On temporal and spatial variations of coastal topography and sediment transport process in Sanya Bay
-
摘要:
海岸侵蚀作为全球性的地质灾害，往往给沿海地区带来巨大经济损失。受人类活动与气候变化的双重影响，近年来海岸侵蚀呈加剧态势；其中，砂质海岸的侵蚀尤为严重。本文通过开展多期海滩剖面地形监测，结合经验正交分解、数值模拟和沿岸输沙计算，摸清了三亚湾海岸地形的时空变化特征。研究结果显示，三亚湾海岸线侵蚀严重，年平均后退距离近2 m。岸线上4个岸段呈现出不同的海滩剖面形态与侵蚀淤积特征。其中，西段海岸由于供砂不足，侵蚀现象长期存在；地形主要受风暴浪控制，随着西岛码头东拦沙堤的建设，西一段由侵蚀转为淤积，西二段接受的沿岸输沙量也随之减少，侵蚀加剧。东部海滩为养护区，其中海月广场以西以侵蚀为主，以东以淤积为主；该段地形受季节性常浪和风暴浪共同作用。三亚湾沿岸输沙量自肖旗港至团结路逐渐降低，净输沙方向为自西向东；中段较长范围的海岸为堆积型海岸，但是其岸线表现为侵蚀后退，这是由于凸堤效应导致西侧沿岸供砂减少，同时该段横向输沙特征为离岸输沙。三亚湾的侵蚀主要发生在破波带内，除岛屿周边外，其他海域基本不冲不淤。该研究结果可为海岸侵蚀防护与治理提供科学依据。
Abstract:As a global natural disaster, coastal erosion brings huge losses to the coastal economy. Affected by the human activities and natural agents, coastal erosion is intensified, especially in sandy coast. By multi-stage beach terrain monitoring during 2016-2021, the temporal and spatial variations of the coastal topography in Sanya Bay, Hainan Island, were investigated via empirical orthogonal decomposition, numerical simulation, and coastal sediment transport calculation. Results show that the coastline of Sanya Bay was eroded obviously, and the average annual retreat distance reached nearly 2 m. The four coastline segments presents different beach erosion and siltation characteristics. In the western segment of the coast, erosion has long existed due to deficient sand supply, and the terrain is mainly controlled by storm waves. With the construction of the east sand barrier at the Xidao wharf, the erosion of the first segment in the west turned into siltation, and the amount of coastal sediment transport received by the second segment in the west also decreased, thereby erosion in this area was intensified. The eastern segment is a maintenance area. The western side of Haiyue Square was eroded, while the eastern side was silted. The topography of the eastern segment was affected by both seasonal waves and storm waves. The coastal sediment transport was gradually reduced from Xiaoqi Port to Tuanjie Road, and the net sediment transport was from west to east. Although the alongshore sediment transport type on the middle segment of the coast is accumulation type, monitoring showed that its coastline was receding due to the convex embankment effect, which decreased sand supply to the western coast and resulted in offshore sediment transport. Therefore, erosion took place in mainly the surf zone, and the outer area had largely no scouring nor silting except for near-island places. The results provide a scientific basis for coastal erosion protection and management.
-
-
表 1 三亚湾海滩剖面高程EOF分析结果统计
Table 1. Statistics of EOF analysis of beach profile elevation in Sanya Bay
主因子 特征值λ 贡献率/% 累计贡献率/% F1 F2 F1 F2 SYPM01 0.50 0.21 65.66 27.19 92.85 SYPM02 4.63 0.27 88.62 5.16 93.78
下载: 导出CSV
表 2 沿岸年输沙量
Table 2. Annual coastal sediment discharge
分段 岸线走向/(°) 输沙量 总输沙量 净输沙量 SE SSE S SSW SW WSW M1 −7.6 −0.93 −4.54 −1.62 7.89 33.71 6.13 54.82 40.64 M2 +1.0 −0.49 −1.99 0.28 7.05 25.88 4.82 40.52 35.55 M3 −1.8 −0.27 −1.76 −0.17 4.79 14.25 2.88 24.11 19.72 M4 −11.6 −0.09 −0.99 −0.85 1.81 10.51 2.62 16.88 13.01 M5 −22.9 −0.03 −0.72 −1.62 −0.37 7.25 2.10 12.10 6.60 M6 −34.3 −0.01 −0.32 −1.27 −1.76 2.32 1.94 7.61 0.90 M7 −42.1 0 −0.07 −0.52 −1.05 3.85 3.07 8.57 5.27 M8 −54.3 0 0.00 −0.06 −0.28 0.38 0.99 1.71 1.03 * 输沙量正值为自西向东，负值为自东向西；输沙量单位：104 m3/a。
下载: 导出CSV
-
[1] Rangel-Buitrago N, Williams A T, Anfuso G. Hard protection structures as a principal coastal erosion management strategy along the Caribbean coast of Colombia. A chronicle of pitfalls[J]. Ocean & Coastal Management, 2018, 156:58-75.
[2] 李平, 丰爱平, 孙惠凤, 等. 海岸侵蚀灾害调查和评价研究进展与展望[J]. 自然灾害学报, 2021, 30(4):55-63
LI Ping, FENG Aiping, SUN Huifeng, et al. Research progress and prospect of coastal erosion investigation and evaluation[J]. Journal of Natural Disasters, 2021, 30(4):55-63.]
[3] Becker M, Meyssignac B, Letetrel C, et al. Sea level variations at tropical Pacific islands since 1950[J]. Global and Planetary Change, 2012, 80-81:85-98. doi: 10.1016/j.gloplacha.2011.09.004
[4] Jevrejeva S, Moore J C, Grinsted A. Potential for bias in 21st century semiempirical sea level projections[J]. Journal of Geophysical Research: Atmospheres, 2012, 117(D20):D20116.
[5] Cooper J A G, Pilkey O H. Pitfalls of Shoreline Stabilization[M]. Dordrecht: Springer, 2012:347.
[6] Rangel-Buitrago N, Anfuso G. Winter wave climate, storms and regional cycles: the SW Spanish Atlantic coast[J]. International Journal of Climatology, 2013, 33(9):2142-2156. doi: 10.1002/joc.3579
[7] 王勇智, 田梓文, 李霞, 等. 海阳市典型砂质海岸侵蚀机制与防护对策研究[J]. 海洋科学, 2021, 45(12):18-30
WANG Yongzhi, TIAN Ziwen, LI Xia, et al. Coastal erosion mechanism and its prevention in Haiyang[J]. Marine Sciences, 2021, 45(12):18-30.]
[8] 李志强, 陈子燊. 海滩平衡剖面模型中参数意义及相互关系探讨[J]. 海洋工程, 2009, 27(4):108-115
LI Zhiqiang, CHEN Zishen. Analysis on the parameters’ meanings and relations in equilibrium beach profile models[J]. The Ocean Engineering, 2009, 27(4):108-115.]
[9] Aagaard T, Hughes M G. Equilibrium shoreface profiles: a sediment transport approach[J]. Marine Geology, 2017, 390:321-330. doi: 10.1016/j.margeo.2016.12.013
[10] Jara M S, González M, Medina R. Shoreline evolution model from a dynamic equilibrium beach profile[J]. Coastal Engineering, 2015, 99:1-14. doi: 10.1016/j.coastaleng.2015.02.006
[11] Lemos C, Floc’h F, Yates M, et al. Equilibrium modeling of the beach profile on a macrotidal embayed low tide terrace beach[J]. Ocean Dynamics, 2018, 68(9):1207-1220. doi: 10.1007/s10236-018-1185-1
[12] 蔡锋, 苏贤泽, 杨顺良, 等. 厦门岛海滩剖面对9914号台风大浪波动力的快速响应[J]. 海洋工程, 2002, 20(2):85-90 doi: 10.3969/j.issn.1005-9865.2002.02.016
CAI Feng, SU Xianze, YANG Shunliang, et al. A rapid response to 9914 typhoon-induced storm wave force made by the beach profiles of Xiamen Island[J]. The Ocean Engineering, 2002, 20(2):85-90.] doi: 10.3969/j.issn.1005-9865.2002.02.016
[13] 冯秀丽, 董卫卫, 庄振业, 等. 莱州湾东岸沿岸输沙率及冲淤演化动态分析[J]. 中国海洋大学学报, 2009, 39(2):304-308
FENG Xiuli, DONG Weiwei, ZHUANG Zhenye, et al. The calculation of alongshore silt discharge rates and evolution development in the Eastcoast of Laizhou Bay[J]. Periodical of Ocean University of China, 2009, 39(2):304-308.]
[14] 戴志军, 李春初, 王文介, 等. 华南弧形海岸的分形和稳定性研究[J]. 海洋学报, 2006, 28(1):176-180 doi: 10.3321/j.issn:0253-4193.2006.01.026
DAI Zhijun, LI Chunchu, WANG Wenjie, et al. Research on stability and fractal of arc-shaped coast in South China[J]. Acta Oceanologica Sinica, 2006, 28(1):176-180.] doi: 10.3321/j.issn:0253-4193.2006.01.026
[15] 许宁, 高志强, 宁吉才. 基于分形维数的环渤海地区海岸线变迁及成因分析[J]. 海洋学研究, 2016, 34(1):45-51 doi: 10.3969/j.issn.1001-909X.2016.01.006
XU Ning, GAO Zhiqiang, NING Jicai. Spatial-temporal variations of coastlines in Bohai Rim based on fractal dimension and their causes analysis[J]. Journal of Marine Sciences, 2016, 34(1):45-51.] doi: 10.3969/j.issn.1001-909X.2016.01.006
[16] Van Duin M J P, Wiersma N R, Walstra D J R, et al. Nourishing the shoreface: observations and hindcasting of the Egmond case, The Netherlands[J]. Coastal Engineering, 2004, 51(8-9):813-837. doi: 10.1016/j.coastaleng.2004.07.011
[17] Radermacher M, de Schipper M A, Price T D, et al. Behaviour of subtidal sandbars in response to nourishments[J]. Geomorphology, 2018, 313:1-12. doi: 10.1016/j.geomorph.2018.04.005
[18] Kroon A, Larson M, Möller I, et al. Statistical analysis of coastal morphological data sets over seasonal to decadal time scales[J]. Coastal Engineering, 2008, 55(7-8):581-600. doi: 10.1016/j.coastaleng.2007.11.006
[19] Winant C D, Inman D L, Nordstrom C E. Description of seasonal beach changes using empirical eigenfunctions[J]. Journal of Geophysical Research: Earth Surface, 1975, 80(15):1979-1986. doi: 10.1029/JC080i015p01979
[20] Aubrey D G. Seasonal patterns of onshore/offshore sediment movement[J]. Journal of Geophysical Research: Oceans, 1979, 84(C10):6347-6354. doi: 10.1029/JC084iC10p06347
[21] Gijsman R, Visscher J, Schlurmann T. The lifetime of shoreface nourishments in fields with nearshore sandbar migration[J]. Coastal Engineering, 2019, 152:103521. doi: 10.1016/j.coastaleng.2019.103521
[22] 李志强, 陈子燊. 砂质岸线变化研究进展[J]. 海洋通报, 2003, 22(4):77-86 doi: 10.3969/j.issn.1001-6392.2003.04.013
LI Zhiqiang, CHEN Zishen. Progress in the studies on shoreline change of sandy coast[J]. Marine Science Bulletin, 2003, 22(4):77-86.] doi: 10.3969/j.issn.1001-6392.2003.04.013
[23] Bernabeu A M, Medina R, Vidal C. A morphological model of the beach profile integrating wave and tidal influences[J]. Marine Geology, 2003, 197(1-4):95-116. doi: 10.1016/S0025-3227(03)00087-2
[24] 庄克琳, 庄振业, 李广雪. 海岸侵蚀的解析模式[J]. 海洋地质与第四纪地质, 1998, 18(2):97-102
ZHUANG Kelin, ZHUANG Zhenye, LI Guangxue. Five analytic models of coastal erosion[J]. Marine Geology & Quaternary Geology, 1998, 18(2):97-102.]
[25] 严珍珍, 杜小平, 范湘涛. 三亚湾海岸动力演变的数值模拟研究[J]. 海岸工程, 2019, 38(3):176-186 doi: 10.3969/j.issn.1002-3682.2019.03.002
YAN Zhenzhen, DU Xiaoping, FAN Xiangtao. Numerical simulation of coastal dynamic evolution of the Sanya Bay[J]. Coastal Engineering, 2019, 38(3):176-186.] doi: 10.3969/j.issn.1002-3682.2019.03.002
[26] 文世勇, 王紫竹, 王涛, 等. 基于遥感技术的海南省海岸侵蚀现状与趋势评估[J]. 灾害学, 2020, 35(1):138-143 doi: 10.3969/j.issn.1000-811X.2020.01.025
WEN Shiyong, WANG Zizhu, WANG Tao, et al. Status and trend assessment of coastal erosion at Hainan province based on remote sensing technology[J]. Journal of Catastrophology, 2020, 35(1):138-143.] doi: 10.3969/j.issn.1000-811X.2020.01.025
[27] 李喜海, 梁海燕. 三亚湾海岸侵蚀原因分析及防治对策[J]. 海洋开发与管理, 2008, 25(12):103-106 doi: 10.3969/j.issn.1005-9857.2008.12.019
LI Xihai, LIANG Haiyan. Analysis on the reasons of coastal erosion in Sanya bay and the preventive treatment countermeasures[J]. Ocean Development and Management, 2008, 25(12):103-106.] doi: 10.3969/j.issn.1005-9857.2008.12.019
[28] 刘文涛, 杨永鹏. 海南三亚湾-红塘湾海岸地形季节性变化和极端天气下变化特征[J]. 中国海洋大学学报, 2021, 51(S1):60-67
LIU Wentao, YANG Yongpeng. Coastal topographic evolusion in the seasonal and extreme weather event along Sanya bay to Hongtang bay in Hainan island[J]. Periodical of Ocean University of China, 2021, 51(S1):60-67.]
[29] 毛龙江, 张永战, 魏灵, 等. 海南岛三亚湾海滩研究[J]. 第四纪研究, 2006, 26(3):477-484
MAO Longjiang, ZHANG Yongzhan, WEI Ling, et al. Study on beach characteristics in Sanya area of Hainan Island[J]. Quaternary Sciences, 2006, 26(3):477-484.]
[30] 中国海湾志编纂委员会. 中国海湾志-第十一分册-(海南省海湾)[M]. 北京: 海洋出版社, 1999: 183-223
Editorial Board of China Bay Survey. China Gulf Atlas: Eleventh Volume (Hainan Provincial Gulf)[M]. Beijing: China Ocean Press, 1999: 183-223.]
[31] 吴小根, 金波, 卫建飞, 等. 三亚港近期淤积变化及其原因分析[J]. 海洋通报, 1998, 17(5):51-57
WU Xiaogen, JIN Bo, WEI Jianfei, et al. Study on the siltation rates of Sanya harbour[J]. Marine Science Bulletin, 1998, 17(5):51-57.]
[32] 王艳红, 曾成杰, 陆培东, 等. 三亚湾东段海岸侵蚀与海滩养护[J]. 自然资源学报, 2022, 37(4):1049-1060 doi: 10.31497/zrzyxb.20220415
WANG Yanhong, ZENG Chengjie, LU Peidong, et al. Beach erosion and nourishment in the east section of Sanya Bay, China[J]. Journal of Natural Resources, 2022, 37(4):1049-1060.] doi: 10.31497/zrzyxb.20220415
[33] 夏非, 张永战, 吴蔚. EOF分析在海岸地貌与沉积学研究中的应用进展[J]. 地理科学进展, 2009, 28(2):174-186
XIA Fei, ZHANG Yongzhan, WU Wei. Progress in applications of the EOF analysis in the research of coastal geomorphology and sedimentology[J]. Progress in Geography, 2009, 28(2):174-186.]
[34] 吕炳全. 海洋地质学概论[M]. 上海: 同济大学出版社, 2008: 117
LÜ Bingquan. Introduction to Marine Geology[M]. Shanghai: Tongji University Press, 2008:117.]
[35] 王鹏. 渤海海砂资源分布、物源及控制因素研究[D]. 青岛: 中国海洋大学, 2013
WANG Peng. Distribution, provenance and control factors analysis of marine sand resources in Bohai sea[D]. Qingdao: Ocean University of China, 2013.]
[36] Fredsoe J, Deigaard R. Mechanics of Coastal Sediment Transport[M]. Singapore: World Scientific, 1992:369.
[37] M'Cowan J. On the highest wave of permanent type[J]. Proceedings of the Edinburgh Mathematical Society, 1893, 12:112.
[38] 贾磊, 刘文涛, 唐得昊, 等. 三亚湾及周边海域表层沉积物重金属分布特征及生态风险评价[J]. 海洋地质前沿, 2020, 36(12):22-31
JIA Lei, LIU Wentao, TANG Dehao, et al. Distribution characteristics and ecological risk assessment of heavy metals in surface sediments in Sanya bay and surrounding waters[J]. Marine Geology Frontiers, 2020, 36(12):22-31.]
[39] Hattori M, Kawamata R. Onshore-offshore transport and beach profile change[C]//Proceedings of Coastal Engineering 1980. New York: ASCE, 1980:1175-1193.
-
