikang, FAN Xuanmei, WANG Wensong, et al. Experimental study on the effect of rainfall patterns on the failure mode of debris flows after earthquakes: A case study of Tiantanggou, Jiuzhai[J]. Bulletin of Geological Science and Technology, 2022, 41(6): 278-286. (in Chinese with English abstract)
-
