IODP349航次地热调查数据分析

张文涛; 许鹤华; 杨小秋

doi:10.16562/j.cnki.0256-1492.2018.02.016

IODP349航次地热调查数据分析

1.
中国科学院边缘海与大洋地质重点实验室, 中国科学院南海海洋研究所, 广州 510301

2.
中国科学院大学, 北京 100049

基金项目:
中国科学院战略性先导科技专项(A类)(XDA13010303)；国家自然科学基金(41376061，91428205)

详细信息

作者简介: 张文涛(1994—)，男，硕士生，主要从事地球动力学和数值模拟研究，E-mail：zhangwentao16@mails.ucas.ac.cn

通讯作者: 许鹤华(1965—)，男，副研究员，硕导，E-mail：xhhcn@scsio.ac.cn

中图分类号: P744

周立君编辑

收稿日期: 2017-05-06

修回日期: 2017-07-26

刊出日期: 2018-04-28

Geothermal data processing and analysis for IODP Expedition 349

1.
Key Laboratory of Ocean and Marginal Sea Geology, South China Sea Institute of Oceanology, Chinese Academy of Sciences, Guangzhou 510301, China

2.
University of Chinese Academy of Sciences, Beijing 100049, China

More Information

Corresponding author: XU Hehua, xhhcn@scsio.ac.cn

Received Date: 06 May 2017

Revised Date: 26 July 2017

Publish Date: 28 April 2018

摘要

摘要:
海底热流是研究大洋地壳和上地幔岩石圈热状态的重要参数。为了解南海深水区地热特征，利用IODP349航次地热调查资料进行数据处理，得到了4个站位浅层热导率数据和3个钻孔的海底热流数据。结果表明，浅层沉积物样品热导率变化范围为0.8~2.2 W/(m·K)，变化范围与沉积物成分有关，热导率随深度的增加有小幅增加的趋势与沉积物压实作用有关；U1431D、U1432C和U1433A三个钻孔热流值分别为24±8 mW/m²、105±3 mW/m²和89±2 mW/m²，后两个钻孔通过与前人实测数据进行对比，与前人结果相当，表明了结果的可靠性；U1431D发生地温梯度倒转和低热流异常可能是与钻孔处于水热循环的下降流附近有关。
- 海底热流 /
- IODP349 /
- 数据处理与分析 /
- 热导率 /
- 热流异常
Abstract:
The seafloor heat flow, as an effective parameter to the study of thermal state, is an important indicator of the oceanic crust or upper crustal lithosphere. To understand the geothermal distribution pattern of the deepwater areas of the South China Sea, the geothermal data of IODP Expedition 349 is processed and studied. We acquired shallow thermal conductivities at four sites and seafloor heat flow data at three sites. The results show that the thermal conductivity varies in a range of 0.8 ~ 2.2W/(m·K), which depends upon the composition of sediments. The thermal conductivity of the sediments increases slightly with depth, probably owing to the effect of sediment compaction. The heat flow of Hole U1431D, Hole U1432C and Hole U1433A is 24±8mW/m², 105±3mW/m² and 89±2mW/m² respectively, basically consistent with previous results and the data from the nearby area. It proves that our results are reliable. The reverse of geothermal gradient and the low heat flow at Site U1431 might be caused by a downwell limb of hydro-thermal circulation.
- seafloor heat flow /
- IODP349 /
- data processing and analysis /
- thermal conductivity /
- heat flow anomaly

HTML全文

图 1 IODP349航次站位和南海热流站位分布

Figure 1.

下载: 全尺寸图片幻灯片

图 2 APCT-3结构示意图

Figure 2.

下载: 全尺寸图片幻灯片

图 3 APCT-3测温曲线

Figure 3.

下载: 全尺寸图片幻灯片

图 4 TK04热导率测量仪(左)及VLQ探针和HLQ探针(右) (图片来源：http://www.te-ka.de/index.php/en/thermal-conductivity)

Figure 4.

下载: 全尺寸图片幻灯片

图 5 3个站位的沉积物温度与地温梯度曲线

Figure 5.

下载: 全尺寸图片幻灯片

图 6 4个站位浅层(深度小于120m)样品热导率随深度变化图像

Figure 6.

下载: 全尺寸图片幻灯片

表 1 标准针状探针(VLQ)和标准接触式探针(HLQ)的技术指标

Table 1. Specifications of standard needle probe(VLQ) and standard contact probe(HLQ)

名称	标准针状探针(VLQ)	标准接触式探针(HLQ)
测量方法	全空间/实验室	半空间/实验室
外形尺寸	长70mm，直径2mm	高30mm，直径88mm
测量范围	0.1~10 W/(m·K)	0.3~l0 W/(m·K)
精度	±2%	±2%
单次测量时间	80s	80s
最小测量样品	长75mm，直径30mm	高15mm，直径80mm

下载: 导出CSV

表 3 U1432C钻孔热流测量数据对比

Table 3. Comparing of heat flow results from Hole U1432C

	U1432C	中美合作中部剖面南段^*	1148A孔^[11]^**
地温梯度/(℃/km)	91.6	72~154(平均116)	83
浅层热导率/W/(m·K)	0.88~1.37	0.84~0.87	0.85~1.17
热流/(mW/m²)	105±3	61~163(平均98)	84±2
注：^比较时选取与U1432C钻孔邻近的剖面南段7A-9W号共31个数据^[10]。^*热流采用Bullard法计算，计算深度为120m。

下载: 导出CSV

表 2 IODP349航次钻孔热流数据

Table 2. Heat flow data from holes of IODP Expedition 349

站位	经度(E)	纬度(N)	水深/m	计算深度/mbsf	地温梯度/℃/km	平均热导率/W/(m·K)	热流/mW/m²
U1431D	117.00 °	15.38°	4240.46	60.2	44.8	1.06	24±8
U1432C	116.39°	18.35°	3829.04	60.2~117.2 100.5	-10.9 91.6	1.32 1.10	105±3
U1433A	115.05°	12.92°	4379.35	122.9	82.4	1.09	89±2

下载: 导出CSV

表 4 U1433A钻孔热流测量数据对比

Table 4. Comparison of heat flow results from Hole U1433A

	U1433A	中美合作西南海盆剖面中段^*
地温梯度/(℃/km)	82.4	—
浅层热导率/W/(m·K)	1.02~1.14	—
热流/mW·m^-2	89±2	70~109(平均89)
注：^*比较时选取与U1433A钻孔邻近的测站并舍去2个低异常值点共7个测站数据^[9]。

下载: 导出CSV
