Composition of geothermal water in porous geothermal reservoir under exploitation in Hebei Plain: A case study in Xinji area
-
摘要: 地热水属于承压水,其储存量包括容积储存量和弹性储存量两部分,当水位处于含水层顶板以上时,已开采出的地热水只能是弹性储存量。在河北平原区进行区域地热资源评价时,地热水可开采量按照开采系数法、解析法等不同方法计算,与弹性储存量存在巨大差距。为研究地热水开采资源的构成并更加准确评价集中开采区地热水的可开采量,采用地下水均衡法对辛集集中开采区地热水开采资源量进行了计算,结果显示: 侧向补给量为126×104 m3,占开采资源量的60.9%; 越流补给量为19.7×104 m3,占开采资源量的9.55%; 弹性释水量为33.1×104 m3,占开采资源量的16.1%; 弱透水层压密释水量为27.4×104 m3,占开采资源量的13.3%。研究结果说明,集中开采区地热水的开采资源量不仅仅来自于热储层的弹性释水量,还包括侧向补给量、越流补给量和弱透水层的压密释水量。研究成果对于科学合理地开发地热资源、更好地遏制和缓解地热水开采引发的地质环境问题具有一定意义。Abstract: Geothermal water belongs to confined water, and its storage capacity includes volume storage capacity and elastic storage capacity. When the water level is above the aquifer roof, the exploited geothermal water can only be elastic storage capacity. The recoverable amount of geothermal water was calculated by mining coefficient method and analytical method in the evaluation of regional geothermal resources in Hebei Plain, which has a huge difference with elastic storage amount. In order to study the composition of geothermal water exploitation resources and evaluate more accurately the exploitable quantity of geothermal water in the concentrated exploitation area, the author of this paper has adopted the groundwater balance method to calculate the exploitation quantity of geothermal water in Xinji concentrated exploitation area. The results show that lateral recharge is 126×104 m3, accounting for 60.9% of the exploitation resources; the overflow recharge is 19.7×104 m3,accounting for 9.55% of the exploitation resources; the elastic water release is 33.1×104 m3,accounting for 16.1% of the exploitation resources, and the impermeable water release is 27.4×104 m3, accounting for 13.3% of the exploitation resources. The exploitation resources of geothermal water in the concentrated mining area not only come from the elastic water release of thermal reservoir, but also include lateral recharge, overflow recharge and compaction water release. These results are of great significance to the scientific and reasonable development of geothermal resources, and to better control and alleviation of the geological environment problems caused by geothermal water exploitation.
-
-
[1] 张德忠,马云青,苏永强.河北平原地热流体可采量计算方法及岩溶热储分布规律研究[J].中国地质调查,2018,5(2):78-85.
[2] Zhang D Z,Ma Y Q,Su Y Q.Study on the calculation of geothermal fluids recoverable quantity and the distribution law of karst geothermal reservoirs in Hebei Plain[J].Geol Surv China,2018,5(2):78-85.
[2] 茹洪久,刘东林,胡慧川,等.天津地热资源评价与综合研究[J].中国地质调查,2018,5(2):25-31.
[4] Ru H J,Liu D L,Hu H C,et al.Evaluation and comprehensive study of geothermal resources in Tianjin[J].Geol Surv China,2018,5(2):25-31.
[3] 刘春华,王威,卫政润.山东省水热型地热资源及其开发利用前景[J].中国地质调查,2018,5(2):51-56.
[6] Liu C H,Wang W,Wei Z R.Analysis of hydrothermal geothermal resources and its prospect of development and utilization in Shandong[J].Geol Surv China,2018,5(2):51-56.
[4] 阎敦实,于英太.京津冀油区地热资源评价与利用[M].武汉:中国地质大学出版社,2000:127.
[8] Yan D S,Yu Y T.Evaluation and Utilization of Geothermal Resources in Beijing Tianjin Hebei Oil Region[M].Wuhan:China University of Geosciences Press,2000:127.
[5] 张中祥,韩建江,徐健,等.沉积盆地型层状热储可采资源量计算方法探索[J].水文地质工程地质,2005,32(1):73-77.
[10] Zhang Z X,Han J J,Xu J,et al.The calculation of exploitable resources in the layered-geothermal reservoirs of sedimentary ba-sin[J].Hydrogeol Eng Geol,2005,32(1):73-77.
[6] 孙颖,许辉熙,刘久荣,等.中低温地热田的地热资源计算评价:以北京市小汤山地热田为例[J].安徽农业科学,2009,37(14):6535-6537.
[12] Sun Y,Xu H X,Liu J R,et al.Calculation assessment of geothermal resources in medium-low temperature geothermal field[J].J Anhui Agric Sci,2009,37(14):6535-6537.
[7] 张德忠,刘志刚,卢红柳.河北地热[M].北京:科学出版社,2012:104-105.
[14] Zhang D Z,Liu Z G,Lu H L.Hebei Geothermal[M].Beijing:Science Press,2012:104-105.
[8] 河北省地矿局第三水文工程地质大队.河北省地热资源现状调查评价与区划报告[R].2015:48-52.
[16] No.3 Hydrogeological and Engineering Group of Hebei Bureau of Geology and Mineral Resources.Report on Investigation Evaluation and Zoning of Geothermal Resources in Hebei Province[R].2015:48-52.
[9] 河北省水文工程地质勘查院.临清台陷北段地热资源勘查报告[R].2019:140-222.
[18] Hebei Institute of Hydroengineering Geology.Report on Exploration of Geothermal Resources in North Section of Linqingtai-xian[R].2019:140-222.
[10] 河北省地矿局第四水文工程地质大队.黄骅台陷沧州段地热资源勘查报告[R].2018:55-56.
[20] No.4 Hydrogeology and Engineering Group of Hebei Bureau of Geology and Mineral Resources.Report on Exploration of Geothermal Resources in Cangzhou Section of Huanghuataixian[R].2018:55-56.
[11] 河北省水文工程地质勘查院.冀中台陷京南段地热资源勘查报告[R].2019:162-263.
[22] Hebei Institute of Hydroengineering Geology.Report on Exploration of Geothermal Resources in South Section of Jingnan in Jizhongtaixian[R].2019:162-263.
[12] 河北省地矿局第三水文工程地质大队.河北省地热水资源保护与开发利用规划(2018—2020年)综合研究报告[R].2019:56-61.
[24] No.3 Hydrogeology and Engineering Group of Hebei Bureau of Geology and Mineral Resources.Comprehensive Research Report on the Protection and Development and Utilization Planning of Geothermal Water Resources in Hebei Province (2018—2020)[R].2019:56-61.
[13] 河北省地矿局第三水文工程地质大队.雄安新区地热清洁能源调查评价D34地热地质勘探钻孔成果报告[R].2020:14.
[26] No.3 Hydrogeology and Engineering Group of Hebei Bureau of Geology and Mineral Resources.Investigation and Evaluation of Geothermal Clean Energy in Xiong'an New District Report on Drilling Results of D34 Geothermal Geological Exploration[R].2020:14.
[14] 杨东东,戴卫华,张迎春,等.渤海砂岩油田岩石压缩系数经验公式研究[J].中国海上油气,2010,22(5):317-319.
[28] Yang D D,Dai W H,Zhang Y C,et al.Studying on an empirical formula of rock compressibility for sandstone oilfields in Bohai Sea[J].China Offshore Oil Gas,2010,22(5):317-319.
[15] 河北省地矿局第三水文工程地质大队.河北省地热资源可开采量评价研究报告[R].2016:22-26.
[30] No.3 Hydrogeology and Engineering Group of Hebei Bureau of Geology and Mineral Resources.Research Report on Exploitable Quantity Evaluation of Geothermal Resources in Hebei Provin-ce[R].2016:22-26.
[16] 河北省地矿局第三水文工程地质大队.河北省典型孔隙型热储集中开采区(景县)地热资源调查评价报告[R].2019:32-33.
[32] No.3 Hydrogeology and Engineering Group of Hebei Bureau of Geology and Mineral Resources.Investigation and Evaluation Report on Geothermal Resources in Typical Porous Heat Reservoir Concentrated Mining Area (Jingxian) of Hebei Province[R].2019:32-33.
[17] 林黎,赵苏民,李丹,等.深层地热水开采与地面沉降的关系研究[J].水文地质工程地质,2006,33(3):34-37.
[34] Lin L,Zhao S M,Li D,et al.A study of the relationship between exploitation of geothermal water in deep-seated aquifers and land subsidence[J].Hydrogeol Eng Geol,2006,33(3):34-37.
[18] 河北省地矿局第一水文地质工程地质大队.黄淮海平原(河北部分)水文地质工程地质综合评价地下水资源评价专题报告[R].1985:91-92.
[36] No.1 Hydrogeology and Engineering Group of Hebei Bureau of Geology and Mineral Resources.Comprehensive Evaluation Report of Groundwater Resources in Hydrogeological Engineering Geology of Huanghuaihai Plain (Hebei part)[R].1985:91-92.
[19] 李红,肖国强,杨吉龙,等.天津滨海新区地面沉降层位的精准识别与沉降过程重建[J].地质通报,2016,35(10):1646-1652.
[38] Li H,Xiao G Q,Yang J L,et al.Precise identification of land-subsiding layers and reconstruction of subsidence process in Tianjin Binhai New Area[J].Geol Bull China,2016,35(10):1646-1652.
-
