Study on coastline changes in the Rizhao area for the past 30 years and their bearing on land use
-
摘要:
海岸带地区是日照市旅游资源的主要汇集地，承担着日照经济文化发展的中心任务。本文选取1988、2000、2011、2018年4期的夏季Landsat影像，对日照海岸带地区岸线多样性指数和岸线变化速率进行分析，采用最大似然法对海岸带地区土地利用进行监督分类研究，探究日照海岸带近30年来土地利用演变。研究表明，日照市在1988—2018年间岸线长度显著增加，人工岸线年均增长率为2.35 km/a，而砂质岸线长度显著减少，年均减少率为0.56 km/a；总体上岸线以向海扩张为主，扩张最剧烈的地区为日照港和岚山港。日照东港区和岚山区耕地面积基本保持不变；建设用地面积大幅增加，林地面积大幅减少，而水体和未利用地总体面积保持稳定，人类的建设活动是驱动日照滨海地区岸线与土地利用现状演变的最主要因素。本研究结果可为日照海岸带可持续开发利用以及城市未来规划决策提供依据。
Abstract:The Rizhao coastal zone is a place rich in tourist resources, which play important roles in economic and cultural development of the Rizhao city. In this paper, four sets of summer Landsat images in the years of 1988, 2000, 2011 and 2018 are collected for visually interpretation, and the coastline of Rizhao coastal zone is classified according to the diversity index of coastline type and the change rate of the coastline. The maximum likelihood method is adopted to explore the changes in land use in the Rizhao coastal zone for the past 30 years. The results suggest that the length of Rizhao coastline is significantly increased from 1988 to 2018 at an artificial growth rate of about 2.35 km/a, while the length of sandy coastline, on the other side, is decreased at an average rate of 0.56 km/a. The coastline mainly moves toward the sea and most of the intensely expanded areas are closed to the Rizhao Port and Lanshan Port. The cultivated land area of Donggang District and Lanshan District, the overall area of water body and the unused land remain basically unchanged. The construction land is significantly increased in the past 30 years, while the forest land decreased drastically. Human construction activities are doubtlessly the main factor that influence the evolution of coastline and land utilization in Rizhao coastal area. The results of this study may be used to promote the sustainable development and rational utilization of Rizhao coastal zone in future urban planning and policy-making.
-
Key words:
- coastline /
- driving force /
- land evolution /
- Rizhao city
-
-
表 1 卫星数据列表
Table 1. The list of satellite data used
序号 成像日期 卫星 传感器 轨道号 地面分辨率/m 1 1988-10-09 Landsat5 TM P120r35 30 2 1988-10-09 Landsat5 TM P120r36 30 3 2000-09-16 Landsat7 ETM+ P120r35 30 4 2000-09-16 Landsat7 ETM+ P120r36 30 5 2011-10-07 Landsat7 ETM+ P120r35 30 6 2011-10-07 Landsat7 ETM+ P120r36 30 7 2018-10-12 Landsat8 OLI_TIRS P120r35 30 8 2018-10-12 Landsat8 OLI_TIRS P120r36 30
下载: 导出CSV
表 2 1988—2018年日照市岸线长度分类统计
Table 2. Length of Rizhao coastline from 1988 to 2018
km 1988年 2000年 2011年 2018年
自然岸线基岩岸线 1.79 1.92 1.67 1.74 砂质岸线 49.87 42.95 31.56 32.89 河口岸线 0.88 1.08 1.03 1.10 淤泥质岸线 4.37 4.87 4.88 4.67 小计 56.91 50.82 39.14 40.40
人工岸线养殖围堤岸线 18.45 28.37 19.26 16.47 港口码头岸线 10.67 19.47 45.10 81.15 建设围堤岸线 6.12 4.07 13.96 20.82 小计 35.23 51.91 78.31 118.44 总计 92.14 102.73 117.45 158.84 自然岸线拥有率/% 61.76 49.47 33.32 25.43
下载: 导出CSV
表 3 1988—2018年日照市岸线年平均变化速率
Table 3. Average annual change rate of Rizhao coastline from 1988 to 2018
km/a 1988—
2000年2000—
2011年2011—
2018年1988—
2018年自然岸线 基岩岸线 0.010 −0.023 0.010 −0.002 砂质岸线 −0.577 −1.035 0.190 −0.566 河口岸线 0.017 −0.005 0.010 0.007 淤泥质岸线 0.042 0.001 −0.030 0.010 人工
岸线养殖围堤岸线 0.827 −0.828 −0.398 −0.066 港口码头岸线 0.733 2.330 5.151 2.350 建设围堤岸线 −0.170 0.899 0.980 0.490 注：负值表示岸线后退或减少；正值表示岸线前进或增加。下同。
下载: 导出CSV
表 4 1988—2018年土地利用面积转移矩阵
Table 4. Conversion of the land use areas from 1988 to 2018
km2 1988年 2018年 耕地 建设用地 林地 水体 未利用地 总计 耕地 828.32 224.25 40.66 5.32 2.21 1100.75 建设用地 120.07 107.06 2.56 4.33 0.44 234.46 林地 140.41 104.21 180.55 5.10 0.31 430.57 水体 4.50 50.68 0.45 50.67 0.00 106.29 未利用地 18.48 1.50 1.43 0.30 0.01 21.71 总计 1111.77 487.69 225.64 65.71 2.96 1893.77 注：表中数字表示由一种土地利用类型向另一种土地利用类型转化的面积，同种土地利用类型间的数据表示未转化的面积。
下载: 导出CSV
表 5 日照市森林公园沙滩剖面和万平口沙滩剖面对台风的侵蚀响应结果
Table 5. Erosion response of beach transects to typhoon in Forest Park and Wanpingkou
时间 森林公园沙滩剖面 万平口沙滩剖面 北部 中部 南部 北部 中部 南部 侵蚀面积/m2 2018—2019 −32.80 +20.35 −14.53 −3.89 −5.71 −0.38 实测侵蚀长度/m 2018.8 −30 −37 −60 −40 −40 −10 2019.8 −83 +28 −10 −45 −35 −30 下切最大深度/m 2018.8 −0.45 −0.25 −0.4 −0.4 −1 −1 2019.8 −0.4 0 +0.1 −0.3 −0.7 −0.7 注：2018年8月为台风“温比亚”过境期， 2019年8月为台风“利奇马”过境期。正值代表淤积，负值代表侵蚀。
下载: 导出CSV
-
[1] 王琰, 田艳. 日照市海岸带保护与利用初探[J]. 海洋开发与管理, 2017, 34(S2):125-129
WANG Yan, TIAN Yan. Protection and utilization of Rizhao coastal zone under the background of ecological civilization [J]. Ocean Development and Management, 2017, 34(S2): 125-129.
[2] 毋亭. 近70年中国大陆岸线变化的时空特征分析[D]. 中国科学院烟台海岸带研究所博士学位论文, 2016.
WU Ting. Analysis of spatio-temporal characteristics of mainland coastline changes in China in nearly 70 years[D]. Doctor Dissertation of Yantai Institute of Coastal Zone Research, Chinese Academy of Sciences, 2016.
[3] 张云, 张建丽, 景昕蒂, 等. 1990年以来我国大陆海岸线变迁及分形维数研究[J]. 海洋环境科学, 2015, 34(3):406-410
ZHANG Yun, ZHANG Jianli, JING Xindi, et al. Historical changes of the length and fractal dimension of Chinese coastline since 1990 [J]. Marine Environmental Science, 2015, 34(3): 406-410.
[4] 孙伟红, 黄燕, 黄博. 江苏省海岸线时空变化特征研究[J]. 现代测绘, 2018, 41(4):32-35 doi: 10.3969/j.issn.1672-4097.2018.04.008
SUN Weihong, HUANG Yan, HUANG Bo. Study on spatial-temporal characteristics of Jiangsu coastline [J]. Modern Surveying and Mapping, 2018, 41(4): 32-35. doi: 10.3969/j.issn.1672-4097.2018.04.008
[5] 方成, 王小丹, 杨金霞, 等. 唐山市海岸线变化特征及环境影响效应分析[J]. 海洋通报, 2014, 33(4):419-427
FANG Cheng, WANG Xiaodan, YANG Jinhua, et al. Analysis of shoreline changes and environmental impact effects in Tangshan city [J]. Marine Science Bulletin, 2014, 33(4): 419-427.
[6] 许宁. 中国大陆海岸线及海岸工程时空变化研究[D]. 中国科学院烟台海岸带研究所博士学位论文, 2016.
XU Ning. Research on spatial and temporal variation of China mainland coastline and coastal engineering[D]. Doctor Dissertation of Yantai Insititute of Coastal Zone Research, Chinese Academy of Sciences, 2016.
[7] Cowart L, Corbett D R, Walsh J P. Shoreline change along sheltered coastlines: insights from the Neuse river estuary, NC, USA [J]. Remote Sensing, 2011, 3(7): 1516-1534. doi: 10.3390/rs3071516
[8] Crowell M, Leatherman S P, Buckley M K. Shoreline change rate analysis: long term versus short term data [J]. Shore and Beach, 1993, 61(2): 13-20.
[9] Douglas B C, Crowell M, Honeycutt M G. Discussion. Coastal storms and shoreline change: Signal or noise? [J]. Journal of Coastal Research, 2002, 18(2): 388-390.
[10] Goodchild M F, Hunter G J. A simple positional accuracy measure for linear features [J]. International Journal of Geographical Information Science, 1997, 11(3): 299-306. doi: 10.1080/136588197242419
[11] Li R X, Liu J K, Felus Y. Spatial modeling and analysis for shoreline change detection and coastal erosion monitoring [J]. Marine Geodesy, 2001, 24(1): 1-12. doi: 10.1080/01490410121502
[12] Anderson T R, Frazer L N. Toward parsimony in shoreline change prediction (III): B-splines and noise handling [J]. Journal of Coastal Research, 2014, 30(4): 729-742.
[13] 庄振业, 印萍, 吴建政, 等. 鲁南沙质海岸的侵蚀量及其影响因素[J]. 海洋地质与第四纪地质, 2000, 20(3):15-21
ZHUANG Zhenye, YIN Ping, WU Jianzheng, et al. Coastal erosion and its influence on southern Shandong sandy coast [J]. Marine Geology & Quaternary Geology, 2000, 20(3): 15-21.
[14] 吕京福, 印萍, 边淑华, 等. 海岸线变化速率计算方法及影响要素分析[J]. 海洋科学进展, 2003, 21(1):51-59 doi: 10.3969/j.issn.1671-6647.2003.01.006
LV Jingfu, YIN Ping, BIAN Shuhua, et al. Selection of methods for calculating shoreline change rate and analysis of affecting factor [J]. Advances in Marine Science, 2003, 21(1): 51-59. doi: 10.3969/j.issn.1671-6647.2003.01.006
[15] 李振函, 朱伟. 日照市海水入侵现状与治理方案[J]. 山东国土资源, 2009, 25(6):21-24 doi: 10.3969/j.issn.1672-6979.2009.06.008
LI Zhenhan, ZHU Wei. Study on disasters caused by sea water intrusion in Rizhao City and protection countermeasures [J]. Shandong Land and Resources, 2009, 25(6): 21-24. doi: 10.3969/j.issn.1672-6979.2009.06.008
[16] 乔庆伟, 许庆福, 张庆淑, 等. 日照市土地利用变化对生态环境的影响[J]. 山东国土资源, 2010, 26(7):30-32,35 doi: 10.3969/j.issn.1672-6979.2010.07.008
QIAO Qingwei, XU Qingfu, ZHANG Qingshu, et al. Effects of changing land use model to ecological environment in Rizhao city [J]. Shandong Land and Resources, 2010, 26(7): 30-32,35. doi: 10.3969/j.issn.1672-6979.2010.07.008
[17] 雷士芬, 张全景, 柳博会, 等. 基于主成分分析的日照市土地利用变化驱动力分析[J]. 上海国土资源, 2015, 36(2):46-50 doi: 10.3969/j.issn.2095-1329.2015.02.011
LEI Shifen, ZHANG Quanjing, LIU Bohui, et al. Principal component analysis of driving forces behind land-use change in Rizhao city of Shandong province [J]. Shanghai Land & Resources, 2015, 36(2): 46-50. doi: 10.3969/j.issn.2095-1329.2015.02.011
[18] 邓清海, 张丹丹, 张丽萍, 等. 日照市土地利用变化遥感监测及驱动力分析[J]. 水土保持研究, 2015, 22(2):184-188,192
DENG Qinghai, ZHANG Dandan, ZHANG Liping, et al. Remote sensing monitoring of land use change in Rizhao City and its driving force analysis [J]. Research of Soil and Water Conservation, 2015, 22(2): 184-188,192.
[19] 乔芳敏. 基于RS的日照市东港区土地利用动态监测及驱动力分析[D]. 曲阜师范大学硕士学位论文, 2016.
QIAO Fangmin. Dynamic monitoring and driving force analysis of land use in Donggang District of Rizhao City based on RS[D]. Master Dissertation of Qufu Normal University, 2016.
[20] 徐文阳, 谢小平, 陈芝聪, 等. 基于遥感影像的日照海岸带景观格局动态演化分析[J]. 曲阜师范大学学报:自然科学版, 2017, 43(3):93-99
XU Wenyang, XIE Xiaoping, CHEN Zhicong, et al. The analysis of dynamic evolution on coastal landscape patterns based on the satellite images in Rizhao City, Shandong Province [J]. Journal of Qufu Normal University:Natural Science, 2017, 43(3): 93-99.
[21] 孙慧. 基于GIS/RS的日照海岸带综合管理[D]. 曲阜师范大学硕士学位论文, 2015
SUN Hui. Integrated management of Rizhao coastal zone based on GIS/RS[D]. Master Dissertation of Qufu Normal University, 2015.
[22] 张萌. 日照市海岸带生态系统健康评价[D]. 曲阜师范大学硕士学位论文, 2015
Zhang Meng. Evaluation of coastal ecosystem health in Rizhao city[D]. Master Dissertation of Qufu Normal University, 2015.
[23] 赵春霞, 钱乐祥. 遥感影像监督分类与非监督分类的比较[J]. 河南大学学报:自然科学版, 2004, 34(3):90-93
ZHAO Chunxia, QIAN Lexiang. Comparative study of supervised and unsupervised classification in remote sensing image [J]. Journal of Henan University:Natural Science, 2004, 34(3): 90-93.
[24] 牛明香, 王俊. 基于Landsat遥感影像的黄河三角洲东营段海岸线变化分析[J]. 水资源保护, 2020, 36(4):26-33 doi: 10.3880/j.issn.1004-6933.2020.04.005
NIU Mingxiang, WANG Jun. Analysis of coastline variations in Dongying section of Yellow River Delta based on Landsat remote sensing image [J]. Water Resources Protection, 2020, 36(4): 26-33. doi: 10.3880/j.issn.1004-6933.2020.04.005
[25] 李广雪, 宫立新, 杨继超, 等. 山东滨海沙滩侵蚀状态与保护对策[J]. 海洋地质与第四纪地质, 2013, 33(5):35-46
LI Guangxue, GONG Lixin, YANG Jichao, et al. Beach erosion along the coast of Shandong Province and protection countermeasures [J]. Marine Geology & Quaternary Geology, 2013, 33(5): 35-46.
[26] 宫立新. 山东半岛东部海滩侵蚀现状与保护研究[D]. 中国海洋大学博士学位论文, 2014
GONG Lixin. Erosion situation and protection of beach in eastern part of Shandong Peninsula[D]. Doctor Dissertation of Ocean University of China, 2014.
[27] Ding D, Yang J C, Li G X, et al. A geomorphological response of beaches to Typhoon Meari in the eastern Shandong Peninsula in China [J]. Acta Oceanologica Sinica, 2015, 34(9): 126-135. doi: 10.1007/s13131-015-0644-5
-
