Metallogenic stages and chronology of the Xijiazhuang gold-lead-zinc polymetallic deposit in Mengcheng, Anhui Province
-
摘要:
西贾庄金铅锌多金属矿床是近年来在蚌埠隆起西段新发现的多金属矿床，该矿床的发现实现了皖西北深覆盖区的找矿突破。开展成矿期次及矿区成矿岩体年代学研究，对该矿床的成因、找矿方向及区域成矿规律认识具有重要意义。文章通过详细的野外地质调查和室内镜下鉴定，依据矿物的生成时代、交生关系及围岩蚀变与矿化之间的关系，将金铅锌多金属成矿作用划分为3个成矿期（矽卡岩期、热液期和表生期）和6个成矿阶段（早期无水简单矽卡岩阶段、晚期含水复杂矽卡岩阶段、石英硫化物阶段、早期碳酸盐阶段、晚期碳酸盐阶段和表生阶段），其中石英硫化物阶段和早期碳酸盐阶段是主要的成矿阶段。利用激光剥蚀-电感耦合等离子体质谱（LA-ICP-MS）锆石U-Pb定年方法，获得了矿区主要成矿岩体花岗闪长斑岩和石英二长斑岩的成岩年龄分别为（114.77±0.48） Ma和（113.70±0.51） Ma，表明西贾庄金铅锌多金属矿床形成于早白垩世晚期。
Abstract:The Xijiazhuang gold-lead-zinc polymetallic deposit is a newly discovered polymetallic deposit in the western section of the Bengbu uplift. The prospecting on it has achieved a breakthrough in the deep covered areas of the northwest Anhui. The study of the metallogenic stages and chronology of ore-forming rock mass of the Xijiazhuang deposit is of great significance for understanding the genesis, prospecting direction, and regional metallogenic regularity of this deposit. Through detailed field geological observation and microscopic identification, this paper divided the mineralization of gold-lead-zinc polymetallic deposits into three mineralization periods (skarn period, hydrothermal period, and supergene period) and six mineralization sub-stages (early anhydrous simple skarn stage, late water-bearing complex skarn stage, quartz sulfide stage, early carbonate stage, late carbonate stage, and supergene stage) according to their genesis epoch, intergeneration and the relation between host-rock alteration and mineralization, among which the quartz sulfide stage and early carbonate stage are the main. Utilizing the zircon LA-ICP-MS U-Pb dating, the ages of the major ore-forming rocks such as granodiorite porphyry and quartz monzonite porphyry in the mining area are determined to be (114.77±0.48) Ma and (113.70±0.51) Ma respectively, which indicate that it is the product of the early Cretaceous magmatism .
-
-
表 1 西贾庄矿床成矿期与成矿阶段划分表
Table 1. Division of mineralization periods and stages in Xijiazhuang deposit
下载: 导出CSV
表 2 西贾庄矿区岩浆岩锆石U-Pb同位素测年数据表
Table 2. Zircon U-Pb isotope dating data for magmatic rocks in Xijiazhuang mining area
点号 含量/10−6 同位素比值 年龄/Ma Pb Th U $ \dfrac{{\mathrm{TH}}}{{\mathrm{U}}}$ $\dfrac{^{207}{\mathrm{Pb}}}{^{206}{\mathrm{Pb}}} $ 1σ $\dfrac{^{207}{\mathrm{Pb}}}{^{235}{\mathrm{U}}} $ 1σ $\dfrac{^{206}{\mathrm{Pb}}}{^{238}{\mathrm{U}}} $ 1σ $\dfrac{^{206}{\mathrm{Pb}}}{^{238}{\mathrm{U}}} $ 1σ 样品2033-GS1 01 8.26 239.75 374.08 0.64 0.0486 0.0018 0.1182 0.0040 0.0179 0.0003 114.5 2.0 02 7.20 217.33 318.52 0.68 0.0492 0.0022 0.1225 0.0056 0.0181 0.0003 115.3 1.8 03 7.21 189.50 327.98 0.58 0.0482 0.0021 0.1188 0.0055 0.0179 0.0003 114.6 1.9 04 9.12 259.83 410.04 0.63 0.0488 0.0019 0.1218 0.0049 0.0180 0.0003 114.8 1.9 05 5.89 169.41 263.08 0.64 0.0486 0.0023 0.1177 0.0049 0.0179 0.0003 114.2 2.1 07 7.63 222.00 343.91 0.65 0.0483 0.0021 0.1210 0.0053 0.0180 0.0003 114.7 1.8 08 7.74 216.45 346.89 0.62 0.0498 0.0020 0.1229 0.0048 0.0181 0.0003 115.3 2.0 10 7.96 190.84 376.52 0.51 0.0488 0.0021 0.1187 0.0050 0.0178 0.0003 113.7 1.9 12 7.55 237.65 329.29 0.72 0.0494 0.0020 0.1199 0.0046 0.0178 0.0003 113.4 1.6 14 7.14 172.74 326.78 0.53 0.0485 0.0022 0.1203 0.0047 0.0182 0.0003 116.0 2.0 17 8.32 235.10 368.16 0.64 0.0486 0.0025 0.1205 0.0062 0.0180 0.0003 115.2 2.1 18 6.46 163.68 292.05 0.56 0.0498 0.0025 0.1209 0.0053 0.0180 0.0003 115.0 2.1 20 8.46 237.61 373.13 0.64 0.0498 0.0025 0.1217 0.0051 0.0181 0.0003 115.5 2.0 21 6.74 198.50 301.88 0.66 0.0518 0.0025 0.1241 0.0058 0.0177 0.0003 113.0 1.8 22 9.20 243.26 424.34 0.57 0.0496 0.0019 0.1216 0.0048 0.0179 0.0003 114.3 1.8 23 10.55 282.48 473.99 0.60 0.0472 0.0016 0.1198 0.0043 0.0184 0.0003 117.4 1.9 样品205-GS1 01 7.71 225.69 356.75 0.63 0.0475 0.0021 0.1155 0.0050 0.0178 0.0003 113.6 1.8 02 8.31 266.47 374.37 0.71 0.0486 0.0018 0.1202 0.0043 0.0178 0.0003 113.6 1.7 03 8.03 253.60 353.24 0.72 0.0481 0.0020 0.1190 0.0046 0.0179 0.0003 114.5 1.8 04 7.35 205.10 333.24 0.62 0.0492 0.0021 0.1219 0.0050 0.0177 0.0003 113.2 1.7 05 7.06 237.75 309.70 0.77 0.0479 0.0022 0.1189 0.0046 0.0178 0.0003 113.8 2.0 07 9.45 320.58 414.58 0.77 0.0493 0.0019 0.1206 0.0040 0.0177 0.0003 113.0 1.8 09 5.35 154.48 239.06 0.65 0.0505 0.0028 0.1222 0.0061 0.0177 0.0003 113.1 2.1 10 8.94 281.56 401.19 0.70 0.0487 0.0021 0.1208 0.0044 0.0178 0.0003 113.6 1.9 11 7.24 207.62 326.52 0.64 0.0476 0.0018 0.1208 0.0045 0.0179 0.0003 114.2 1.9 12 7.80 235.83 342.68 0.69 0.0498 0.0027 0.1230 0.0059 0.0179 0.0003 114.1 2.1 15 6.38 173.47 289.09 0.60 0.0485 0.0021 0.1191 0.0049 0.0178 0.0003 113.5 1.8 17 3.34 120.63 134.81 0.89 0.0484 0.0037 0.1208 0.0091 0.0179 0.0004 114.5 2.6 18 6.26 213.06 256.75 0.83 0.0505 0.0031 0.1236 0.0071 0.0177 0.0004 113.1 2.6 20 6.05 166.33 268.77 0.62 0.0494 0.0025 0.1214 0.0064 0.0178 0.0004 114.0 2.3 25 8.06 235.32 364.39 0.65 0.0501 0.0019 0.1213 0.0043 0.0179 0.0003 114.1 1.9
下载: 导出CSV
-
[1] BUREAU OF GEOLOGY AND MINERAL EXPLORATION OF ANHUI PROVINCIAL. 1987. An outline of the regional geology of Anhui Province[M]. Beijing: Geology Press, 1-172 (in Chinese).
[2] CHEN Y, FAN Y, LIU Y N, WANG B, LIU Q. 2019. Chronology, Hf isotope and geochemistry of the ore-hosting and magmatic rocks in Xijiazhuang Pb-Zn-Au-Ag deposit, Bengbu, Anhui Province, and its signiciance[J]. Acta Petrologica Sinica,35(12):3763-3781 (in Chinese with English abstract). doi: 10.18654/1000-0569/2019.12.12
[3] DONG F X, LI Z J, CHEN B L, LIU J M, MENG X G, WANG J P. 1995. Gold ore control structures and prospecting directions in the Dafanshan Rongdu area of Wuhe County, Anhui Province[M]. Beijing: Geology Press (in Chinese).
[4] HU Z C, LIU Y S, CHEN L, ZHOU L, LI M, ZONG K Q, ZHU L, GAO S. 2011. Contrasting matrix induced elemental fractionation in NIST SRM and rock glasses during laser ablation ICP-MS analysis at high spatial resolution[J]. Journal of Analytical Atomic Spectrometry,26(2):425-430. doi: 10.1039/C0JA00145G
[5] HUANG J Z, SHENG Y, ZHANG L, LI R H. 2020. Application of gravity and magnetic data in prognosis of concealed rock mass in thick overburden area—a case study of prospecting hidden rock mass in the periphery of the Xijiazhuang gold polymetallic deposit[J]. Geology of Anhui,30(3):186-189,198 (in Chinese with English abstract).
[6] LI D P, JIANG H Q, Cheng A G. 1991. The era meaning, evolutionary history, and coal control function of Bengbu uplift[J]. Coal Geology of China, 3(4): 1-6, 11 (in Chinese).
[7] LU X, ZHANG L L, CUI X W, WANG Q S. 2022. 3D electrical structure of the Qianchang East copper iron mining area, Anhui Province[J]. East China Geology,43(3):268-275. (in Chinese with English abstract).
[8] LIU Y S, GAO S, HU Z C, GAO C G, ZONG K Q, WANG D B. 2010a. Continental and oceanic crust recycling-induced melt-peridotite interactions in the Trans-North China Orogen: U-Pb dating, Hf isotopes and trace elements in zircons from mantle xenoliths[J]. Journal of Petrology,51(1/2):537-571. doi: 10.1093/petrology/egp082
[9] LIU Y S, HU Z C, ZONG K Q, GAO C G, GAO S, XU J, CHEN H H. 2010b. Reappraisement and refinement of zircon U-Pb isotope and trace element analyses by LA-ICP-MS[J]. Chinese Science Bulletin,55(15):1535-1546. doi: 10.1007/s11434-010-3052-4
[10] LUDWIG K R. 2003. User’s manual for Isoplot/EX, version 3.00, a geochronological toolkit for Microsoft Excel[R]. Berkeley: Berkeley Geochronology Center, 1-70.
[11] MAO J W, HE Y, DING T P. 2002. Mantle fluids involved in metallogenesis of Jiaodong (East Shandong) gold district: evidence of C, O and H Isotopes[J]. Mineral Deposits,21(2):121-128 (in Chinese with English abstract).
[12] QI J Z. 1990. Geodynamic background for Yenshanian endogenous metallogenesis in southeast China[J]. Bulletin of Nanjing Institule of Geology and Mineral Resources, Chinese Academy Geological Sciences, 11(4): 1-15 (in Chinese with English abstract).
[13] QIU R L, XU X, HUANG D Z. 1999. The isotopic age of the Jingshan intrusivein the Bengbu region of the southeastern edge of the North China Block and its geological implications[J]. Geology of Anhui,9(3):161-164 (in Chinese with English abstract).
[14] SHENG Y, WANG J W, ZHANG J S, PAN F. 2014. An initial analysis of geophysical features and oreprospecting direction in the Bengbu uplift zone[J]. Geology of Anhui,24(2):119-121 (in Chinese with English abstract).
[15] WEI B. 2011. The study of mineralization and genesis of Au-Pb-Zn polymetallic deposit in Bengbu area of Anhui Province[D]. Beijing: China University of Geosciences (Beijing), 1-85 (in Chinese with English abstract).
[16] WU J, CHEN Z H. 1991. The Existence of the ancient Bengbu uplift in the Huainan and Huaibei areas[J]. Coal Geology & Exploration, 19(3): 28-34 (in Chinese).
[17] XU J W. 1980. The great left-lateral horizontal displacement of Tancheng-Lujiang fault zone, eastern China[J]. Journal of Hefei Polytechnic University,3(1):1-26 (in Chinese with English abstract).
[18] XU J W. 1984. Tancheng-Lujiang translational fault system[M]. Beijing: Geology Press, 18-32 (in Chinese).
[19] XU X, HOU M J, QIU R L, WU L B, LI J S. 2005. 40Ar-39Ar dating of granites and related dikes in the Bengbu area on the southeastern margin of the North China block[J]. Geology in China,32(4):588-595 (in Chinese with English abstract).
[20] YANG D B. 2006. Chronology and geochemistry of Jingshan “migmatitic” granite in Bengbu[D]. Changchun: Jilin University, 1-61 (in Chinese with English abstract).
[21] YANG D B. 2009. Chronology and geochemistry of granitoids in Bengbu uplift, central China: constraints on tectonic evolution in the eastern North China Craton[D]. Changchun: Jilin University, 1-148 (in Chinese with English abstract).
[22] YANG M G, WANG G H, XU M G, HU Q H. 2016. Basic characteristics of the Marina Pacific tectonic activities in Jiangxi Province and its adjacent areas[J]. East China Geology,37(1):10-18 (in Chinese with English abstract).
[23] YANG D B, XU W L, PEI F P, WANG Q H, LIU X M. 2005. Formation time and magma source of granites in Bengbu uplift: evidence from LA-ICPMS zircon U-Pb dating and tracing[J]. Geochimica,34(5):443-454 (in Chinese with English abstract).
[24] YANG D B, XU W L, WANG Q H, PEI F P, JI W Q. 2006. Petrogenesis of late Jurassic Jingshan granite in Bengbu uplift, Anhui Province: constraints from geochemistry and Hf isotope of zircons[J]. Acta Petrologica Sinica,22(12):2923-2932 (in Chinese with English abstract).
[25] YANG D B, XU W L, WANG Q H, PEI F P, JI W Q. 2007. Petrogenesis of the Mesozoic granite in Bengbu uplift: constraints from zircon Hf isotope[J]. Acta Petrologica Sinica,23(2):381-392 (in Chinese with English abstract).
[26] YING H L, LIU B G. 2002. 40Ar/39Ar dating of gold-bearing quartz veins in Fengyang and Zhangbaling areas, Anhui Province, and its geological significance[J]. Mineral Deposits,21(3):240-245 (in Chinese with English abstract).
[27] YUAN J Q, ZHU S Q, ZHAI Y S. 1985. Ore deposit science[M]. Beijing: Geology Press, 1-345 (in Chinese).
[28] ZHANG Z X, YANG F Q, YAN S H, ZHANG R, CHAI F M, LIU F, GENG X X. 2010. Sources of ore-forming fluids and materials of the Baogutu porphyry copper deposit in Xinjiang: constraints from sulfur-hydrogen-oxygen isotopes geochemistry[J]. Acta Petrologica Sinica,26(3):707-716 (in Chinese with English abstract).
[29] ZHU G. 1999. Discussion on the western extension of the Zhao-Ye gold ore belt, Shandong[J]. Geology and Prospecting,35(2):6-9 (in Chinese with English abstract).
[30] ZHU Y K, ZHAO J H, MIAO X H, MA X J, ZHANG S L, WANG J X. 2023. Application of comprehensive geophysical survey in Bengbu uplift gold polymetallic ore exploration: a case study of Huaiyuan Shuanggou exploration area[J]. East China Geology,44(1):82-92 (in Chinese with English abstract).
[31] 安徽省地质矿产局. 1987. 安徽省区域地质志[M]. 北京: 地质出版社, 1-172.
[32] 陈杨, 范裕, 刘一男, 王彪, 刘青. 2019. 安徽蚌埠西贾庄铅锌金银矿床赋矿地层和岩浆岩年代学、Hf同位素、地球化学特征及其意义[J]. 岩石学报,35(12):3763-3781. doi: 10.18654/1000-0569/2019.12.12
[33] 董法先, 李中坚, 陈柏林, 刘建民, 孟宪刚, 王建平. 1995. 安徽省五河县大巩山—荣渡地区金矿控矿构造和找矿方向[M]. 北京: 地质出版社.
[34] 黄寄洲, 盛勇, 张磊, 李仁和. 2020. 重磁资料在厚覆盖区隐伏岩体勘查中的应用——以西贾庄金多金属矿外围地区推测隐伏岩体为例[J]. 安徽地质,30(3):186-189,198. doi: 10.3969/j.issn.1005-6157.2020.03.006
[35] 李东平, 江汉铨, 程爱国. 1991. 蚌埠隆起的时代含义、演化历史与控煤作用[J]. 中国煤田地质,3(4):1-6,11.
[36] 鲁杏, 张玲玲, 崔先文, 汪青松. 2022. 安徽淮北前常东铜铁矿区三维电性结构特征[J]. 华东地质,43(3):268-275.
[37] 毛景文, 赫英, 丁悌平. 2002. 胶东金矿形成期间地幔流体参与成矿过程的碳氧氢同位素证据[J]. 矿床地质,21(2):121-128. doi: 10.3969/j.issn.0258-7106.2002.02.004
[38] 戚建中. 1990. 中国东南燕山期内生金属成矿地动力背景探讨[J]. 中国地质科学院南京地质矿产研究所所刊,11(4):1-15.
[39] 邱瑞龙, 徐祥, 黄德志. 1999. 华北陆块东南缘蚌埠地区荆山岩体同位素年龄及其地质意义[J]. 安徽地质,9(3):161-164.
[40] 盛勇, 王建伟, 张劲松, 潘芳. 2014. 蚌埠隆起带地球物理特征及找矿方向[J]. 安徽地质,24(2):119-121. doi: 10.3969/j.issn.1005-6157.2014.02.009
[41] 魏波. 2011. 安徽省蚌埠地区金铅锌多金属矿成矿作用及矿床成因研究[D]. 北京: 中国地质大学(北京), 1-85.
[42] 吴江, 陈钟惠. 1991. 两淮地区古蚌埠隆起之存在[J]. 煤田地质与勘探,19(3):28-34.
[43] 徐嘉炜. 1980. 郯—庐断裂带巨大的左行平移运动[J]. 合肥工业大学学报,3(1):1-26.
[44] 徐嘉炜. 1984. 郯城—庐江平移断裂系统[M]. 北京: 地质出版社, 18-32.
[45] 徐祥, 侯明金, 邱瑞龙, 吴礼彬, 李建设. 2005. 华北陆块东南缘蚌埠地区花岗岩与相关脉岩40Ar-39Ar定年[J]. 中国地质,32(4):588-595. doi: 10.3969/j.issn.1000-3657.2005.04.007
[46] 杨德彬. 2006. 蚌埠荆山“混合”花岗岩的形成时代和地球化学特征[D]. 长春: 吉林大学, 1-61.
[47] 杨德彬. 2009. 蚌埠隆起区花岗岩的年代学和地球化学: 对华北克拉通东部构造演化的制约[D]. 长春: 吉林大学, 1-148.
[48] 杨明桂, 王光辉, 徐梅桂, 胡青华. 2016. 江西省及邻区滨太平洋构造活动的基本特征[J]. 华东地质,37(1):10-18.
[49] 杨德彬, 许文良, 裴福萍, 王清海, 柳小明. 2005. 蚌埠隆起区花岗岩形成时代及岩浆源区性质: 锆石LA-ICPMS U-Pb定年与示踪[J]. 地球化学,34(5):443-454. doi: 10.3321/j.issn:0379-1726.2005.05.003
[50] 杨德彬, 许文良, 王清海, 裴福萍, 纪伟强. 2006. 安徽蚌埠荆山晚侏罗世花岗岩岩体成因——来自地球化学和锆石Hf同位素的制约[J]. 岩石学报,22(12):2923-2932. doi: 10.3321/j.issn:1000-0569.2006.12.010
[51] 杨德彬, 许文良, 王清海, 裴福萍, 纪伟强. 2007. 蚌埠隆起区中生代花岗岩的岩石成因: 锆石Hf同位素的证据[J]. 岩石学报,23(2):381-392. doi: 10.3969/j.issn.1000-0569.2007.02.017
[52] 应汉龙, 刘秉光. 2002. 安徽凤阳和张八岭地区含金石英脉的40Ar/39Ar年龄及其地质意义[J]. 矿床地质,2002,21(3):240-245. doi: 10.3969/j.issn.0258-7106.2002.03.004
[53] 袁见齐, 朱上庆, 翟裕生. 1985. 矿床学[M]. 北京: 地质出版社, 1-345.
[54] 张志欣, 杨富全, 闫升好, 张锐, 柴凤梅, 刘锋, 耿新霞. 2010. 新疆包古图斑岩铜矿床成矿流体及成矿物质来源——来自硫、氢和氧同位素证据[J]. 岩石学报,26(3):707-716.
[55] 朱光. 1999. 山东招—掖金矿带的西延去向探讨[J]. 地质与勘探,35(2):6-9. doi: 10.3969/j.issn.0495-5331.1999.02.002
[56] 朱义坤, 赵景怀, 缪旭煌, 马学静, 张顺林, 王金鑫. 2023. 综合物探方法在蚌埠隆起金多金属矿勘查中的应用——以怀远双沟勘查区为例[J]. 华东地质,44(1):82-92.
-
