EVALUATION OF A NEW DYNAMIC LASER PARTICLE SIZE &SHAPE ANALYZER AND COMPARISON WITH THE SIEVING AND LASER DIFFRACTION PARTICLE SIZE ANALYZER
-
摘要: 对140个海滩砂样筛取0.5Φ间隔的子样共455个,分别用QICPIC快速粒度粒形仪和HELOS激光粒度仪做对比测试。结果显示:与筛分法相比,QICPIC快速粒度粒形仪和HELOS激光粒度仪的中值粒径普遍偏粗、粒径值偏小0.25~0.5Φ,同时测量结果的粒径范围更宽;HELOS激光粒度仪较QICPIC快速粒度粒形仪对细颗粒和粗颗粒部分敏感;球形度与粒径大致呈负相关关系。HELOS激光粒度仪与QICPIC快速粒度粒形仪的结果存在显著的线性相关关系,一般情况下可用公式(H=1.020 4×Q+0.047 9)从QICPIC粒径转换出HELOS粒径。两种激光粒度仪(QICPIC快速粒度粒形仪和HELOS激光粒度仪)与筛分法的粒度分析结果差异的主要原因是测量原理不同和海滩砂的不规则形状。QICPIC快速粒度粒形仪和HELOS激光粒度仪之间的差异原因有测量原理的不同、取样的不可重复性以及分散系统不同。Abstract: 140 samples of beach sand collected in Hainan and Zhejiang Provinces were sieved for 0.5Φ interval and 455 sub-samples were obtained.These sub-samples are used to test QICPIC,a new dynamic laser particle size &shape analyzer.The results are compared with those by HELOS,a laser diffraction particle size analyzer.It is found that comparing to sieving method,the median particle size given by both QICPIC and HELOS are coarser,or about 0.25~0.5Φ finer in Phi-diameter.The ranges of particle size measured by QICPIC and HELOS are wider.The HELOS is more sensitive to both fine and coarse fractions than QICPIC.Sphericity and particle size shows an approximately negative correlation.There is a significant linear correlation between median particle size measured by HELOS and QICPIC.Therefore,a formula(H=1.020 4×Q+0.047 9)is suggested in this paper to transform the median particle size given by QICPIC into that of HELOS.The difference of the results between the laser particle size analyzers(QICPIC and HELOS)and sieving method is mainly from the difference in measuring principles,the non-repeatability of sampling and the dispersion.
-
Key words:
- particle size /
- sieving /
- laser particle size analyzer /
- sand
-
-
[1] McCAVE I N,Syvitski J P M.Principles and methods of geological particle size analysis[C]//In:Syvitski J P M (editor). Principles,methods and application of particle size analysis. Cambridge University Press,1991:3-21.
[2] 蔡廷禄,贾建军,汪亚平.河口海岸和近海沉积物的粒度资料同化技术[J].海洋地质与第四纪地质,2014,34(1):185-193.
[CAI Tinglu,JIA Jianjun,WANG Yaping.Techniques for particle size data standardization:an example from estuarine and coastal sediments[J].Marine Geology and Quaternary Geology,2014,34(1):185-193.]
[3] Syvitski J P M,Leblanc K W G,Asprey K W.Interlaboratory instrument calibration experiment[C]//In:Syvitski J P M, (editor).Principles,methods and application of particle size analysis. Cambridge University Press,New York,1991:174-193.
[4] McManus D A.A criticism of certain usage of the Phi-Notation[J].Journal of Sedimentary Petrology,1963,33(3):670-674.
[5] Folk R L,Ward W C.Brazos river bar:a study in the signification of grain size parameters[J].Journal of Sedimentary Petrology, 1957,27:3-27.
[6] McManus J.Grain size determination and interpretation[C]//In:Tucker M (editor).Techniques in Sedimentology.Backwell, Oxford,1988:63-85.
[7] 贾建军,高抒,薛允传.图解法与矩法沉积物粒度参数的对比[J].海洋与湖沼,2002,33(6):577-582.
[JIA Jianjun,GAO Shu,XUE Yuanchuan.Grain-size parameters derived from graphic and moment methods:A comparative study[J]. Oceanologia et Limnologia sinica,2002,33(6):621-626.]
[8] 和瑞莉,吉俊峰,王爱霞.激光法与筛分法泥沙颗粒测试浅析[J].中国粉体技术,2005,11(Z1):181-184.
[HE Ruili,JI Junfeng,WANG Aixia.Analysis of results between laser particle analyzer and sieving method in particle size distribution[J].China Powder Science and Technology,2005,11(Z1):181-184.]
[9] 高抒.海洋沉积动力学研究导引[M].南京:南京大学出版社, 2013.[Shu Gao.Research guide of marine sediment dynamics[M].Nanjing:Nanjing University Press,2013.]
[10] Gao S,Collins M.Net sediment transport patterns inferred from grain-size trends,based upon definition of "transport vectors"[J].Sedimentary Geology,1992a,81(3/4):47-60.
[11] 范北林,闵凤阳,黎礼刚,等.几种模型沙激光粒度仪测试结果与筛析-沉降法的比较[J].长江科学院院报,2009,26(12):6-9.
[FAN Beilin,MIN Fengyang,LI Ligang,et al.Comparison between grain sizes measured by laser diffract instrument and sieve pipette methods for several model sediment[J]. Journal of Yangtze River Scientific Research Institute,2009, 26(12):6-9.]
[12] 程鹏,高抒,李徐生.激光粒度仪测试结果及其与沉降法、筛析法的比较[J].沉积学报,2001,19(3):449-455.
[CHENG Peng,GAO Shu,LI Xusheng.Evaluation of a wide rang laser particle size analyses and comparison with Pipette and Sieving methods[J].Acta Sedimentologica Sinica,2001,19(3):449-455.]
[13] Jonasz M.Size,shape,composition and structure of microparticles from light scattering[C]//In:SyvitskiJ P M (editor). Principles,methods and application of particle size analysis. Cambridge University Press,NewYork,1991:143-162.]
-
