摘要:
珠江口盆地神狐海域是天然气水合物钻探和试验开采的重点区域，大量钻探取心、测井与地震等综合分析表明不同站位水合物的饱和度、厚度与气源条件存在差异。本文利用天然气水合物调查及深水油气勘探所采集的测井和地震资料建立地质模型，利用PetroMod软件模拟地层的温度场、有机质成熟度、烃源岩生烃量、流体运移路径以及不同烃源岩影响下的水合物饱和度，结果表明：生物成因气分布在海底以下1 500 m范围内的有机质未成熟地层，而热成因气分布在深度超过2 300 m的成熟、过成熟地层。水合物稳定带内生烃量难以形成水合物，形成水合物气源主要来自于稳定带下方向上运移的生物与热成因气。模拟结果与测井结果对比分析表明，稳定带下部生物成因气能形成的水合物饱和度约为10%，在峡谷脊部的局部区域饱和度较高；相对高饱和度（＞40%）水合物形成与文昌组、恩平组的热成因气沿断裂、气烟囱等流体运移通道幕式释放密切相关，W19井形成较高饱和度水合物的甲烷气体中热成因气占比达80%，W17井热成因气占比为73%，而SH2井主要以生物成因为主，因此，不同站位甲烷气体来源占比不同。
Abstract:The Shenhu area is located in the Pearl River Mouth Basin. It is a critical testing area for gas hydrate drilling and pilot production. Comprehensive studies of core samples and logging and seismic data suggest that gas hydrate saturation, thickness of gas hydrate layer and gas source conditions are different from sites to sites. Based on the geological model established by integrating the well log and seismic data from both gas hydrate and deep-water oil and gas drilling sites, we simulated the temperature field, organic matter maturity, hydrocarbon generation of source rocks, fluid migration pathways and gas hydrate saturation related to different source rocks with the PetroMod software. The results suggest that biogenic gas is mainly distributed in the immature organic strata 1 500 m below the seafloor, while thermogenic gas is distributed in the matured and over matured deposits over a depth of 2 300 m. Gas hydrate cannot be formed by in-situ biogenic gas within the gas hydrate stability zone. Therefore, the gases, which may form gas hydrate are mainly the biogenic and thermogenic gases moving up from the deep strata. The comparison between the modeling results and the log-derived saturation data suggest that the simulated saturation is around 10% for biogenic gas to become gas hydrate in the lower part of stability zone, while the value is higher at some areas such as canyon ridges. Higher saturation (＞40%) for hydrate formation is closely related to deep source thermogenic gas from the Wenchang and Enping Formations released in an episodic manner along the fluid migration channels such as sand layers, faults and gas chimneys. In addition, the methane contents from biogenic and thermogenic gases are calculated based on the modeling gas hydrate saturation. It shows that the thermogenic gas content is about 80% at Site W19 and 73% at Site W17, and nearly no thermogenic gas is found at Site SH2.
-
Key words:
- numerical modeling /
- thermogenic gas /
- fluid migration /
- gas hydrate saturation /
- Shenhu area
-
-
表 1 模型中各地层岩性、TOC和HI等参数
Table 1. The parameters of lithology, TOC and HI of each stratum for the numerical modeling
地层 沉积相 岩性 TOC/% HI/ （mg/g TOC） 第四纪万山组 浅海相 20%泥岩、80%粉砂岩 1 [5] 150 半深海相 30%泥岩、70%粉砂岩 0.5 [5] 150 粤海组韩江组 半深海相 30%泥岩、70%粉砂岩 0.5 150 珠江组 半深海相 30%泥岩、70%粉砂岩 0.5 [39] 150[39] 珠海组 浅湖相 60%泥岩、40%粉砂岩 0.75[39] 180[39] 三角洲相 100%砂岩 边滩相 50%泥岩、50%砂岩 恩平组 深湖相 100%泥岩 1[23,39-40] 200[23,39-40] 辫状三角洲相 75%泥岩、25%粉砂岩 文昌组 深湖相 75%泥岩、25%粉砂岩 2[23, 39-40] 450[23, 39-40] 辫状三角洲相
