Application of comprehensive geophysical survey in Bengbu uplift gold polymetallic ore exploration:a case study of Huaiyuan Shuanggou exploration area
-
摘要: 为展现综合物探方法在蚌埠隆起区金多金属矿勘查中的应用效果,更好地指导该区找矿工作,该文以怀远双沟勘查区为例,通过开展面积性高精度重磁测量和综合物探剖面测量,初步建立了近EW向与NE—近NS向叠加的构造格架,并经钻探验证发现了分别受韧脆性断裂和脆性断裂控制的2种类型的金多金属矿化带。在此基础上,总结了勘查区NE—近NS向的磁异常中心和重磁异常梯级带2种金多金属矿成矿有利部位,识别出NE—近NS向磁异常、NE—近NS向重磁异常梯级带、重力异常梯级带背景下的局部重力高、CSAMT剖面上的视电阻率等值线梯级带或明显的错断带等特征,作为区内金多金属矿的综合地球物理找矿标志。Abstract: In order to show the application effect of comprehensive geophysical survey in gold polymetallic ore exploration in Bengbu uplift area and better guide the prospecting work, this paper carried out areal high-precision gravity-magnetic survey and comprehensive geophysical profile survey in the Huaiyuan Shuanggou case study area, and then preliminarily built a superimposed structural framework of near EW and NE-near NS direction. Based on drilling verification, two types of gold polymetallic mineralization zones respectively controlled by ductile-brittle and brittle fractures are discovered. Accordingly, two kinds of gold polymetallic ore metallogenic favorable areas are concluded, namely the NE, near NS magnetic anomaly center, and the NE, near NS gravity-magnetic anomaly cascade zone. The NE, near NS magnetic anomaly, the NE, near NS gravity-magnetic anomaly cascade zone, local gravity height under the background of gravity anomaly cascade zone, and the apparent resistivity contour cascade zone or obvious fault zone on the CSAMT profile are recognized as the comprehensive geophysical prospecting indicators for the gold polymetallic ore in the region.
-
-
[1] 李东平,江汉铨.蚌埠隆起的时代含义、演化历史及控煤作用[J].中国煤田地质,1991,3(4):1-6.
LI D P, JIANG H Q. The formative era, evolutionary history and coal-controlling Process of Bengbu uplift[J]. China Coalfield Geology, 1991,3(4):1-6.
[2] 胡海风,徐晓春,陈芳,等.安徽蚌埠-五河地区与胶东地区金矿床成矿地质背景对比研究[J].地质学刊, 2015,39(2):187-193.
HU H F, XU X C, CHEN F, et al. A comparison of metallogenetic geological conditions of gold deposits between the Bengbu-Wuhe area in Anhui and Eastern Shandong Province[J]. Journal of Geology, 2015,39(2):187-193.
[3] 张顺林,汪青松,张家嘉,等.五河地区与胶东及小秦岭地区金矿成矿地质对比研究[J].安徽地质, 2017,27(2):90-94.
ZHANG S L, WANG Q S, ZHANG J J, et al. Comparative study of geology for the gold formations in the Wuhe, Jiaodong and Xiaoqinling areas[J]. Geology of Anhui,2017,27(2):90-94.
[4] 盛勇,王建伟,张劲松,等.蚌埠隆起带地球物理特征及找矿方向[J].安徽地质,2014,24(2):119-121.
SHENG Y, WANG J W, ZHANG J S,et al. An initial analysis of geophysical features and ore prospecting direction in the Bengbu uplift zone[J]. Geology of Anhui.,2014,24(2):119-121.
[5] 汪青松.蚌埠-凤阳地区构造格架与找矿方向研究[J].地质科学,2014,49(2):405-416.
WANG Q S. Studying on the tectonic system and the orientation of prospecting of Bengbu-Fengyang area[J]. Chinese Journal of Geology, 2014,49(2):405-416.
[6] 王培建,江忠民,李晓禄,等.蚌埠地区航磁异常特征及找矿潜力分析[J].化工矿产地质,2016,38(3):156-160.
WANG P J, JIANG Z M, LI X L, et al. Analysis of aeromagnetic anomaly characteristics and ore-prospecting potential at Bengbu area[J]. Geology of Chemical Minerals, 2016,38(3):156-160.
[7] 杜化宇,李晓禄,杨玉勤.蚌埠隆起航磁构造特征和进一步找矿方向[J].矿产勘查,2018,9(5):927-937.
DU H Y, LI X L, YANG Y Q. Aeromegnetic characteristics in Bengbu uplift and the prospecting on iron dposits direction[J]. Mineral Exploration, 2018,9(5):927-937.
[8] 汪青松,张家嘉,张顺林,等.安徽五河金矿整装勘查的重要发现及其地质意义[J].中国地质调查, 2019,6(2):26-33.
WANG Q S, ZHANG J J, ZHANG S L, et al. Important discoveries in Wuhe integrated exploration gold mine area in Anhui Province and its geological significance[J]. Geological Survey of China,2019,6(2):26-33.
[9] 张景,陈国光,曾勇,等.综合找矿方法在宁芜北火山岩覆盖区的应用——以南门头工区为例[J].华东地质,2016,37(3):221-228.
ZHANG J, CHEN G G, ZENG Y, et al. Application of the integrated ore-prospecting methods in the northern Ningwu volcanic covering areas:an example from the nanmentou work area.[J]. East China Geology, 2016,37(3):221-228.
[10] 王云云,兰学毅,郭冬,等.地质-地球物理精细建模技术在庐枞下含山铁矿深部结构探测中的应用[J].华东地质,2021,42(3):293-301.
WANG Y Y, LAN X Y, GUO D, et al. Application of geological-geophysical modeling technique in deep structural exploration of Xiahanshan iron deposit in the Luzong basin[J]. East China Geology, 2021,42(3):293-301.
[11] 安徽省地质矿产局.安徽省区域地质志[M].北京:地质出版社,1987.Anhui Bureau of Geology and Mineral Resources. Regional Geology of Anhui Province[M]. Beijing:Geological Publishing House,1987.
[12] 冶金工业部地球物理探矿公司航测大队.徐州-蚌埠地区航空磁测工作报告[R].保定:冶金工业部地球物理探矿公司航测大队,1975:66-70.
Aerial survey team,Geophysical prospecting Co. Ministry of Metallurgical Industry. Aeromagnetic survey report in Xuzhou-Bengbu District[R]. Baoding:Aerial survey team,Geophysical prospecting Co. 1975:66-70.
[13] 安徽省勘查技术院.安徽省五河地区金矿成矿条件调查评价报告[R].合肥:安徽省勘查技术院,2016:104-105.
Geological Exploration Technologies Institute of Anhui Province. Investigation report on Au Metallogenetic conditions in Wuhe District, Anhui Province[R]. Hefei:Geological Exploration Technologies Institute of Anhui Province,2016:104-105.
[14] 陈杨,范裕,刘青,等.安徽省凤阳江山金矿床赋矿地层和相关岩浆岩锆石年代学研究及其意义[J].矿床地质, 2018,37(6):1217-1232.CHEN Y, FAN Y, LIU Q, et al. Zircon chronology of ore-bearing strata and related magmatic rocks in Jiangshan gold deposit, Fengyang, Anhui Province,and its significance[J].Mineral Deposits, 2018, 37(6):1217-1236.
[15] 张家嘉,张顺林,朱义坤.安徽五河地区河口铅金矿成矿地质条件及成矿模式[J].地质学刊, 2019,43(1):57-65.
ZHANG J J, ZHANG S L, ZHU Y K, et al. Metallogenic geological conditions and metallogenic model of the Hekou Pb-Au deposit in the Wuhe area, Anhui Province[J]. Journal of Geology,2019,43(1):57-65.
[16] 陈杨,范裕,刘一男,等.安徽蚌埠西贾庄铅锌金银矿床赋矿地层和岩浆岩年代学、Hf同位素、地球化学特征及其意义[J].岩石学报, 2019,35(12):3763-3777.CHEN Y, FAN Y, LIU Y N,et al. Chronology,Hf isotope and geochemistry of the ore-hosting and magmatic rocks in Xijiazhuang Pb-Zn-Au-Ag deposit,Bengbu,Anhui Province,and its signiciance[J]. Acta Petrologica Sinica,2019, 35(12):3763-3781.
[17] 李勇,赵亮,查名章.安徽省蚌埠市城隍庙铁矿地质特征及找矿标志[J].安徽地质,2011,21(2):150-154.
LI Y, ZHAO L, ZHA M Z. Geological features and ore indicators of the Chenghuangmiao iron ore deposit, Bengbu city, Anhui province[J]. Geology of Anhui, 2011, 21(2):150-154.
[18] 安徽省地质局区域地质调查队. 1:20万蚌埠幅区域地质调查报告[R].巢县:安徽省地质局区域地质调查队,1979:298-319.
Regional Geological Survey Team of Anhui Provincial Bureau of Geology. Regional geological survey report of Bengbu sheet(1:200000)[R]. Chao County:Regional Geological Survey Team of Anhui Provincial Bureau of Geology,1979:298-319.
-
